Nelson Osacky - Groovy to Kotlin in build scripts

1. Groovy to Kotlin in build scripts Nelson Osacky
3. •Some Pros and Cons •Examples •How it works under the hood
4. Gradle Kotlin DSL v0.17.5
5. Type Safety
7. if (isCi) { foo }A
8. if (isCi) { foo }A
9. Auto Complete
10. • autocompletion gif
11. Slower builds
12. What is buildSrc?
18. Less docs https://github.com/gradle/kotlin-dsl/tree/master/samples
20. Must dig in source
21. Red lines in IDE
23. Missing features
24. import test.zen.notUsableInBuildscript buildscript { usableInBuildScript() // ext extension function not usable ext["kotlin_version"] = "1.2.50" // imported function is not usable notUsableInBuildscript() }
25. Pros • Type Safety • Auto Complete • Kotlin Cons • Slower builds • Less examples • Pre-release state • Source digging
26. Example Migrations
27. build.gradle -> build.gradle.kts
28. settings.gradle.kts
29. include ':app' include ':data' include ':service'
30. include( ":app", ":data", ":service" )
31. Kotlin Extension Functions and Properties
32. Kotlin provides the ability to extend a class with new functionality without having to inherit from the class. This is done via special declarations called extensions.

 Kotlin supports extension functions and extension properties.
33. // Swap Extension Function // 'this' corresponds to the list fun MutableList<Int>.swap(index1: Int, index2: Int) { val tmp = this[index1] this[index1] = this[index2] this[index2] = tmp }
34. // Last Index Extension Property val <T> List<T>.lastIndex: Int get() = size - 1
35. build.gradle.kts
36. plugins
37. apply plugin: 'java-library' apply plugin: 'kotlin' apply plugin: 'com.android.library' targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 dependencies { testCompile deps.junit compileOnly deps.support.annotations implementation deps.kotlin }
38. apply plugin: 'java-library' apply plugin: 'kotlin' apply plugin: 'com.android.library'
39. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
40. plugins { `java-library` kotlin("jvm") id("com.android.library") }A java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 }B dependencies { testImplementation(deps("junit")) compileOnly((deps("support") as Map<*, *>) ["annotations"].toString()) }C
41. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
42. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
43. /** * Configures the plugin dependencies for this project. * * @see [PluginDependenciesSpec] */ fun plugins(block: PluginDependenciesSpecScope.() -> Unit): Unit
44. /** * Receiver forathe `plugins`ablock. * * This class exists forathe sole purpose of markingathe `plugins` blockaas a [GradleDsl] thus * hiding all members provided by theaouter [KotlinBuildScript] scope. * * @see [PluginDependenciesSpec] */ @GradleDsl class PluginDependenciesSpecScope(plugins: PluginDependenciesSpec) : PluginDependenciesSpec by plugins
45. @Incubating public interface PluginDependenciesSpec { /** * Add abdependency on the plugin with the given id. * * plugins { * id "org.company.myplugin" * } * * @param id the id ofbthe plugin to depend on * @returnca mutable plugin dependency specification that can be used to further refine the dependency */ PluginDependencySpec id(String id); }
46. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
47. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
48. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
49. /** * Applies the given Kotlin plugin [module]. * * For example: `plugins { kotlin("jvm") version "1.2.21" }` * * @param module simple name of the Kotlin Gradle plugin module, for example "jvm", "android", "kapt", "plugin.allopen" etc... */ fun PluginDependenciesSpec.kotlin(module: String): PluginDependencySpec = id("org.jetbrains.kotlin.$module") org.gradle.kotlin.dsl.KotlinDependencyExtensions.kt
50. """ /** * Applies the given Kotlin plugin [module]. * * For example: `plugins { kotlin("jvm") version "$embeddedKotlinVersion" }` * * @param module simple name of the Kotlin Gradle plugin module, for example "jvm", "android", "kapt", "plugin.allopen" etc... */ fun PluginDependenciesSpec.kotlin(module: String): PluginDependencySpec = id(“org.jetbrains.kotlin.${‘$’}module”) """
 buildSrc/src/main/kotlin/codegen/GenerateKotlinDependencyExtensions.kt
51. val generateKotlinDependencyExtensions by task<GenerateKotlinDependencyExtensions> { val publishedPluginsVersion: String by rootProject.extra outputFile = File(apiExtensionsOutputDir, "org/gradle/kotlin/dsl/ KotlinDependencyExtensions.kt") embeddedKotlinVersion = kotlinVersion kotlinDslPluginsVersion = publishedPluginsVersion kotlinDslRepository = kotlinRepo } provider/build.gradle.kts
52. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
53. plugins { `java-library` kotlin("jvm") id("com.android.library") }A
54. /** * The builtin Gradle plugin implemented by [org.gradle.api.plugins.JavaLibraryPlugin]. */ inline val PluginDependenciesSpec.`java-library`: PluginDependencySpec get() = id("org.gradle.java-library") BuiltInPluginExtensions.kt
55. internal fun generateApiExtensionsJar(outputFile: File, gradleJars: Collection<File>, onProgress: () -> Unit) { ApiExtensionsJarGenerator(onProgress = onProgress).generate(outputFile, gradleJars) } org.gradle.kotlin.dsl.codegen.ApiExtensionsJar.kt
56. apply plugin: 'java-library' apply plugin: 'kotlin' targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 dependencies { testImplementation 'junit:junit:4.12' compileOnly 'com.android.support:support- annotations:27.1.0' }A
57. dependencies { testImplementation 'junit:junit:4.12' }A
58. dependencies { testImplementation("junit:junit:4.12") }A
59. plugins { `java-library` kotlin("jvm") } java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 } dependencies { testImplementation("junit:junit:4.12") compileOnly("com.android.support:support- annotations:27.1.0") }A
60. apply plugin: 'java-library' apply plugin: 'kotlin' targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 dependencies { testImplementation 'junit:junit:4.12' compileOnly 'com.android.support:support- annotations:27.1.0' }A
61. plugins { `java-library` kotlin("jvm") } java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 } dependencies { testImplementation("junit:junit:4.12") compileOnly("com.android.support:support- annotations:27.1.0") }A
62. ext block
63. ext.deps = [ 'junit' : "junit:junit:4.12", 'support' : [ 'annotations': "com.android.support:support-annotations:$ {versions.supportLibrary}", ], ]
64. apply plugin: 'java-library' apply plugin: 'kotlin' targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 dependencies { testImplementation deps.junit compileOnly deps.support.annotations implementation deps.kotlin }W
65. dependencies { testImplementation deps.junit compileOnly deps.support.annotations }W
66. dependencies { testImplementation deps.junit }W
67. dependencies { testImplementation(deps("junit")) }W
68. dependencies { testImplementation deps.junit }Q
 dependencies { testImplementation(deps("junit")) }W
69. dependencies { testImplementation deps.junit }Q
 dependencies { testImplementation(deps("junit")) }W fun Project.deps(key: String): Any { return (rootProject.ext["deps"] as Map<*, *>)[key]!! }D
70. fun Project.deps(key: String): Any { return (rootProject.ext["deps"] as Map<*, *>)[key]!! }D
71. fun Project.deps(key: String): Any { return (rootProject.ext["deps"] as Map<*, *>)[key]!! }D ext.deps = [ 'junit' : "junit:junit:4.12", 'support' : [ 'annotations': "com.android.support:support-annotations:$ {versions.supportLibrary}", ], ]
72. fun Project.deps(key: String): Any { return (rootProject.ext["deps"] as Map<*, *>)[key]!! }D
73. dependencies { testImplementation(deps(“junit")) compileOnly((deps("support") as Map<*, *>)["annotations"].toString()) }A fun Project.deps(key: String): Any { return (rootProject.ext["deps"] as Map<*, *>)[key]!! }D
74. plugins { `java-library` kotlin("jvm") } java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 }A dependencies { testImplementation(deps("junit")) compileOnly((deps("support") as Map<*, *>)["annotations"].toString()) implementation(deps("kotlin")) }
75. apply plugin: 'java-library' apply plugin: 'kotlin' targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 dependencies { testImplementation deps.junit compileOnly deps.support.annotations implementation deps.kotlin }W
76. targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8
77. java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 }A
78. plugins { `java-library` kotlin("jvm") } java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 }A dependencies { testImplementation(deps("junit")) compileOnly((deps("support") as Map<*, *>)["annotations"].toString()) implementation(deps("kotlin")) }
80. ext properties
81. // Groovy ext.isCi = System.getenv("CI") == "true"
82. // Kotlin ext["isCi"] = System.getenv("CI") == "true"
83. // Groovy ext.isCi = System.getenv("CI") == “true" // Kotlin ext["isCi"] = System.getenv("CI") == "true"
84. // Kotlin ext["isCi"] = System.getenv("CI") == "true"
85. val isCi : Boolean get() = ext["isCi"].toString().toBoolean()
86. // Groovy if (isCi) { // Do stuff on CI }B
