1. SELECT ALL THE THINGS!
   Cascading Lingual
   ANSI SQL for Apache Hadoop
   TU-Berlin, January 13th 2014
   André Kelpe
   concurrentinc.com


   View Slide

2. Speaker
   André Kelpe
   Software Engineer at Concurrent
   The company behind Cascading and Lingual
   concurrentinc.com / @concurrent
   andre@concurrentinc.com
   @fs111


   View Slide

3. Agenda
   Cascading and Lingual
   Lingual: design goals
   Lingual: features
   Demo: Lingual in action
   Q&A


   View Slide

4. Cascading
   http://cascading.org


   View Slide

5. Cascading terminology
   Taps are sources and sinks for data
   Schemes represent the format of the data
   Pipes are connecting Taps


   View Slide

6. Cascading terminology
   Tuples flow through Pipes
   Fields describe the Tuples
   Operations are executed on Tuples in
   TupleStreams
   Flows get scheduled and executed


   View Slide

7. Word Count 1/4
   // define source and sink Taps.
   Scheme sourceScheme = new TextLine( new Fields( "line" ) );
   Tap source = new Hfs( sourceScheme, inputPath );
   Scheme sinkScheme = new TextLine( new Fields( "word", "count" ) );
   Tap sink = new Hfs( sinkScheme, outputPath, SinkMode.REPLACE );
   // the 'head' of the pipe assembly
   Pipe assembly = new Pipe( "wordcount" );


   View Slide

8. Word Count 2/4
   // For each input Tuple
   // parse out each word into a new Tuple with the field name "word"
   // regular expressions are optional in Cascading
   String regex = "(?Function function = new RegexGenerator( new Fields( "word" ), regex );
   assembly = new Each( assembly, new Fields( "line" ), function );
   // group the Tuple stream by the "word" value
   assembly = new GroupBy( assembly, new Fields( "word" ) );


   View Slide

9. // For every Tuple group
   // count the number of occurrences of "word" and store result in
   // a field named "count"
   Aggregator count = new Count( new Fields( "count" ) );
   assembly = new Every( assembly, count );
   // initialize app properties, tell Hadoop which jar file to use
   Properties properties = new Properties();
   FlowConnector.setApplicationJarClass( properties, Main.class );
   Word Count 3/4


   View Slide

10. // plan a new Flow from the assembly using the source and sink Taps
    // with the above properties
    FlowConnector flowConnector = new FlowConnector( properties );
    Flow flow = flowConnector.connect( "word-count", source, sink, assembly );
    // execute the flow, block until complete
    flow.complete();
    Word Count 4/4


    View Slide

11. Not just Java!


    View Slide

12. Scalding
    Scala DSL on top of Cascading
    Developed by twitter
    https://github.com/twitter/scalding/


    View Slide

13. Cascalog
    Clojure DSL on top of Cascading
    Inspired by datalog
    https://github.com/nathanmarz/cascalog


    View Slide

14. ANSI SQL via Lingual
    http://www.cascading.org/lingual/


    View Slide

15. Lingual – design goals 1/3
    Immediate Data Access
    SQL access via Shell or JDBC driver


    View Slide

16. Lingual – design goals 2/3
    Simplify SQL Migration
    move SQL workflows on your Hadoop Cluster
    via Cascading flows or JDBC driver


    View Slide

17. Lingual – design goals 3/3
    Simplify System
    & Data Integration
    Read and write from hdfs, jdbc, memcached,
    HBase, redshift...


    View Slide

18. Lingual – ANSI SQL on Cascading
    http://www.cascading.org/lingual/


    View Slide

19. Lingual and Cascading are
    about batch processing large
    amounts of data


    View Slide

20. Demo


    View Slide

21. SQL in Cascading 1/2
    String statement = "select *\n"
    + "from \"example\".\"sales_fact_1997\" as s\n"
    + "join \"example\".\"employee\" as e\n"
    + "on e.\"EMPID\" = s.\"CUST_ID\"";
    Tap empTap = new FileTap( new SQLTypedTextDelimited( ",", "\"" ),
    "src/main/resources/data/example/employee.tcsv", SinkMode.KEEP );
    Tap salesTap = new FileTap( new SQLTypedTextDelimited( ",", "\"" ),
    "src/main/resources/data/example/sales_fact_1997.tcsv",
    SinkMode.KEEP );
    Tap resultsTap = new FileTap( new SQLTypedTextDelimited( ",", "\"" ),
    "build/test/output/flow/results.tcsv", SinkMode.REPLACE );


    View Slide

22. SQL in Cascading 2/2
    FlowDef flowDef = FlowDef.flowDef()
    .setName( "sql flow" )
    .addSource( "example.employee", empTap )
    .addSource( "example.sales_fact_1997", salesTap )
    .addSink( "results", resultsTap );
    SQLPlanner sqlPlanner = new SQLPlanner()
    .setSql( statement );
    flowDef.addAssemblyPlanner( sqlPlanner );
    Flow flow = new LocalFlowConnector().connect( flowDef );
    flow.complete();


    View Slide

23. Lingual – ANSI SQL on Cascading
    http://www.cascading.org/lingual/


    View Slide

24. Q&A
    @fs111 / http://concurrentinc.com
    http://cascading.org/lingual


    View Slide

25. Link collection
    http://www.cascading.org/lingual/
    http://www.cascading.org/
    http://docs.cascading.org/lingual/1.0/
    https://github.com/Cascading/
    http://concurrentinc.com
    https://groups.google.com/forum/#!forum/lingual-user
    https://groups.google.com/forum/#!forum/cascading-user
    http://docs.cascading.org/impatient/
    https://github.com/Cascading/vagrant-cascading-hadoop-cluster


    View Slide
