Gushed Light Field - Augmented Human 2017

Gushed Light Field - Augmented Human 2017

This slide was presented at Augmented Human 2017 long papers session.
Design Method for Gushed Light Field: Aerosol-Based Aerial and Instant Display
http://doi.acm.org/10.1145/3041164.3041170

【Project page】
http://digitalnature.slis.tsukuba.ac.jp/2016/08/glf/

【Project movie】
https://www.youtube.com/watch?v=LOpch4XHDJc

【Presenter】
Ippei Suzuki (鈴木 一平)
University of Tsukuba, School of Informatics
College of Media Arts, Science and Technology
Digital Nature Group (Yoichi Ochiai)
https://1heisuzuki.com

【Abstract】
We present a new method to render aerial images using aerosol-based fog screens. Conventional fog screens are easily affected by air flow, and their fog generators occupy large areas. In this study, we propose to add new tradeoffs between the display time and the payloads. We employ aerosol distribution from off-the-shelf sprays as a fog screen that can resist wind and has high portability. Results showed that the minimum weight of the entire system is approximately 600 g including all components, the screen raise time is approximately 0.5s, the disappearance time is approximately 0.4 s, and the maximum wind speed at which we can project images is approximately 10 m/s. We conducted user studies on wearable applications, aerial imaging with a drone or radio-controlled model car, multi-viewpoint display, and a display embedded in the environment. This study will contribute to the exploration of new application areas for fog displays, and will augment expressions of entertainment and interactivity.