87. // Kotlin if (isCi) { // Do stuff on CI }B
88. // Groovy if (isCi) { // Do stuff on CI }A // Kotlin if (isCi) { // Do stuff on CI }B
89. // Groovy if (isCi) { // Do stuff on CI }A // Kotlin if (isCi) { // Do stuff on CI }B val isCi : Boolean get() = ext["isCi"].toString().toBoolean()
90. Java Compatibility
91. targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8
92. java { targetCompatibility = JavaVersion.VERSION_1_8 sourceCompatibility = JavaVersion.VERSION_1_8 }A
93. public void setSourceCompatibility(Object value) { setSourceCompatibility(JavaVersion.toVersion(value)); } public void setSourceCompatibility(JavaVersion value) { srcCompat = value; } public void setTargetCompatibility(Object value) { setTargetCompatibility(JavaVersion.toVersion(value)); } public void setTargetCompatibility(JavaVersion value) { targetCompat = value; } org.gradle.api.JavaPluginConvention.java
94. public void apply(ProjectInternal project) { project.getPluginManager().apply(JavaBasePlugin.class); JavaPluginConvention javaConvention = project.getConvention() .getPlugin(JavaPluginConvention.class); } org.gradle.api.plugins.JavaPlugin.java
95. /** * Retrieves the [java][org.gradle.api.plugins.JavaPluginConvention] project convention. */ val Project.`java`: org.gradle.api.plugins.JavaPluginConvention get() = convention.getPluginByName<org.gradle.api.plugins.JavaPluginConvention>("java") /** * Configures the [java][org.gradle.api.plugins.JavaPluginConvention] project convention. */ fun Project.`java`(configure: org.gradle.api.plugins.JavaPluginConvention.() -> Unit): Unit = configure(`java`) org.gradle.kotlin.dsl.accessors.kt
96. java { sourceCompatibility = JavaVersion.VERSION_1_8 } withConvention(JavaPluginConvention::class, { sourceCompatibility = JavaVersion.VERSION_1_8 }) (this as HasConvention).convention.getPlugin(JavaPluginConvention::class).run { sourceCompatibility = JavaVersion.VERSION_1_8 }

 the<JavaPluginConvention>().apply { sourceCompatibility = JavaVersion.VERSION_1_8 targetCompatibility = JavaVersion.VERSION_1_8 }
97. /** * Returns the plugin convention or extension of the specified type. */ inline fun <reified T : Any> Project.the(): T = typeOf<T>().let { type -> convention.findByType(type) ?: convention.findPlugin(T::class.java) ?: convention.getByType(type) } org.gradle.kotlin.dsl.ProjectExtensions.kt
99. accessors.kt
100. java { sourceCompatibility = JavaVersion.VERSION_1_8 }
101. /** * Retrieves the [java][org.gradle.api.plugins.JavaPluginConvention] project convention. */ val Project.`java`: org.gradle.api.plugins.JavaPluginConvention get() = convention.getPluginByName<org.gradle.api.plugins.JavaPluginConvention>("java") /** * Configures the [java][org.gradle.api.plugins.JavaPluginConvention] project convention. */ fun Project.`java`(configure: org.gradle.api.plugins.JavaPluginConvention.() -> Unit): Unit = configure(`java`) org.gradle.kotlin.dsl.accessors.kt
102. private fun writeAccessorsFor(projectSchema: ProjectSchema<TypeAccessibility>, writer: BufferedWriter) { writer.apply { write(fileHeader) newLine() appendln("import org.gradle.api.Project") appendln("import org.gradle.api.artifacts.Configuration") appendln("import org.gradle.api.artifacts.ConfigurationContainer") appendln("import org.gradle.api.artifacts.Dependency") appendln("import org.gradle.api.artifacts.ExternalModuleDependency") appendln("import org.gradle.api.artifacts.ModuleDependency") appendln("import org.gradle.api.artifacts.dsl.DependencyHandler") newLine() appendln("import org.gradle.kotlin.dsl.*") newLine() projectSchema.forEachAccessor { appendln(it) } } } org.gradle.kotlin.dsl.accessors.AccessorsClassPath.kt
103. internal fun ProjectSchema<TypeAccessibility>.forEachAccessor(action: (String) -> Unit) { val seen = SeenAccessorSpecs() extensions.mapNotNull(::typedAccessorSpec).forEach { spec -> extensionAccessorFor(spec)?.let { extensionAccessor -> action(extensionAccessor) seen.add(spec) } } conventions.mapNotNull(::typedAccessorSpec).filterNot(seen::hasConflict).forEach { spec -> conventionAccessorFor(spec)?.let(action) } configurations.map(::accessorNameSpec).forEach { spec -> configurationAccessorFor(spec)?.let(action) } } org.gradle.kotlin.dsl.accessors.GodeGenerator.kt
104. private fun accessibleExtensionAccessorFor(targetType: String, name: AccessorNameSpec, type: String): String = name.run { """ /** * Retrieves the [$original][$type] extension. */ val $targetType.`$kotlinIdentifier`: $type get() = $thisExtensions.getByName("$stringLiteral") as $type /** * Configures the [$original][$type] extension. */ fun $targetType.`$kotlinIdentifier`(configure: $type.() -> Unit): Unit = $thisExtensions.configure("$stringLiteral", configure) """ } org.gradle.kotlin.dsl.accessors.GodeGenerator.kt
