[PyCon JP 2018] Interpretable Machine Learning, making black box models explainable with Python!

Ever wonder how does a Machine Learning model make predictions? In particularly a 256-layers deep neural network, how does it distinguish a Corgi from a Husky puppy? Come to my talk and I’ll enlighten you by demystifying black-box ML models with some Python magic!

Machine learning models are increasingly complex due to the advancements of model architectures such as deep neural networks and ensemble models. While these sophisticated models have achieved higher accuracy, they are like black boxes which how the decision was made couldn’t be fully understood. There are potential risks of misrepresentation, discrimination or overfitting. Furthermore, the need of interpretability is crucial to gain the trusts of regulators and users towards ML models.

Transcript

1. Interpretable Machine Learning:
   Making black-box models explainable with Python!
   David Low
   Co-founder / CDS


   View Slide

2. Bio
   ●
   ●
   ●
   ●
   ●


   View Slide

3. ●
   ●
   ○
   ○
   ○
   ●
   ○
   ○
   Overview


   View Slide

4. Machine Learning is everywhere!
   Source: Nvidia


   View Slide

5. Source: xkcd


   View Slide

6. Is there a need to explain ML model?
   ● Safety
   Make sure the system is making sound decisions.
   ● Debugging
   Understand why a system doesn't work, so we can fix that.
   ● Science
   Enable new discovery.
   ● Mismatched Objectives and multi-objectives trade-offs:
   The system may not be optimizing the true objective.
   ● Legal / Ethics:
   Legally required to provide an explanation and/or avoid discriminate against particular
   groups due to bias in data.


   View Slide

7. EU General Data Protection Regulation (GDPR)
   ● Article 15 and 22 from GDPR suggest that:
   Customer/User has the rights to request for information/explanation pertaining to
   decision made by the automated system.
   ● Such a right would enable people to ask how a specific decision (e.g. being declined
   insurance or being denied a promotion) was reached.


   View Slide

8. A highly accurate model to classify Wolf and Husky


   View Slide

9. A highly accurate model BUT...
   ● Does the model learn the RIGHT things?
   The answer is “NO”. Instead of learning the appearance feature of the dogs, the model picks up the signal from
   the background (Snow in, this case)


   View Slide

10. Machine Learning Model
    ● ML model is a function that takes the input and produce output
    f(x)
    x (Data) y (Output)


    View Slide

11. Complexity of learned function
    1. Linear + Monotonic function
    2. Non-linear + Monotonic function
    3. Non-linear + Non-monotonic function
    Increased complexity,
    hence harder to interpret...
    Eg of Linear model:
    ● Linear regression, Logistic Regression, Naives Bayes...
    Eg of Non-linear model
    ● Neural Network, Tree-based (Random Forest, Gradient Boosting)...


    View Slide

12. Monotonicity
    Non-monotonic
    x
    y
    Monotonic
    x
    y


    View Slide

13. Scope of Interpretability
    ● Global Interpretability
    ○ How do parts of the model influence predictions?
    ● Local Interpretability
    ○ Why did the model make a specific decision for an instance?
    ○ What factors contributed to a particular decision impacting a
    specific person


    View Slide

14. Approaches
    ● Interpretable Models
    ● Model-Agnostic Methods
    ○ Partial Dependence Plot (PDP)
    ○ Individual Conditional Expectation (ICE)
    ○ Feature Importance
    ○ Surrogate Models


    View Slide

15. Partial Dependence Plot (PDP) I
    ● Shows the marginal effect of a feature on the predicted outcome of a previously fit model
    ● Steps
    ○ Select a feature: Temperature
    ○ Identify a list of value for that feature: 0 to 35 Celcius
    ○ Iterate over the list
    ■ Replace Temperature one value at a time
    ■ Take the average of the prediction outputs
    ○ Repeat it for other features


    View Slide

16. Partial Dependence Plot (PDP) II


    View Slide

17. Visualize in 3D


    View Slide

18. Individual Conditional Expectations (ICE)
    ● Visualizes the dependence of the predicted response on a feature for EACH instance
    separately, resulting in multiple lines, one for each instance.


    View Slide

19. ● Determined by the changes in the model’s prediction error after permuting the feature’s
    values
    ● Steps
    ○ For each feature
    ■ Replace the selected feature with noise (random) values
    ■ Measure the changes in prediction error
    ● Important feature → Decline in accuracy
    Less important feature → No changes / Increase of accuracy
    Feature Importance I


    View Slide

20. Feature Importance II


    View Slide

21. Local Interpretable Model-Agnostic Explanations (LIME)
    ● Local surrogate models that can explain single predictions of any black-box machine
    learning model
    ● Surrogate models are interpretable models (Linear mode / Decision Tree) that are learned
    on the predictions of the original black box model.
    ● How it works
    ○ Generate a artificial dataset from the example we’re going to explain.
    ○ Use original model to get target values for each example in a generated dataset
    ○ Train a new interpretable model, using generated dataset and generated labels as training data.
    ○ Explain the original example through weights/rules of this new model.
    *Prediction quality of a white-box classifier shows how well it approximates the original model. If
    the quality is low then explanation shouldn’t be trusted.


    View Slide

22. No Perfect Solution
    ●
    ●
    ○
    ■


    View Slide

23. Do it with Python


    View Slide

24. Libraries
    ● Scikit-Learn
    ○ https://scikit-learn.org/
    ● Local Interpretable Model-Agnostic Explanations (LIME)
    ○ https://github.com/marcotcr/lime
    ● ELI5
    ○ https://github.com/TeamHG-Memex/eli5


    View Slide

25. View Slide

26. Dog Breeds Classification
    ● Stanford Dogs Dataset (subset of ImageNet)
    ○ http://vision.stanford.edu/aditya86/ImageNetDogs/
    ● Summary
    ○ 120 dog breeds
    ○ Around 150 images per class
    ○ In total, 20580 images


    View Slide

27. DEMO


    View Slide

28. Further readings
    ●
    ○
    ●
    ○
    ●
    ○


    View Slide

29. We’re hiring Front-end Developer and SW Engineer!
    Send your CV to david@pand.ai


    View Slide
