flapjack - monitoring notification system

This talk was given on the Open Source Monitoring Conference in Nuremberg OSMC2013.

To quote the flapjack website (http://flapjack.io/): “Flapjack is a highly scalable and distributed monitoring notification system.

It sits on top of existing
monitoring engines like Nagios or Sensu, and does event processing & notifications.”

Transcript

1. 23.10.2013 Flapjack monitoring notification system
2. 23.10.2013 Who is that guy? and what company is he working for?
3. Birger Schmidt since mid 2012 R&D engineer at
4. ✤ since mid 2012 R&D engineer at Bulletproof, Sydney, Australia ✤ 2008 - 2012 consultant / trainer at NETWAYS GmbH ✤ Dipl. Inf. Uni Rostock and HU zu Berlin ✤ since the beginning of the 90s working in ✤ IT-Infrastructure, Operating and Development today called DevOps Birger Schmidt
5. ✤ Bulletproof v1.0 ✤ Founded 2000 as a Managed Service Provider, providing managed networking services ✤ Bulletproof v2.0 ✤ First VMware based public Cloud service in Australia in 2006 ✤ Bulletproof v3.0 ✤ First to launch Managed AWS in Australia in 2012, and most successful provider currently Bulletproof
6. Bulletproof Customers
7. 23.10.2013 agenda
8. agenda ✤ 1. who (already done) and what ✤ 2. motivation ✤ 3. history ✤ 4. surrounding facts ✤ 5. background ✤ 6. architecture, documentation ✤ 7. demo
9. 23.10.2013 “Flapjack is a highly scalable and distributed monitoring notification system. It sits on top of existing monitoring engines like Nagios or Sensu, and does event processing & notifications.” http://flapjack.io/
10. 23.10.2013 motivation
11. ✤ we want to monitor things in an insane way ✤ like mad ✤ existing systems are not fully designed for that ✤ there is demand for that Motivation I
12. Movember is one of our the biggest customers they want the numbers and not only the bold ones that I’ll show you now
13. Movember is a charity organization that fundraises money to found research for mens health
16. ✤ we do not want to be bothered with ✤ too many alerts ✤ configuration of dependencies like ✤ parent / child ✤ host or service ✤ we can not afford to restart monitoring (on notification rule changes) Motivation II
17. 23.10.2013 history
18. ✤ Lindsay Holmwood and Matt Moor wanted to build the “next generation monitoring system” ✤ simple to setup & operate ✤ with obvious paths to scale History 2008
19. ✤ Lindsay Holmwood started hacking on Flapjack ✤ a working prototype that runs basic monitoring checks was ready by mid 2009 ✤ idea was simple: decouple the check execution from the alerting and notification, and use message queues to distribute the check execution across lots of machines ✤ but... History 2009
20. ✤ Flapjack was considered a dead project **  WARNING:  Flapjack  is  no  longer  under  active  development.  ** **  Feel  free  to  fork  it,  but  I  don't  have  the  bandwidth  to  work  on  this  project  any  longer.  ** ✤ but there were plenty of other interesting projects like Sensu with similar goals making excellent progress ✤ later on, Mod-Gearman and others walked into the same direction ✤ no secret, other people where doing awesome work in the monitoring space History 2010 and 2011
21. ✤ Flapjack was rebooted with a significantly altered focus ✤ check execution is no longer part of it ✤ it is now focused on ✤ Event processing ✤ Correlation & rollup ✤ API driven configuration History 2012
22. ✤ we use Flapjack in production since January 2013 ✤ and we still heavily develop it ✤ the rollup just got in but is not entirely finished yet Present / current state 2013
23. 23.10.2013 surrounding flapjack facts
24. ✤ fully open source ✤ MIT license ✤ development sponsored by Bulletproof ✤ up to 3 full time engineers working on it ✤ the team... surrounding facts I
25. ✤ Lindsay Holmwood ✤ Jesse Reynolds ✤ Ali Graham ✤ me, you? distributed team
26. ✤ based on redis, eventmachine, and written in ruby (which could change later for some components) surrounding facts II EventMachine*
27. 23.10.2013 background
28. ✤ notify a dynamic group of people in different ways ✤ Bulletproof has thousands of people to be notified ✤ each of those individuals can have different notification settings based on time of day or week, the type of service affected, or the severity of the failure ✤ on-call is just one fashion of those people Background / Problem I
29. ✤ alert, but make sure nobody gets bombarded during outages ✤ do the above in an API driven way, and it must work in a multitenant environment with strong segregation between customers, and integrate with an existing monitoring & customer self-service stack Background / Problem II
