Sulu - Leverage the power of a framework based CMS

Batteries included! Thanks to Symfony.

Transcript

1. I installed this free plugin and now the whole website crashed! It can´t take that long to add this simple feature! Why is our website so slow?! Can we add a new language to the site by tomorrow? Sulu CMS Batteries included! Thanks to Symfony.
2. I'm Thomas Schedler @chirimoya | https://github.com/chirimoya
3. I'm Thomas Schedler @chirimoya | https://github.com/chirimoya ... head of development and technical consultant. Young father trying to master Heston Blumenthal recipes.
4. Router The main entry point to your Symfony application.
5. Request Response
6. / /services /blog Request Response
7. / /services /blog Request Response Front Controller
8. / /services /blog Request Response Kernel Front Controller
9. / /services /blog Request Response Kernel Router Request URI Controller & Action Front Controller
10. / /services /blog Request Response Kernel Controller Router Request URI Controller & Action Front Controller
11. / /services /blog Request Response Kernel Controller Router Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction()
12. / /services /blog Request Response Kernel Controller Router Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Model View Services
13. / /services /blog Request Response Kernel Controller Router Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services
14. Router / /services /blog Request Response Kernel Controller Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services
15. Router / /services /blog Request Response Kernel Controller Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services
16. Router Chain Router / /services /blog Request Response Kernel Controller Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services
17. Router Chain Router / /services /blog Request Response Kernel Controller Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services
18. Router Chain Router / /services /blog Request Response Kernel Controller Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services Dynamic Router
19. Sulu routing summarized
20. Sulu routing summarized – CMF ChainRouter replaces the default routing system
21. Sulu routing summarized – CMF ChainRouter replaces the default routing system – and works by accepting a set of prioritized Routers
22. Sulu routing summarized – CMF ChainRouter replaces the default routing system – and works by accepting a set of prioritized Routers – The Symfony default Router is registered with the highest priority
23. Sulu routing summarized – CMF ChainRouter replaces the default routing system – and works by accepting a set of prioritized Routers – The Symfony default Router is registered with the highest priority – DynamicRouters handle all the dynamically defined routes (pages, redirects, …)
24. // app/WebsiteKernel.php

 class WebsiteKernel extends AbstractKernel
 {
 /**
 * {@inheritdoc}
 */
 protected $name = 'website';

 /**
 * @param string $environment
 * @param bool $debug
 */
 public function __construct($environment, $debug)
 {
 parent::__construct($environment, $debug);
 $this->setContext(self::CONTEXT_WEBSITE);
 }

 /**
 * {@inheritdoc}
 */
 public function registerBundles()
 {
 $bundles = parent::registerBundles();
 $bundles[] = new Symfony\Cmf\Bundle\RoutingBundle\CmfRoutingBundle();
 return $bundles;
 }
 }
25. // app/WebsiteKernel.php

 class WebsiteKernel extends AbstractKernel
 {
 /**
 * {@inheritdoc}
 */
 protected $name = 'website';

 /**
 * @param string $environment
 * @param bool $debug
 */
 public function __construct($environment, $debug)
 {
 parent::__construct($environment, $debug);
 $this->setContext(self::CONTEXT_WEBSITE);
 }