1. Ippei Suzuki Undergraduate Student, University of Tsukuba Shuntarou Yoshimitsu, Keisuke Kawahara, Nobutaka Ito, Atsushi Shinoda, Akira Ishii, Takatoshi Yoshida, Yoichi Ochiai Gushed Light Field Aerosol-Based Aerial and Instant Display Design Method for U n i v e r s i t y o f Ts u k u b a , Yo i c h i O c h i a i L a b o r a t o r y
2. How can we build lightweight midair display? Introduction 3
3. Ismo Rakkolainen et al. “The interactive fogscreen” 2005 Introduction 4 Siggraph 2005 - The Interactive Fogscreen https://youtu.be/RfmSJQuhlk4
4. Introduction 5 Fog screen is for… Fixed Large Long time "Fogscreen at N-Gage booth" by Ville Miettinen (CC BY-NC 2.0) https://flic.kr/p/dNkBS Display
5. Large Heavy Movable Introduction 6 Fog generator is … “FogScreen downloads” http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html 110kg (245lbs) 110cm (3.6 ft)
6. Introduction 7“FogScreen Projection screen for Hire” (CC BY 2.0) https://flic.kr/p/9uejWK
7. Large Heavy Movable How can we build lightweight midair fog display? Small Light Movable We need generator such as… Introduction 8
8. Introduction 9 Aerosol Spray
9. Introduction 10 vs.Display time Weight
10. Introduction 11 Display time Weight< In this study…
11. Introduction — Summary of Contribution 12 1. Evaluate an aerosol spray as a screen 2. Provide a design and fabrication method for the aerosol-based display 3. Enables the exploration of new application areas & expands the expression of fog display
12. Related Work 13 Passive Midair Display Free-Floating Display
13. Racing car is track. Dust. (Free photobank torange.biz) / ©torange.biz (CC BY 4.0) Fog Water dropsDisplay Composed of Water Drops; Eitoku et al. 2006 Bubbles Dust Foam beads Related Work — Passive Midair Display 14
14. Related Work — Passive Midair Display 15“FogScreen downloads” http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html Display Composed of Water Drops Eitoku et al. 2006 Fog screen Rakkolainen et al. 2002 The Information Percolator Heiner et al. 1999
15. Related Work — Passive Midair Display 16“FogScreen downloads” http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html Display Composed of Water Drops Eitoku et al. 2006 Fog screen Rakkolainen et al. 2002 The Information Percolator Heiner et al. 1999 Suited for Static & long-tern display But NOT suited for moving applications… Not enough small, heavy
16. 17 “Flying Display” Nozaki 2014 “BitDrones” Gomes et al. 2016 “Midair Displays” Schneegass et al. 2014 Related Work — Free-Floating Display
17. Implementation — Overview 18
18. Implementation — Overview 19 SpraySpraySpray ServoServoServo ArduinoArduinoArduino MirrorMirrorMirror ProjectorProjectorProjector Raspberry PiRaspberry PiRaspberry Pi Nozzle Actuator
19. Implementation — Aerosol Sprays 20 111 mm 175 mm Cooling spray 70 ml Isopentane, LPG Deodorant spray 280 ml Fatty acid salt-based deodorant, Quaternaty ammonium compounds, Ethanol , LPG
20. Implementation — Spray Nozzles 21 Nozzles for cooling spray Nozzles for deodorant spray Nozzles for graffiti Nozzles for graffiti
21. Implementation — Spray Nozzles 22 Graffiti (spray painting)
22. Implementation — Spray Actuator 23
23. Implementation — Computer 24 Spray Laser projector Servo Video signal USB serial Pin conectorPin conector Mirror Servo Raspberry Pi Arduino http://www.raspberrypi.org https://www.arduino.cc
24. Implementation — Projector 25 Portable Laser Projector seeser m1 WXGA (800 × 480) Up to 25 ANSI lumens 60 × 118 × 20 mm 148.5 g 2 hours battery life http://amzn.asia/4oy1hX4
25. Implementation — Projector 26 Servo-Controlled Mirror Earn projection distance ON/OFF Lights Make height shorter Mirror ProjectorProjector Projector
26. Implementation — Overview 27 SpraySpraySpray ServoServoServo ArduinoArduinoArduino MirrorMirrorMirror ProjectorProjectorProjector Raspberry PiRaspberry PiRaspberry Pi Nozzle Actuator
27. Evaluation — Viewing Angle 28 0° 90° 0° (a) (b) (c) 10° 20° 30° 40° Cam Source Projector Distribution ±10°
28. Evaluation — Spray Patterns 29
29. Evaluation — Spray Patterns 30 (a) 10cm 5cm 10cm 15cm 20cm 25cm 30cm (b) (c) (d)
30. Evaluation — Spray Patterns (a) 10cm 5cm 10cm 15cm 20cm 25cm 30cm (b) (c) (d) 31
31. Evaluation — Spray Patterns (a) 10cm 5cm 10cm 15cm 20cm 25cm 30cm (b) (c) (d) 32 High density near nozzles but short
32. Evaluation — Spray Patterns (a) 10cm 5cm 10cm 15cm 20cm 25cm 30cm (b) (c) (d) 33 When it is attached to a small & low-pressure spray, the width becomes narrow Optimal
33. Evaluation — Length of distribution 34
34. 35 (a) (b) (c) Laser source 50cm 50cm (c) (d) 50cm 50cm *Photos are lighten composed 15 frames. Evaluation — Length of distribution
35. 36 (a) (b) (c) Laser source 50cm 50cm (c) (d) 50cm 50cm *Photos are lighten composed 15 frames. Longest, moderately wide Not steady with small spray Evaluation — Length of distribution
36. 37 (a) (b) (c) Laser source 50cm 50cm (c) (d) 50cm 50cm *Photos are lighten composed 15 frames. Narrow, short Evaluation — Length of distribution
37. 38 (a) (b) (c) Laser source 50cm 50cm (c) (d) 50cm 50cm *Photos are lighten composed 15 frames. Evaluation — Length of distribution
38. 39 Evaluation — Wind Tolerance
39. Evaluation — Wind Tolerance 40 Gushed from above Gushed from bottom 6 m/s 10 m/s 11 m/s Wind Wind
40. Evaluation — Response Speed 41 Rise: 0.5s Disappearance: 0.4s
41. 42 Evaluation — Display Time Continuous (non-stop)
42. 43 Evaluation — Display Time Continuous (non-stop)
43. 44 Evaluation — Display Time 1 sec Gush & 1 sec Interval
44. 45 Evaluation — Display Time 1 sec Gush & 1 sec IntervalContinuous (non-stop)
45. 46 Evaluation — Display Time 1 sec Gush & 1 sec IntervalContinuous (non-stop)
46. Application — Wearable Display 47
47. Application — w/ Drone 48
48. Application — w/ Drone 49
49. Application — w/ Radio-Controlled Model Car 50
50. Application — Embedded in Environment 51 Photo by Keisuke Yasuda
51. Application — Embedded in Environment 52
52. Application — Multi-viewpoints 53[Reference] “360degreee fog projection interactive display” Yagi et al. 2011
53. Discussion — Safety Issue 54 Fire in Axe (Bodyspray) https://youtu.be/pWXfftugSBQ Spray contains Flammable gas (e.g., LPG) *This video is for illustration purposes.
54. Discussion — Safety Issue 55
55. Discussion — Spray Performance 56 More tolerance for wind More large display area Higher pressure… Shorter display time, Heavier spray But…
56. Discussion — Spray Performance 57 Fabricate nozzles & spray Use properly according to the application In future work…
57. Discussion — Narrow Viewing Angle 58 Control drone/mirrors based on results of simulation In future work…
58. Conclusion — Summary of Contribution 59 1. Evaluate an aerosol spray as a screen 2. Provide a design and fabrication method for the aerosol-based display 3. Enables the exploration of new application areas & expands the expression of fog display
59. Research Group 60 Ippei Suzuki University of Tsukuba Shuntarou Yoshimitsu Waseda University Keisuke Kawahara University of Tsukuba Nobutaka Ito The University of Tokyo Atushi Shinoda University of Tsukuba Akira Ishii University of Tsukuba Takatoshi Yoshida The University of Tokyo Prof. Yoichi Ochiai University of Tsukuba
60. Special Thanks 61 Takanari Kawasumi Technical support for Drone
61. Special Thanks 62 Contributors via Crowdfunding project https://readyfor.jp
62. Ippei Suzuki Undergraduate Student, University of Tsukuba Shuntarou Yoshimitsu, Keisuke Kawahara, Nobutaka Ito, Atsushi Shinoda, Akira Ishii, Takatoshi Yoshida, Yoichi Ochiai Gushed Light Field Aerosol-Based Aerial and Instant Display Design Method for University of Tsukuba , Yoichi Ochiai Laboratory

