Kubernetes Networking

Intro to Kubernetes Networking at the Seattle Kubernetes Meetup, December 2, 2015.

Transcript

1. Kubernetes Networking Seattle Kubernetes Meetup CJ Cullen <cjcullen@google.com> Software Engineer @cj_cullen github.com/cjcullen
2. Docker Networking
3. Docker networking docker start ...
4. Docker networking docker start ...
5. Docker networking docker0 172.16.1.0/24
6. Docker networking docker0 172.16.1.0/24 docker run ...
7. Docker networking docker0 172.16.1.0/24
8. Docker networking docker0 172.16.1.0/24 172.16.1.1 vethAQ2IT eth0
9. Docker networking docker0 172.16.1.0/24 172.16.1.1 vethAQ2IT eth0 docker run ...
10. Docker networking docker0 172.16.1.0/24 172.16.1.1 vethAQ2IT eth0 172.16.1.2 vethS1LUI eth0
11. 172.16.1.1 172.16.1.2 Docker networking 172.16.1.1 172.16.1.1
12. 172.16.1.1 172.16.1.2 Docker networking 172.16.1.1 172.16.1.1 NAT NAT NAT NAT NAT
13. Host ports A: 172.16.1.1 3306 B: 172.16.1.2 80 9376 11878 SNAT SNAT C: 172.16.1.1 8000
14. Host ports A: 172.16.1.1 3306 B: 172.16.1.2 80 9376 11878 SNAT SNAT C: 172.16.1.1 8000 REJECTED
15. Kubernetes Networking
16. Kubernetes networking IPs are routable • vs docker default private IP Pods can reach each other without NAT • even across nodes No brokering of port numbers • too complex, why bother? This is a fundamental requirement • can be L3 routed • can be underlayed (cloud) • can be overlayed (SDN)
17. 10.1.1.0/24 10.1.1.1 10.1.1.2 Kubernetes networking 10.1.2.0/24 10.1.2.1 10.1.3.0/24 10.1.3.1
18. 10.1.1.0/24 10.1.1.1 10.1.1.2 Kubernetes networking 10.1.2.0/24 10.1.2.1 10.1.3.0/24 10.1.3.1 ?
19. Kubernetes networking On GCE/GKE • GCE Advanced Routes (program the fabric) • “Everything to 10.1.1.0/24, send to this VM” Plenty of other ways • AWS: Route Tables • Weave • Calico • Flannel • OVS • OpenContrail • Cisco Contiv • Others...
20. Kubernetes networking On GCE/GKE • GCE Advanced Routes (program the fabric) • “Everything to 10.1.1.0/24, send to this VM” Plenty of other ways • AWS: Route Tables • Weave • Calico • Flannel • OVS • OpenContrail • Cisco Contiv • Others...
21. Kubernetes networking On GCE/GKE • GCE Advanced Routes (program the fabric) • “Everything to 10.1.1.0/24, send to this VM” Plenty of other ways • AWS: Route Tables • Weave • Calico • Flannel • OVS • OpenContrail • Cisco Contiv • Others...
