Be Proactive: Use Reactive

What is “functional reactive programming?” Why should you use it? This talk is a high-level, easy-to-grasp intro to the core concepts behind reactive programming.

A video of this talk is available: https://vimeo.com/125191686

And speakers' notes, etc. are on my blog: https://www.dzombak.com/talks/2015-04-be-proactive-use-reactive.html

Transcript

1. BE PROACTIVE
   USE
   REACTIVE


   View Slide

2. iOS @ NY Times
   @cdzombak
   github.com/cdzombak
   chris dzombak
   dzombak@nytimes.com


   View Slide

3. What is
   reactive programming?


   View Slide

4. “ ”
   reactive |rēˈaktiv|
   … a programming
   paradigm oriented
   around data flows and
   the propagation of
   change


   View Slide

5. View Slide

6. View Slide

7. View Slide

8. View Slide

9. reactive programming
   data flows
   propagation of change
   =


   View Slide

10. View Slide

11. we all
    respond to flowing data
    and
    react to changes
    Model
    View
    Controller


    View Slide

12. Cocoa’s KVO?
    NSNotificationCenter?
    Ember or Angular observers?
    Callbacks?
    Listeners?
    How is this different from…
    Programming?


    View Slide

13. Back to the basics


    View Slide

14. Subject
    Observer
    notify()


    View Slide

15. DATA STREAMS


    View Slide

16. Data type
    a value over time


    View Slide

17. •updated property values
    •mouse cursor position
    •typing characters into a text field
    •database records


    View Slide

18. •updated property values
    •mouse cursor position
    •typing characters into a text field
    •database records


    View Slide

19. Collection of emitted events
    ordered in time


    View Slide

20. with functions
    for observation


    View Slide

21. View Slide

22. onNext( )


    View Slide

23. onNext( )


    View Slide

24. onNext( )


    View Slide

25. onComplete()


    View Slide

26. View Slide

27. onNext( )


    View Slide

28. onNext( )


    View Slide

29. onError()
    x


    View Slide

30. [ "value”, "other value”, "another value” ]


    View Slide

31. [ "value”, "other value”, "another value” ]
    "a value",


    View Slide

32. [ "value”, "other value”, "another value” ]
    "a value", "other value",


    View Slide

33. [ "value”, "other value”, "another value” ]
    "a value", "other value", "another value"


    View Slide

34. textField.rac_textSignal()
    .subscribeNext({ (value) -> Void in
    // value = “H”, “He”, …
    })


    View Slide

35. textField.rac_textSignal()
    .subscribeNext({ (value) -> Void in
    // value = “H”, “He”, …
    })


    View Slide

36. apiClient.performRequest(request)
    .subscribeNext({ (response) -> Void in
    // do something with response
    },
    error: { (error) -> Void in
    println(“Error: \(error)”)
    },
    completed: { () -> Void in
    println(“Done.”)
    })


    View Slide

37. Stream.transform(f: (x) -> y) -> Stream
    Streams are composable


    View Slide

38. 1 3 2
    2 6 4
    map { (x) -> Int in x * 2 }
    Streams are composable


    View Slide

39. 1 2 4
    filter { (x) -> Bool in x % 2 == 0 }
    4
    2
    Streams are composable


    View Slide

40. Double tap!
    Demo


    View Slide

41. View Slide

42. View Slide

43. taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }


    View Slide

44. taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }


    View Slide

45. taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }


    View Slide

46. 1 2 3
    taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }


    View Slide

47. 2
    taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }


    View Slide

48. taps
    .bufferWithTime(0.5)
    .map { ($0 as RACTuple).count }
    .filter { ($0 as Int) == 2 }
    .subscribeNext { (_) in
    println("Double tap!")
    }
    Double tap!


