Creating and Analyzing Playable Narratives with Linear Logic

Computational procedures afford us with a rich design space of narratives that can be explored and played in a variety of ways, and interactive narrative as a field has the potential to help humans understand complex systems of causality. But we need better tools for authoring and conceptualizing playable narratives, especially those that arise from multiple story agents acting interdependently.

I illustrate how linear logic, a general formalism with ties to
computational concurrency, can be used to encode a narrative space in such a way that we can a) run a proof search algorithm to generate different narratives, and b) analyze causal structure. I will then discuss ongoing work in developing a programming language based on linear logic, with the aim of supporting a broad range of idioms in interactive simulation and game design.

Transcript

1. Creating and Analyzing!
   Playable Narratives!
   with Linear Logic
   Chris Martens
   1
   Graphics Lab, CMU

   April 21, 2015


   View Slide

2. Creating and Analyzing!
   Playable Narratives!
   with Linear Logic
   Chris Martens
   2
   Graphics Lab, CMU

   April 21, 2015


   View Slide

3. 3
   Parable of the Polygons (Vi Hart and Nicky Case)


   View Slide

4. 4
   Causal Understanding


   View Slide

5. 5
   Outline:

   !
   1. Background: forms of narrative play

   2. Extended example: Shakespeare World

   3. Ongoing work: playable specifications


   View Slide

6. 6
   1. FORMS OF NARRATIVE PLAY


   View Slide

7. 7
   branching stories


   View Slide

8. 8
   branching stories
   Twine (twinery.org)


   View Slide

9. View Slide

10. 10
    Sam Kabo Ashwell: “Standard Patterns in Choice-Based
    Games"


    View Slide

11. 11
    Sam Kabo Ashwell: “Standard Patterns in Choice-Based
    Games"


    View Slide

12. 12
    branching stories with state
    foyer:
    (set:$key = true) You found a key!

    [[den]]

    !
    den:
    (if: not $key)[There is a cabinet here, but you can't open it.]

    (else: )[There's a cabinet here. [[open it]] ]

    [[foyer]]

    !
    open it:
    yay cabinet!


    View Slide

13. 13
    What’s the structure of a stateful story?


    View Slide

14. View Slide

15. 15
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    Petri Net


    View Slide

16. 16
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    permanent

    states
    Petri Net


    View Slide

17. 17
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    Petri Net


    View Slide

18. 18
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    Petri Net


    View Slide

19. 19
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    Petri Net


    View Slide

20. 20
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    choice between

    actions
    Petri Net


    View Slide

21. 21
    JRWRIR\HU
    RSHQFDELQHW
    JRWRGHQ
    NH\ IR\HU
    ZLQ
    GHQ
    Petri Net


    View Slide

22. 22
    Linear Logic
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.


    View Slide

23. 23
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.
    Linear Logic
    “atoms” or “(atomic) resources”


    View Slide

24. 24
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.
    Linear Logic
    “lolli:” linear implication


    View Slide

25. 25
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.
    Linear Logic
    antecedents and consequents


    View Slide

26. 26
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.
    Linear Logic
    “tensor:” resource conjunction


    View Slide

27. 27
    go_to_foyer : in_den -o in_foyer * !key.
    go_to_den : in_foyer -o in_den.
    open_cabinet : in_den * key
    -o in_den * !cabinet_open.
    Linear Logic
    “bang:” persistent resources


    View Slide

28. 28
    another form of narrative play


    View Slide

29. 29
    greet

    insult

    compliment

    gossip

    reject

    ...
    social verbs: social state:
    knowledge

    sentiment

    emotional state

    personality

    beliefs

    goals


    View Slide

30. 30
    aka

    “character-driven”

    “emergent”

    “combinatorial”
    COMPOSITIONAL NARRATIVE


    View Slide

31. 31
    aka

    “character-driven”

    “emergent”

    “combinatorial”
    COMPOSITIONAL NARRATIVE
    One rule might be applied several times, each in a different
    narrative state.

    !
    Thus: rules must be parametric over narrative states!


    View Slide

32. 32
    COMPOSITIONAL NARRATIVE
    Research question:

    How can we provide computational support to authoring,
    understanding the structure of,

    and playing with compositional narratives?