22. Pods
23. Pods Small group of containers & volumes Tightly coupled The atom of scheduling & placement Shared namespace • share IP address & localhost • share IPC, etc. Managed lifecycle • bound to a node, restart in place • can die, cannot be reborn with same ID Example: data puller & web server Consumers Content Manager File Puller Web Server Volume Pod
24. Pods Small group of containers & volumes Tightly coupled The atom of scheduling & placement Shared namespace • share IP address & localhost • share IPC, etc. Managed lifecycle • bound to a node, restart in place • can die, cannot be reborn with same ID Example: data puller & web server 10.1.1.2
25. Pods Small group of containers & volumes Tightly coupled The atom of scheduling & placement Shared namespace • share IP address & localhost • share IPC, etc. Managed lifecycle • bound to a node, restart in place • can die, cannot be reborn with same ID Example: data puller & web server c1 --net=container:infra --ipc=container:infra infra 10.1.1.2 c2 --net=container:infra --ipc=container:infra
26. Services
27. Services A group of pods that work together • grouped by a selector Defines access policy • “load balanced” or “headless” Gets a stable virtual IP and port • sometimes called the service portal • also a DNS name VIP is managed by kube-proxy • watches all services • updates iptables when backends change Hides complexity - ideal for non-native apps Client Virtual IP
28. kube-proxy
29. kube-proxy (legacy) iptables kube-proxy apiserver Node X
30. iptables apiserver Node X watch services & endpoints kube-proxy (legacy) kube-proxy
31. iptables apiserver Node X kubectl run ... watch kube-proxy (legacy) kube-proxy
32. iptables apiserver Node X schedule watch kube-proxy (legacy) kube-proxy
33. iptables apiserver Node X watch kubectl expose ... kube-proxy (legacy) kube-proxy
34. iptables apiserver Node X new service! update kube-proxy (legacy) kube-proxy
35. iptables apiserver Node X watch kube-proxy (legacy) kube-proxy listen
36. iptables apiserver Node X watch kube-proxy (legacy) kube-proxy listen
37. iptables apiserver Node X watch configure kube-proxy (legacy) kube-proxy
38. iptables apiserver Node X watch VIP kube-proxy (legacy) kube-proxy
39. iptables apiserver Node X new endpoints! update VIP kube-proxy (legacy) kube-proxy
40. iptables apiserver Node X VIP watch kube-proxy (legacy) kube-proxy
41. iptables apiserver Node X VIP watch kube-proxy (legacy) kube-proxy Client
42. iptables apiserver Node X VIP watch kube-proxy (legacy) kube-proxy Client
43. iptables apiserver Node X VIP watch kube-proxy (legacy) kube-proxy Client
44. iptables apiserver Node X VIP watch kube-proxy (legacy) kube-proxy Client
45. kube-proxy (legacy) Userspace proxy isn’t ideal Burns CPU copying bytes • “Proxy” is just parallel copy loops. Loses source IP • Everything looks like it’s from the node IP. Userspace TCP listening = higher latency
46. iptables kube-proxy
47. iptables kube-proxy iptables kube-proxy apiserver Node X
48. iptables kube-proxy iptables kube-proxy apiserver Node X watch services & endpoints
49. iptables kube-proxy iptables kube-proxy apiserver Node X kubectl run ... watch
50. iptables kube-proxy iptables kube-proxy apiserver Node X schedule watch
51. iptables kube-proxy iptables kube-proxy apiserver Node X watch kubectl expose ...
52. iptables kube-proxy iptables kube-proxy apiserver Node X new service! update
53. iptables kube-proxy iptables kube-proxy apiserver Node X watch configure
54. iptables kube-proxy iptables kube-proxy apiserver Node X watch VIP
55. iptables kube-proxy iptables kube-proxy apiserver Node X new endpoints! update VIP
56. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch configure
57. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch
58. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch Client
59. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch Client
60. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch Client
61. iptables kube-proxy iptables kube-proxy apiserver Node X VIP watch Client
62. iptables kube-proxy Mean Latency contrib/for-tests/netperf-tester --number=1000 Mean Latency Microseconds iptables kube-proxy legacy kube-proxy
63. Services are just an abstraction • Only requirement: route (and maybe load balance) a virtual IP to a set of backends. Kube-proxy is an implementation • Kube-proxy watches apiserver. • iptables is re-configured on changes. There could be other ways • Userspace, iptables, IP Virtual Servers? Services
64. DNS Run SkyDNS as a pod in the cluster • kube2sky bridges Kubernetes API -> SkyDNS • Tell kubelets about it (static service IP) Strictly optional, but practically required • LOTS of things depend on it • Probably will become more integrated Or plug in your own! kubernetes kubernetes.default kubernetes.default.svc.cluster.local foo.my-namespace.svc.cluster.local
