  1. Replace API to Firebase Database - The view from client

    side Daiki Matsudate / @d_date 2017/11/03 / Serverlessconf Tokyo 2017
  2. Daiki Matsudate iOS Mobile App Engineer @d_date

  3. Tokyo 2018/3/1 - 3

  4. Firebase

  5. Firebase

  6. Cloud Messaging

  7. None
  8. None
  9. 31 Oct. at Amsterdam #FirebaseSummit

  10. • Prediction • A/B Testing • Integrate Crashlytics into Firebase

    #FirebaseSummit
  11. #FirebaseSummit

  12. Agenda • Firebase Realtime Database • Feature • Introduce to

    Mobile App • Architecture • Testing • ???
  13. Firebase Database

  14. • NoSQL cloud database • Realtime Data Sync with JSON

    Tree • Available data on offline Firebase Database
  15. Firebase Database

  16. Replace API to Realtime Database Case Study

  17. Replace API to Realtime Database API Client (Native App) Server

  18. Client (Native App) Server Firebase Database Replace API to Realtime

    Database
  19. Replace API to Realtime Database • use func observeSingleEvent(:_) in

    FirebaseDatabase
  20. Replace API to Realtime Database • Reduce building API man-hours

    • No more performance tunings • Easy to handle data in offline Purpose
  21. Client (Native App) Server Firebase Database Replace API to Realtime

    Database
  22. Client (Native App) Firebase Database Replace API to Realtime Database

  23. NoSQL

  24. NoSQL = Denormalization

  25. Denormalization in NoSQL { "users": { "user1": { "name": "Alice"

    }, "user2": { "name": "Bob" } }, "links": { "link1": { "title": "Example", "href": "http://example.org", "submitted": "user1" } }, "comments": { "comment1": { "link": "link1", "body": "This is awesome!", "author": "user2" } } }
  26. Denormalization in NoSQL { "users": { "user1": { "name": "Alice"

    }, "user2": { "name": "Bob" } }, "links": { "link1": { "title": "Example", "href": "http://example.org", "submitted": "user1" } }, "comments": { "comment1": { "link": "link1", "body": "This is awesome!", "author": "user2" } } }
  27. Denormalization in NoSQL { "users": { "user1": { "name": "Alice"

    }, "user2": { "name": "Bob" } }, "links": { "link1": { "title": "Example", "href": "http://example.org", "submitted": "user1" } }, "comments": { "comment1": { "link": "link1", "body": "This is awesome!", "author": "user2" } } } Join data in client
  28. None
  29. JOIN data in client in Swift self.ref.child("comments").observeSingleEvent(of: .value, with: {

    [weak self] (snapshot) in guard let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) })
  30. Not Swifty!! self.ref.child("comments").observeSingleEvent(of: .value, with: { [weak self] (snapshot) in

    guard let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) }) “Stringly“ typed Pyramid of Death
  31. Easy to replace from API? self.ref.child("comments").observeSingleEvent(of: .value, with: { [weak

    self] (snapshot) in guard let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) }) Need reference of database
  32. None
  33. To make friend with NoSQL in Swift

  34. To make friend with NoSQL in Swift • Re-Design Architecture

    • Introduce Reactive Programming
  35. Re-Design Architecture

  36. None
  37. None
  38. None
  39. None
  40. None
  41. !Architecture → Ideal State "Ideal State → Architecture

  42. Ideal State • Data from Firebase ≠ Data in app

    -> Need translation • Easy to replace from API to Firebase -> I/F is same as API, then want to replace DAO
  43. Replaceable Data Access Object Entity Data Access to API Data

    Access Interface (Repository) Server
  44. Replaceable Data Access Object Entity Data Access to Firebase Data

    Access Interface (Repository)
  45. Translation Entity Data Access Interface Data Access to Firebase Interactor

    Model View
  46. Requirement for Architecture Entity Data Access Interface Data Access to

    Firebase Interactor Model View
  47. What is this architecture? Entity Data Access Interface Data Access

    to Firebase Interactor Model Presenter View
  48. None
  49. How to resolve Pyramid of Death self.ref.child("comments").observeSingleEvent(of: .value, with: {

