Conductor: Architecture and Alternatives

In a world of Architecture Components and Jetpack, what place does a view-navigation library like Conductor have? I think quite a lot!

Links
-----
Conductor: https://github.com/bluelinelabs/Conductor
Managing State with RxJava by Jake Wharton: https://youtu.be/0IKHxjkgop4
Combining Conductor and Navigation: https://bit.ly/2MD9LSn
Combination repo: https://github.com/prolificinteractive/navigation-conductor
My website: https://chrishorner.codes

Transcript

1. Conductor
   Architecture and Alternatives
   @chris_h_codes


   View Slide

2. Navigation is hard


   View Slide

3. Navigation is hard
   • Picking the difference between up and back


   View Slide

4. Navigation is hard
   • Picking the difference between up and back
   • Sometimes up is… not up?


   View Slide

5. Navigation is hard
   • Picking the difference between up and back
   • Sometimes up is… not up?
   • What happens when we deep link?


   View Slide

6. Navigation is hard
   • Picking the difference between up and back
   • Sometimes up is… not up?
   • What happens when we deep link?
   • Bottom navigation gets involved


   View Slide

7. Navigation is hard
   • Picking the difference between up and back
   • Sometimes up is… not up?
   • What happens when we deep link?
   • Bottom navigation gets involved


   View Slide

8. Google’s making it
   worse
   “The bottom navigation bar remains in view when
   navigating through an app’s hierarchy.”
   - Google’s new design guidelines


   View Slide

9. There’s a term for this


   View Slide

10. View Slide

11. Single Activity apps


    View Slide

12. Single Activity apps
    • Control over UI elements remaining on screen


    View Slide

13. Single Activity apps
    • Control over UI elements remaining on screen
    • Easier shared element transitions


    View Slide

14. Single Activity apps
    • Control over UI elements remaining on screen
    • Easier shared element transitions
    • Single and stable entry point for your UI


    View Slide

15. Single Activity apps
    • Control over UI elements remaining on screen
    • Easier shared element transitions
    • Single and stable entry point for your UI

    - Kind of like main() with lifecycle callbacks


    View Slide

16. Fragments…


    View Slide

17. Fragment transactions


    View Slide

18. Fragment transactions
    val newFragment = NextFragment()
    val transaction = getSupportFragmentManager().beginTransaction()
    transaction.replace(R.id.fragment_container, newFragment)
    transaction.addToBackStack(null)
    transaction.commit()


    View Slide

19. Fragment transactions
    val newFragment = NextFragment()
    val transaction = getSupportFragmentManager().beginTransaction()
    transaction.replace(R.id.fragment_container, newFragment)
    transaction.addToBackStack(null)
    transaction.commitAllowingStateLoss()


    View Slide

20. Fragment transactions
    val newFragment = NextFragment()
    val transaction = getSupportFragmentManager().beginTransaction()
    transaction.replace(R.id.fragment_container, newFragment)
    transaction.addToBackStack(null)
    transaction.commitNow()


    View Slide

21. Fragment transactions
    val newFragment = NextFragment()
    val transaction = getSupportFragmentManager().beginTransaction()
    transaction.replace(R.id.fragment_container, newFragment)
    transaction.addToBackStack(null)
    transaction.commitNowAllowingStateLoss()


    View Slide

22. Fragment lifecyle


    View Slide

23. Fragment lifecyle


    View Slide

24. Fragment lifecyle


    View Slide

25. Fragment identity crisis


    View Slide

26. Fragment identity crisis
    android:name="codes.chrishorner.fragments.Example"
    android:id="@+id/exampleFragment"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    />


    View Slide

27. Fragment identity crisis
    class MyFragment : Fragment() {
    }}


    View Slide

28. Fragment identity crisis
    class MyFragment : Fragment() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    }}
    }}


    View Slide

29. Fragment identity crisis
    class MyFragment : Fragment() {
    @Inject lateinit var ...
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    // Do some dependency injection...
    }}
    }}


    View Slide

30. Fragment identity crisis
    class MyFragment : Fragment() {
    @Inject lateinit var ...
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    // Do some dependency injection...
    }}
    override fun onStart() {
    super.onStart()
    // Use your injected dependencies to modify sub-views.
    }}
    }}


    View Slide

31. Applying your
    MV-Whatever


    View Slide

32. Applying your MV-Whatever
    • Maybe a Fragment is a presenter? A controller? A view?


    View Slide

33. Applying your MV-Whatever
    • Maybe a Fragment is a presenter? A controller? A view?
    • Whatever it is, it does a lot!