Digital Nature Group

March 16, 2017
Tweet

More Decks by Digital Nature Group

Other Decks in Research

Transcript

  1. Ippei Suzuki Undergraduate Student, University of Tsukuba
    Shuntarou Yoshimitsu, Keisuke Kawahara, Nobutaka Ito,
    Atsushi Shinoda, Akira Ishii, Takatoshi Yoshida, Yoichi Ochiai
    Gushed Light Field
    Aerosol-Based Aerial and Instant Display
    Design Method for
    U n i v e r s i t y o f Ts u k u b a , Yo i c h i O c h i a i L a b o r a t o r y

    View Slide

  2. View Slide

  3. How can we build lightweight midair display?
    Introduction
    3

    View Slide

  4. Ismo Rakkolainen et al. “The interactive fogscreen” 2005
    Introduction
    4
    Siggraph 2005 - The Interactive Fogscreen
    https://youtu.be/RfmSJQuhlk4

    View Slide

  5. Introduction
    5
    Fog screen is for…
    Fixed
    Large
    Long time
    "Fogscreen at N-Gage booth" by Ville Miettinen (CC BY-NC 2.0)
    https://flic.kr/p/dNkBS
    Display

    View Slide

  6. Large
    Heavy
    Movable
    Introduction
    6
    Fog generator is …
    “FogScreen downloads”
    http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html
    110kg (245lbs)
    110cm (3.6 ft)

    View Slide

  7. Introduction
    7
    “FogScreen Projection screen for Hire” (CC BY 2.0)
    https://flic.kr/p/9uejWK

    View Slide

  8. Large
    Heavy
    Movable
    How can we build lightweight midair fog display?
    Small
    Light
    Movable
    We need generator such as…
    Introduction
    8

    View Slide

  9. Introduction
    9
    Aerosol Spray

    View Slide

  10. Introduction
    10
    vs.
    Display time Weight

    View Slide

  11. Introduction
    11
    Display time Weight
    <
    In this study…

    View Slide

  12. Introduction — Summary of Contribution
    12
    1. Evaluate an aerosol spray as a screen
    2. Provide a design and fabrication method
    for the aerosol-based display
    3. Enables the exploration of
    new application areas &
    expands the expression of fog display

    View Slide

  13. Related Work
    13
    Passive Midair Display Free-Floating Display

    View Slide

  14. Racing car is track. Dust. (Free photobank torange.biz) / ©torange.biz (CC BY 4.0)
    Fog
    Water drops
    Display Composed of Water Drops; Eitoku et al. 2006
    Bubbles
    Dust
    Foam beads
    Related Work — Passive Midair Display
    14

    View Slide

  15. Related Work — Passive Midair Display
    15
    “FogScreen downloads”
    http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html
    Display Composed of Water Drops
    Eitoku et al. 2006
    Fog screen
    Rakkolainen et al. 2002
    The Information Percolator
    Heiner et al. 1999

