  1. Docker Meetup Tokyo #27
    2019.1.16
    © 2019 cyberblack28
    RANCHER’S
    NEW MLUTI-TENANT
    PROMETHEUS SUPPORT

    View Slide

  2. Profile
    Twitter:cyberblack28
    Hatena Blog:https://cyberblack28.hatenablog.com/
    Job
    Educational Solution Architect
    Developer Advocate/Technical Evangelist
    Infrastructure Engineer
    Frontend Engineer
    Community
    Music,Live,FES !! Take a picture !!
    https://www.flickr.com/photos/cyberblack
    ISBN-10: 4798155373
    ISBN-13: 978-4798155371
    I wrote the Chapter 6 Rancher 2.0 part.
    Release on March 15, 2018
    !
    #rancherjp
    #kujiraya
    #deepcn

    View Slide

  3. AP Communications Co., Ltd

    View Slide

  4. KubeCon + CloudNativeCon NA 2018 Recap
    http://ur0.link/PkTG
    Vitess
    MySQL Operator
    http://ur0.link/PkUm

    View Slide

  5. 1. What’s Rancher
    2. Rancher’s New Multi-Tenant Prometheus
    Support
    Agenda

    View Slide

  6. WHAT’S RANCHER

    View Slide

  7. Feature of Rancher2.1
    Kubernetes
    Clusters
    Create
    Import




    Bare Metal
    Create,Import,Manage Kubernetes Clusters !!
    Manage

    View Slide

  8. Feature of Rancher2.1
    One Click Deployment ! !
    #-$,(%!

    !
    Creating Private Catalogs ! !
    )"'& +*

    View Slide

  9. Feature of Rancher2.1
    Major developer catalogs

    View Slide

  10. Rancher v2.1.0
    • Rancher1$
    Cattle OrchestratorRancher2$
    Kubernetes

    • Windows Kubernetes
    #
    Rancher 2.1 !Windows Node Kubernetes "http://ur0.link/PjA3
    Main outline
    • Latest - v2.1.5 - rancher/rancher:latest
    • Stable - v2.1.5 - rancher/rancher:stable
    Version
    Rancher Release - v2.1.0
    http://urx3.nu/MJA0
    Details

    View Slide

  11. RANCHER’S NEW MULTI-
    TENANT PROMETHEUS
    SUPPORT

    View Slide

  12. Rancher’s New Multi-Tenant Prometheus Support

    PrometheusGrafana
    Deploy from Catalog function

    View Slide

  13. Rancher’s New Multi-Tenant Prometheus Support
    http://ur0.link/PjFf
    Rancher Official Blog

    View Slide

  14. Rancher’s New Multi-Tenant Prometheus Support
    Rancher 2.2 simplifies and cuts this process down to just 2 steps

    View Slide

  15. Rancher’s New Multi-Tenant Prometheus Support
    Rancher Official Blog
    http://ur0.link/PjHe

    View Slide

  16. 1.Rancher Server
    Rancher’s New Multi-Tenant Prometheus Support
    2.Single Kubernetes Cluster
    3.Kubernetes

    4.Prometheus
    Verification Environment

    View Slide

  17. 1.Rancher Server
    1.Instance
    2.Docker
    $ curl https://releases.rancher.com/install-docker/17.03.2.sh | sh
    3.Rancher v2.2.0-Alpha3 Server
    $ sudo docker run -d --restart=unless-stopped -p 80:80 -p 443:443 rancher/rancher:v2.2.0-alpha3
    Rancher’s New Multi-Tenant Prometheus Support


    -+ rancher-server
    %#' asia-northeast1(,
    ' asia-northeast1-b
    "'! vCPUx1
    Ubuntu 16.04 LTS
    80GB
    & HTTP$0/ HTTPS$0/ .*)

    View Slide

  18. 4.RancherUI
    https://EXTERNAL-IP/
    5.