    View Slide

34. Applying your MV-Whatever
    • Maybe a Fragment is a presenter? A controller? A view?
    • Whatever it is, it does a lot!
    • Receive lifecycle events
    • Manage view hierarchies
    • Save instance state
    • Deal with non-configuration instance object passing
    • Handle a back stack


    View Slide

35. So what’s Conductor?
    github.com/bluelinelabs/Conductor


    View Slide

36. How Conductor works
    Fragment Controller


    View Slide

37. How Conductor works
    Fragment Controller
    “Think of it as a lighter-weight and more predictable Fragment
    alternative with an easier to manage lifecycle.”
    - The Conductor documentation


    View Slide

38. How Conductor works
    • Represents a screen; a node in your navigation graph
    • Must have a View; cannot be headless
    • Cannot be declared in XML
    • Survives orientation changes by default
    • Permits passing arguments in a constructor*
    abstract class Controller


    View Slide

39. Declaring a Controller
    class MyController : Controller() {
    }}


    View Slide

40. Declaring a Controller
    class MyController : Controller() {
    override fun onCreateView(inflater: LayoutInflater,
    container: ViewGroup): View {
    return inflater.inflate(R.layout.my_layout, container, false)
    }
    }}


    View Slide

41. Declaring a Controller
    class MyController : Controller() {
    override fun onCreateView(inflater: LayoutInflater,
    container: ViewGroup): View {
    return inflater.inflate(R.layout.my_layout, container, false)
    }}
    override fun onAttach(view: View) { … }
    override fun onDetach(view: View) { … }
    }}


    View Slide

42. Navigating Controllers


    View Slide

43. Navigating Controllers
    class MainActivity : AppCompatActivity() {
    }}


    View Slide

44. Navigating Controllers
    class MainActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.main)
    }
    }}
    android:id="@+id/container"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    />


    View Slide

45. Navigating Controllers
    class MainActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.main)
    }}
    }}
    android:id="@+id/container"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    />


    View Slide

46. Navigating Controllers
    class MainActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.main)
    val container: ViewGroup = findViewById(R.id.container)
    val router = Conductor.attachRouter(this, container, savedInstanceState)
    }}
    }}


    View Slide

47. Navigating Controllers
    class MainActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.main)
    val container: ViewGroup = findViewById(R.id.container)
    val router = Conductor.attachRouter(this, container, savedInstanceState)
    if (!router.hasRootController()) {
    router.setRoot(RouterTransaction.with(HomeController()))
    }
    }}
    }}


    View Slide

48. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    }}
    }}


    View Slide

49. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    view.events.ofType()
    }}
    }}


    View Slide

50. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    view.events.ofType().subscribe {
    }}
    }}
    }}


    View Slide

51. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    view.events.ofType().subscribe {
    val transaction = RouterTransaction.with(NextController())
    }}
    }}
    }}


    View Slide

52. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    view.events.ofType().subscribe {
    val transaction = RouterTransaction.with(NextController())
    router.pushController(transaction)
    }}
    }}
    }}


    View Slide

53. Navigating Controllers
    class MyController : Controller() {
    override fun onAttach(view: View) {
    view.events.ofType().subscribe {
    val transaction = RouterTransaction.with(NextController())
    .pushChangeHandler(HorizontalChangeHandler())
    .popChangeHandler(HorizontalChangeHandler())
    router.pushController(transaction)
    }}
    }}
    }}


