Resilient by Design at React SF 2014

In order to operate 24/7 an application must embrace constant change and failure. This kind of resiliency is achievable through the application of reactive design principles. Learn the theory via real-world examples at Netflix along with some lessons learned the hard way in production. Topics of interest will include service-oriented architectures (microservices), cloud computing, where to put application state, hot deployments, bulk heading, circuit breakers, degrading gracefully, operational tooling and how application architecture affects resilience.

Presented at React Conf 2014 in San Francisco http://reactconf.com

Video: http://youtu.be/MEgyGamo79I

Transcript

1. Ben Christensen
   Developer – Edge Engineering at Netflix
   @benjchristensen
   http://techblog.netflix.com/
   React San Francisco - November 2014
   Resilient By Design


   View Slide

2. “the explosive growth of software has added
   greatly to systems’ interactive complexity. With
   software, the possible states that a system can
   end up in become mind-boggling.”
   Dekker, Sidney (2012-10-01). Drift into Failure (Kindle Locations 3268-3270). Ashgate Publishing. Kindle Edition.
   – Sidney Dekker, Drift into Failure


   View Slide

3. “We can model and understand in isolation.
   But, when released into competitive, nominally
   regulated societies, their connections proliferate,
   their interactions and interdependencies multiply,
   their complexities mushroom.
   And we are caught short.”
   Dekker, Sidney (2012-10-01). Drift into Failure (Kindle Locations 290-292). Ashgate Publishing. Kindle Edition.
   – Sidney Dekker, Drift into Failure


   View Slide

4. Cache
   Origin Servers
   Cache
   Cache
   Read-through Cache


   View Slide

5. Cache
   Origin Servers
   Cache
   Cache
   low ~1% cache miss rate


   View Slide

6. Cache
   Origin Servers
   Cache
   Cache
   reads through to origin


   View Slide

7. Cache
   Origin Servers
   Cache
   Cache
   writes back to cache


   View Slide

8. Cache
   Origin Servers
   Cache
   Cache
   lose a cache shard


   View Slide

9. Cache
   Origin Servers
   Cache
   Cache
   normal 1% cache miss rate becomes
   10% … 30% … origin is overwhelmed


   View Slide

10. Cache for Performance
    Becomes an Availability Concern
    Cache
    Origin Servers
    Cache
    Cache


    View Slide

11. Multiple Dependencies


    View Slide

12. Allowing One To
    Break User Experience


    View Slide

13. Transitive Failure


    View Slide

14. Sticky Sessions


    View Slide

15. Complicate Fault Tolerance
    & Scaling


    View Slide

16. Feature Complete!


    View Slide

17. … hmmm …
    resilience?


    View Slide

18. We Must
    Design For Resilience


    View Slide

19. Source: http://reich-chemistry.wikispaces.com/file/view/liquid_thorium_reactor_large.jpg/245978425/616x547/liquid_thorium_reactor_large.jpg


    View Slide

20. Source: http://reich-chemistry.wikispaces.com/file/view/liquid_thorium_reactor_large.jpg/245978425/616x547/liquid_thorium_reactor_large.jpg


    View Slide

21. "LFTRs (liquid fluoride thorium reactor) also have excellent safety
    features. My favorite is the use of a ‘plug’ which would melt if the
    molten mass got too hot for any reason, draining it away into a
    protected lower tank which would stop any fissioning and cool the
    whole lot down. It’s a clever idea: the plug is a frozen wedge of salt
    in a pipe at the bottom of the core tank, cooled by an external fan. If
    power is lost for some reason which might threaten to overheat the
    LFTR, the fan stops, the plug melts, and the salts all drain away. The
    fuel can’t melt down for the straightforward reason that it is already
    molten. No China Syndrome here."
    – Mark Lynas, Nuclear 2.0


    View Slide

22. "LFTRs (liquid fluoride thorium reactor) also have excellent safety
    features. My favorite is the use of a ‘plug’ which would melt if the
    molten mass got too hot for any reason, draining it away into a
    protected lower tank which would stop any fissioning and cool the
    whole lot down. It’s a clever idea: the plug is a frozen wedge of salt
    in a pipe at the bottom of the core tank, cooled by an external fan. If
    power is lost for some reason which might threaten to overheat the
    LFTR, the fan stops, the plug melts, and the salts all drain away. The
    fuel can’t melt down for the straightforward reason that it is already
    molten. No China Syndrome here."
    – Mark Lynas, Nuclear 2.0