    Rancher’s New Multi-Tenant Prometheus Support

    View Slide

  19. 2.Single Kubernetes Cluster
    Rancher’s New Multi-Tenant Prometheus Support
    2.rancher-k8s-clusterDocker
    $ curl https://releases.rancher.com/install-docker/17.03.2.sh | sh
    1.Instance


    -+ rancher-host
    %#' asia-northeast1(,
    ' asia-northeast1-b
    "'! vCPUx1
    Ubuntu 16.04 LTS
    80GB
    & HTTP$0/ HTTPS$0/ .*)

    View Slide

  20. 1.Add Cluster

    Rancher’s New Multi-Tenant Prometheus Support
    3.Kubernetes

    View Slide

  21. Rancher’s New Multi-Tenant Prometheus Support
    2.CustomCluster Name
    Next
    1
    2
    3

    View Slide

  22. Rancher’s New Multi-Tenant Prometheus Support
    3.Node RoleetcdControl Plane Copy to Clipboard

    1
    2

    View Slide

  23. Rancher’s New Multi-Tenant Prometheus Support
    4. rancher-k8s-cluster

    $ sudo docker run -d --privileged --restart=unless-stopped --net=host -v /etc/kubernetes:/etc/kubernetes -v /var/run:/var/run
    rancher/rancher-agent:v2.2.0-alpha3 --server https://35.243.83.224 --token
    xx9ttl6ckrkzppk6msvx7jzslcc75m8m7pwbws7fjvbdls2g9l6nrn --ca-checksum
    487497cfc43e87a717ca8c775c2b0e19677bf0a73b5091ee1572b8546defec75 --etcd --controlplane --worker
    5.Done

    View Slide

  24. Rancher’s New Multi-Tenant Prometheus Support
    6.rancher-k8s-cluster

    View Slide

  25. Rancher’s New Multi-Tenant Prometheus Support
    1. Tools-Monitoring
    4.Prometheus

    View Slide

  26. Rancher’s New Multi-Tenant Prometheus Support
    2.Prometheus
    Save

    1
    2

    View Slide

  27. Rancher’s New Multi-Tenant Prometheus Support
    3. Prometheus + Grafana

    View Slide

  28. Rancher’s New Multi-Tenant Prometheus Support
    4.





    View Slide

  29. Rancher’s New Multi-Tenant Prometheus Support
    5.Grafana
    Grafana

    View Slide

  30. Rancher’s New Multi-Tenant Prometheus Support
    Nodes Cluster
    6.Launch kubectl

    View Slide

  31. Rancher’s New Multi-Tenant Prometheus Support
    7.kubectl get pods --all-namespaces

    # Run kubectl commands inside here
    # e.g. kubectl get all
    > kubectl get pods --all-namespaces
    NAMESPACE NAME READY STATUS RESTARTS AGE
    cattle-prometheus exporter-kube-state-cluster-monitoring-779b96cf75-gg272 1/1 Running 0 20m
    cattle-prometheus exporter-node-cluster-monitoring-ljhch 1/1 Running 0 20m
    cattle-prometheus grafana-cluster-monitoring-5b4bc74756-hx7mx 3/3 Running 0 20m
    cattle-prometheus prometheus-cluster-monitoring-0 4/4 Running 1 20m
    cattle-prometheus prometheus-cluster-monitoring-nginx-5ff785dd4d-d6l8l 1/1 Running 3 20m
    cattle-prometheus prometheus-operator-system-monitor-77df6db6df-gdmmz 1/1 Running 0 20m
    cattle-system cattle-cluster-agent-77498f79c-5w78s 1/1 Running 0 30m
    cattle-system cattle-node-agent-s8gnz 1/1 Running 0 30m
    ingress-nginx default-http-backend-5bdd9fdd69-2ntmw 1/1 Running 0 30m
    ingress-nginx nginx-ingress-controller-xdwnk 1/1 Running 0 30m
    kube-system canal-wzw4r 3/3 Running 0 30m
    kube-system kube-dns-autoscaler-689f6f9756-zqn6f 1/1 Running 0 30m
    kube-system kube-dns-ddddcfcc8-xbpwn 3/3 Running 0 30m
    kube-system metrics-server-5444cf6dfc-g7xvp 1/1 Running 0 30m
    kube-system rke-ingress-controller-deploy-job-bshtx 0/1 Completed 0 30m
    kube-system rke-kubedns-addon-deploy-job-k9vxg 0/1 Completed 0 30m
    kube-system rke-metrics-addon-deploy-job-hmr7k 0/1 Completed 0 30m
    kube-system rke-network-plugin-deploy-job-tjqhn 0/1 Completed 0 31m

    View Slide

  32. Rancher’s New Multi-Tenant Prometheus Support
    http://ur0.link/PjJn
    • December 2018 Online Meetup Introducing
    Rancher's New Multi Tenant Prometheus
    Support
    Webinar
    • Rancher v2.2.0-Alpha3 Multi-Tenant Prometheus Support
    Docs
    http://ur0.link/PjK6

    View Slide

  33. ! !