 /**
 * {@inheritdoc}
 */
 public function registerBundles()
 {
 $bundles = parent::registerBundles();
 $bundles[] = new Symfony\Cmf\Bundle\RoutingBundle\CmfRoutingBundle();
 return $bundles;
 }
 } $bundles[] = new AppBundle\AppBundle();
26. // app/config/website/routing.yml app:
 resource: "@AppBundle/Controller/"
 type: annotation
 prefix: /app
27. // app/config/website/routing.yml app:
 resource: "@AppBundle/Controller/"
 type: annotation
 prefix: /app // src/AppBundle/Controller/DefaultController.php namespace AppBundle\Controller; use Symfony\Bundle\FrameworkBundle\Controller\Controller; use Sensio\Bundle\FrameworkExtraBundle\Configuration\Route; class DefaultController extends Controller { /** * @Route("/") */ public function indexAction() { return $this->render('AppBundle:Default:index.html.twig'); } }
28. // app/config/website/routing.yml app:
 resource: "@AppBundle/Controller/"
 type: annotation
 prefix: /app // src/AppBundle/Controller/DefaultController.php namespace AppBundle\Controller; use Symfony\Bundle\FrameworkBundle\Controller\Controller; use Sensio\Bundle\FrameworkExtraBundle\Configuration\Route; class DefaultController extends Controller { /** * @Route("/") */ public function indexAction() { return $this->render('AppBundle:Default:index.html.twig'); } } // src/AppBundle/Resources/views/Default/index.html.twig Hallo World!
30. Controller & View Add your custom logic within your own content Controller.
31. Controller Chain Router Router / /services /blog Request Response Kernel Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services Dynamic Router
32. Chain Router Router / /services /blog Request Response Kernel Request URI Controller & Action Front Controller indexAction() servicesAction() blogAction() Response Response Response Model View Services Dynamic Router DefaultController
33. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http:// schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>


 <cacheLifetime>2400</cacheLifetime>

 <meta>
 <title lang="en">Default</title>
 <title lang="de">Standard</title>
 </meta>

 ... </template>
 <controller>SuluWebsiteBundle:Default:index</controller> <view>templates/default</view>
34. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http:// schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>


 <cacheLifetime>2400</cacheLifetime>

 <meta>
 <title lang="en">Default</title>
 <title lang="de">Standard</title>
 </meta>

 ... </template>
 <controller>AppBundle:Custom:index</controller> <view>templates/default</view>
35. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http:// schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>


 <cacheLifetime>2400</cacheLifetime>

 <meta>
 <title lang="en">Default</title>
 <title lang="de">Standard</title>
 </meta>

 ... </template>
 <view>AppBundle:Custom:index</view> <controller>AppBundle:Custom:index</controller>
36. // src/AppBundle/Controller/CustomController.php

 namespace AppBundle\Controller;

 use Sulu\Bundle\WebsiteBundle\Controller\WebsiteController;
 use Sulu\Component\Content\Compat\StructureInterface;

 class CustomController extends WebsiteController
 {
 /**
 * My custom controller action.
 *
 * @param StructureInterface $structure
 * @param bool $preview
 * @param bool $partial
 *
 * @return Response
 */
 public function indexAction(StructureInterface $structure, $preview = false, $partial = false)
 {
 $response = $this->renderStructure(
 $structure,
 [
 // here you can add some custom data for your template
 'myData' => $this->get('my_custom_service')->getMyData(),
 ],
 $preview,
 $partial
 );

 return $response;
 }
 }
37. Response Format HTML, XML or JSON
38. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http://schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>

 <view>AppBundle:Custom:index</view>
 <controller>AppBundle:Custom:index</controller>
 <cacheLifetime>2400</cacheLifetime>

 ... </template>
39. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http://schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>

 <view>AppBundle:Custom:index</view>
 <controller>AppBundle:Custom:index</controller>
 <cacheLifetime>2400</cacheLifetime>

 ... </template> .html.twig
40. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http://schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>

 <view>AppBundle:Custom:index</view>
 <controller>AppBundle:Custom:index</controller>
 <cacheLifetime>2400</cacheLifetime>

 ... </template> // src/AppBundle/Resources/views/Custom/index.html.twig {% extends "master.html.twig" %} {% block content %} <h1 property="title">{{ content.title }}</h1> <div property="article"> {{ content.article|raw }} </div> {% endblock %} .html.twig
41. // app/Resources/templates/pages/default.xml <?xml version="1.0" ?>
 <template xmlns="http://schemas.sulu.io/template/template"
 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 xsi:schemaLocation="http://schemas.sulu.io/template/template http://schemas.sulu.io/template/template-1.0.xsd">

 <key>default</key>

 <view>AppBundle:Custom:index</view>
 <controller>AppBundle:Custom:index</controller>
 <cacheLifetime>2400</cacheLifetime>