30. ✤ in the end human beings are always the receiver of alerts ✤ Lindsay had given some great talks about the psychologic and human mechanisms of processing alerts ✤ hindsight bias / confirmation bias or why do we don’t accept to be wrong (and how that causes the inability to see mistakes) ✤ rate of alerts that humans can (or can not) handle Background / Humans
31. ✤ Lindsay Holmwood talked about Mountainwest RubyConf 04/2013 Escalating complexity: DevOps learnings from Air France 447 devops downunder 07/2013 Monitorama EU 09/2013 Background / Humans
32. 23.10.2013 architecture
33. ✤ event producer (fj nagios reciver) ✤ flapjack executive (fj executive) ✤ flapjack notifier (as of now part of the fj executive) ✤ gateways (implemented as Pikelets, say flapjack components which can be run within the same ruby process, or as separate processes) ✤ unidirectional: Email, SMS ✤ bidirectional: XMPP, PagerDuty ✤ diagram... architecture
34. Nagios Nagios nagios-receiver Redis nagios-receiver events state lookup alerts processor notifier processor notifier PagerDuty SMS Email Executive Gateways
35. Nagios Nagios nagios-receiver Redis nagios-receiver events state lookup alerts processor notifier processor notifier PagerDuty SMS Email Executive Gateways
36. ✤ events are processed as pictured in the following diagram event processing
37. event processing
38. event processing event
39. event processing event filters Find failing events
40. event processing notification event filters Find failing events
41. event processing Find people interested in entity map [ alice bob, carol ] notification event filters Find failing events
42. event processing Find people interested in entity map map Find media owned by people [ [ alice, email ], [ alice, sms ], [ bob, email ], [ bob, sms ], [ carol, sms ], ] notification event filters Find failing events
43. event processing Find people interested in entity map map reduce Find media owned by people Delete media based on tags, severity, time of day [ [ alice, email ], [ alice, sms ], [ bob, sms ], ] notification event filters Find failing events
44. event processing Find people interested in entity map map reduce reduce Find media owned by people Delete media based on tags, severity, time of day Delete media based on blackholes [ [ alice, sms ], [ bob, sms ], ] notification event filters Find failing events
45. event processing Find people interested in entity map map reduce reduce reduce Find media owned by people Delete media based on tags, severity, time of day Delete media based on blackholes Delete media based on notification intervals notification event filters Find failing events [ [ alice, sms ], [ bob, sms ], ]
46. event processing Find people interested in entity map map reduce reduce reduce Find media owned by people Delete media based on tags, severity, time of day Delete media based on blackholes Delete media based on notification intervals notification event filters Find failing events alert alert [ [ alice, sms ], [ bob, sms ], ]
48. 23.10.2013 event filters
49. ✤ filter on status (warning, critical, recovery) ✤ (new entities won't trigger alerts) ✤ maintenance ✤ ack ✤ delay (think of soft states in nagios) Event filters
50. 23.10.2013 notifications
51. ✤ are event driven ✤ flapjack needs the flow of incoming check results / events ✤ are time based ✤ flapjack alerts / or holds back alerts according to time constrains ✤ and tags... Notifications
52. ✤ you can use tags to direct notifications Tags
53. ✤ right now you can use tags in notification rules to match against failing checks ✤ flapjack creates auto-tags from all the words in the entity name, check name, and the summary output from the monitoring check ✤ you can add custom tags to entities ✤ tag a host with 'top-priority' and set your notification rules to alert via sms, email, pagerduty ✤ or tag with 'nobody-cares-except-fred' and then everyone but fred could set a notification rule to match this tag and blackhole all matching notifications Tags
54. 23.10.2013 web interface
55. Web interface
56. 23.10.2013 excellent documentation
57. Documentation https://github.com/flpjck/flapjack/wiki
61. We care about documentation!
62. Bad documentation? BUG
63. 23.10.2013 future
64. ✤ improve rollup ✤ we try to make you feel welcome as much as we can ✤ documentation ✤ vagrant-flapjack - go test for yourself ✤ omd? future
65. 23.10.2013 Talk is cheap, demo it!
66. 23.10.2013 Thank you! https://github.com/flpjck bs-flapjack@netgaroo.com
67. 23.10.2013 feedback https://github.com/flpjck bs-flapjack@netgaroo.com
68. 23.10.2013 Questions? https://github.com/flpjck bs-flapjack@netgaroo.com
69. 23.10.2013 https://github.com/flpjck