    View Slide

54. Handling change


    View Slide

55. Handling change
    • Swaps the View of one Controller out for another
    • …or not! You’re in control
    • Your opportunity to provide custom animations / transitions
    • Comes in a variety of built in flavours
    abstract class ControllerChangeHandler


    View Slide

56. Handling change
    • Comes in a variety of built in flavours
    class FadeChangeHandler : AnimatorChangeHandler
    class HorizontalChangeHandler : AnimatorChangeHandler
    class VerticalChangeHandler : AnimatorChangeHandler


    View Slide

57. Handling change
    abstract class AnimatorChangeHandler


    View Slide

58. Handling change
    class FadeAndScaleChangeHandler : AnimatorChangeHandler() {
    }}


    View Slide

59. Handling change
    class FadeAndScaleChangeHandler : AnimatorChangeHandler() {
    override fun getAnimator(container: ViewGroup,
    from: View?,
    to: View?,
    isPush: Boolean,
    toAddedToContainer: Boolean): Animator {
    }
    }}


    View Slide

60. Handling change
    class FadeAndScaleChangeHandler : AnimatorChangeHandler() {
    override fun getAnimator(container: ViewGroup,
    from: View,
    to: View,
    isPush: Boolean,
    toAddedToContainer: Boolean): Animator {
    val set = AnimatorSet()
    set.playTogether(
    ObjectAnimator.ofFloat(to, View.SCALE_X, 0.9f, 1f),
    ObjectAnimator.ofFloat(to, View.SCALE_Y, 0.9f, 1f),
    ObjectAnimator.ofFloat(to, View.ALPHA, 0f, 1f))
    return set


    View Slide

61. set.playTogether(
    ObjectAnimator.ofFloat(to, View.SCALE_X, 0.9f, 1f),
    ObjectAnimator.ofFloat(to, View.SCALE_Y, 0.9f, 1f),
    ObjectAnimator.ofFloat(to, View.ALPHA, 0f, 1f))
    return set
    Handling change


    View Slide

62. Handling change
    abstract class TransitionChangeHandler


    View Slide

63. Handling change
    class ListToDetailsChangeHandler : TransitionChangeHandler() {
    override fun getTransition(container: ViewGroup,
    from: View?,
    to: View?,
    isPush: Boolean): Transition {
    }
    }


    View Slide

64. Serious customisation
    override fun getTransition(container: ViewGroup,
    from: View?,
    to: View?,
    isPush: Boolean): Transition {
    return TransitionSet()
    // Slide the Alarm content on screen.
    .addTransition(Slide()
    .addTarget(to.container)
    .setInterpolator(LinearOutSlowInInterpolator()))
    // Slide bottom nav bar off screen.
    .addTransition(BottomViewSlide()
    .addTarget(from.bottomNav)
    .setDuration(270)
    .setInterpolator(sharpCurveInterpolator()))


    View Slide

65. Where do I bind my
    views?


    View Slide

66. Where do I bind my views?
    • A Controller is not the V in your MV-Whatever
    • A good place to initialise the wiring between model and view
    • Don’t make a Controller do too much


    View Slide

67. Fragments were never a
    good V in your MV-Whatever


    View Slide

68. Activity


    View Slide

69. Activity


    View Slide

70. Fragment A


    View Slide

71. Fragment A onCreate()


    View Slide

72. Fragment A
    View A
    onCreate()
    onCreateView()


    View Slide

73. Fragment A
    View A
    onCreate()
    onCreateView()
    onStart()
    onResume()


    View Slide

74. Fragment A
    View A
    onCreate()
    onCreateView()
    onStart()
    onResume()
    Navigate!


    View Slide

75. Fragment A
    View A
    onCreate()
    onCreateView()
    onStart()
    onResume()
    onPause()
    onStop()


    View Slide

76. Fragment A onCreate()
    onCreateView()
    onStart()
    onResume()
    onPause()
    onStop()
    onDestroyView()


    View Slide

77. Fragment A Fragment B


    View Slide

78. Fragment A Fragment B onCreate()


    View Slide

79. Fragment A Fragment B onCreate()
    View B onCreateView()
    onStart()
    onResume()


    View Slide

80. Fragment A Fragment B onCreate()
    View B onCreateView()
    onStart()
    onResume()
    Go back!


    View Slide

81. Fragment A Fragment B onCreate()
    onCreateView()
    onStart()
    onResume()
    onPause()
    onStop()
    onDestroyView()