 ... </template> // src/AppBundle/Resources/views/Custom/index.html.twig {% extends "master.html.twig" %} {% block content %} <h1 property="title">{{ content.title }}</h1> <div property="article"> {{ content.article|raw }} </div> {% endblock %} // src/AppBundle/Resources/views/Custom/index.json.twig {{ content|json_encode|raw }} .html.twig
43. HTTP Cache & ESI HTTP Standards FTW!
44. Reverse Proxy Caches
45. Reverse Proxy Caches – A HTTP Cache is a full page cache
46. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid
47. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid – HTTP cache headers are used to mark a response cacheable and for how long
48. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid – HTTP cache headers are used to mark a response cacheable and for how long – Symfony comes with a reverse proxy written in PHP
49. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid – HTTP cache headers are used to mark a response cacheable and for how long – Symfony comes with a reverse proxy written in PHP – Switch to something more robust like Varnish without any problem
50. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid – HTTP cache headers are used to mark a response cacheable and for how long – Symfony comes with a reverse proxy written in PHP – Switch to something more robust like Varnish without any problem https://tomayko.com/blog/2008/things-caches-do
51. Reverse Proxy Caches – A HTTP Cache is a full page cache – It bypasses your application entirely, if the cache entry is valid – HTTP cache headers are used to mark a response cacheable and for how long – Symfony comes with a reverse proxy written in PHP – Switch to something more robust like Varnish without any problem https://tomayko.com/blog/2008/things-caches-do
52. “ Caching entire responses isn't always possible for highly dynamic sites, or is it?
53. ESI - Edge Side Includes
54. ESI - Edge Side Includes – The ESI specification describes tags to communicate with the gateway cache
55. ESI - Edge Side Includes – The ESI specification describes tags to communicate with the gateway cache – In Symfony the <esi:include/> is implemented
56. ESI - Edge Side Includes – The ESI specification describes tags to communicate with the gateway cache – In Symfony the <esi:include/> is implemented – If the response contains ESI tags, the cache either requests the page fragment from the backend or embeds the fresh cache entry
57. // app/config/config.yml framework:
 ... esi: { enabled: true }
58. // app/config/config.yml framework:
 ... esi: { enabled: true } // app/Resources/views/Default/index.html.twig {# you can use a controller reference #} {{ render_esi(controller('AppBundle:News:latest', { 'limit': 5 })) }} {# ... or a URL #} {{ render_esi(url('latest_news', { 'limit': 5 })) }}
59. Model Customize what you need.
60. Customizing Models
61. Customizing Models – Doctrine doesn't support model customization
62. Customizing Models – Doctrine doesn't support model customization – Inheritance leads to multiple tables for the same data structure
63. Customizing Models – Doctrine doesn't support model customization – Inheritance leads to multiple tables for the same data structure – Sulu’s PersistenceBundle allows to replace models via configuration
64. Customizing Models – Doctrine doesn't support model customization – Inheritance leads to multiple tables for the same data structure – Sulu’s PersistenceBundle allows to replace models via configuration – Inspired by Sylius ResourceBundle
65. // src/AppBundle/EntityTag.php <?php namespace AppBundle\Entity; use Sulu\Bundle\TagBundle\Entity\Tag as SuluTag; class Tag extends SuluTag { public $description; }
66. // src/AppBundle/EntityTag.php <?php namespace AppBundle\Entity; use Sulu\Bundle\TagBundle\Entity\Tag as SuluTag; class Tag extends SuluTag { public $description; } // src/AppBundle/Resources/config/doctrine/Tag.orm.xml <?xml version="1.0" encoding="utf-8"?> <doctrine-mapping xmlns="http://doctrine-project.org/schemas/orm/doctrine-mapping" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://doctrine-project.org/schemas/orm/doctrine-mapping http://doctrine-project.org/schemas orm/doctrine-mapping.xsd"> <entity name="AppBundle\Entity\Tag" table="ta_tags"> <field name="description" type="text" column="description" nullable="true"/> </entity> </doctrine-mapping>
67. // src/AppBundle/EntityTag.php <?php namespace AppBundle\Entity; use Sulu\Bundle\TagBundle\Entity\Tag as SuluTag; class Tag extends SuluTag { public $description; } // src/AppBundle/Resources/config/doctrine/Tag.orm.xml <?xml version="1.0" encoding="utf-8"?> <doctrine-mapping xmlns="http://doctrine-project.org/schemas/orm/doctrine-mapping" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://doctrine-project.org/schemas/orm/doctrine-mapping http://doctrine-project.org/schemas orm/doctrine-mapping.xsd"> <entity name="AppBundle\Entity\Tag" table="ta_tags"> <field name="description" type="text" column="description" nullable="true"/> </entity> </doctrine-mapping> // app/config/config.yml sulu_tag: objects: tag: model: AppBundle\Entity\Tag
68. Event Dispatcher Handle additional business logic within your Event Subscriber.
70. Symfony Events
71. Symfony Events Kernel Events – kernel.request – kernel.response – kernel.controller – kernel.view – kernel.terminate …
72. Symfony Events Kernel Events – kernel.request – kernel.response – kernel.controller – kernel.view – kernel.terminate … Doctrine Events
73. Symfony Events Kernel Events – kernel.request – kernel.response – kernel.controller – kernel.view – kernel.terminate … Doctrine Events Lifecycle Events – [pre|post]Remove – [pre|post]Persist – [pre|post]Update – [pre|on|post]Flush – onClear …
75. Sulu Document Manager Events
76. Sulu Document Manager Events bin/adminconsole sulu:document:subscriber:debug
77. Sulu Document Manager Events +----------------------+ | Events | +----------------------+ | persist | | hydrate | | remove | | refresh | | copy | | move | | create | | clear | | find | | reorder | | publish | | unpublish | | remove_draft | | flush | | query.create | | query.create_builder | | query.execute | | configure_options | | metadata_load | | restore | +----------------------+ bin/adminconsole sulu:document:subscriber:debug
78. // src/AppBundle/Document/Subscriber/MailSubscriber.php