    [weak self] (snapshot) in guard let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) }) Pyramid of Death
  50. None
  51. How to resolve Pyramid of Death self.ref.child("comments").observeSingleEvent(of: .value, with: {

    [weak self] (snapshot) in guard let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) })
  52. protocol Entity: Codable {} struct UserEntity: Entity { let name:

    String } struct LinkEntity: Entity { let title: String let href: URL let submitted: String } struct CommentEntity: Entity { let link: String let body: String let author: String } Entity Entity Data Access Data Access Interactor Model Presenter View
  53. Data Access + RxSwift extension DatabaseReference { func get<T: Entity>()

    -> Single<T> { return Single.create(subscribe: { (observer) in self.observeSingleEvent(of: .value, with: { (snapshot) in guard let jsonObject = snapshot.value else { observer(.error(ProviderError.valueNotExist)) return } do { let data = try JSONSerialization.data(withJSONObject: jsonObject) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch(let error) { observer(.error(error)) } }) return Disposables.create() }) } }
  54. Data Access + RxSwift extension DatabaseReference { func get<T: Entity>()

    -> Single<T> { return Single.create(subscribe: { (observer) in self.observeSingleEvent(of: .value, with: { (snapshot) in guard let jsonObject = snapshot.value else { observer(.error(ProviderError.valueNotExist)) return } do { let data = try JSONSerialization.data(withJSONObject: jsonObject) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch(let error) { observer(.error(error)) } }) return Disposables.create() }) } } If value not exist, invoke error
  55. Data Access + RxSwift extension DatabaseReference { func get<T: Entity>()

    -> Single<T> { return Single.create(subscribe: { (observer) in self.observeSingleEvent(of: .value, with: { (snapshot) in guard let jsonObject = snapshot.value else { observer(.error(ProviderError.valueNotExist)) return } do { let data = try JSONSerialization.data(withJSONObject: jsonObject) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch(let error) { observer(.error(error)) } }) return Disposables.create() }) } } If fail to serialize JSON, invoke error
  56. Data Provider class DataProvider { static let shared = DataProvider()

    private init() {} lazy var ref: DatabaseReference = { return Database.database().reference() }() func getUser(key: String) -> Single<UserEntity> { return ref.child("users").child(key).get() } func getLink(key: String) -> Single<LinkEntity> { return ref.child("links").child(key).get() } func getComments() -> Single<CommentEntity> { return ref.child("comments").get() } }
  57. Data Provider class DataProvider { static let shared = DataProvider()

    private init() {} lazy var ref: DatabaseReference = { return Database.database().reference() }() func getUser(key: String) -> Single<UserEntity> { return ref.child("users").child(key).get() } func getLink(key: String) -> Single<LinkEntity> { return ref.child("links").child(key).get() } func getComments() -> Single<CommentEntity> { return ref.child("comments").get() } } Singleton in Swift
  58. Data Provider class DataProvider { static let shared = DataProvider()

    private init() {} lazy var ref: DatabaseReference = { return Database.database().reference() }() func getUser(key: String) -> Single<UserEntity> { return ref.child("users").child(key).get() } func getLink(key: String) -> Single<LinkEntity> { return ref.child("links").child(key).get() } func getComments() -> Single<CommentEntity> { return ref.child("comments").get() } } Retain DatabaseReference
  59. Data Provider class DataProvider { static let shared = DataProvider()

    private init() {} lazy var ref: DatabaseReference = { return Database.database().reference() }() func getUser(key: String) -> Single<UserEntity> { return ref.child("users").child(key).get() } func getLink(key: String) -> Single<LinkEntity> { return ref.child("links").child(key).get() } func getComments() -> Single<CommentEntity> { return ref.child("comments").get() } } Get Entity from Database, then return Single<Entity>
  60. Data Access struct UserRepository { let dataStore: LinkDataStore func get(userId:

    String) -> Single<UserEntity> { return dataStore.get(key: userId) } } struct UserDataStore { let provider = DataProvider.shared func get(key: String) -> Single<UserEntity> { return provider.getUser(key: key) } } Entity Data Access Data Access Interactor Model Presenter View
  61. Data Access struct UserRepository { let dataStore: LinkDataStore func get(userId:

