  1. Linked Lists II Week 3

  2. Linked List Tips and Tricks

  3. Linked List Tips and Tricks Take multiple passes through the

    linked list
 - get length
 - save other information about contents
  4. Linked List Tips and Tricks Take multiple passes through the

    linked list
 - get length
 - save other information about contents Two pointers
 - ‘race car’ strategy with one regular pointer, and one fast pointer
  5. Linked List Tips and Tricks Take multiple passes through the

    linked list
 - get length
 - save other information about contents Two pointers
 - ‘race car’ strategy with one regular pointer, and one fast pointer Dummy node
 - helpful for preventing errors when returning ‘head’
  6. Understand Match Pseudocode / Plan Implement Review Evaluate

  7. Understand Match Pseudocode / Plan Implement Review Evaluate

  8. Match

  9. Match Think about what data structures might be helpful for

    the problem (hash map, queue, binary search, …)
  10. Match Think about what data structures might be helpful for

    the problem (hash map, queue, binary search, …) See if there are any specific techniques that you can apply (ie : using a dummy node, or taking multiple passes)
  11. Plan / Pseudocode Start to figure out how you would

    solve the problem
  12. Plan / Pseudocode Start to figure out how you would

    solve the problem Can you create any ‘magic’ helper methods that would simplify the solution? (ie : getLength(), reverse() )
  13. Plan / Pseudocode Start to figure out how you would

    solve the problem Can you create any ‘magic’ helper methods that would simplify the solution? (ie : getLength(), reverse() ) Talk through different approaches you can take, and their tradeoffs
  14. Plan / Pseudocode Start to figure out how you would

    solve the problem Can you create any ‘magic’ helper methods that would simplify the solution? (ie : getLength(), reverse() ) Talk through different approaches you can take, and their tradeoffs Be able to verbally describe your approach and explain how an example input would produce the desired output
  15. Example: Remove Nth Node from End of List

  16. Example: Remove Nth Node from End of List Understand: Always

    start by understanding the question and running through an example
  17. Example: Remove Nth Node from End of List Understand: Always

    start by understanding the question and running through an example 1->2->3->4->5, n = 2

  18. Example: Remove Nth Node from End of List Understand: Always

    start by understanding the question and running through an example 1->2->3->4->5, n = 2
 return 1->2->3->5
  19. Example: Remove Nth Node from End of List Understand: Always

    start by understanding the question and running through an example 1->2->3->4->5, n = 2
 return 1->2->3->5 Let’s assume we start without any time / space constraints. So our goal is to figure out ANY kind of solution to produce the right answer
  20. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?


  21. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array


  22. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array
 -> We can also take a pass to get the length of the linked list

  23. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array
 -> We can also take a pass to get the length of the linked list Plan : What are some different ways we can solve this problem?


  24. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array
 -> We can also take a pass to get the length of the linked list Plan : What are some different ways we can solve this problem?
 1) We can store the elements in an array, get the length of the array, and then rebuild our list excluding the nth to last node


  25. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array
 -> We can also take a pass to get the length of the linked list Plan : What are some different ways we can solve this problem?
 1) We can store the elements in an array, get the length of the array, and then rebuild our list excluding the nth to last node
 2) We can follow the first idea, but instead of storing things in an array, remove the reference to the nth to last node the second time we iterate through the list

  26. Example: Remove Nth Node from End of List Match :

    Are there any special techniques that we can use to help make this easier?
 -> We can take a first pass through the linked list to store the elements in an array
 -> We can also take a pass to get the length of the linked list Plan : What are some different ways we can solve this problem?
 1) We can store the elements in an array, get the length of the array, and then rebuild our list excluding the nth to last node
 2) We can follow the first idea, but instead of storing things in an array, remove the reference to the nth to last node the second time we iterate through the list
 What would be the space / time complexity of our solution?
  27. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node


  28. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2)
  29. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2) First pass, we get length = 3. Since n = 1, that means we want to remove the 3 -1 = 2 node (with index starting at 0)


  30. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2) First pass, we get length = 3. Since n = 1, that means we want to remove the 3 -1 = 2 node (with index starting at 0)

 As we iterate through the list..
 at node 1 -> numberOfNodesSeen = 0
  31. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2) First pass, we get length = 3. Since n = 1, that means we want to remove the 3 -1 = 2 node (with index starting at 0)

 As we iterate through the list..
 at node 1 -> numberOfNodesSeen = 0
 at node 2-> numberOfNodesSeen = 1
  32. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2) First pass, we get length = 3. Since n = 1, that means we want to remove the 3 -1 = 2 node (with index starting at 0)

 As we iterate through the list..
 at node 1 -> numberOfNodesSeen = 0
 at node 2-> numberOfNodesSeen = 1
 at node 3 -> numberOfNodesSeen = 2 -> at this point we need to set node 2’s next to be node 3’s next!
  33. Example: Remove Nth Node from End of List Our approach:


    1) make initial pass through linked list to get length
 2) make second pass to remove any reference to nth to last node

 Let’s draw out how this might work with an example
 Given linked list 1->2->3, n = 1 (we want to return 1->2) First pass, we get length = 3. Since n = 1, that means we want to remove the 3 -1 = 2 node (with index starting at 0)

 As we iterate through the list..
 at node 1 -> numberOfNodesSeen = 0, previousNode = null
 at node 2-> numberOfNodesSeen = 1, previousNode = 1
 at node 3 -> numberOfNodesSeen = 2, previousNode = 2 -> we set previousNode.next = node.next (node 3’s next = null)
  34. Group Exercise Work together in groups to practice Matching /

    Planning the solution to the problem
  35. Group Exercise Work together in groups to practice Matching /

    Planning the solution to the problem Verbally discuss 2-3 ways to solve the problem and discuss tradeoffs with each approach
  36. Group Exercise Work together in groups to practice Matching /

    Planning the solution to the problem Verbally discuss 2-3 ways to solve the problem and discuss tradeoffs with each approach Think about whether there are any 'magical' helper methods that would greatly help you solve the problem
  37. Group Exercise Work together in groups to practice Matching /

    Planning the solution to the problem Verbally discuss 2-3 ways to solve the problem and discuss tradeoffs with each approach Think about whether there are any 'magical' helper methods that would greatly help you solve the problem Walk through 2 example inputs and explain how the solution would produce the desired output
  38. Let’s discuss the problems together!

  39. Given a linked list, determine if it has a cycle

    in it.
  40. Given a sorted linked list, delete all duplicates such that

    each element appear only once.
  41. Merge two sorted linked lists and return it as a

    new list. The new list should be made by splicing together the nodes of the first two lists.
