  1. Databinding in Android
    BRYAN HERBST

    View Slide

  2. Job Interview
    Q: How does an Android Activity fit in to the MVC pattern?
    A: Ehh…

    View Slide

  3. MV[C|P|VM]
    A Model that represents your raw data. Aka POJOs.
    A View that dictates how your data is displayed to the user
    Something to get the data and display the view

    View Slide

  4. View

    {{title}}
    {{body}}

    View Slide

  5. Controller
    var template = Handlebars.compile(viewTemplate);
    var data = {title: “Hello World", body: “Templating rocks!"};
    var html = template(data);

    View Slide

  6. Let there be data binding
    Now we can have better separation of concerns
    Activities and Fragments now have more limited scope and a clearer purpose:
    ◦ Load data
    ◦ Bind data to the View
    ◦ Respond to events

    View Slide

  7. Setup
    buildscript {
    dependencies {
    classpath 'com.android.databinding:dataBinder:1.0-rc0'
    }
    }
    apply plugin: 'com.android.databinding'

    View Slide

  8. The View- step one


    android:orientation="vertical"
    android:layout_width="match_parent"
    android:layout_height="match_parent">


    Wrap your layout in a tag

    View Slide

  9. The View- step two






    Add a tag with s for your models

    View Slide

  10. The View- step three
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:text="@{animal.species}"/>
    Bind to model with @{model.property}

    View Slide

  11. The binding class
    Plugin generates binding class
    my_fancy_layout.xml becomes MyFancyLayoutBinding

    View Slide

  12. The controller side
    @Override
    protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    ActivityAnimalBinding binding = DataBindingUtil.setContentView(this,
    R.layout.activity_animal);
    binding.setAnimal(new Elephant());
    }

    View Slide

  13. Demo time!

    View Slide

  14. Can the views be smarter?
    What else can we bind?

    View Slide

  15. Visibility- step one




    Import types into layouts just like Java

    View Slide

  16. Visibility- step two
    android:visibility="@{note.content == null ? View.GONE : View.VISIBLE}"

    View Slide

  17. Introducing the ViewModel
    Because that date format is terrible.

    View Slide

  18. NoteViewModel
    public class NoteViewModel {
    private static final DateFormat TIMESTAMP_FORMAT = DateFormat.getDateInstance();
    private Note mNote;
    public String getFormattedTimestamp() {
    return TIMESTAMP_FORMAT.format(mNote.getCreatedTime());
    }
    }
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:text="@{note.formattedTimestamp}"/>

    View Slide

  19. Demo time!

    View Slide

  20. Data binding: Two way street
    android:orientation="vertical“
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    app:onClickListener="@{note.clickListener}">
    Using app namespace, bind to anything with a setter

    View Slide

  21. Automatic updates
    What happens when our data changes?

    View Slide

  22. Observables
    No, not RxJava

    View Slide

  23. Observables in the ViewModel
    public ObservableInt numClicks;
    public View.OnClickListener clickListener = new View.OnClickListener() {
    @Override
    public void onClick(View view) {
    numClicks.set(numClicks.get() + 1);
    }
    };

    View Slide

  24. Observables in the layout
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:text="@{String.valueOf(note.numClicks)}"/>
    Text now automatically updates

    View Slide

  25. Demo time!

    View Slide

  26. Resources
    https://developer.android.com/tools/data-binding/guide.html
    Tons of information about:
    ◦ s
    ◦ Operators in bindings
    ◦ Accessing arrays/lists/maps
    ◦ Using resources in bindings
    ◦ Value converters
    ◦ Binding custom view properties
    ◦ More ways to make data observable