    View Slide

82. Fragment A


    View Slide

83. Fragment A
    View A onCreateView()


    View Slide

84. Fragment A
    View A onCreateView()
    onCreate()


    View Slide

85. Fragment A
    View A


    View Slide

86. A pattern I don’t mind


    View Slide

87. A pattern I don’t mind
    View
    Controller


    View Slide

88. A pattern I don’t mind
    View
    Controller
    State


    View Slide

89. A pattern I don’t mind
    View
    Controller
    State
    Event


    View Slide

90. A pattern I don’t mind
    View
    Controller
    Observable
    Observable


    View Slide

91. A pattern I don’t mind
    View
    Controller
    Observable
    Observable


    View Slide

92. sealed class State {
    object Idle : State()
    object Loading : State()
    data class Error(val message: String) : State()
    data class Success(val items: List) : State()
    }


    View Slide

93. fun display(state: State) {
    when (state) {
    is Idle ->
    is Loading ->
    is Error ->
    is Success ->
    }}
    }}


    View Slide

94. class HomeView(...) : FrameLayout(...) {
    fun display(state: State) {
    when (state) {
    is Idle ->
    is Loading ->
    is Error ->
    is Success ->
    }}
    }}
    }


    View Slide

95. class HomeView(...) : FrameLayout(...) {
    fun display(state: State) {
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    >




    View Slide

96. class HomeView(...) : FrameLayout(...) {
    fun display(state: State) {
    when (state) {
    is Idle ->
    is Loading ->
    is Error ->
    is Success ->
    }}
    }}
    }}


    View Slide

97. class HomeView(context: Context, ...) : FrameLayout(...) {
    fun display(state: State) {
    when (state) {
    is Idle ->
    is Loading ->
    is Error ->
    is Success ->
    }}
    }}
    }}


    View Slide

98. class HomeView(context: Context, ...) : FrameLayout(...) {
    // RxBinding helps a lot here
    val events: Observable = ...
    fun display(state: State) {
    when (state) {
    is Idle ->
    is Loading ->
    is Error ->
    is Success ->
    }}
    }}
    }}


    View Slide

99. class HomeController : Controller() {
    }}


    View Slide

100. class HomeController : Controller() {
     override fun onAttach(view: View) {
     }}
     override fun onDetach(view: View) {
     }}
     }}


     View Slide

101. class HomeController : Controller() {
     override fun onAttach(view: View) {
     states.subscribe { view.display(it) }

     view.events.subscribe { .. }
     }}
     override fun onDetach(view: View) {
     }}
     }}


     View Slide

102. class HomeController : Controller() {
     private val disposables = CompositeDisposable()
     override fun onAttach(view: View) {
     disposables += states.subscribe { view.display(it) }
     disposables += view.events.subscribe { .. }
     }}
     override fun onDetach(view: View) {
     }}
     }}


     View Slide

103. class HomeController : Controller() {
     private val disposables = CompositeDisposable()
     override fun onAttach(view: View) {
     disposables += states.subscribe { view.display(it) }
     disposables += view.events.subscribe { .. }
     }}
     override fun onDetach(view: View) {
     disposables.clear()
     }}
     }}


     View Slide

104. class HomeController : Controller() {
     private val disposables = CompositeDisposable()
     override fun onAttach(view: View) {
     disposables += states.subscribe { view.display(it) }
     disposables += view.events.subscribe { .. }
     }}
     override fun onDetach(view: View) {
     disposables.clear()
     }}
     }}