    String) -> Single<UserEntity> { return dataStore.get(key: userId) } } struct UserDataStore { let provider = DataProvider.shared func get(key: String) -> Single<UserEntity> { return provider.getUser(key: key) } } I/F for data access Implementation for data access Entity Data Access Data Access Interactor Model Presenter View
  62. Interactor (UseCase) struct UseCase { let commentsRepository: CommentRepository let usersRepository:

    UserRepository let linksRepository: LinkRepository func getComments() -> Single<[CommentModel]> { return commentsRepository.get() .map { (comment) -> [CommentModel] in let link = self.getLink(linkId: comment.link) let author = self.getUser(userId: comment.author) return Single<(LinkModel, UserModel)>.zip(link, author) { ($0, $1) }).map(translator: CommentTranslator()) } } } Entity Data Access Data Access Interactor Model Presenter View
  63. Before self.ref.child("comments").observeSingleEvent(of: .value, with: { [weak self] (snapshot) in guard

    let strongSelf = self else { return } guard let comments = snapshot.value as? [String: Any] else { return } comments.forEach({ (key, value) in guard let comment = value as? [String: Any] else { return } let linkKey: String = comment["link"] as! String // "link1" let authorKey: String = comment["author"] as! String // "user2" strongSelf.ref.child("links").child(linkKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let link = snapshot.value as? [String: Any] else { return } let submittedKey: String = link["submitted"] as! String // "user1" strongSelf.ref.child("users").child(submittedKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Alice" print(name) }) }) strongSelf.ref.child("users").child(authorKey).observeSingleEvent(of: .value, with: { (snapshot) in guard let user = snapshot.value as? [String: Any] else { return } let name: String = user["name"] as! String // “Bob” print(name) }) }) })
  64. Presenter class Presenter { let useCase: UseCase init(useCase: UseCase) {

    self.useCase = useCase } func getComments() -> Single<[CommentModel]> { return useCase.getComments() } } Entity Data Access Data Access Interactor Model Presenter View
  65. View class ViewController: UIViewController { weak var presenter: Presenter! private

    let disposeBag = DisposeBag() func inject(presenter: Presenter) { self.presenter = presenter } override func viewDidLoad() { super.viewDidLoad() presenter.getComments() .subscribe(onSuccess: { (models) in //Handling model }, onError: { (error) in //Handling Error }).disposed(by: disposeBag) } } Entity Data Access Data Access Interactor Model Presenter View
  66. View class ViewController: UIViewController { weak var presenter: Presenter! private

    let disposeBag = DisposeBag() func inject(presenter: Presenter) { self.presenter = presenter } override func viewDidLoad() { super.viewDidLoad() presenter.getComments() .subscribe(onSuccess: { (models) in //Handling model }, onError: { (error) in //Handling Error }).disposed(by: disposeBag) } } Entity Data Access Data Access Interactor Model Presenter View Focus on UI Handling
  67. Side Effect

  68. Side Effect Entity Data Access Interface Data Access to Firebase

    Interactor Model Presenter View
  69. Side Effect - Easy Unit Testing Entity Data Access Interface

    Mock Object Interactor Model Presenter View Easy to replace
  70. class DatabaseReference { func get<T: Entity>() -> Single<T> { return

    Single.create(subscribe: { (observer) in guard let bundlePath = Bundle(for: type(of: self)).path(forResource: "Stub", ofType: "bundle") else { observer(.error(SerializeError.missingBundle)) return Disposables.create() } let jsonName = String(describing: T.self) guard let path = Bundle(path: bundlePath)?.path(forResource: jsonName, ofType: "json") else { observer(.error(SerializeError.missingJson(jsonName: jsonName))) return Disposables.create() } do{ let data = try Data(contentsOf: URL(fileURLWithPath: path)) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch { observer(.error(error)) } return Disposables.create() }) } } Side Effect - Easy Unit Testing
  71. class DatabaseReference { func get<T: Entity>() -> Single<T> { return