    View Slide

49. RACSignal.combineLatest([
    slowToEmitStream,
    evenSlowerToEmitStream,
    ])
    .doNext {
    let tuple = $0 as RACTuple
    processResults(
    tuple.first,
    tuple.second)
    }
    .deliverOn(RACScheduler.mainThreadScheduler())
    .subscribeCompleted { () -> Void in
    println("The work is done!")
    }


    View Slide

50. MODEL WITH STREAMS


    View Slide

51. MODEL WITH STREAMS
    BUT…WHY?


    View Slide

52. Claim
    code should communicate intent


    View Slide

53. Current tooling
    is insufficient


    View Slide

54. map
    extension Array {
    func map(transform: (T) -> U) -> [U]
    }


    View Slide

55. let input = [1, 2, 3]
    var output = [Int]()
    for number in input {
    output.append(number * 2)
    }
    // output: [2, 4, 6]
    let output = [1, 2, 3].map { $0 * 2 }
    // output: [2, 4, 6]


    View Slide

56. let input = [1, 2, 3]
    var output = [Int]()
    for number in input {
    output.append(number * 2)
    }
    // output: [2, 4, 6]
    let output = [1, 2, 3].map { $0 * 2 }
    // output: [2, 4, 6]
    Concept: 1-1 mapping


    View Slide

57. map
    reifies
    1-1 data transformation


    View Slide

58. Good Thing™
    reify |ˈrēəәˌfī|
    make (something abstract)
    more concrete or real


    View Slide

59. reactive programming
    reifies
    event-driven software


    View Slide

60. View Slide

61. View Slide

62. var count = 0
    upButton.addTarget(self, action: “upButtonTouched:”,
    forControlEvents: .TouchUpInside)
    downButton.addTarget(self, action: “downButtonTouched:",
    forControlEvents: .TouchUpInside)
    countLabel.text = String(count)
    func upButtonTouched(sender: UIButton) {
    count++
    countLabel.text = String(count)
    }
    func downButtonTouched(sender: UIButton) {
    count--
    countLabel.text = String(count)
    }


    View Slide

63. let upTaps = upButton
    .rac_signalForControlEvents(.TouchUpInside)
    let downTaps = downButton
    .rac_signalForControlEvents(.TouchUpInside)
    let count = RACSignal.merge([
    RACSignal.return(0),
    upTaps.mapReplace(1),
    downTaps.mapReplace(-1)
    ])
    .scanWithStart(0, reduce: { $0 + $1 })
    .map { String($0) }
    count ~> RAC(self, "countLabel.text")


    View Slide

64. client.loginWithSuccess({
    client.loadCachedTweetsWithSuccess({ (tweets) in
    client.fetchTweetsAfterTweet(tweets.last,
    success: { (tweets) -> Void in
    // Now we can show our tweets
    },
    failure: { (error) -> Void in
    presentError(error)
    })
    },
    failure: { (error) -> Void in
    presentError(error)
    })
    },
    failure: { (error) -> Void in
    presentError(error)
    })


    View Slide

65. client.login()
    .then {
    return client.loadCachedTweets()
    }
    .flattenMap { (tweets) -> RACStream in
    return client.fetchTweetsAfterTweet(tweets.last)
    }
    .subscribeError({ (error) -> Void in
    presentError(error)
    },
    completed: { () -> Void in
    // Now we can show our tweets
    })


    View Slide

66. bring
    changes over time
    into your type system


    View Slide

67. /// Clients should observe via property
    observer:
    public var title: String
    public let title: Signal


    View Slide

68. func loginWithSuccess(
    success: () -> Void,
    failure: (NSError) -> Void)
    {
    // function doesn’t return anything
    // it jumps into two callbacks based on return
    }
    func login() -> RACSignal {
    // function has a native return value
    // a data stream object that we can observe
    }


    View Slide

69. becomes easier
    concurrency


    View Slide

70. Scheduler

    schedules when and where work is performed



    reactive concurrency


    View Slide

71. Scheduler

    schedules when and where work is performed



    deliverOn(Scheduler)
    subscribeOn(Scheduler)
    reactive concurrency


    View Slide

72. SO…
    HOW DO I DO THIS?
    (photo by Andrew Sardone)


    View Slide

73. ReactiveCocoa
    ReactiveExtensions
    RxJava
    Bacon.js
    Elm
    github.com/ReactiveCocoa/ReactiveCocoa
    github.com/Reactive-Extensions
    github.com/ReactiveX/RxJava
    github.com/baconjs/bacon.js
    elm-lang.org


    View Slide

74. SOURCES
    FURTHER READING


    View Slide

75. Missing RX Intro
    Input & Output
    RxMarbles
    Other
    j.mp/missingrxintro
    j.mp/joshaberio
    rxmarbles.com
    pinboard.in/u:cdzombak/t:reactiveprogramming


    View Slide

76. B
    Y
    E
    (photo by Chris Dzombak)
    (puppy by Shane Bliemaster)


    View Slide