     View Slide

105. class HomeController : Controller() {
     private val disposables = CompositeDisposable()
     override fun onAttach(view: View) {
     if (view !is HomeView) throw IllegalArgumentException()
     disposables += states.subscribe { view.display(it) }
     disposables += view.events.subscribe { .. }
     }}
     override fun onDetach(view: View) {
     disposables.clear()
     }}
     }}


     View Slide

106. class HomeController : Controller() {
     }}


     View Slide

107. class HomeController : Controller() {
     override fun onCreateView(inflater: LayoutInflater,
     container: ViewGroup): View {
     return inflater.inflate(R.layout.home, container, false)
     }}
     }}


     View Slide

108. R.layout.home
     xmlns:android="http://schemas.android.com/apk/res/android"
     android:layout_width="match_parent"
     android:layout_height="match_parent"
     >




     View Slide

109. What’s to like?
     • Simple “states go in, events come out” way of thinking
     • Test output of view states, rather than interactions with methods
     • Clear separation of concerns


     View Slide

110. More on streams…
     Managing State with RxJava by Jake Wharton
     https:/
     /youtu.be/0IKHxjkgop4
     <>
     Observable
     Observable
     Observable
     Observable


     View Slide

111. What about Architecture
     Components?


     View Slide

112. What about Architecture Components
     • LifecycleOwners
     • LiveData
     • ViewModel
     • Room
     • Paging
     • Navigation
     • WorkManager


     View Slide

113. What about Architecture Components
     • LifecycleOwners
     • LiveData
     • ViewModel


     View Slide

114. ViewModel
     class MyActivity : AppCompatActivity {
     fun onCreate(savedInstanceState: Bundle) {
     val model = ViewModelProviders.of(this).get(MyViewModel.class)
     model.getUsers().observe(this, { users ->
     // Update UI.
     })
     }
     } LiveData


     View Slide

115. ViewModel
     class MyActivity : AppCompatActivity {
     fun onCreate(savedInstanceState: Bundle) {
     val model = ViewModelProviders.of(this).get(MyViewModel.class)
     model.getUsers().observe(this, { users ->
     // Update UI.
     })
     }
     } LifecycleOwner


     View Slide

116. Activity created
     Activity rotated
     finish()
     Finished
     onCreate
     onStart
     onResume
     onPause
     onStop
     onDestroy
     onCleared()
     ViewModel
     scope
     onCreate
     onStart
     onResume
     onPause
     onStop
     onDestroy


     View Slide

117. Does Controller replace
     ViewModel?


     View Slide

118. dependencies {
     implementation 'com.bluelinelabs:conductor-archlifecycle:0.1.1'
     }
     abstract class LifecycleController : Controller, LifecycleOwner


     View Slide

119. What about the new
     Navigation component?


     View Slide

120. Out of the box
     advantages
     android.arch.navigation:navigation-fragment


     View Slide

121. Out of the box advantages
     • Avoid touching FragmentTransaction with your bear hands
     • Simplified deep linking
     • Type safe passing of arguments between destinations
     • Visualise and edit your navigation graph


     View Slide

122. View Slide

123. Can we combine them?


     View Slide

124. Can we combine them?
     Navigating Conductor and the Navigation
     Architecture Component
     Tiven Jeffery
     https:/
     /bit.ly/2MD9LSn (long medium link)
     GitHub repo
     https:/
     /github.com/prolificinteractive/navigation-conductor


     View Slide

125. Limitations
     • Navigator feels like the simple cousin of Router
     • No transitions; only R.anim or R.animator resources
     • Strange having both Router and NavController hold back stack


     View Slide

126. Summary


     View Slide

127. Summary
     • Simple in the right ways; configurable when you need it
     • Good starting point to play with different architectures
     • An alternative to many architecture components; or an addition


     View Slide

128. Conductor
     Architecture and Alternatives
     chris_h_codes
     chris-horner
     chrishorner.codes


     View Slide