    View Slide

  16. Related Work — Passive Midair Display
    16
    “FogScreen downloads”
    http://www.3dtv-research.org/publicDocs/showCase/rakkolainen/fogscreen.html
    Display Composed of Water Drops
    Eitoku et al. 2006
    Fog screen
    Rakkolainen et al. 2002
    The Information Percolator
    Heiner et al. 1999
    Suited for
    Static & long-tern display
    But NOT suited for moving applications…
    Not enough small, heavy

    View Slide

  17. 17
    “Flying Display” Nozaki 2014
    “BitDrones” Gomes et al. 2016 “Midair Displays” Schneegass et al. 2014
    Related Work — Free-Floating Display

    View Slide

  18. Implementation — Overview
    18

    View Slide

  19. Implementation — Overview
    19
    Spray
    Spray
    Spray
    Servo
    Servo
    Servo
    Arduino
    Arduino
    Arduino
    Mirror
    Mirror
    Mirror
    Projector
    Projector
    Projector
    Raspberry Pi
    Raspberry Pi
    Raspberry Pi
    Nozzle Actuator

    View Slide

  20. Implementation — Aerosol Sprays
    20
    111 mm 175 mm
    Cooling spray
    70 ml
    Isopentane, LPG
    Deodorant spray
    280 ml
    Fatty acid salt-based deodorant,
    Quaternaty ammonium compounds,
    Ethanol , LPG

    View Slide

  21. Implementation — Spray Nozzles
    21
    Nozzles for cooling spray Nozzles for deodorant spray
    Nozzles for graffiti Nozzles for graffiti

    View Slide

  22. Implementation — Spray Nozzles
    22
    Graffiti (spray painting)

    View Slide

  23. Implementation — Spray Actuator
    23

    View Slide

  24. Implementation — Computer
    24
    Spray
    Laser projector
    Servo
    Video signal
    USB serial
    Pin conector
    Pin conector
    Mirror
    Servo
    Raspberry Pi
    Arduino
    http://www.raspberrypi.org
    https://www.arduino.cc

    View Slide

  25. Implementation — Projector
    25
    Portable Laser Projector
    seeser m1
    WXGA (800 × 480)
    Up to 25 ANSI lumens
    60 × 118 × 20 mm
    148.5 g
    2 hours battery life
    http://amzn.asia/4oy1hX4

    View Slide

  26. Implementation — Projector
    26
    Servo-Controlled Mirror
    Earn projection distance
    ON/OFF Lights
    Make height shorter
    Mirror
    Projector
    Projector Projector

    View Slide

  27. Implementation — Overview
    27
    Spray
    Spray
    Spray
    Servo
    Servo
    Servo
    Arduino
    Arduino
    Arduino
    Mirror
    Mirror
    Mirror
    Projector
    Projector
    Projector
    Raspberry Pi
    Raspberry Pi
    Raspberry Pi
    Nozzle Actuator

    View Slide

  28. Evaluation — Viewing Angle
    28

    90°

    (a) (b) (c)
    10° 20° 30° 40°
    Cam
    Source
    Projector Distribution
    ±10°

    View Slide

  29. Evaluation — Spray Patterns
    29

    View Slide

  30. Evaluation — Spray Patterns
    30
    (a)
    10cm
    5cm 10cm 15cm 20cm 25cm 30cm
    (b)
    (c)
    (d)

    View Slide

  31. Evaluation — Spray Patterns
    (a)
    10cm
    5cm 10cm 15cm 20cm 25cm 30cm
    (b)
    (c)
    (d)
    31

    View Slide

  32. Evaluation — Spray Patterns
    (a)
    10cm
    5cm 10cm 15cm 20cm 25cm 30cm
    (b)
    (c)
    (d)
    32
    High density near nozzles but short

    View Slide

  33. Evaluation — Spray Patterns
    (a)
    10cm
    5cm 10cm 15cm 20cm 25cm 30cm
    (b)
    (c)
    (d)
    33
    When it is attached to
    a small & low-pressure spray,
    the width becomes narrow
    Optimal

    View Slide

  34. Evaluation — Length of distribution
    34

    View Slide

  35. 35
    (a) (b) (c)
    Laser source
    50cm 50cm
    (c) (d)
    50cm 50cm
    *Photos are lighten composed 15 frames.
    Evaluation — Length of distribution

