CMM-Manager - Machine Setup, Probe Assembly, Tip Calibration

CMM-Manager tutorial for Machine Setup, Probe Assembly &Tip Calibration. After completing this tutorial your machine is ready to perform measurements.

B2f304acaf00b8a625a02374dff2bdf5?s=128

CrashN8

January 07, 2020
Tweet

Transcript

  1. CMM-Manager Tutorial Machine Setup, Probe Assembly, Tip Calibration

  2. Machine Setup  From Ribbon Tab  System>Machine Setup

  3. Machine Setup  Controller Tab  See install guide for

    details  Unique to each machine  Connect before continuing… Password is ‘service’
  4. Machine Setup  Probe Tab  Probe Head  Rotate

    Before Homing (optional / DCC only)
  5. Machine Setup  Machine Tab  Working Volume – move

    machine to limits  Ram (z axis) Size
  6. Probe Assembly  From Ribbon Tab  Probe>Probe Assembly

  7. Probe Assembly  Extensions & Touch Probes  Select Model(s)

     Press [<-] button to add  Press Up / Down to re-order  Update Assembly to save
  8. Probe Assembly  Stylus  Choose 3P, 6P or Star

     Press [Edit Stylus]  Enter dimensions for stylus  Press [OK]  Update Assembly to save
  9. Setup Calibration Sphere  From Ribbon Tab  Probe>Setup Cal.

    Sphere
  10. Setup Calibration Sphere  Cal Sphere Model  Press [Edit]

     Cal Sphere Editor  Enter Dimensions  Enter Vector Direction  Press [OK]
  11. Tip Manager  From Ribbon Tab  Probe>Tip Manager

  12. Tip Manager  New Tip

  13. Tip Manager  New Tip  Choose A & B

    Angle  Press [OK]
  14. Tip Manager  New Tip  Choose A & B

    Angle  Press [OK]  New Set…
  15. Tip Manager  New Tip  Choose A & B

    Angle  Press [OK]  New Set…  Choose A & B Interval  Press [OK]
  16. Tip Manager  New Tip  Choose A & B

    Angle  Press [OK]  New Set…  Choose A & B Interval  Press [OK]  Calibrate RefTip first  Calibrate  Calibrate All
  17. Tip Manager  New Tip  Choose A & B

    Angle  Press [OK]  New Set…  Choose A & B Interval  Press [OK]  Calibrate RefTip first  Calibrate  Calibrate All  Select  Highlight tip angle from list  Press [Select] to perform tip change
  18. Update Table Position  From Ribbon Tab  System>Machine Properties

  19. Update Table Position  Machine Property  Choose Table category

     Press [Update Table Position]  Move Probe Tip near CMM Table  Press [OK]
  20. Ready to Measure