    View Slide

23. "LFTRs (liquid fluoride thorium reactor) also have excellent safety
    features. My favorite is the use of a ‘plug’ which would melt if the
    molten mass got too hot for any reason, draining it away into a
    protected lower tank which would stop any fissioning and cool the
    whole lot down. It’s a clever idea: the plug is a frozen wedge of salt
    in a pipe at the bottom of the core tank, cooled by an external fan. If
    power is lost for some reason which might threaten to overheat the
    LFTR, the fan stops, the plug melts, and the salts all drain away. The
    fuel can’t melt down for the straightforward reason that it is already
    molten. No China Syndrome here."
    – Mark Lynas, Nuclear 2.0


    View Slide

24. Source: http://reich-chemistry.wikispaces.com/file/view/liquid_thorium_reactor_large.jpg/245978425/616x547/liquid_thorium_reactor_large.jpg


    View Slide

25. “System operations are dynamic, with
    components (organizational, human, technical)
    failing and being replaced continuously.”
    – Richard Cook, How Complex Systems Fail
    Richard I. Cook - How Complex Systems Fail - http://www.ctlab.org/documents/How%20Complex%20Systems%20Fail.pdf


    View Slide

26. View Slide

27. View Slide

28. View Slide

29. AWS
    Availability Zone
    AWS
    Availability Zone
    AWS
    Availability Zone


    View Slide

30. View Slide

31. View Slide

32. View Slide

33. View Slide

34. View Slide

35. View Slide

36. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R


    View Slide

37. “Overt catastrophic failure occurs when small,
    apparently innocuous failures join to create
    opportunity for a systemic accident.”
    – Richard Cook, How Complex Systems Fail
    Richard I. Cook - How Complex Systems Fail - http://www.ctlab.org/documents/How%20Complex%20Systems%20Fail.pdf


    View Slide

38. View Slide

39. View Slide

40. View Slide

41. View Slide

42. View Slide

43. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R
    User request
    blocked by
    latency in
    single
    network call


    View Slide

44. At high
    volume
    all request
    threads can
    block in
    seconds
    User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R
    User Request
    User Request
    User Request
    User Request
    User Request
    User Request
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


    View Slide

45. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R
    User Request
    User Request
    User Request
    User Request
    User Request
    User Request
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
    At high
    volume
    all request
    threads can
    block in
    seconds


    View Slide

46. cy D
    dency G
    ependency J
    Dependency M
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    User Request
    User Request
    User Request
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
    Network Request - TCP/HTTP, latency, 4xx, 5xx, etc
    Deserialization - JSON/XML/Thrift/Protobuf/etc
    Logic - argument validation, caches, metrics, logging,
    multivariate testing, routing, etc
    Serialization - URL and/or body generation
    Logic - validation, decoration, object model, caching,
    metrics, logging, etc


    View Slide

47. "Timeout guard" daemon prio=10 tid=0x00002aaacd5e5000 nid=0x3aac runnable [0x00002aaac388f000] java.lang.Thread.State: RUNNABLE
    at java.net.PlainSocketImpl.socketConnect(Native Method)
    at java.net.AbstractPlainSocketImpl.doConnect(AbstractPlainSocketImpl.java:339)
    - locked <0x000000055c7e8bd8> (a java.net.SocksSocketImpl)
    at java.net.AbstractPlainSocketImpl.connectToAddress(AbstractPlainSocketImpl.java:200)
    at java.net.AbstractPlainSocketImpl.connect(AbstractPlainSocketImpl.java:182)
    at java.net.SocksSocketImpl.connect(SocksSocketImpl.java:391)
    at java.net.Socket.connect(Socket.java:579)
    at java.net.Socket.connect(Socket.java:528)
    at java.net.Socket.(Socket.java:425)
    at java.net.Socket.(Socket.java:280)
    at org.apache.commons.httpclient.protocol.DefaultProtocolSocketFactory.createSocket(DefaultProtocolSocketFactory.java:80)
    at org.apache.commons.httpclient.protocol.ControllerThreadSocketFactory$1.doit(ControllerThreadSocketFactory.java:91)
    at org.apache.commons.httpclient.protocol.ControllerThreadSocketFactory$SocketTask.run(ControllerThreadSocketFactory.java:158) at java.lang.Thread.run(Thread.java:722)
    [Sat Jun 30 04:01:37 2012] [error] proxy: HTTP: disabled connection for (127.0.0.1)
    > 80% of requests rejected
    Median
    Latency