    View Slide

33. 33
    COMPOSITIONAL NARRATIVE
    Answer in progress:

    programming language(s) based on linear logic.
    Research question:

    How can we provide computational support to authoring,
    understanding the structure of,

    and playing with compositional narratives?


    View Slide

34. 34
    Outline:

    !
    1. Background: forms of narrative play

    2. Extended example: Shakespeare World

    3. Ongoing work: playable specifications


    View Slide

35. 35
    II. EXTENDED EXAMPLE:

    SHAKESPEAREAN TRAGEDY

    STORY WORLD


    View Slide

36. 36
    at

    has

    anger

    affection

    depressed

    dead
    World state:


    View Slide

37. 37
    insult:
    ➡️


    View Slide

38. 38
    do/insult : !
    at Alice L * at Eliza L

    * anger Alice Eliza!
    -o !
    at Alice L * at Eliza L

    * anger Alice Eliza

    * anger Eliza Alice

    * depressed Eliza.!


    View Slide

39. 39
    do/insult : !
    $at Alice L * $at Eliza L

    * $anger Alice Eliza!
    -o !
    anger Eliza Alice

    * depressed Eliza.!
    (notation: $ for resources we want to keep)


    View Slide

40. 40
    do/insult : !
    $at C L * $at C’ L

    * $anger C C’!
    -o anger C’ C

    * depressed C’.!
    for all C, C’, L


    View Slide

41. 41
    do/insult : !
    $at C L * $at C’ L

    * $anger C C’!
    -o anger C’ C

    * depressed C’.!
    for all C, C’, L
    Logic Programming!

    (aka Relational Programming)


    View Slide

42. 42
    Main idea of this section:

    Use linear logic programming

    (computation = proof search)

    to generate narratives over a

    space specified by rules.


    View Slide

43. 43
    compliment:
    ➡️


    View Slide

44. 44
    ➡️
    travel_toward:


    View Slide

45. 45
    murder:
    !
    !
    ➡️


    View Slide

46. 46
    loot:
    ➡️


    View Slide

47. View Slide

48. 48
    initial state
    !adjacent mon_house town.!
    !adjacent town mon_house.!
    !adjacent cap_house town.!
    !adjacent town cap_house.!


    View Slide

49. View Slide

50. View Slide

51. Program Execution
    51
    A -o B
    Δ, A → Δ, B
    Δ = arbitrary context of resources A1, …, An


    View Slide

52. 52
    6 6¶
    6R6¶

    U6R6¶


    Q

    /RJLF3URJUDP
    LQLWLDOVWDWH
    Program execution in CLF (Watkins et al. 2002)

    as realized by Celf (Schack-Nielsen & Schürmann 2008)
    quiescence


    View Slide

53. Program Execution
    53
    At the end we get:
    !
    Δ , the final context
    !
    a trace of rules applied (sequence of narrative actions,
    AKA story!)
    n


    View Slide

54. 54
    x0 : p(romeo,juliet)
    x1 : q
    x2 : r
    =


    View Slide

55. 55
    rule :
    p(C,C’) * q -o s(C)
    x0 : p(romeo,juliet)
    x1 : q
    x2 : r


    View Slide

56. 56
    x3 : s(romeo)
    x2 : r
    x0 : p(romeo,juliet)
    x1 : q
    x2 : r
    rule :
    p(C,C’) * q -o s(C)


    View Slide

57. 57
    let x3 = rule x0 x1
    …
    x0 : p(romeo,juliet)
    x1 : q
    x2 : r
    x3 : s(romeo)
    x2 : r
    rule :
    p(C,C’) * q -o s(C)


    View Slide

58. 58
    x3 : s(romeo)
    x2 : r
    let x3 = rule x0 x1
    …
    rule2 :
    r * s(C) -o t(C) * u


    View Slide

59. 59
    let x3 = rule x0 x1
    let [x4, x5] = rule2 x2 x3
    …
    x4 : t(romeo)
    x5 : u
    x3 : s(romeo)
    x2 : r
    rule2 :
    r * s(C) -o t(C) * u


