Docker Machine Swarm

http://www.meetup.com/Docker-Tel-Aviv/events/221950270/

Overview of Docker Machine and Docker Swarm
by Evgeny Zislis

Show the latest updates and news coming from Docker about Docker Swarm and Docker Machine.

Video (in hebrew) https://youtu.be/eCFReLak7Ps

Transcript

1. Docker Machine / Swarm
2. > whoami Evgeny Zislis www.devops.co.il il.linkedin.com/in/evgenyzislis
3. Docker Machine github.com/docker/machine
4. docker machine
5. static website user data web frontend queue analytics development environments qa servers customer data center public cloud production cluster
6. list machines docker-machine ls docker machine
7. create machines docker-machine create \ --driver virtualbox \ machine_name Amazon EC2, Azure, DigitalOcean, Google Cloud Engine, OpenStack, RackSpace, Softlayer, VirtualBox, VMware Fusion, VMware vCloud Air, VMware vSphere docker machine
8. create machines $ docker-machine create -d virtualbox dev INFO[0000] Creating SSH key... INFO[0000] Image cache does not exist, creating it at /Users/evgeny/.docker/machine/cache... INFO[0000] No default boot2docker iso found locally, downloading the latest release... INFO[0000] Downloading latest boot2docker release to ~/.docker/machine/cache/boot2docker.iso INFO[0062] Creating VirtualBox VM... INFO[0068] Starting VirtualBox VM... INFO[0069] Waiting for VM to start… INFO[0123] "dev" has been created and is now the active machine. INFO[0123] To point your Docker client at it, run this in your shell: eval "$(docker-machine env dev)" docker machine
9. configure the docker client docker-machine env machine_name $ eval "$(docker-machine env foobar)" $ env | grep DOCKER docker-machine config machine_name $ docker `docker-machine config machine_name` ps docker machine
10. docker-machine ssh machine_name $ docker-machine ssh foobar some_command docker-machine ip machine_name docker-machine url machine_name connect to machines docker machine
11. docker-machine inspect machine_name docker-machine stop machine_name docker-machine start machine_name docker-machine kill machine_name docker-machine rm machine_name manage machines docker machine
12. docker-machine upgrade machine_name docker-machine regenerate-certs \ machine_name manage docker (on a machine) docker machine
13. Docker Swarm github.com/docker/swarm registry.hub.docker.com/_/swarm
14. docker swarm
15. create a swarm docker-machine create -d virtualbox \ --swarm \ --swarm-discovery token://26504993705d190ddddda6db575934f8 \ --swarm-master \ beequeen docker-machine create -d virtualbox \ --swarm \ --swarm-discovery token://26504993705d190ddddda6db575934f8 \ beeworker0 ... docker swarm
16. $ eval "$(docker-machine env --swarm beequeen)" $ env|grep DOCKER DOCKER_HOST=tcp://192.168.99.101:3376 DOCKER_TLS_VERIFY=1 DOCKER_CERT_PATH=~/.docker/machine/machines/beequeen connect to a swarm manager docker swarm
17. $ docker info inspect a swarm docker swarm Containers: 5 Strategy: spread Filters: affinity, health, constraint, port, dependency Nodes: 4 beequeen: 192.168.99.100:2376 └ Containers: 2 └ Reserved CPUs: 0 / 4 └ Reserved Memory: 0 B / 1.025 GiB beeworker0: 192.168.99.101:2376 └ Containers: 1 └ Reserved CPUs: 0 / 4 └ Reserved Memory: 0 B / 1.025 GiB beeworker1: 192.168.99.102:2376 └ Containers: 1 └ Reserved CPUs: 0 / 4 └ Reserved Memory: 0 B / 1.025 GiB beeworker2: 192.168.99.103:2376 └ Containers: 1 └ Reserved CPUs: 0 / 4 └ Reserved Memory: 0 B / 1.025 GiB
18. $ docker ps swarm containers docker swarm CONTAINER ID … PORTS NAMES a6d11e0760f7 … 2375/tcp beeworker2/swarm-agent e4a05f4f1291 … 2375/tcp beeworker1/swarm-agent eb2f5fbb295c … 2375/tcp beeworker0/swarm-agent b6f144eea15c … 2375/tcp beequeen/swarm-agent 5c6d7bf83ff4 … 192.168.99.100:3376->3376/tcp, 2375/tcp beequeen/swarm-agent-master
