Big Data Collection, Storage and Analytics (SFLiveBerlin2012 2012-11-22)

Presentation given at Symfony Live Berlin 2012 in Berlin, Germany.

Transcript

1. BIG DATA COLLECTION,
   STORAGE AND ANALYTICS


   View Slide

2. David Zülke


   View Slide

3. David Zuelke


   View Slide

4. View Slide

5. http://en.wikipedia.org/wiki/File:München_Panorama.JPG


   View Slide

6. Founder


   View Slide

7. View Slide

8. Lead Developer


   View Slide

9. View Slide

10. @dzuelke


    View Slide

11. PROLOGUE
    The Big Data Challenge


    View Slide

12. we want to process data


    View Slide

13. how much data exactly?


    View Slide

14. SOME NUMBERS
    • Facebook, ingest per day:
    • I/08: 200 GB
    • II/09: 2 TB compressed
    • I/10: 12 TB compressed
    • III/12: 500 TB
    • Google
    • Data processed per
    month: 400 PB (in 2007!)
    • Average job size: 180 GB


    View Slide

15. what if you have that much data?


    View Slide

16. what if Google’s 180 GB per job is all the data you have?


    View Slide

17. “No Problemo”, you say?


    View Slide

18. reading 180 GB sequentially off a disk will take ~45 minutes


    View Slide

19. and you only have 16 to 64 GB of RAM per computer


    View Slide

20. so you can't process everything at once


    View Slide

21. general rule of modern computers:


    View Slide

22. data can be processed much faster than it can be read


    View Slide

23. solution: parallelize your I/O


    View Slide

24. but now you need to coordinate what you’re doing


    View Slide

25. and that’s hard


    View Slide

26. how do you avoid overloading your network?


    View Slide

27. what if a node dies?


    View Slide

28. is data lost?
    will other nodes in the grid have to re-start?
    how do you coordinate this?


    View Slide

29. CHAPTER ONE
    Batch Processing of Big Data


    View Slide

30. Hadoop is now the industry standard


    View Slide

31. I wouldn’t bother with anything else


    View Slide

32. ENTER: OUR HERO
    Introducing MapReduce


    View Slide

33. in the olden days, the workload was distributed across a grid


    View Slide

34. and the data was shipped around between nodes


    View Slide

35. or even stored centrally on something like an SAN


    View Slide

36. which was fine for small amounts of information


    View Slide

37. but today, on the web, we have big data


    View Slide

38. I/O bottleneck


    View Slide

39. along came a Google publication in 2004


    View Slide

40. MapReduce: Simplified Data Processing on Large Clusters
    http://labs.google.com/papers/mapreduce.html


    View Slide

41. now the data is distributed


    View Slide

42. computing happens on the nodes where the data already is


    View Slide

43. processes are isolated and don’t communicate (share-nothing)


    View Slide

44. BASIC MAPREDUCE FLOW
    1.A Mapper reads records and emits pairs
    1.Input could be a web server log, with each line as a record
    2.A Reducer is given a key and all values for this specific key
    1.Even if there are many Mappers on many computers; the
    results are aggregated before they are handed to Reducers
    * In pratice, it’s a lot smarter than that


    View Slide

45. EXAMPLE OF MAPPED INPUT
    IP Bytes
    212.122.174.13 18271
    212.122.174.13 191726
    212.122.174.13 198
    74.119.8.111 91272
    74.119.8.111 8371
    212.122.174.13 43


    View Slide

46. REDUCER WILL RECEIVE THIS
    IP Bytes
    212.122.174.13
    18271
    212.122.174.13
    191726
    212.122.174.13
    198
    212.122.174.13
    43
    74.119.8.111
    91272
    74.119.8.111
    8371


    View Slide

47. AFTER REDUCTION
    IP Bytes
    212.122.174.13 210238
    74.119.8.111 99643


    View Slide

48. PSEUDOCODE
    function  map($line_number,  $line_text)  {
       $parts  =  parse_apache_log($line_text);
       emit($parts['ip'],  $parts['bytes']);
    }
    function  reduce($key,  $values)  {
       $bytes  =  array_sum($values);
       emit($key,  $bytes);
    }
    212.122.174.13  210238
    74.119.8.111      99643
    212.122.174.13  -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /foo  HTTP/1.1"  200  18271
    212.122.174.13  -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /bar  HTTP/1.1"  200  191726
    212.122.174.13  -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /baz  HTTP/1.1"  200  198
    74.119.8.111      -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /egg  HTTP/1.1"  200  43
    74.119.8.111      -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /moo  HTTP/1.1"  200  91272
    212.122.174.13  -­‐  -­‐  [30/Oct/2009:18:14:32  +0100]  "GET  /yay  HTTP/1.1"  200  8371


    View Slide

49. A YELLOW ELEPHANT
    Introducing Apache Hadoop


    View Slide

50. View Slide

51. Hadoop is a MapReduce framework


    View Slide

52. it allows us to focus on writing Mappers, Reducers etc.


