  1. Load balancing 101 Smoke and mirrors.

  2. What is load balancing Spreading load over multiple workers, servers,

    cores, processes, and time. • A queue of discrete requests/jobs/transactions and workers which can complete this work • A slew of concurrent, long lived connections
  3. When do you have a load balancing problem? Always.

  4. What can you load balance? • HTTP level load balancing

    • Socket level load balancing • Queue + slow legacy system
  5. Queue everything and delight everyone (when you can, at the

    right priority)
  6. Every man and his dog has a load balancer these

    days • HAProxy • Nginx • Amazon ELB • Varnish • Pound • Apache mod_proxy_balancer • Gearman • Celery • ØMQ • keepalived etc.
  7. Load balancing terms • Hardware: ◦ Fast/Efficient ◦ Fixed circuitry/purpose

    ◦ In-stream decisions ◦ Reason people get Cisco qualifications ◦ SPoF (can be mitigated) • Software ◦ Plethora of options ◦ Performance tradeoffs ◦ More cleverness ◦ More deployability
  8. Scheduling • Round robin • Least-connections • Random! • Clever

    ◦ Make decisions based on latency, worker load, geography, etc. (e.g. ELB) ◦ Dynamic: see Varnish DNS Director and Nginx Resolver / Nginx lua ◦ Hash Based: Consistent hashing based on incoming request data: see haproxy map Links: http://rapgenius.com/James-somers-herokus-ugly-secret-lyrics
  9. Session stickyness / Persistence: • Sticky: route requests from known/seen

    requestors to the same backend worker ◦ Source IP ◦ Cookie-based ◦ How does this work in high availability? • Non-sticky: don't stick to backend workers ◦ Means you have to be clever about shared session state
  10. Health checks • Do them right • Check frequently, but

    not too much • Check that you're getting a valid response from the backend ◦ not just that port 80 is open ◦ is it accepting http? ◦ is the page loading? ◦ is it loading correctly (ie, is the DB up?) • Build a url which gives you good health indicators, and tell the LB to check it • Spend time configuring your LB error pages
  11. Example 1 - naïveté level 8 • Requests land on

    http://router.myapp.com • Redirect with HTTP 302 Found to http://web {1,2,3}.myapp.com Kakness: • Discuss
  12. Example 2.0 - Let's use hardware! • Buy a hardware

    load balancer • Plug it in • Packets are free to roam! Kakness • Discuss
  13. Example 2.1 - let's use software! • User hits http://myapp.com

    • Proxies to backend worker servers • Responses flow freely Kakness: • Discuss
  14. Example 3 - let's use DNS! • User requests http://myapp.com

    • DNS round robins you an IP • Be careful about TTL! Kakness • Discuss
  15. Cool links Varnish cleverness: http://dev.theladders.com/2013/05/varnish-in-five-acts/ Link header: http://blog.kevburnsjr.com/tagged-cache-invalidation Nginx cleverness:

    http://wiki.nginx.org/HttpUpstreamConsistentHash Heroku's ugly secret: http://rapgenius.com/James-somers-herokus-ugly-secret-lyrics
  16. Thanks? Collaborated by • Adrian Moisey • Bradley Whittington •

    Bearnard Hibbins • Jonathan Hitchcock • Simon de Haan