19. $ docker-swarm create# use hub.docker.com tokens 09d27ee662e9b31a371e1886377faeb8 $ docker-machine … \ --swarm-discovery token://09d27ee662e9b31a371e1886377faeb8 swarm discovery - hosted docker swarm
20. Static Files, etcd, Consul, ZooKeeper, IP List file:///tmp/my_cluster # echo <node_ips1:2375> >> my_cluster etcd://<etcd_ip>/<path> consul://<consul_addr>/<path> zk://<zookeeper_addr1>,<zookeeper_addr2>/<path> nodes://<node_ip1:2375>,<node_ip2:2375> # create a manager for a swarm docker-swarm manage -H tcp://<swarm_ip:swarm_port> <discovery_string> swarm discovery docker swarm
21. # put swarm-agent IP:port in a file $ echo "10.0.0.[11:100]:2375" >> /tmp/my_cluster $ echo "10.0.1.[15:20]:2375" >> /tmp/my_cluster $ echo "192.168.1.2:[2:20]375" >> /tmp/my_cluster # run a manager swarm manage -H tcp://<swarm_ip:swarm_port> file:///tmp/my_cluster swarm discovery - patterns docker swarm
22. swarm constraint filter # docker daemon on a host docker -d --label storage=ssd \ --label region=us-east-1 # filter containers in a swarm docker run -d -P --name db \ -e "constraint:storage==ssd" \ mysql docker swarm
23. swarm built-in constraints • storagedriver • executiondriver • kernelversion • operatingsystem docker run -e "constraint:storagedriver=aufs" docker run -e "constraint:operatingsystem=fedora" docker swarm
24. swarm affinity filter docker run -d -p 80:80 --name front nginx docker run -d --name logger \ -e affinity:container==front \ logger docker run -d --name redis1 \ -e affinity:image==redis \ redis docker swarm
25. $ docker run -d -p 80:80 nginx $ docker run -d -p 80:80 nginx # when no hosts available with free ports - 2014/10/29 00:33:20 Error response from daemon: no resources available to schedule container swarm port filter docker swarm
26. Shared volumes: --volumes-from=dependency Links: --link=dependency:alias Shared network stack: --net=container:dependency swarm dependency filter docker swarm
27. -m="": Memory limit format: <number><optional unit>, where unit = b, k, m or g -memory-swap="": Total memory limit (memory+swap) -c, --cpu-shares=0: CPU shares (relative weight) docker cgroup constraints docker 1.6
28. > swarm manage --strategy <strategy_type> • spread (default) • binpack • random swarm scheduler strategies docker swarm
29. Docker 1.6
30. windows client docs.docker.com/installation/windows/
31. builder resource constraints > docker build -h Usage: docker build [OPTIONS] PATH | URL | - Build a new image from the source code at PATH -c, --cpu-shares=0 CPU shares (relative weight) --cpuset-cpus= CPUs in which to allow execution (0-3, 0,1) ... -m, --memory= Memory limit --memory-swap= Total memory (memory + swap), '-1' to disable swap ... docker 1.6
32. interrupt long builds KEEP CALM AND CTRL-C docker 1.6
33. > docker commit --change > docker import --change modify images docker 1.6
34. Example: Change state interactively, then add ports after the fact. > docker commit \ --change 'EXPOSE 80' \ --change 'CMD ["nginx"]' \ container_name \ new_image_name modify images docker 1.6
35. Example: docker import to squash an image into a single layer > docker export myimage | \ docker import - --change 'EXPOSE 80' new_name modify images docker 1.6
36. Example: docker import to squash an image into a single layer > docker run --log-driver=syslog … > docker run --log-driver=none … > docker run --log-driver=json-file … logging driver docker 1.6
37. > docker -d --default-ulimit nproc=1024:2048 > docker run -d --ulimit nproc=2048:4096 httpd container ulimits docker 1.6
38. > cgcreate -a user -g memory,cpu:groupname > docker run -d \ --cgroup-parent /sys/fs/cgroup/memory/groupname \ httpd container cgroup parent docker 1.6
39. We invite you to join Operations Israel Facebook group on on.fb.me/Ops-IL link to slides dvps.me/docker-machine-swarm link to video (hebrew) youtu.be/eCFReLak7Ps Thank you! www.devops.co.il
