[php[tek] 2013] MySQL High Availability, Disaster Recovery and Load Balancing

Using Oracle MySQL Server and Percona XtraDB Cluster we will take a look at several possible replication configurations for MySQL high-availability, disaster recovery and load-balancing.

After comparing them for administration ease, scalability of reads and writes, robustness of the system for errors and time for data recovery as well as looking at how they impact your code-layer we will discuss the ins-and-outs of each setup, looking at the pros and cons, and what trade-offs you will need to make depending on your needs.

Note: This talk was co-presented with Ligaya Turmelle

Transcript

1. MySQL HA, DR and
   Load Balancing
   1
   Friday, May 17, 13


   View Slide

2. •Engineer at Engine Yard on the
   Community Team
   •Author of Zend PHP 5 Certification
   Study Guide, Sitepoints PHP
   Anthology: 101 Essential Tips, Tricks
   & Hacks & PHP Master: Write
   Cutting Edge Code
   •A contributor to Zend Framework,
   phpdoc, FRAPI and PHP internals
   •@dshafik
   Davey Shafik
   2
   Friday, May 17, 13


   View Slide

3. • PHP Women
   • MySQL Ace (10+ Years)
   • @lig
   • Full Disclosure
   Ligaya Turmelle
   3
   Friday, May 17, 13


   View Slide

4. High Availability (HA)
   • Not: servers that don’t die
   • Ensures service availability, not server
   availability
   4
   Friday, May 17, 13


   View Slide

5. Disaster Recovery
   (DR)
   • Process for recovering from different
   failure scenarios
   • Automated or not (or in-between)
   • Planning
   • Something to recover from
   • Something to recover to
   5
   Friday, May 17, 13


   View Slide

6. Load Balancing
   • Balancing the load between multiple
   machines
   • Smart (based on system resources)
   • Dumb (round-robin)
   • ELB is easy, but slow
   • HAProxy is super faster (and still pretty
   easy)
   6
   Friday, May 17, 13


   View Slide

7. Why?
   • Curiosity — MySQL admin is fun
   • Goal: Make system predictable — then it
   can be automated (some)
   • Impacts of design decisions
   • Percona Cluster: oooh shiny!
   7
   Friday, May 17, 13


   View Slide

8. What
   • HA + Performance
   • Minimal code impact (drop-in system)
   • Simple (less moving parts)
   8
   Friday, May 17, 13


   View Slide

9. MySQL 5.5
   9
   Friday, May 17, 13


   View Slide

10. Semi-Sync Replication
    • Improved Data Integrity
    • Master blocks until 1 slave has written to
    relay log, flushed to disk & acknowledged
    • Slower... a little.
    • Failover to asynchronous replication
    10
    Friday, May 17, 13


    View Slide

11. 11
    Friday, May 17, 13


    View Slide

12. Semi-Sync Master Setup
    •INSTALL PLUGIN rpl_semi_sync_master
    SONAME 'semisync_master.so';
    •rpl_semi_sync_master_enabled = {0|1};
    •rpl_semi_sync_master_timeout = N;
    12
    Friday, May 17, 13


    View Slide

13. Semi-Sync Slave Setup
    •INSTALL PLUGIN rpl_semi_sync_slave
    SONAME 'semisync_slave.so';
    •rpl_semi_sync_slave_enabled = {0|
    1};
    13
    Friday, May 17, 13


    View Slide

14. Disaster Recovery
    • Primary slave is pre-determined
    failover master
    • Will have the most up-to-date content
    (not necessarily ALL the content)
    • Slaves must re-connect to new master
    • CHANGE MASTER to correct (new)
    position
    • Switch app to new master
    14
    Friday, May 17, 13


    View Slide

15. Performance
    • Benchmarker: 1 XL AWS Instance
    • Master: 1 AWS Medium Instance
    • Slaves: 3 AWS Large Instances (one semi-
    sync)
    • HAProxy: 1 AWS Large Instance
    15
    Friday, May 17, 13


    View Slide

16. Benchmarks
    • Sysbench OLTP Benchmark
    • 1.5 Million Rows
    • 64 Connection
    • InnoDB Storage Engine
    • 50,000 Queries
    • Optionally: Read-only
    16
    Friday, May 17, 13


    View Slide

17. Performance
    • Writing 1.5 Million Records, with indexes:
    • 1m 13s seconds (replicated)
    • Sysbench OLTP Benchmark:
    • Read/Write (with semi-sync): 2900/qps
    • Read/Write (without semi-sync): 2850/qps
    • Read only: 10850/qps
    17
    Friday, May 17, 13


    View Slide

18. MySQL 5.6
    18
    Friday, May 17, 13


    View Slide

19. Global Transaction IDs
    (GTIDs)
    • Unique identifier across all server (binlogs)
    • combines server UUID:Transaction ID
    • Transaction based
    • No need for log files or positions with
    CHANGE MASTER
    • Consistent group-wide
    • Easier failover
    19
    Friday, May 17, 13


    View Slide

20. 20
    Friday, May 17, 13


    View Slide

21. GTID Master & Slave
    Setup
    • gtid-mode = ON
    • log-bin
    • enforce-gtid-consistency = ON
    • log-slave-updates = ON
    21
    Friday, May 17, 13


    View Slide

22. GTID Slave Setup
    • STOP SLAVE;
    • CHANGE MASTER TO
    MASTER_HOST=' ',
    MASTER_USER='',
    MASTER_PASSWORD='',
    MASTER_AUTO_POSITION=1;
    • START SLAVE;
    22
    Friday, May 17, 13