    View Slide

48. “Overt catastrophic failure occurs when small,
    apparently innocuous failures join to create
    opportunity for a systemic accident.”
    – Richard Cook, How Complex Systems Fail
    Richard I. Cook - How Complex Systems Fail - http://www.ctlab.org/documents/How%20Complex%20Systems%20Fail.pdf


    View Slide

49. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R


    View Slide

50. View Slide

51. View Slide

52. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R


    View Slide

53. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R


    View Slide

54. User Request
    Dependency A
    Dependency D
    Dependency G
    Dependency J
    Dependency M
    Dependency P
    Dependency B
    Dependency E
    Dependency H
    Dependency K
    Dependency N
    Dependency Q
    Dependency C
    Dependency F
    Dependency I
    Dependency L
    Dependency O
    Dependency R


    View Slide

55. View Slide

56. Logic - validation, decoration, object model, caching,
    metrics, logging, etc
    Deserialization - JSON/XML/Thrift/Protobuf/etc
    Network Request - TCP/HTTP, latency, 4xx, 5xx, etc
    Serialization - URL and/or body generation
    Logic - argument validation, caches, metrics, logging,
    multivariate testing, routing, etc


    View Slide

57. Tryable Semaphore
    Rejected
    Permitted
    Logic - validation, decoration, object model, caching,
    metrics, logging, etc
    Deserialization - JSON/XML/Thrift/Protobuf/etc
    Network Request - TCP/HTTP, latency, 4xx, 5xx, etc
    Serialization - URL and/or body generation
    Logic - argument validation, caches, metrics, logging,
    multivariate testing, routing, etc


    View Slide

58. Thread-pool
    Rejected
    Permitted
    Logic - validation, decoration, object model, caching,
    metrics, logging, etc
    Deserialization - JSON/XML/Thrift/Protobuf/etc
    Network Request - TCP/HTTP, latency, 4xx, 5xx, etc
    Serialization - URL and/or body generation
    Logic - argument validation, caches, metrics, logging,
    multivariate testing, routing, etc
    Timeout
    with
    non-blocking
    IO


    View Slide

59. Thread-pool
    Rejected
    Permitted
    Logic - validation, decoration, object model, caching,
    metrics, logging, etc
    Deserialization - JSON/XML/Thrift/Protobuf/etc
    Network Request - TCP/HTTP, latency, 4xx, 5xx, etc
    Serialization - URL and/or body generation
    Logic - argument validation, caches, metrics, logging,
    multivariate testing, routing, etc
    Timeout
    with
    blocking
    IO


    View Slide

60. Tryable semaphores for non-blocking clients and fallbacks
    Separate threads for blocking clients
    Bulkhead – Limit Concurrency
    Aggressive timeouts to “give up and move on”
    Circuit breakers as the “release valve”
    Release Pressure


    View Slide

61. HystrixCommand run()
    public  class  CommandHelloWorld  extends  HystrixCommand  {
           ...
           protected  String  run()  {
                   return  "Hello  "  +  name  +  "!";
           }
    }


    View Slide

62. public  class  CommandHelloWorld  extends  HystrixCommand  {
           ...
           protected  String  run()  {
                   return  "Hello  "  +  name  +  "!";
           }
    }
    run() invokes
    “client” Logic
    HystrixCommand run()


    View Slide

63. HystrixCommand run()
    throw Exception
    Fail Fast


    View Slide

64. HystrixCommand run()
    getFallback()
    return  null;
    return  new  Option();
    return  Collections.emptyList();
    return  Collections.emptyMap();
    Fail Silent


    View Slide

65. HystrixCommand run()
    getFallback()
    return  true;
    return  DEFAULT_OBJECT;
    Static Fallback


    View Slide

66. HystrixCommand run()
    getFallback()
    return  new  UserAccount(customerId,  "Unknown  Name",
                                   countryCodeFromGeoLookup,  true,  true,  false);
    return  new  VideoBookmark(movieId,  0);
    Stubbed Fallback