 namespace AppBundle\Document\Subscriber;

 use Sulu\Component\DocumentManager\Event\PublishEvent;
 use Sulu\Component\DocumentManager\Events;
 use Symfony\Component\EventDispatcher\EventSubscriberInterface;

 class MailSubscriber implements EventSubscriberInterface
 {
 ...

 /**
 * {@inheritdoc}
 */
 public static function getSubscribedEvents()
 {
 return [
 Events::PUBLISH => ['sendNotification', -1000],
 ];
 }

 public function sendNotification(PublishEvent $event)
 {
 $message = new \Swift_Message('Page Published', 'URL: ' . $event->getDocument()->getResourceSegment());

 $this->mailer->send($message);
 }
 }
79. // src/AppBundle/Document/Subscriber/MailSubscriber.php

 namespace AppBundle\Document\Subscriber;

 use Sulu\Component\DocumentManager\Event\PublishEvent;
 use Sulu\Component\DocumentManager\Events;
 use Symfony\Component\EventDispatcher\EventSubscriberInterface;

 class MailSubscriber implements EventSubscriberInterface
 {
 ...

 /**
 * {@inheritdoc}
 */
 public static function getSubscribedEvents()
 {
 return [
 Events::PUBLISH => ['sendNotification', -1000],
 ];
 }

 public function sendNotification(PublishEvent $event)
 {
 $message = new \Swift_Message('Page Published', 'URL: ' . $event->getDocument()->getResourceSegment());

 $this->mailer->send($message);
 }
 } <service id="app.document_subscriber.email" class="AppBundle\Document\Subscriber\MailSubscriber"> <argument type="service" id="mailer" /> <tag name="sulu_document_manager.event_subscriber"/> </service>
80. Service Container The control center for all you application.
81. Service Container
82. Service Container – Foundation for extensibility & customizability
83. Service Container – Foundation for extensibility & customizability – Sulu heavily uses service definitions
84. Service Container – Foundation for extensibility & customizability – Sulu heavily uses service definitions – Add new functionality (Modulnavigation, Content-Type, ...)
85. Service Container – Foundation for extensibility & customizability – Sulu heavily uses service definitions – Add new functionality (Modulnavigation, Content-Type, ...) – Extend existing (Smart-Content, Teaser, ...)
86. Service Container – Foundation for extensibility & customizability – Sulu heavily uses service definitions – Add new functionality (Modulnavigation, Content-Type, ...) – Extend existing (Smart-Content, Teaser, ...) – Overwrite services
87. // src/AppBundle/Admin/AppAdmin.php
 namespace AppBundle\Admin;

