Transcript

  1. Maptiles by MIERUNE, under CC BY. Data by OpenStreetMap contributors,

    under ODbL. Leaflet 初級編 MIERUNE Inc. / Yasunori Kirimoto 2017.06.30 FOSS4G 2017 Hokkaido ハンズオン - Web地図サイトを構築してみよう-

  2. Maptiles by MIERUNE, under CC BY. Data by OpenStreetMap contributors,

    under ODbL. 地理空間情報エンジニア Yasunori Kirimoto

  3. MIERUNE地図 Maptiles by MIERUNE, under CC BY. Data by OpenStreetMap

    contributors, under ODbL.

  4. KIKI-TORI MAP 国立環境研究所(2017)KIKI-TORI マップ, 国立環境研究所 生物・生態系環境研究センター制作. ​http://www.nies.go.jp/kikitori/contents/map (2017/6/18 閲覧)

  5. Contents はじめに ハンズオン その他事例

  6. Introduction はじめに

  7. 事前準備できてますか？？ http://day-journal.com/blog/day-016

  8. HTML CSS JS Web Technology

  9. JavaScript Library

  10. OpenLayers 3

  11. CESIUM

  12. D3.js

  13. Leaflet

  14. Web Service

  15. CARTO

  16. Mapbox

  17. Hands On ハンズオン

  18. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  19. demo demo

  20. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  21. index.html stylesheet.css script.js HTML CSS JS

  22. フォルダ構成

  23. 初期表示状態

  24. <!DOCTYPE html> <html lang="ja"> <head> <meta charset="UTF-8"> <title>Leaflet Sample</title> <!--

    Leafletライブラリ読み込み --> <script src="./library/leaflet-0.7.3/leaflet.js"></script> <link href="./library/leaflet-0.7.3/leaflet.css" rel="stylesheet" /> <!-- CSS読み込み --> <link href="./css/stylesheet.css" rel="stylesheet" /> </head> <body> <!-- Map読み込み --> <div id="map"></div> <!-- JS読み込み --> <script src="./js/script.js"></script> </body> </html> HTML

  25. html, body { height: 100%; padding: 0; margin: 0; }

    #map { z-index: 0; height: 100%; } CSS

  26. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  27. OpenStreetMap

  28. None

  29. var map = L.map('map'); L.tileLayer('https://{s}.tile.openstreetmap.org/{z}/{x}/{y}.png', { attribution: '&copy; <a href="http://osm.org/copyright">OpenStreetMap</a>

    contributors' }).addTo(map); map.setView([35.680899409847584, 139.76712226867676], 16); JS

  30. 地理院地図

  31. None

  32. L.tileLayer('https://cyberjapandata.gsi.go.jp/xyz/pale/{z}/{x}/{y}.png', { attribution: "<a href='http://www.gsi.go.jp/kikakuchousei/kikakuchousei40182.html' target='_blank'>国土地理院</a>" }).addTo(map); JS

  33. None

  34. L.tileLayer('https://cyberjapandata.gsi.go.jp/xyz/ort/{z}/{x}/{y}.jpg', { attribution: "<a href='http://www.gsi.go.jp/kikakuchousei/kikakuchousei40182.html' target='_blank'>国土地理院</a>" }).addTo(map); JS

  35. MIERUNE地図

  36. None

  37. L.tileLayer('https://tile.mierune.co.jp/mierune_mono/{z}/{x}/{y}.png', { attribution: "Maptiles by <a href='http://mierune.co.jp/' target='_blank'>MIERUNE</a>, under CC

    BY. Data by <a href='http://osm.org/copyright' target='_blank'>OpenStreetMap</a> contributors, under ODbL." }).addTo(map); JS

  38. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  39. レイヤ統合

  40. var t_pale = new L.tileLayer('https://cyberjapandata.gsi.go.jp/xyz/pale/{z}/{x}/{y}.png', { attribution: "<a href='http://www.gsi.go.jp/kikakuchousei/kikakuchousei40182.html' target='_blank'>国土地理院</a>"

    }); var t_ort = new L.tileLayer('https://cyberjapandata.gsi.go.jp/xyz/ort/{z}/{x}/{y}.jpg', { attribution: "<a href='http://www.gsi.go.jp/kikakuchousei/kikakuchousei40182.html' target='_blank'>国土地理院</a>" }); var o_std = new L.tileLayer('https://{s}.tile.openstreetmap.org/{z}/{x}/{y}.png', { attribution: '&copy; <a href="http://osm.org/copyright">OpenStreetMap</a> contributors' }); var m_mono = new L.tileLayer('https://tile.mierune.co.jp/mierune_mono/{z}/{x}/{y}.png', { attribution: "Maptiles by <a href='http://mierune.co.jp/' target='_blank'>MIERUNE</a>, under CC BY. Data by <a href='http://osm.org/copyright' target='_blank'>OpenStreetMap</a> contributors, under ODbL." }); JS