    View Slide

60. Nondeterminism
    60
    A -o B
    Δ, B
    A -o C
    Δ, C
    Δ, A


    View Slide

61. 61
    A -o B C -o D


    View Slide

62. 62
    A -o B C -o D
    Δ, B, C Δ, A, D
    Δ, A, C


    View Slide

63. 63
    A -o B C -o D
    Δ, B, C Δ, A, D
    Δ, A, C
    Δ, B, D


    View Slide

64. 64
    A -o B C -o D
    Δ, B, C Δ, A, D
    Δ, A, C
    Δ, B, D
    r1 r2
    r2 r1


    View Slide

65. 65
    A -o B C -o D
    Δ, B, C Δ, A, D
    Δ, A, C
    Δ, B, D
    r1 r2
    r2 r1
    let y1 = r1 x1
    let y2 = r2 x2
    in E
    let y2 = r2 x2
    let y1 = r1 x1
    in E


    View Slide

66. 66
    Δ, B, C Δ, A, D
    Δ, A, C
    Δ, B, D
    r1 r2
    r2 r1
    Concurrent Equality
    =
    let y1 = r1 x1
    let y2 = r2 x2
    in E
    let y2 = r2 x2
    let y1 = r1 x1
    in E


    View Slide

67. 67
    y1:B y2:D
    r1 r2 let y2 = r2 x2
    let y1 = r1 x1
    in E
    let y1 = r1 x1
    let y2 = r2 x2
    in E
    x1:A x2:C


    View Slide

68. 68
    @KšEJOQHP PU>=HP¡ NKIAK¡
    PKSJ¡
    =JCAN
    @Kš?KILHEIAJP JQNOA¡ FQHEAP¡
    ?=L‹DKQOA¡
    @KšPN=RAH NKIAK¡ PKSJ¡
    ?=L‹DKQOA¡
    HEGAO
    =P
    =JCAN
    =JCAN HEGAO
    HEGAO
    HEGAO
    HEGAO HEGAO
    @Kš?KILHEIAJP FQHEAP¡ NKIAK¡
    =P
    =P
    =P
    =P
    =P
    =P
    =P
    =P
    =P
    =P


    View Slide

69. 69
    program traces are!
    causally-structured stories


    View Slide

70. 70
    Outline:

    !
    1. Background: forms of narrative play

    2. Extended example: Shakespeare World

    3. Ongoing work: playable specifications


    View Slide

71. 71
    3. ONGOING WORK:

    PLAYABLE SPECIFICATIONS


    View Slide

72. 72
    accessible tools for making

    games


    View Slide

73. 73
    PuzzleScript


    View Slide

74. View Slide

75. View Slide

76. 76
    Horizontal [ > Player | No Obstacle ] ->
    [ PlayerBodyH | PlayerHead1 ] sfx2


    View Slide

77. 77
    Idea:

    Replace nondeterminism in the system

    with human interactor choice.


    View Slide

78. 78
    move/up/red : move up * at L (player_head red)
    -o at L (player_head red).
    !
    move/up : move up * at L (player_head C) * next C C'
    * adj L up L' * empty L' -o
    -o at L player_body * at L' (player_head L’).
    !
    move/r : move right * at L (player_head C) * adj L right L'
    * empty L'
    -o at L player_body * at L' (player_head lime).
    !
    move/l : move left * at L (player_head C) * adj L left L'
    * empty L'
    -o at L player_body * at L' (player_head lime).
    !
    % gravity
    gravity : at L (player_head C) * adj L down L' * empty L'
    -o at L player_body * at L' (player_head C).


    View Slide

79. 79
    move/up/red : move up * at L (player_head red)
    -o at L (player_head red).
    !
    move/up : move up * at L (player_head C) * next C C'
    * adj L up L' * empty L' -o
    -o at L player_body * at L' (player_head L’).
    !
    move/r : move right * at L (player_head C) * adj L right L'
    * empty L'
    -o at L player_body * at L' (player_head lime).
    !
    move/l : move left * at L (player_head C) * adj L left L'
    * empty L'
    -o at L player_body * at L' (player_head lime).
    !
    % gravity
    gravity : at L (player_head C) * adj L down L' * empty L'
    -o at L player_body * at L' (player_head C).


