Offline-First Apps with PouchDB and Cloudant Sync at Cloud Expo

It's easy to assume that your app will run on a fast and reliable network. The reality for your app's users, though, is often a slow, unreliable network with spotty coverage. What happens when the network doesn't work, or when the device is in airplane mode? You get unhappy, frustrated users. An offline-first app is an app that works, without error, when there is no network connection. Offline-first apps built with PouchDB and Cloudant Sync can provide better, faster user experiences by storing data locally and then synchronizing with a cloud database when a network connection is available.

Transcript

1. Cloud Computing Expo
   Bradley Holt, Developer Advocate
   Wednesday, June 8, 2016
   Offline-First Apps with
   PouchDB and Cloudant Sync
   @BradleyHolt


   View Slide

2. @BradleyHolt


   View Slide

3. View Slide

4. IBM Cloud Data Services
   Open for Data
   A comprehensive por.olio of open source data services


   View Slide

5. Why offline first?


   View Slide

6. View Slide

7. View Slide

8. Mobile First
   Design for the smallest device first and then apply progressive enhancement techniques to
   take advantage of larger screen sizes when available


   View Slide

9. Offline First
   Design for offline usage first and then apply progressive enhancement techniques to take
   advantage of network connectivity when available


   View Slide

10. Ubiquitous Connectivity
    Why offline first in a world of ubiquitous connectivity?


    View Slide

11. The Eight Fallacies of Distributed Computing
    1.  The network is reliable
    2.  Latency is zero
    3.  Bandwidth is infinite
    4.  The network is secure
    5.  Topology doesn't change
    6.  There is one administrator
    7.  Transport cost is zero
    8.  The network is homogeneous
    @BradleyHolt


    View Slide

12. Mobile Backend
    What happens when your mobile backend service is unreachable?


    View Slide

13. Benefits of Offline First


    View Slide

14. Faster User Experience
    Better, faster user experience — both offline and online


    View Slide

15. Works Offline
    Ability to disconnect and continue to work offline


    View Slide

16. Battery and Bandwidth
    Limited access to power and communications infrastructure in disaster scenarios


    View Slide

17. Offline-First Patterns and
    Anti-Patterns


    View Slide

18. View Slide

19. View Slide

20. View Slide

21. View Slide

22. View Slide

23. Tools and Use Cases


    View Slide

24. CouchDB Replication Protocol
    @BradleyHolt
    Cloudant Sync
    CouchDB PouchDB
    CouchDB Replication Protocol
    CouchDB


    View Slide

25. View Slide

26. @BradleyHolt


    View Slide

27. PouchDB Code Examples
    github.com/bradley-holt/offline-first


    View Slide

28. View Slide

29. JSON Documents
    {

    _id: "6EF9D2B0-13D3-1378-8D30-39E3CE0B36C2",

    _rev: "1-0b457efcf82fb29492ef927ba5b6ee15",

    type: "Feature",

    geometry: {

    type: "Point",

    coordinates: [

    -71.1028,

    42.3691

    ]

    },

    properties: {

    session_id: "3486b13f-7b8a-8a96-dfbf-9b82800e367f",

    timestamp: 1422928591717

    }

    }
    @BradleyHolt


    View Slide

30. Creating a PouchDB Database
    var db = new PouchDB("smart-meter");
    @BradleyHolt


    View Slide

31. Creating a New Document
    var db = new PouchDB("smart-meter");
    db.put({
    _id: "2014-11-12T23:27:03.794Z",
    kilowatt_hours: 14
    }).then(function() {
    console.log("Document created");
    }).catch(function(error) {
    console.log(error);
    });
    @BradleyHolt


    View Slide

32. Updating a Document
    db.put({
    _id: "2014-11-12T23:27:03.794Z",
    kilowatt_hours: 14
    }).then(function(response) {
    return db.get(response.id);
    }).then(function(doc) {
    // Update the value for kilowatt hours
    doc.kilowatt_hours = 15;
    // Put the document back to the database
    return db.put(doc);
    }).catch(function(error) {
    console.log(error);
    });
    @BradleyHolt


    View Slide

33. Querying a Database with allDocs
    db.bulkDocs([
    {_id: "2014-11-12T23:27:03.794Z", kilowatt_hours: 14},
    {_id: "2014-11-13T00:52:01.471Z", kilowatt_hours: 15},
    {_id: "2014-11-13T01:39:28.911Z", kilowatt_hours: 16},
    {_id: "2014-11-13T02:52:01.471Z", kilowatt_hours: 17}
    ]).then(function(result) {
    // Get all documents
    return db.allDocs({include_docs: true});
    }).then(function(response) {
    console.log(response);
    }).catch(function(error) {
    console.log(error);
    });
    @BradleyHolt


    View Slide

34. allDocs Options
    §  include_docs
    – conflicts
    – attachments
    §  startkey
    §  endkey
    §  inclusive_end
    (true by default)
    §  limit
    §  skip
    §  descending
    §  key
    §  keys
    @BradleyHolt


