Probabilistic Data Structures in Redis Srinivasan Rangarajan @cnu
Srinivasan Rangarajan •
[email protected]
• @cnu • https://cnu.name
Log Analysis
User Events Kinesis Firehose ELK
Sample Event Data { "ip": "123.123.123.123", "client_id": 232, "user_id": "35827",
"email": "
[email protected]
", "product_id": "ABC-12345", "image_id": 3, "action": "pageview", "datetime": "2017-06-29T12:42:53Z", }
Challenges • 100s of Millions of events processed every day
• Peak of ~10 Million events in an hour • Needed Real Time processing • Low memory/storage requirements
None
User Events Kinesis Firehose ELK AWS Lambda Redis
Cost Accuracy Scale
Probabilistic Data Structures
xkcd/1132
Loading Modules • ./redis-server --loadmodule /path/to/module.so • redis.conf loadmodule /path/to/module.so
• MODULE LOAD /path/to/module.so
Execute custom commands >>> import redis >>> r = redis.Redis()
>>> out = r.execute_command('CMD param1 param2')
Data Structures • HyperLogLog • TopK • CountMinSketch • Bloom
Filters
HyperLogLog Count the Cardinality of a Set
Count Unique Visitors/hour >>> r.pfadd('users:2017083120', 123, 456, 789) 1 >>>
r.pfcount('users:2017083120') 3 >>> r.pfadd('users:2017083120', 456) 0
Merge Hourly into Daily >>> r.pfadd('users:2017083121', 121, 454, 787) 1
>>> r.pfmerge('users:20170831', 'users:2017083120', 'users:2017083121') True >>> r.pfcount('users:20170831’) 6
Links • https://redis.io/commands#hyperloglog • http://antirez.com/news/75
TopK Get top K elements in a set
Top K IP Addresses >>> r.execute_command('TOPK.ADD ip:20170831 3 123.45.67.89') >>>
r.execute_command('TOPK.ADD ip:20170831 3 123.45.67.90') >>> r.execute_command('TOPK.ADD ip:20170831 3 123.45.67.91') 1L >>> r.execute_command('TOPK.ADD ip:20170831 3 123.45.67.92') -1L
Top K IP Addresses >>> r.zrange('ip:20170831’, 0, -1, withscores=True) [('TOPK:1.0.1:1.0:\xff\xff\xff\xff\xff\xff\xff\xff\x04\x00\x0
0\x00\x00\x00\x00\x00', 1.0), ('123.45.67.89', 1.0), ('123.45.67.90', 1.0), ('123.45.67.92', 2.0)]
Links • https://github.com/RedisLabsModules/topk
CountMinSketch Count the frequency of items
1 2 3 4 h1 0 0 0 0 h2
0 0 0 0 h3 0 0 0 0
1 2 3 4 h1 1 0 0 0 h2
0 1 0 0 h3 0 0 1 0 h1(s1) = 1; h2(s1) = 2; h3(s1) = 3
1 2 3 4 h1 1 0 0 1 h2
0 1 0 1 h3 0 0 1 1 h1(s2) = 4; h2(s2) = 4; h3(s2) = 4
1 2 3 4 h1 2 1 1 1 h2
0 1 0 1 h3 0 0 1 1 h1(s3) = 1; h2(s3) = 1; h3(s3) = 1
User Pageview counter >>> r.execute_command('CMS.INCRBY u:pv:20170831 123 1 456 3
789 2 234 1 567 1') 'OK' >>> r.execute_command('CMS.QUERY u:pv:20170831 123 456 789 234 567') [1L, 3L, 2L, 1L, 1L]
Merge Counters >>> r.execute_command('CMS.MERGE u:pv:201708 3 u:pv:20170829 u:pv:20170830 u:pv:20170831') 'OK'
Links • https://github.com/RedisLabsModules/countminsketch • https://redislabs.com/blog/count-min-sketch-the-art-and-science- of-estimating-stuff/
Bloom Filters Test Membership in a Set
0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 Empty Bit Array
0 0 1 0 0 1 0 0 1 0
0 0 0 0 0 0 h1(item1) = 2; h2(item1) = 5; h3(item1) = 8 Insert Item 1
0 0 1 0 0 1 0 1 1 0
1 0 0 0 0 0 h1(item2) = 7; h2(item2) = 8; h3(item2) = 10 Insert Item 2
0 0 1 0 0 1 0 1 1 0
1 0 0 0 0 0 h1(item3) = 2; h2(item3) = 11; h3(item3) = 0 Check Item3
0 0 1 0 0 1 0 1 1 0
1 0 0 0 0 0 h1(item4) = 10; h2(item4) = 8; h3(item4) = 7 Check Item4
Bloom Filter returns What it means False Definitely not in
the set True Maybe in the set
Check User Session >>> r.execute_command('BF.MADD u:sess:20170831 123 456 789') [1L,
1L, 1L] >>> r.execute_command('BF.EXISTS u:sess:20170831 456') 1L >>> r.execute_command('BF.EXISTS u:sess:20170831 234') 0L
Links • https://github.com/RedisLabsModules/rebloom • https://redislabs.com/blog/rebloom-bloom-filter-datatype-redis/ • https://github.com/kristoff-it/redis-cuckoofilter - Better than
bloom filters
“An 80% solution today is much better than an 100%
solution tomorrow.”
Thank You https://cnu.name/talks/redisconf-2018/
