CMM-Manager Tutorial Alignments – Canned, Level, Align, Set Origin, Free
Position & CAD
Canned Alignments From Ribbon Tab Alignment>Canned 3-2-1
Plane-Circle-Circle Etc…
Canned Alignments 3-2-1 Measure Top, Front, Side
Set Axes direction Press [OK]
Canned Alignments Plane-Circle-Circle Measure Top & 2 Circles
Set Axes direction Press [OK]
Traditional Alignments From Ribbon Tab Alignment>Traditional Level,
Align, Set Origin Offset Align Translate / Rotate
Traditional Alignments Level Choose measured Plane, Cylinder, Cone,
etc. Set Axes direction Press [OK]
Traditional Alignments Align Choose measured Line, Cylinder, Circle,
etc. Set Working Plane & Axes direction Press [OK]
Traditional Alignments Set Origin Choose measured Point, Circle,
etc. Set Axis Options Press [OK]
Traditional Alignments Offset Align Choose measured Point, Circle,
etc. Set Working Plane & Offsets Press [OK]
Traditional Alignments Translate / Rotate Set Translation Value(s)
Set Rotation Axis & Angle Press [OK]
Advanced Alignments From Ribbon Tab Alignment>Advanced CAD
Free Position RPS
Advanced Alignments CAD Alignment Pick minimum 6 points
from 3D CAD Measure Points in approximate location as picked Press [OK] to accept results 1 2
Advanced Alignments Free Position Move CMM Probe to
location near part i.e. – corner or center of small hole Press [OK]
Advanced Alignments RPS (Relative Point System) Select Datum
Targets and Datum Features Apply Locks and Offsets to each Datum Feature Press [OK]
Ready to Measure