    View Slide

53. and it works extremely well


    View Slide

54. how well exactly?


    View Slide

55. HADOOP AT FACEBOOK
    • Predominantly used in combination with Hive (~95%)
    • Largest cluster holds over 100 PB of data
    • Typically 8 cores, 12 TB storage and 32 GB RAM per node
    • 1x Gigabit Ethernet for each server in a rack
    • 4x Gigabit Ethernet from rack switch to core
    Hadoop is aware of racks and locality of nodes


    View Slide

56. HADOOP AT YAHOO!
    • Over 25,000 computers with over 100,000 CPUs
    • Biggest Cluster:
    • 4000 Nodes
    • 2x4 CPU cores each
    • 16 GB RAM each
    • Over 40% of jobs run using Pig
    http://wiki.apache.org/hadoop/PoweredBy


    View Slide

57. OTHER NOTABLE USERS
    • Twitter (storage, logging, analysis. Heavy users of Pig)
    • Rackspace (log analysis; data pumped into Lucene/Solr)
    • LinkedIn (contact suggestions)
    • Last.fm (charts, log analysis, A/B testing)
    • The New York Times (converted 4 TB of scans using EC2)


    View Slide

58. OTHER EXECUTION MODELS
    Why Even Write Code?


    View Slide

59. HADOOP FRAMEWORKS
    AND ECOSYSTEM
    • Apache Hive
    SQL-like syntax
    • Apache Pig
    Data flow language
    • Cascading
    Java abstraction layer
    • Scalding (Scala)
    • Apache Mahout
    Machine Learning toolkit
    • Apache HBase
    BigTable-like database
    • Apache Nutch
    Search engine
    • Cloudera Impala
    Realtime queries (no MR)


    View Slide

60. CHAPTER TWO
    Real-Time Big Data


    View Slide

61. sometimes, you can’t wait a few hours


    View Slide

62. Twitter’s trending topics, fraud warning systems, ...


    View Slide

63. batch processing won’t cut it


    View Slide

64. View Slide

65. TWITTER STORM
    • Often called “the Hadoop for Real-Time”
    • Central Nimbus service coordinates execution w/ ZooKeeper
    • A Storm cluster runs Topologies, processing continuously
    • Spouts produce streams: unbounded sequences of tuples
    • Bolts consume input streams, process, output again
    • Topologies can consist of many steps for complex tasks


    View Slide

66. TWITTER STORM
    • Bolts can be written in other languages
    • Uses STDIN/STDOUT like Hadoop Streaming, plus JSON
    • Storm can provide transactions for topologies and guarantee
    processing of messages
    • Architecture allows for non stream processing applications
    • e.g. Distributed RPC


    View Slide

67. CLOUDERA IMPALA
    • Implementation of a Dremel/BigQuery like system on Hadoop
    • Uses Hadoop v2 YARN infrastructure for distributed work
    • No MapReduce, no job setup overhead
    • Query data in HDFS or HBase
    • Hive compatible interface
    • Potential game changer for its performance characteristics


    View Slide

68. DEMO
    Hadoop Streaming & PHP in Action


    View Slide

69. STREAMING WITH PHP
    Introducing HadooPHP


    View Slide

70. HADOOPHP
    • A little framework to help with writing mapred jobs in PHP
    • Takes care of input splitting, can do basic decoding et cetera
    • Automatically detects and handles Hadoop settings such as
    key length or field separators
    • Packages jobs as one .phar archive to ease deployment
    • Also creates a ready-to-rock shell script to invoke the job


    View Slide

71. written by


    View Slide

72. View Slide

73. EPILOGUE
    Things to Keep in Mind


    View Slide

74. DATA ACQUISITION
    • Batch loading
    • Log files into HDFS
    • *SQL to Hive via Sqoop
    • Streaming
    • Facebook Scribe
    • Apache Flume
    • Apache Chuckwa
    • Apache Kafka


    View Slide

75. WANT TO KEEP IT SIMPLE?
    • Measure Anything, Measure Everything
    http://codeascraft.etsy.com/2011/02/15/measure-anything-
    measure-everything/
    • StatsD receives counter or timer values via UDP
    • StatsD::increment("grue.dinners");
    • Periodically flushes information to Graphite
    • But you need to know what you want to know!


    View Slide

76. OPS MONITORING
    • Flume and Chuckwa have sources for everything:
    MySQL status, Kernel I/O, FastCGI statistics, ...
    • Build a flow into HDFS store for persistence
    • Impala queries for fast checks on service outages etc
    • Correlate with Storm flow results to find problems
    • Use cloud-based notifications to produce SMS/email alerts


    View Slide

77. just kidding


    View Slide

78. just use Nagios/Icinga for that


    View Slide

79. !e End


    View Slide

80. Questions?


    View Slide

81. THANK YOU!
    This was http://joind.in/7564
    by @dzuelke
    Send me questions:
    david.zuelke@bitextender.com


    View Slide
