Citus Hyperscale Overview | CI&T Data Week | Leandro Santana

In this talk, Leandro explains how to scale Postgres on Azure by using the Citus extension. Citus is a powerful extension to transform PostgreSQL into a distributed database. He covers the shard rebalancer, columnar storage, and much more.

Transcript

1. © Copyright Microsoft Corporation. All rights reserved.
   Leandro Santana
   linkedin.com/in/leandroeredia/
   @citusdata
   @AzureDBPostgres
   Citus Hyperscale Overview


   View Slide

2. View Slide

3. Postgres


   View Slide

4. PostgreSQL is more popular than ever
   PostgreSQL at core of many digital transformations
   Open source Proven resilience & stability Rich feature set
   enterprise-ready
   • Zero data loss • Rich indexing and data types,
   including geospatial
   • Low TCO. No Lock-in
   • Innovate faster with broad
   ecosystem


   View Slide

5. Single Server
   Fully-managed, single-node
   PostgreSQL
   Hyperscale (Citus)
   High-performance Postgres for
   scale out
   Enterprise-ready, fully
   managed community
   PostgreSQL with built-in HA
   and multi-layered security


   View Slide

6. Monitor Azure Database for PostgreSQL with Azure Monitor
   Azure Database for PostgreSQL tracks
   performance metrics and logs telemetry data
   Collect, analyze, and take action on telemetry
   data gathered from your database using
   Azure Monitor
   Better understand your apps with deep
   insights into app and database behavior,
   view alerts, and build remediation plans
   Azure Monitor
   Visualize
   Analyze
   Respond
   Integrate Insights


   View Slide

7. Migrating to Azure Database for PostgreSQL
   Opportunity
   DBAs spending time maintaining their
   databases, not focused on their apps
   On premises PostgreSQL
   VM PostgreSQL
   Other Managed Services
   Azure Database
   Migration Services
   Azure Database
   for PostgreSQL
   Solution
   Azure Database for PostgreSQL takes care
   of patching, high availability, and
   performance management
   Provides added benefits of comprehensive,
   intelligent security and compliance,
   including threat alerts


   View Slide

8. Migration from Oracle to Azure Database for PostgreSQL
   Single instance
   of Oracle
   Opportunity
   Oracle license cost is expensive and
   additional features (such as partitioning
   and high availability) come at added cost
   Solution
   Migrating to Azure Database for
   PostgreSQL removes need for licenses as
   the customer can take advantage of open
   source PostgreSQL
   Azure Database
   for PostgreSQL
   Azure Database
   Migration Services


   View Slide

9. Citus
   extension
   to Postgres


   View Slide

10. What is Citus?
    • Distributed tables
    • Reference tables
    • & more, as of Citus 10
    Extension to Postgres (not a fork!)
    • Add nodes
    • Rebalance
    Simplicity & flexibility of using PostgreSQL, at scale
    • Scale transactional workloads
    • Scale analytical workloads
    • Mixed workloads too
    Multi-purpose:


    View Slide

11. aka.ms/citus


    View Slide

12. Why


    View Slide

13. Citus


    View Slide

14. • Joins
    • Functions
    • Constraints
    • Indexes: B-tree, GIN,
    BRIN, & GiST
    • Partial Indexes
    • Other extensions
    • PostGIS
    • Rich datatypes
    • JSONB
    • Window functions
    • CTEs
    • Atomic update / delete
    • Partitioning
    • Interactive transactions
    • Open source
    • …
    Citus


    View Slide

15. Workloads that benefit
    from PostgreSQL
    CITUS WORKLOADS Workloads that benefit
    from scaling out


    View Slide

16. Multi-tenant
    SaaS
    Time series
    Analytics
    dashboards
    Mixed
    OLTP/OLAP


    View Slide

17. Citus
    Coordinator
    Hyperscale (Citus)
    Coordinator
    Hyperscale (Citus)
    Workers
    Hyperscale (Citus)
    Coordinator
    Standard Tier in Hyperscale (Citus)
    Basic Tier


    View Slide

18. SELECT create_distributed_table(
    'table_name',
    'distribution_column');


    View Slide

19. Citus
    Coordinator
    Choosing the distribution column for Multi-Tenant scenarios
    SELECT create_distributed_table('companies', 'id’);
    SELECT create_distributed_table('campaigns', 'company_id’);
    SELECT create_distributed_table('ads', 'company_id’);
    SELECT create_distributed_table('clicks', 'company_id’);
    SELECT create_distributed_table('impressions', 'company_id');