65. DNS Run SkyDNS as a pod in the cluster • kube2sky bridges Kubernetes API -> SkyDNS • Tell kubelets about it (static service IP) Strictly optional, but practically required • LOTS of things depend on it • Probably will become more integrated Or plug in your own! apiserver watch etcd kube-dns-qxin kube2sky skyDNS
66. DNS Run SkyDNS as a pod in the cluster • kube2sky bridges Kubernetes API -> SkyDNS • Tell kubelets about it (static service IP) Strictly optional, but practically required • LOTS of things depend on it • Probably will become more integrated Or plug in your own! nameserver 10.0.0.10 ... /etc/resolv.conf apiserver watch etcd kube-dns-qxin kube2sky skyDNS
67. DNS Run SkyDNS as a pod in the cluster • kube2sky bridges Kubernetes API -> SkyDNS • Tell kubelets about it (static service IP) Strictly optional, but practically required • LOTS of things depend on it • Probably will become more integrated Or plug in your own! nameserver 10.0.0.10 ... /etc/resolv.conf apiserver watch etcd kube-dns-qxin kube2sky skyDNS 10.0.0.10
68. Putting it Together What happens when I... $ curl foo.my-namespace Client
69. What happens when I... $ curl foo.my-namespace Putting it Together nameserver 10.0.0.10 ... /etc/resolv.conf Client 10.1.0.1
70. 10.1.0.1 Putting it Together What happens when I... $ curl foo.my-namespace etcd kube-dns-qxin kube2sky skyDNS 10.0.0.10 foo.my-namespace? Client
71. Putting it Together What happens when I... $ curl foo.my-namespace etcd kube-dns-qxin kube2sky skyDNS 10.0.0.10 10.0.123.45 Client 10.1.0.1
72. Putting it Together What happens when I... $ curl foo.my-namespace 10.0.123.45 Client 10.1.0.1
73. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 10.1.0.1
74. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.0.1
75. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3
76. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.3.1 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3
77. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.3.1 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 10.1.3.0/24 -> Node X
78. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.3.1 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3
79. Putting it Together What happens when I... $ curl foo.my-namespace Client VIP 10.0.123.45 iptables 10.1.3.1 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 Hello World!
80. Putting it Together What happens when I... $ curl foo.my-namespace Client iptables Hello World! 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 10.1.0.1
81. Putting it Together What happens when I... $ curl foo.my-namespace Client iptables Hello World! 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 10.1.0.0/24 -> Node Y 10.1.0.1
82. Putting it Together What happens when I... $ curl foo.my-namespace Client iptables Hello World! 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 10.1.0.0/24 -> Node Y 10.1.0.1
83. Putting it Together What happens when I... $ curl foo.my-namespace Hello World! Client iptables Hello World! 10.1.0.1 10.1.0.6 10.1.3.1 10.1.6.3 10.1.0.0/24 -> Node Y 10.1.0.1
84. What about external?
85. External Services Services IPs are only available inside the cluster Need to receive traffic from “the outside world” Builtin: Service “type” • nodePort: expose on a port on every node • loadBalancer: provision a cloud load-balancer DiY load-balancer solutions • socat (for nodePort remapping) • haproxy • nginx
86. The Bleeding Edge
87. Ingress (L7) Services are assumed L3/L4 Lots of apps want HTTP/HTTPS Ingress maps incoming traffic to backend services • by HTTP host headers • by HTTP URL paths HAProxy and GCE implementations No SSL yet Status: BETA in Kubernetes v1.1 URL Map Client
88. Ingress (L7) Services are assumed L3/L4 Lots of apps want HTTP/HTTPS Ingress maps incoming traffic to backend services • by HTTP host headers • by HTTP URL paths HAProxy and GCE implementations No SSL yet Status: BETA in Kubernetes v1.1 URL Map Client api.company.com api.company.com/foo api.company.com/bar othercompany.com/*
89. Network Plugins
90. Network Plugins Introduced in Kubernetes v1.0 • VERY experimental Uses CNI (CoreOS) in v1.1 • Simple exec interface • Not using Docker libnetwork • but can defer to Docker for networking Cluster admins can customize their installs • DHCP, MACVLAN, Flannel, custom net Plugin Plugin Plugin
91. Kubernetes is Open - open community - open design - open source - open to ideas Networking is Hard - help guide us! http://kubernetes.io https://github.com/kubernetes/kubernetes slack: kubernetes twitter: @kubernetesio