    View Slide

67. HystrixCommand run()
    getFallback()
    public  class  CommandHelloWorld  extends  HystrixCommand  {
           ...
           protected  String  run()  {
                   return  "Hello  "  +  name  +  "!";
           }
           protected  String  getFallback()  {
                   return  "Hello  Failure  "  +  name  +  "!";
           }
    }
    Stubbed Fallback


    View Slide

68. HystrixCommand run()
    getFallback()
    public  class  CommandHelloWorld  extends  HystrixCommand  {
           ...
           protected  String  run()  {
                   return  "Hello  "  +  name  +  "!";
           }
           protected  String  getFallback()  {
                   return  "Hello  Failure  "  +  name  +  "!";
           }
    }
    Stubbed Fallback


    View Slide

69. HystrixCommand run()
    getFallback() HystrixCommand
    run()
    Fallback via network


    View Slide

70. HystrixCommand run()
    getFallback() HystrixCommand
    run()
    getFallback()
    Fallback via network then Local


    View Slide

71. Transitive Failure


    View Slide

72. Transitive Failure
    with Bulkheads & Fallbacks


    View Slide

73. All Relationships


    View Slide

74. State
    State State State
    Application State?


    View Slide

75. State
    State State State
    Cluster Replication (and similar approaches)


    View Slide

76. State
    State
    State
    State
    State
    State
    All Instances
    Are Now Stateful


    View Slide

77. State
    State
    State
    State
    State
    State
    This Can Be Done


    View Slide

78. State
    State
    State
    State
    State
    State
    But Doesn’t Need
    To Be
    State
    State
    State State
    State
    State


    View Slide

79. So Where To Put State?


    View Slide

80. State State State
    State State
    Stateful Client


    View Slide

81. State State State
    State State
    Cache
    Cache
    Ephemeral Cache
    (ie. memcached, redis, etc)


    View Slide

82. State State State
    State State
    Cache
    Cache
    Cache
    Database
    Database
    (SQL, key-value, etc)


    View Slide

83. State State State
    State State
    Cache
    Cache
    Cache
    Database
    Database
    (generally ends up
    here anyways)


    View Slide

84. State State State
    State State
    Cache
    Cache
    Cache
    Database
    Why?
    Isn’t this more
    complicated?


    View Slide

85. Cache
    Cache Database
    Database
    Bounded
    Context


    View Slide

86. Cache
    Cache Database
    Database
    Despite more parts it simplifies
    ownership, operations,
    reasoning, deployments, failure
    modes.
    Most systems focus on logic and
    behavior with simple
    operations.


    View Slide

87. Cache
    Cache Database
    Database
    Few focus on durability and
    state and increased
    operational challenges and
    costs.
    Despite more parts it simplifies
    ownership, operations,
    reasoning, deployments, failure
    modes.
    Most systems focus on logic and
    behavior with simple
    operations.


    View Slide

88. State
    An example …


    View Slide

89. State
    Cookie
    Identity is a critical service.
    Client state in cookie
    allows a reasonable fallback
    even if entire Identity
    service fails.


    View Slide

90. “In complex systems, decision-makers are
    locally rather than globally rational. But that
    doesn’t mean that their decisions cannot lead
    to global, or system-wide events. In fact, that
    is one of the properties of complex systems:
    local actions can have global results.”
    Dekker, Sidney (2012-10-01). Drift into Failure (Kindle Locations 3268-3270). Ashgate Publishing. Kindle Edition.
    – Sidney Dekker, Drift into Failure


    View Slide

91. “In complex systems, decision-makers are
    locally rather than globally rational. But that
    doesn’t mean that their decisions cannot lead
    to global, or system-wide events. In fact, that
    is one of the properties of complex systems:
    local actions can have global results.”
    Dekker, Sidney (2012-10-01). Drift into Failure (Kindle Locations 3268-3270). Ashgate Publishing. Kindle Edition.
    – Sidney Dekker, Drift into Failure


    View Slide

92. Load Shedding → Retry Storms


    View Slide

93. Cache Shard Failure → DDOS Origin


    View Slide

94. Dynamic Property Change → Saturate All CPUs


    View Slide

95. Reactive Scaling
    → Scale Down During Outage
    → Overwhelmed By Thundering Herd


    View Slide

96. Reactive Scaling
    → Scale Down During Superbowl
    → Overwhelmed By Thundering Herd


    View Slide

97. Achieve Resilience → Neglect → Drift → Vulnerability


    View Slide

98. "Failure Recovery must be a very
    simple path and that path must be
    tested frequently"
    https://www.usenix.org/legacy/event/lisa07/tech/full_papers/hamilton/hamilton_html/
    – James Hamilton