    View Slide

23. Disaster Recovery:
    mysqlfailover
    • Performs replication health monitoring
    • handles automatic failover
    • automatic !== immediate (interval in
    seconds >= 5s)
    • Hook scripts for failed check, before/after
    failover, after complete recovery,
    23
    Friday, May 17, 13


    View Slide

24. Hooks
    • Failed check:
    • Alert somebody
    • Set app to maintenance
    • Before failover:
    • Alert somebody
    • Log Something
    • Take backups
    24
    Friday, May 17, 13


    View Slide

25. Hooks
    • After Failover:
    • Alert Somebody
    • After complete recovery:
    • Modify Application Config
    • Switchover elastic IPs (amazon)
    • Verify Application
    • Alert Somebody!
    25
    Friday, May 17, 13


    View Slide

26. Performance
    • Benchmarker: 1 XL AWS Instance
    • Master: 1 AWS Medium Instance
    • Slaves: 3 AWS Large Instances
    • HAProxy: 1 AWS Large Instance
    26
    Friday, May 17, 13


    View Slide

27. Performance
    • Writing 1.5 Million Records, with indexes:
    • 60 seconds (replicated)
    • Sysbench OLTP Benchmark:
    • Read/Write: 2950/qps
    • Read only: 9500/qps
    27
    Friday, May 17, 13


    View Slide

28. Percona XtraDB
    Cluster
    28
    Friday, May 17, 13


    View Slide

29. Multi-Master
    Replication
    • Everything replicates to everything
    • Uses XtraDB table engine (innodb
    compatible) — not NDB
    • Automatically transfer state to newly
    introduced nodes
    • Still has a “primary” server
    29
    Friday, May 17, 13


    View Slide

30. 30
    Friday, May 17, 13


    View Slide

31. Primary Server Setup
    [mysqld]
    wsrep_cluster_address=gcomm://
    datadir=/var/lib/mysql
    user=mysql
    binlog_format=ROW
    wsrep_provider=/usr/lib/
    libgalera_smm.so
    wsrep_slave_threads=2
    wsrep_cluster_name=benchmarking
    wsrep_sst_method=xtrabackup
    wsrep_node_name=
    innodb_locks_unsafe_for_binlog=1
    innodb_autoinc_lock_mode=2
    31
    Friday, May 17, 13


    View Slide

32. Other Server Setup
    [mysqld]
    wsrep_cluster_address=gcomm://
    datadir=/var/lib/mysql
    user=mysql
    binlog_format=ROW
    wsrep_provider=/usr/lib/
    libgalera_smm.so
    wsrep_slave_threads=2
    wsrep_cluster_name=benchmarking
    wsrep_sst_method=xtrabackup
    wsrep_node_name=
    innodb_locks_unsafe_for_binlog=1
    innodb_autoinc_lock_mode=2
    32
    Friday, May 17, 13


    View Slide

33. Disaster Recovery
    • Choose a new Primary server
    • Update config
    • Restart all servers
    33
    Friday, May 17, 13


    View Slide

34. Performance
    • Unable to test!
    • More than 4 concurrent “users” resulted in
    auto increment primary key collisions
    • Unable to complete the benchmark at all
    with >= 16 threads
    •ALERT: failed to execute
    mysql_stmt_execute(): Err1062
    Duplicate entry
    '500519' for key 'PRIMARY'
    FATAL: database error,
    exiting...
    34
    Friday, May 17, 13


    View Slide

35. Other Issues
    • Replication was very brittle, restarting the
    daemon would sometimes break it
    • Restarting the server almost always break it
    • Adding new nodes very often failed
    • Completely unable to get the system up
    and running with the latest version for this
    talk.
    35
    Friday, May 17, 13


    View Slide

36. Read/Write Splitting
    $ pecl install mysqlnd_ms
    mysqlnd_ms.enable=1
    mysqlnd_ms.config_file=
    /path/to/mysqlnd_ms.ini
    36
    Friday, May 17, 13


    View Slide

37. Read/Write Splitting
    {
           "myapp":  {
                   "master":  {
                           "master_0":  {
                                   "host":  "localhost",
                                   "socket":  "\/tmp\/mysql.sock"
                           }
                   },
                   "slave":  {
                           "slave_0":  {
                                   "host":  "192.168.2.27",
                                   "port":  "3306"
                           }
                   }
           }
    }
    37
    Friday, May 17, 13


    View Slide

38. Read/Write Splitting
    SELECT * FROM foo; -- Use Slave
    /* MYSQLND_MS_SLAVE_SWITCH */SELECT * FROM foo; -- Use Slave
    SELECT * FROM foo; INSERT INTO bar VALUES ('baz'); -- Use Slave!
    /* MYSQLND_MS_MASTER_SWITCH */SELECT * FROM foo; -- Use Master
    /* MYSQLND_MS_LAST_USED_SWITCH */SELECT * FROM foo; -- Use whatever
    -- was last used
    38
    Friday, May 17, 13


    View Slide

39. Questions?
    39
    Friday, May 17, 13


    View Slide

40. Thank You
    • https://joind.in/8170
    • @lig | lig@phpwomen.org
    • @dshafik | davey@engineyard.com
    • http://daveyshafik.com/slides
    40
    Friday, May 17, 13


    View Slide

41. Other Resources
    • Semi-Sync Replication: http://bit.ly/10uT3bc
    • Replication with GTIDs: http://bit.ly/
    THduPa
    • MySQL Utilities (include mysqlfailover):
    http://bit.ly/W98HGC
    • Percona XtraDB Cluster: http://bit.ly/
    RtK6aP