  41. var lat = 35.680899409847584; var lng = 139.76712226867676; var map

    = L.map('map', { center: [lat, lng], zoom: 15, maxZoom: 18, zoomControl: true, layers: [m_mono] }); var Map_BaseLayer = { "地理院地図 淡色": t_pale, "地理院地図 オルソ": t_ort, "OpenStreetMap 標準": o_std, "MIERUNE地図 MONO": m_mono }; L.control.layers( Map_BaseLayer, null ).addTo(map); JS

  42. レイヤ表示ON

  43. L.control.layers( Map_BaseLayer, null, {collapsed:false} ).addTo(map); JS

  44. スケール

  45. L.control.scale({ imperial: false, maxWidth: 300 }).addTo(map); JS

  46. ズームバー

  47. var map = L.map('map', { center: [lat, lng], zoom: 15,

    maxZoom: 18, zoomControl: false, layers: [m_mono] }); JS

  48. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  49. マーカー

  50. var Map_Point = L.marker( [35.68089940984, 139.7671222686] ).addTo(map); var comment =

    '東京駅だよ!!'; Map_Point.bindPopup(comment); JS

  51. var IconPin01 = L.icon({ iconUrl: "./img/pin01.png", iconSize: [25, 25], iconAnchor:

    [0, 25], popupAnchor: [0, -35] }); var Map_Point = L.marker( [35.68089940984, 139.7671222686], { icon: IconPin01 } ).addTo(map); JS

  52. ライン

  53. var Map_Line = L.polyline([ [35.67500798914924,139.75952625274658], [35.67845922918971,139.76094245910645], [35.689369743530044,139.76420402526855] ],{ "color": "#2DE9C4",

    "weight": 5, "opacity": 0.6 }).addTo(map); JS

  54. ポリゴン

  55. var Map_Polygon = L.polygon([ [35.675949251235025,139.76617813110352], [35.67410157813001,139.77188587188718], [35.67455478492641,139.77227210998535], [35.683757812281115,139.77862358093262], [35.68431553740134,139.77343082427979], [35.68469897115985,139.77094173431396],

    [35.679923346539084,139.76871013641357], [35.675949251235025,139.76617813110352] ],{ "color": "#E92D63", "weight": 3, "opacity": 0.8, "fillColor": "#562DE9", "fillOpacity": 0.4 }).addTo(map); JS

  56. オーバーレイヤ

  57. var Map_AddLayer = { "Point": Map_Point, "Line": Map_Line, "Polygon": Map_Polygon

    }; L.control.layers( Map_BaseLayer, Map_AddLayer, {collapsed:false} ).addTo(map); JS

  58. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  59. データ準備

  60. 地理空間データ作成 : geojson.io

  61. オープンデータ

  62. 国土数値情報（都市公園データ）を使用 QGIS : Shp → GeoJSON 変換

  63. 表示

  64. var sampledata = { "type": "FeatureCollection", "crs": { "type": "name",

    "properties": { "name": "urn:ogc:def:crs:OGC:1.3:CRS84" } }, "features": [ { "type": "Feature", "properties": { "P13_003": "北6条エルムの里公園" }, "geometry": { "type": "Point", "coordinates": [ 141.34308642, 43.0666937 ] } }, { "type": "Feature", "properties": { "P13_003": "宮部記念緑地" }, "geometry": { "type": "Point", "coordinates": [ 141.33550164, 43.0666937 ] } }, { "type": "Feature", "properties": { "P13_003": "偕楽園緑地" }, "geometry": { "type": "Point", "coordinates": [ 141.34429626, 43.06828667 ] } }, { "type": "Feature", "properties": { "P13_003": "八軒コスモス公園" }, "geometry": { "type": "Point", "coordinates": [ 141.32328053000001, 43.08470141 ] } } ] }; GeoJSON