    View Slide

  36. 36
    (a) (b) (c)
    Laser source
    50cm 50cm
    (c) (d)
    50cm 50cm
    *Photos are lighten composed 15 frames.
    Longest, moderately wide
    Not steady with small spray
    Evaluation — Length of distribution

    View Slide

  37. 37
    (a) (b) (c)
    Laser source
    50cm 50cm
    (c) (d)
    50cm 50cm
    *Photos are lighten composed 15 frames.
    Narrow, short
    Evaluation — Length of distribution

    View Slide

  38. 38
    (a) (b) (c)
    Laser source
    50cm 50cm
    (c) (d)
    50cm 50cm
    *Photos are lighten composed 15 frames.
    Evaluation — Length of distribution

    View Slide

  39. 39
    Evaluation — Wind Tolerance

    View Slide

  40. Evaluation — Wind Tolerance
    40
    Gushed from above
    Gushed from bottom
    6 m/s 10 m/s 11 m/s
    Wind
    Wind

    View Slide

  41. Evaluation — Response Speed
    41
    Rise: 0.5s Disappearance: 0.4s

    View Slide

  42. 42
    Evaluation — Display Time
    Continuous (non-stop)

    View Slide

  43. 43
    Evaluation — Display Time
    Continuous (non-stop)

    View Slide

  44. 44
    Evaluation — Display Time
    1 sec Gush & 1 sec Interval

    View Slide

  45. 45
    Evaluation — Display Time
    1 sec Gush & 1 sec Interval
    Continuous (non-stop)

    View Slide

  46. 46
    Evaluation — Display Time
    1 sec Gush & 1 sec Interval
    Continuous (non-stop)

    View Slide

  47. Application — Wearable Display
    47

    View Slide

  48. Application — w/ Drone
    48

    View Slide

  49. Application — w/ Drone
    49

    View Slide

  50. Application — w/ Radio-Controlled Model Car
    50

    View Slide

  51. Application — Embedded in Environment
    51
    Photo by Keisuke Yasuda

    View Slide

  52. Application — Embedded in Environment
    52

    View Slide

  53. Application — Multi-viewpoints
    53
    [Reference] “360degreee fog projection interactive display” Yagi et al. 2011

    View Slide

  54. Discussion — Safety Issue
    54
    Fire in Axe (Bodyspray)
    https://youtu.be/pWXfftugSBQ
    Spray contains
    Flammable gas (e.g., LPG)
    *This video is for illustration purposes.

    View Slide

  55. Discussion — Safety Issue
    55

    View Slide

  56. Discussion — Spray Performance
    56
    More tolerance for wind
    More large display area
    Higher pressure…
    Shorter display time, Heavier spray
    But…

    View Slide

  57. Discussion — Spray Performance
    57
    Fabricate nozzles & spray
    Use properly according to the application
    In future work…

    View Slide

  58. Discussion — Narrow Viewing Angle
    58
    Control drone/mirrors
    based on results of simulation
    In future work…

    View Slide

  59. Conclusion — Summary of Contribution
    59
    1. Evaluate an aerosol spray as a screen
    2. Provide a design and fabrication method
    for the aerosol-based display
    3. Enables the exploration of
    new application areas &
    expands the expression of fog display

    View Slide

  60. Research Group
    60
    Ippei Suzuki
    University of Tsukuba
    Shuntarou Yoshimitsu
    Waseda University
    Keisuke Kawahara
    University of Tsukuba
    Nobutaka Ito
    The University of Tokyo
    Atushi Shinoda
    University of Tsukuba
    Akira Ishii
    University of Tsukuba
    Takatoshi Yoshida
    The University of Tokyo
    Prof. Yoichi Ochiai
    University of Tsukuba

    View Slide

  61. Special Thanks
    61
    Takanari Kawasumi
    Technical support for Drone

    View Slide

  62. Special Thanks
    62
    Contributors
    via Crowdfunding project
    https://readyfor.jp

    View Slide

  63. Ippei Suzuki Undergraduate Student, University of Tsukuba
    Shuntarou Yoshimitsu, Keisuke Kawahara, Nobutaka Ito,
    Atsushi Shinoda, Akira Ishii, Takatoshi Yoshida, Yoichi Ochiai
    Gushed Light Field
    Aerosol-Based Aerial and Instant Display
    Design Method for
    U n i v e r s i t y o f Ts u k u b a , Yo i c h i O c h i a i L a b o r a t o r y

    View Slide