    View Slide

35. Querying a Database with Map/Reduce
    §  Most queries can be done with allDocs (in PouchDB)
    §  Map functions transform documents into indexes
    §  Reduce functions aggregate results of Map functions
    – _sum
    – _count
    – _stats
    @BradleyHolt


    View Slide

36. Querying a Database with PouchDB Find
    §  Based on Cloudant Query (Mango)
    §  Declarative indexes
    §  MongoDB-style query language
    @BradleyHolt


    View Slide

37. Replication


    View Slide

38. Apache CouchDB
    CouchDB is a document database featuring an HTTP API, JSON documents,
    and peer-to-peer replication
    @BradleyHolt


    View Slide

39. View Slide

40. Creating a Remote PouchDB Database
    var remoteDb = new PouchDB("https://bradley-holt.cloudant.com/smart-meter");
    @BradleyHolt


    View Slide

41. Cross-Origin Resource Sharing (CORS)
    A security restriction implemented by browsers on cross-site HTTP requests
    @BradleyHolt


    View Slide

42. Bidirectional Replication
    @BradleyHolt


    View Slide

43. Bidirectional Replication
    db.sync(remoteDb, {
    live: false,
    retry: false
    }).on("change", function(info) {
    // Replication has written a new document
    console.log(info);
    }).on("complete", function(info) {
    // Replication has complete or been cancelled
    console.log(info);
    }).on("error", function(error) {
    // Replication has stopped due to an unrecoverable failure
    console.log(error);
    });
    @BradleyHolt


    View Slide

44. Live Replication
    @BradleyHolt


    View Slide

45. Live Replication
    var sync = db.sync(remoteDb, {
    live: true,
    retry: true
    }).on("change", function(info) {
    // Replication has written a new document
    console.log(info);
    }).on("complete", function(info) {
    // Replication has complete or been cancelled
    console.log(info);
    }).on("error", function(error) {
    // Replication has stopped due to an unrecoverable failure
    console.log(error);
    });
    @BradleyHolt


    View Slide

46. Filtered Replication
    @BradleyHolt


    View Slide

47. Filtered Replication
    db.replicate.to(remoteDb, {
    filter: function(doc) {
    return doc._id >= "2014-11-13T00:00:00.000Z";
    }
    }).on("change", function(info) {
    // Replication has written a new document
    console.log(info);
    }).on("complete", function(info) {
    // Replication has complete or been cancelled
    console.log(info);
    });
    @BradleyHolt


    View Slide

48. One Database Per User
    @BradleyHolt
    userdb-d76846
    userdb-905cec
    userdb-adc95b
    userdb-c082f2
    userdb-730bba
    userdb-c3d3e5
    userdb-a1ec1f
    userdb-85a327
    userdb-9b9aba
    userdb-85bcfe
    serdb-da3d25


    View Slide

49. View Slide

50. Boilerplates & Tools
    §  Frontend Web Apps
    –  React Boilerplate with Service Workers

    §  Backend Web Apps
    –  PouchDB npm Package

    –  PouchDB Server npm Package

    §  Mobile Apps
    –  PouchDB for Ionic Framework

    –  "Hello world" Cordova app with PouchDB

    –  "Hello world" Cordova app with PouchDB, using the SQLite Plugin

    –  Cloudant FoodTracker (uses Cloudant Sync for iOS)

    §  Desktop Apps
    –  PouchDB for Electron (formerly Atom Shell)

    –  PouchDB for Chrome packaged apps

    –  "Hello world" Chrome app with PouchDB

    –  PouchDB for NW.js (aka Node-Webkit)

    §  Internet of Things (IoT) Apps
    –  Node-RED

    @BradleyHolt


    View Slide

51. Cloudant FoodTracker
    An offline-first demo app built with Swift and Cloudant Sync for iOS


    View Slide

52. View Slide

53. Offline Camp
    June 24th - 26th, Catskill Mountains


    View Slide

54. offlinefirst.org/camp


    View Slide

55. Image Credits
    §  A mockup of the golden Apple iPhone 5S by Zach Vega,
    on Wikimedia Commons

    §  Joan Touzet (@wohali), ASF Member, CouchDB PMC Member

    §  Device landscape by Jeremy Keith, on Flickr
    §  Cloud Formation Over the Adirondacks by Bradley Holt, on Twitter

    §  Cell phone tower by Gary Lerude, on Flickr
    §  Pneumatic Central by Sleestak, on Flickr
    §  Colunas by Daniel Zanini H., on Flickr
    §  Speed DLR on Doklands by Umberto Rotundo, on Flickr

    §  Waterfall by Paulo Valdivieso, on Flickr
    §  Wildfire by U.S. Fish and Wildlife Service Southeast Region, on Flickr

    §  Arduino Uno by Pete Prodoehl, on Flickr
    §  Mango with section on a white background by bangdoll, on Flickr

    §  Warning by Stefano Brivio, on Flickr
    @BradleyHolt


    View Slide

56. Questions?
    @BradleyHolt


    View Slide