 use Sulu\Bundle\AdminBundle\Admin\Admin;
 use Sulu\Bundle\AdminBundle\Navigation\Navigation;
 use Sulu\Bundle\AdminBundle\Navigation\NavigationItem;

 class AppAdmin extends Admin
 {
 public function __construct($title)
 {
 $rootNavigationItem = new NavigationItem($title);
 $section = new NavigationItem('navigation.modules');

 $myModule = new NavigationItem('app.my_module');
 $myModule->setIcon('custom');

 $item = new NavigationItem('app.my_module.title');
 $item->setAction('my_module/custom');
 $myModule->addChild($item);

 $rootNavigationItem->addChild($section);
 $section->addChild($myModule);

 $this->setNavigation(new Navigation($rootNavigationItem));
 }
 }
88. // src/AppBundle/Admin/AppAdmin.php
 namespace AppBundle\Admin;

 use Sulu\Bundle\AdminBundle\Admin\Admin;
 use Sulu\Bundle\AdminBundle\Navigation\Navigation;
 use Sulu\Bundle\AdminBundle\Navigation\NavigationItem;

 class AppAdmin extends Admin
 {
 public function __construct($title)
 {
 $rootNavigationItem = new NavigationItem($title);
 $section = new NavigationItem('navigation.modules');

 $myModule = new NavigationItem('app.my_module');
 $myModule->setIcon('custom');

 $item = new NavigationItem('app.my_module.title');
 $item->setAction('my_module/custom');
 $myModule->addChild($item);

 $rootNavigationItem->addChild($section);
 $section->addChild($myModule);

 $this->setNavigation(new Navigation($rootNavigationItem));
 }
 } <service id="app.admin" class="AppBundle\Admin\AppAdmin"> <argument>%sulu_admin.name%</argument> <tag name="sulu.admin"/> <tag name="sulu.context" context="admin"/> </service>
89. // src/AppBundle/DependencyInjection/AppCompilerPass.php

 namespace AppBundle\DependencyInjection;

 use AppBundle\Contact\CustomContactManager;
 use Symfony\Component\DependencyInjection\Compiler\CompilerPassInterface;
 use Symfony\Component\DependencyInjection\ContainerBuilder;
 use Symfony\Component\DependencyInjection\Reference;

 class AppCompilerPass implements CompilerPassInterface
 {
 public function process(ContainerBuilder $container)
 {
 $definition = $container->getDefinition('sulu_contact.contact_manager');
 $definition->setClass(CustomContactManager::class);
 $definition->addArgument(new Reference('app.my_custom_service'));
 }
 }
90. // src/AppBundle/DependencyInjection/AppCompilerPass.php

 namespace AppBundle\DependencyInjection;

 use AppBundle\Contact\CustomContactManager;
 use Symfony\Component\DependencyInjection\Compiler\CompilerPassInterface;
 use Symfony\Component\DependencyInjection\ContainerBuilder;
 use Symfony\Component\DependencyInjection\Reference;

 class AppCompilerPass implements CompilerPassInterface
 {
 public function process(ContainerBuilder $container)
 {
 $definition = $container->getDefinition('sulu_contact.contact_manager');
 $definition->setClass(CustomContactManager::class);
 $definition->addArgument(new Reference('app.my_custom_service'));
 }
 } // src/AppBundle/AppBundle.php namespace AppBundle; use AppBundle\DependencyInjection\AppCompilerPass; use Symfony\Component\DependencyInjection\ContainerBuilder; use Symfony\Component\HttpKernel\Bundle\Bundle; class AppBundle extends Bundle { public function build(ContainerBuilder $container) { $container->addCompilerPass(new AppCompilerPass()); } }
91. Thanks for watching! www.sulu.io