  65. <script src="./vecter/map.geojson"></script> HTML

  66. var GeoJsonSample = L.geoJson(sampledata).addTo(map); JS

  67. アレンジ

  68. <script src="./vecter/point.geojson"></script> HTML

  69. var lat = 42.333174; var lng = 141.004646; var IconPin02

    = L.icon({ iconUrl: "./img/pin02.png", iconSize: [25, 25], iconAnchor: [15, 20], popupAnchor: [-5, -30] }); var PointAll = L.layerGroup().addTo(map); var PointGeojson = L.geoJson(pointdata, { onEachFeature: function (feature, layer) { var field ="目標地点: " + feature.properties.OBJECTID; layer.bindPopup(field); }, pointToLayer: function (feature, layer) { if (feature.properties.OBJECTID > 25) { return L.marker(layer, { icon: IconPin01 }); }else if (feature.properties.OBJECTID <= 25) { return L.marker(layer, { icon: IconPin02 }); } } }).addTo(PointAll); JS

  70. var Map_AddLayer = { "目標地点": PointAll }; L.control.layers( Map_BaseLayer, Map_AddLayer,

    {collapsed:false} ).addTo(map); JS

  71. <script src="./vecter/line.geojson"></script> HTML

  72. var LineAll = L.layerGroup().addTo(map); var line_geojson = L.geoJson(linedata, { style:

    { "color": "#58BE89", "weight": 3, "opacity": 0.7, "dashArray":[10, 5] }, onEachFeature: function (feature, layer) { var field ="距離(m): " + feature.properties.Shape_len; layer.bindPopup(field); }, clickable: true }).addTo(LineAll); var Map_AddLayer = { "目標地点": PointAll, "避難経路": LineAll }; JS

  73. <script src="./vecter/polygon.geojson"></script> HTML

  74. var PolygonAll = L.layerGroup().addTo(map); var PolygonGeojson = L.geoJson(polygondata, { style:

    function(feature) { if (feature.properties.MEANmax_ < 2) { return { "color": "#90D6E5", "weight": 0.5, "fill": true, "fillColor":"#90D6E5", "fillOpacity":0.4 }; }else if (feature.properties.MEANmax_ >= 2 && feature.properties.MEANmax_ < 4) { return { "color": "#2A5CAA", "weight": 0.5, "fill": true, "fillColor":"#2A5CAA", "fillOpacity":0.4 }; }else if (feature.properties.MEANmax_ >= 4 && feature.properties.MEANmax_ < 6) { return { "color": "#F4EE4F", "weight": 0.5, "fill": true, "fillColor":"#F4EE4F", "fillOpacity":0.6 }; }else if (feature.properties.MEANmax_ >= 6 && feature.properties.MEANmax_ < 8) { JS

  75. var Map_AddLayer = { "目標地点": PointAll, "避難経路": LineAll, "津波区域": PolygonAll

    }; JS

  76. 完成イメージ 基本構成 背景地図 コントロール オブジェクト GeoJSON プラグイン

  77. ©OpenStreetMap contributors Leaflet LocateControl

  78. <script src="./plugin/leaflet-locatecontrol/L.Control.Locate.min.js"></script> <link href="./plugin/leaflet-locatecontrol/L.Control.Locate.min.css" rel="stylesheet"/> <link href="//maxcdn.bootstrapcdn.com/font-awesome/4.5.0/css/font-awesome.min.css" rel="stylesheet" > HTML

  79. L.control.locate().addTo(map); JS

  80. ©OpenStreetMap contributors Leaflet Label

  81. <script src="./plugin/leaflet-label/leaflet.label.js"></script> <link href="./plugin/leaflet-label/leaflet.label.css" rel="stylesheet"/> HTML

  82. onEachFeature: function (feature, layer) { var field ="浸水深さ(m): " +

    feature.properties.MEANmax_; layer.bindLabel(field); } JS

  83. Other Cases その他事例

  84. その他のプラグイン

  85. Leaflet.MultiTileLayer

  86. ©OpenStreetMap contributors Leaflet Minimap

  87. Leaflet.heat

  88. ©OpenStreetMap contributors Leaflet Draw

  89. Leaflet-icon-pulse

  90. ©OpenStreetMap contributors Leaflet MeasureControl

  91. Leaflet Animated Marker

  92. ©OpenStreetMap contributors Leaflet Routing Machine

  93. ハイブリッドアプリ

  94. CORDOVA

  95. PhoneGap

  96. Monaca

  97. 使い方

  98. 新規プロジェクトの作成

  99. プロジェクト選択

  100. ファイルをインポート

  101. プレビュー機能・実機検証

  102. CARTO,Mapboxと連携

  103. みんなの公園マップ - 札幌版 -

  104. Leaflet

  105. CARTO

  106. Mapbox

  107. Maptiles by MIERUNE, under CC BY. Data by OpenStreetMap contributors,

    under ODbL. おつかれさまでした！