    View Slide

20. Citus
    Coordinator
    Choosing the distribution column for Real-Time scenarios
    SELECT create_distributed_table('github_users', 'user_id’);
    SELECT create_distributed_table('github_events', 'user_id');


    View Slide

21. Rest of the tables
    can be reference
    tables or local table
    SELECT create_reference_table(
    'table_name')


    View Slide

22. APPLICATION
    CREATE TABLE campaigns (…);
    SELECT create_distributed_table(
    'campaigns','company_id');
    METADATA
    COORDINATOR
    NODE
    WORKER NODES
    W1
    W2
    W3 …
    Wn
    CREATE TABLE
    campaigns_102
    CREATE TABLE
    campaigns_105
    CREATE TABLE
    campaigns_101
    CREATE TABLE
    campaigns_104
    CREATE TABLE
    campaigns_103
    CREATE TABLE
    campaigns_106
    How Citus distributes tables across the database cluster


    View Slide

23. APPLICATION
    SELECT
    FROM
    GROUP BY
    company_id,
    avg(spend) AS avg_campaign_spend
    campaigns
    company_id;
    METADATA
    COORDINATOR
    NODE
    WORKER NODES
    W1
    W2
    W3 …
    Wn
    SELECT company_id
    sum(spend),
    count(spend) …
    FROM
    campaigns_2009 …
    SELECT company_id
    sum(spend),
    count(spend) …
    FROM
    campaigns_2001 …
    SELECT company_id
    sum(spend),
    count(spend) …
    FROM
    campaigns_2017 …
    Query across distribution columns.


    View Slide

24. Transactions routed to a single node
    BEGIN;
    UPDATE
    SET
    WHERE
    COMMIT;
    campaigns
    start_date = '2018-03-17'
    company_id = 'Pat Co';
    METADATA
    W1
    W2
    W3 …
    Wn
    BEGIN; UPDATE
    Campaigns_2012
    SET …;
    COMMIT;
    APPLICATION
    COORDINATOR
    NODE
    WORKER NODES


    View Slide

25. Node A Node B
    Node C
    1 2 4 5
    3 6


    View Slide

26. Node A Node B
    1 2 4 5
    3 6
    Node C
    Node A Node B
    Node C
    1 2 4 5
    3 6


    View Slide

27. Node A Node B
    1 2
    3 4


    View Slide

28. 1
    4
    3
    2
    Node A Node B


    View Slide

29. 10M+ queries per day;
    75%
    https://techcommunity.microsoft.com/t5/Azure-Database-for-
    PostgreSQL/Architecting-petabyte-scale-analytics-by-scaling-out-Postgres-on/ba-
    p/969685


    View Slide

30. Min Wei, Principal Engineer at Microsoft
    Distributed PostgreSQL
    is a game changer."
    aka.ms/blog-petabyte-scale-analytics


    View Slide

31. Storage efficiency
    IOPs
    Query speed
    Cost Savings
    Benefits
    of
    Citus
    Columnar


    View Slide

32. Row-based Storage Columnar storage


    View Slide

33. CREATE TABLE events_columnar(
    ts timestamptz, i int,
    n numeric, s text) USING columnar;
    It’s as simple as “USING columnar;”


    View Slide

34. Can change access method from heap à columnar
    SELECT alter_table_set_access_method(
    'events_2021_jan', 'columnar');


    View Slide

35. Citus Columnar && Range Partitioning in Postgres
    CREATE TABLE events(
    ts timestamptz, i int,
    n numeric, s text)
    PARTITION BY RANGE (ts);
    CREATE TABLE events_2021_jan PARTITION OF events
    FOR VALUES FROM ('2021-01-01') TO ('2021-02-01');
    CREATE TABLE events_2021_feb PARTITION OF events
    FOR VALUES FROM ('2021-02-01') TO ('2021-03-01');


    View Slide

36. events table
    …


    View Slide

37. events table
    …


    View Slide

38. events table


    View Slide

39. View Slide

40. Multi-tenant
    (SaaS)
    tutorial
    aka.ms/hyperscale-citus-multi-tenant-tutorial


    View Slide

41. Tutorial:
    Real-time
    analytics
    dashboard
    aka.ms/hyperscale-citus-real-time-tutorial


    View Slide

42. © Copyright Microsoft Corporation. All rights reserved.
    Leandro Santana
    linkedin.com/in/leandroeredia/
    @citusdata
    @AzureDBPostgres
    Thank you!


    View Slide