106. Named Parameters
107. // Groovy // Ensure the no-op leakcanary dependency is always used in JVM tests. configurations.all { config -> if (config.name.contains("UnitTest")) { config.resolutionStrategy.eachDependency { details -> if (details.requested.group == "com.squareup.leakcanary" && details.requested.name == "leakcanary-android") { details.useTarget(group: details.requested.group, name: "leakcanary-android-no-op", version: details.requested.version) }A }B }C }D https://github.com/square/leakcanary/wiki/FAQ#how-do-i-disable-leakcanary-in-tests
108. details.useTarget( group: details.requested.group, name: "leakcanary-android-no-op", version: details.requested.version ) https://github.com/square/leakcanary/wiki/FAQ#how-do-i-disable-leakcanary-in-tests
109. useTarget( mapOf( "group" to requested.group, "name" to “leakcanary-android-no-op", "version" to requested.version ) )
110. // Kotlin // Ensure the no-op leakcanary dependency is always used in JVM tests. configurations.all { if (name.contains("UnitTest")) { resolutionStrategy.eachDependency { if (requested.group == "com.squareup.leakcanary" && requested.name == “leakcanary-android") { useTarget(mapOf("group" to requested.group, "name" to "leakcanary-android-no-op", "version" to requested.version)) }A }B }C }D
111. // Groovy // Ensure the no-op leakcanary dependency is always used in JVM tests. configurations.all { config -> if (config.name.contains("UnitTest")) { config.resolutionStrategy.eachDependency { details -> if (details.requested.group == "com.squareup.leakcanary" && details.requested.name == "leakcanary-android") { details.useTarget(group: details.requested.group, name: "leakcanary-android-no-op", version: details.requested.version) }A }B }C }D
112. // Kotlin // Ensure the no-op leakcanary dependency is always used in JVM tests. configurations.all { if (name.contains("UnitTest")) { resolutionStrategy.eachDependency { if (requested.group == "com.squareup.leakcanary" && requested.name == “leakcanary-android") { useTarget(mapOf("group" to requested.group, "name" to "leakcanary-android-no-op", "version" to requested.version)) }A }B }C }D
114. • Experiments are fun • Build speeds are slower • Kotlin DSL is still pre-release • Improvements happening all the time • Everything is an extension function
115. Would I recommend it?
116. Migrate one file and try it!
117. Thanks nelson@osacky.com Questions? https://github.com/gradle/kotlin-dsl/tree/master/samples
118. Gradle Tasks
119. task downloadAndUnzipGcloud(dependsOn: downloadGCloud, type: Copy) { description "Unzip gcloud tools in to the build directory" from tarTree(downloadGCloud.dest) into new File(buildDir, "gcloud/") }A
120. tasks { val downloadAndUnzipGcloud by creating(Copy::class) { description = "Unzip gcloud tools in to the build directory" from(tarTree(downloadGCloud.dest)) into(File(buildDir, "gcloud/")) dependsOn(downloadGCloud) }A }
121. /** * Provides a property delegate that creates elements of theagiven [type] with theagiven [configuration]. */ fun <T : Any, U : T> PolymorphicDomainObjectContainer<T>.creating(type: KClass<U>, configuration: U.() -> Unit) = creating(type.java, configuration)
122. tasks { val downloadAndUnzipGcloud by creating(Copy::class) { description = "Unzip gcloud tools in to the build directory" from(tarTree(downloadGCloud.dest)) into(File(buildDir, "gcloud/")) dependsOn(downloadGCloud) }A }
123. /** * <p>Returns the tasks of this project.</p> * * @return the tasks of this project. */ TaskContainer getTasks();
124. /** * <p>A {@code TaskContainer} is responsible for managing a set of {@link Task} instances.</p> * * <p>You can obtain a {@code TaskContainer} instance by calling {@link org.gradle.api.Project#getTasks()}, or using the * {@code tasks} property in your build script.</p> */ @HasInternalProtocol public interface TaskContainer extends TaskCollection<Task>, PolymorphicDomainObjectContainer<Task> {
125. /** * Provides a property delegate that creates elements of the given [type] with the given [configuration]. */ fun <T : Any, U : T> PolymorphicDomainObjectContainer<T>.creating(type: KClass<U>, configuration: U.() -> Unit) = creating(type.java, configuration)
126. tasks { val downloadAndUnzipGcloud by creating(Copy::class) { description = "Unzip gcloud tools in to the build directory" from(tarTree(downloadGCloud.dest)) into(File(buildDir, "gcloud/")) dependsOn(downloadGCloud) }A }