    Single.create(subscribe: { (observer) in guard let bundlePath = Bundle(for: type(of: self)).path(forResource: "Stub", ofType: "bundle") else { observer(.error(SerializeError.missingBundle)) return Disposables.create() } let jsonName = String(describing: T.self) guard let path = Bundle(path: bundlePath)?.path(forResource: jsonName, ofType: "json") else { observer(.error(SerializeError.missingJson(jsonName: jsonName))) return Disposables.create() } do{ let data = try Data(contentsOf: URL(fileURLWithPath: path)) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch { observer(.error(error)) } return Disposables.create() }) } } Side Effect - Easy Unit Testing FackObject
  72. class DatabaseReference { func get<T: Entity>() -> Single<T> { return

    Single.create(subscribe: { (observer) in guard let bundlePath = Bundle(for: type(of: self)).path(forResource: "Stub", ofType: "bundle") else { observer(.error(SerializeError.missingBundle)) return Disposables.create() } let jsonName = String(describing: T.self) guard let path = Bundle(path: bundlePath)?.path(forResource: jsonName, ofType: "json") else { observer(.error(SerializeError.missingJson(jsonName: jsonName))) return Disposables.create() } do{ let data = try Data(contentsOf: URL(fileURLWithPath: path)) let entity = try JSONDecoder().decode(T.self, from: data) observer(.success(entity)) } catch { observer(.error(error)) } return Disposables.create() }) } } Return Entity created from Stub JSON Side Effect - Easy Unit Testing FackObject
  73. Tips - Realtime update or not lazy var realtimeRef: DatabaseReference

    = { let ref = Database.database().reference() ref.keepSynced(true) return ref }() func getFavorite(userId: String) -> Single<Void> { return realtimeRef.child(userId).child("favorites").get() }
  74. Tips - Realtime update or not lazy var realtimeRef: DatabaseReference

    = { let ref = Database.database().reference() ref.keepSynced(true) return ref }() func getFavorite(userId: String) -> Single<Void> { return realtimeRef.child(userId).child("favorites").get() } Reflect database update immediately
  75. Pros/Cons • Reduce building API man-hours • No more performance

    tunings • Easy to handle data in offline Pros
  76. Pros/Cons • Reduce building API man-hours • No more performance

    tunings • Easy to handle data in offline Pros #
  77. Pros/Cons • Must have join logic in client side •

    Need more money $ to build in some case • Data cache system doesn’t suit for your app in some case • Sorting and Query are hard to use • Scaling requires sharding (100,000 concurrent connections & 1,000 writes/sec.) Cons
  78. Pros/Cons • Must have join logic in client side •

    Need more money $ to build in some case • Data cache system doesn’t suit for your app in some case • Sorting and Query are hard to use • Scaling requires sharding (100,000 concurrent connections & 1,000 writes/sec.) Cons %
  79. Alternatives • Realtime Database + Cloud Functions • Building API

    server (Old way) • ???
  80. None
  81. One more thing…

  82. Cloud Firestore

  83. • Stores data in documents organized in collections • Sending

    data with protobuf, which have more types • Introduced reference type, so requires less denormalization and data flattening • Indexed queries with compound sorting and filtering Cloud Firestore
  84. Cloud Firestore

  85. Cloud Firestore Reference type

  86. What will be changed on architecture Entity Data Access Interface

    Data Access to Firebase Interactor Model Presenter View
  87. What will be changed on architecture Entity Data Access Interface

    Data Access to Firebase Interactor Model Presenter View
  88. Recap • Serverless architecture ( mBaaS / SaaS and etc.

    ) is also effective to use on native apps • API server can be replaced by Firebase Database / Cloud firestore in some case • Replaceable DAO and separate Entity and Model in app is important • With side effect, easy to test modules
  89. If you have Questions… Daiki Matsudate d.matsudate@gmail.com twitter: @d_date GitHub:

    @d-date
  90. Enjoy! Your serverless

  91. References • Clean Code: A Handbook of Agile Software Craftsmanship

    by Robert C. Martin • https://firebase.google.com/docs/firestore/rtdb-vs-firestore • https://firebase.google.com/docs/firestore/firestore-for- rtdb • https://speakerdeck.com/bpyamasinn/api-wo-firebase- realtime-database-niyi-xing-siteqi-fu-itakoto-ver2