    View Slide

99. View Slide

100. View Slide

101. AWS
     Availability Zone
     AWS
     Availability Zone
     AWS
     Availability Zone


     View Slide

102. View Slide

103. View Slide

104. Auditing via Simulation


     View Slide

105. Auditing via Simulation


     View Slide

106. Auditing via Simulation


     View Slide

107. View Slide

108. 125 → 1500+


     View Slide

109. ~5000


     View Slide

110. ~1


     View Slide

111. View Slide

112. View Slide

113. View Slide

114. View Slide

115. View Slide

116. View Slide

117. Constantly Changing


     View Slide

118. View Slide

119. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

120. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

121. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

122. View Slide

123. View Slide

124. View Slide

125. View Slide

126. View Slide

127. View Slide

128. View Slide

129. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

130. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

131. User Request
     Dependency A
     Dependency D
     Dependency G
     Dependency J
     Dependency M
     Dependency P
     Dependency B
     Dependency E
     Dependency H
     Dependency K
     Dependency N
     Dependency Q
     Dependency C
     Dependency F
     Dependency I
     Dependency L
     Dependency O
     Dependency R
     System
     Relationship
     Over
     Network
     without
     Bulkhead


     View Slide

132. Zuul Routing Layer
     Canary vs Baseline
     Squeeze
     Production
     "Coalmine"


     View Slide

133. Failure inevitably happens ...


     View Slide

134. Cluster adapts
     Failure Isolated


     View Slide

135. Cluster adapts
     Failure Isolated


     View Slide

136. Cluster adapts
     Failure Isolated


     View Slide

137. Cluster adapts
     Failure Isolated


     View Slide

138. View Slide

139. View Slide

140. View Slide

141. View Slide

142. View Slide

143. Note: This is a mockup


     View Slide

144. Note: This is a mockup


     View Slide

145. “…complex systems run as broken systems.
     The system continues to function because it
     contains so many redundancies and because
     people can make it function, despite the
     presence of many flaws.”
     Richard I. Cook - How Complex Systems Fail - http://www.ctlab.org/documents/How%20Complex%20Systems%20Fail.pdf
     – Richard Cook, How Complex Systems Fail


     View Slide

146. Where to next?


     View Slide

147. Low Latency Anomaly Detection


     View Slide

148. Automate Configuration?


     View Slide

149. Global vs Regional Deployment


     View Slide

150. Servers as Pets → Herds (Clusters)
     Clusters as Pets → Herds (Global Application)


     View Slide

151. Human Involvement


     View Slide

152. Assert Production Readiness?


     View Slide

153. We have long believed that 80% of operations issues originate
     in design and development, so this section on overall service
     design is the largest and most important. When systems fail,
     there is a natural tendency to look first to operations since that
     is where the problem actually took place. Most operations
     issues, however, either have their genesis in design and
     development or are best solved there.
     https://www.usenix.org/legacy/event/lisa07/tech/full_papers/hamilton/hamilton_html/
     – James Hamilton


     View Slide

154. We have long believed that 80% of operations issues originate
     in design and development, so this section on overall service
     design is the largest and most important. When systems fail,
     there is a natural tendency to look first to operations since that
     is where the problem actually took place. Most operations
     issues, however, either have their genesis in design and
     development or are best solved there.
     https://www.usenix.org/legacy/event/lisa07/tech/full_papers/hamilton/hamilton_html/
     – James Hamilton


     View Slide

155. Resilience is by Design


     View Slide

156. Ben Christensen
     @benjchristensen
     jobs.netflix.com
     Fault Tolerance in a High Volume, Distributed System
     http://techblog.netflix.com/2012/02/fault-tolerance-in-high-volume.html
     Hystrix
     https://github.com/Netflix/Hystrix/wiki
     Drift Into Failure
     http://www.amazon.com/Drift-into-Failure-Sidney-Dekker/dp/1409422216
     Release It!
     http://www.amazon.com/Release-It-Production-Ready-Pragmatic-Programmers/dp/0978739213


     View Slide