    View Slide

80. 80
    CEPTRE

    3 additions to the core language:

    !
    sensing predicates

    acting predicates

    stages


    View Slide

81. 81
    targeted applications:

    !
    1. game design: easily combine rules from many domains;
    invent new mechanics and game logics

    !
    2. distributed algorithms & systems: easily prototype and
    experiment with local rules and their global behavior


    View Slide

82. 82
    ONGOING/FUTURE WORK


    View Slide

83. 83
    language implementation
    https://github.com/chrisamaphone/interactive-lp


    View Slide

84. 84
    emergent systems have lots of corner cases

    =>

    bugs!


    View Slide

85. 85
    Reasoning Tools

    !
    1. Statistical analysis of sets of traces

    2. Invariant, precondition, and postcondition checking for
    stages (static or dynamic)

    3. Exhaustive analysis (model checking) for certain
    fragments of the language?


    View Slide

86. 86
    Reasoning Tools

    !
    1. Statistical analysis of sets of traces

    2. Invariant, precondition, and postcondition checking
    for stages (static or dynamic)
    3. Exhaustive analysis (model checking) for certain
    fragments of the language?


    View Slide

87. 87
    Invariant Checking
    Example:

    “Whenever the player can reach a locked door, she can
    also reach its key.”

    !
    for all doors D, reachable(player,D)
    => reachable(player, key(D))


    View Slide

88. 88
    CONCLUSION


    View Slide

89. 89
    Method:

    Linear logic programming + proof theory

    !
    Results:

    1. Structured narrative generation

    2. Playable narratives and game sketches


    View Slide

90. 90
    Takeaway:

    !
    Programming languages based on logic can bring

    rules, narrative, and code into closer alignment,

    which aids

    prototyping, testing, and reasoning
    of compositional simulations.


    View Slide

91. 91
    Questions?
    7ZLQH
    %UDQFKLQJ
    VWRU\
    JUDSKV
    6WDWHIXO
    6WRULHV
    (PHUJHQW
    VWRU\WHOOLQJ
    7KHDWULFV
    3URP
    :HHN
    7KH6LPV
    /LQHDU
    /RJLF
    3HWUL1HWV
    &/)&HOI
    SURJUDPPLQJ
    ODQJXDJH
    7KHVLV
    VWDWHPHQW
    5HVHDUFK
    4XHVWLRQ
    (YLGHQFHIRU
    GHVLJQWRROSDUW
    RIWKHVLV
    VWDWHPHQW
    UHDVRQLQJ
    WRROV
    EXJV
    &HSWUH
    VHQVLQJ
    SUHGLFDWHV
    3X]]OH6FULSW
    (YLGHQFHIRU
    SURWRW\SLQJDQG
    DQDO\VLVSDUWRI
    WKHVLVVWDWHPHQW
    3DUW
    3DUW
    3DUW
    &/)
    WUDFHVSURRIV
    3URRIVDV
    VWRULHV
    6KDNHVSHDUH
    ZRUOG
    /RJLF
    3URJUDPPLQJ
    &RQFXUUHQW
    VWUXFWXUH
    Thanks!


    View Slide

92. Extra Slides
    92


    View Slide

93. 93
    Open Q:

    !
    What is the narrative structure of, say, a classic arcade
    game or single-player RPG?

    !
    Is this structure useful to a designer?


    View Slide

94. 94
    Hypothesis:

    !
    Concurrent structure of play traces will not be all that
    interesting (modulo independently-acting NPCs)

    !
    …but Petri Net structure of the rules might be:

    feedback loops, “orphan verbs,” resource accumulation
    properties, other design features (& bugs)


    View Slide

95. 95
    Proof search:

    !
    To run a query

    \Delta |- B

    !
    Seed \Delta_0 = \Delta

    Run to quiescence to get \Delta’

    Check whether \Delta’ contains everything in B

    (and nothing more)


    View Slide

96. 96
    So for instance I could codify endings in Shakespeare world
    like:

    !
    married A B * dead C -o ending

    !
    then do a query for

    !
    init -o ending

    !
    (in fact this is what I did since Celf doesn’t support traces
    for goalless queries!)


    View Slide

97. 97
    Tamara
    Participatory theatre in which participants may follow any
    character when they exit a scene

    !
    Many concurrent + reconverging scenes — concurrent
    structure!

    !
    CLF as dramaturgy tool?


    View Slide
