1. Docker in production:
   service discovery with Consul
   Giovanni Toraldo - Lead developer @ ClouDesire.com
   Road to OpsCon 2015 - Milano


   View Slide

2. About me
   Open Source Enthusiast
   with SuperCow Powers
   PHP/Java/whatever
   developer
   writer of the OpenNebula
   book
   Lead developer at
   ClouDesire.com
   2


   View Slide

3. What is ClouDesire?
   Application Marketplace to help software vendors to sell and provision
   applications
   ● Web Applications:
   ○ provision VM
   ○ on multiple cloud providers
   ○ deploy/upgrade application and dependencies
   ○ application logging
   ○ resource monitoring
   ● With multi-tenant applications/SaaS:
   ○ expose REST hooks and API for billing lifecycle
   ● manage subscriptions, billing, pay-per-use, invoicing, payments.
   3


   View Slide

4. ClouDesire platform components
   Multitude of components of different stacks:
   ● Multiple Java/Tomcat REST backends
   ● Minor Ruby, Node REST backends
   ● AngularJS frontend
   ● PostgreSQL
   ● MongoDB
   ● Rsyslog + nxlog + Logstash + ElasticSearch
   ● ActiveMQ
   4


   View Slide

5. Before Docker: platform deployments
   Problems faced:
   ● Different stacks, different ways to handle deployments
   ○ Hundreds LOC of Chef recipes
   ○ Inevitable complexity
   ○ No trustworthy procedure to rollback
   ● Hard to switch between deps versions
   ○ Only the one available on official Ubuntu repositories
   ● Heterogeneous dev environments (vagrant?)
   ○ Ubuntu, Arch Linux, Mac
   5


   View Slide

6. Before Docker: application packaging
   How to grab applications from ClouDesire vendors?
   ● GIT repository (heroku)?
   ○ Not really its use-case, require understanding
   ○ Customization may require branching
   ● DEB/RPM packages?
   ○ Too much complexity
   ● Custom approach?
   6


   View Slide

7. Before Docker: hand-made zip package
   Requirements:
   ● Everyone should be able to do it
   ● even Windows users
   ● in a short time
   Our solution, not elegant but effective:
   ● A ZIP archive with:
   ○ a folder for sources/artifacts
   ○ a folder for sql scripts
   ○ predefined environment variables to use
   7


   View Slide

8. Before Docker: custom zip package
   Application source code itself is not sufficient:
   ● Custom dependencies (e.g.: Alfresco)
   ● Custom dependencies versions
   ● Configuration for external resources
   ● Shameful hacks?
   8


   View Slide

9. “Maybe Docker can help?”
   9


   View Slide

10. View Slide

11. Docker: container lifecycle
    ● Pulls an image from a registry
    ● Creates a new container
    ○ Allocates a r/w filesystem
    ○ Allocates a network interface (on a bridge)
    ○ Sets up network (IP address, dns..)
    ● Launch a process into the container
    ● Captures and provides application output
    ● Container terminates when the process exits
    11


    View Slide

12. Docker: why?
    Enables software developers to:
    ● package an application
    ● with all dependencies
    ● runs it everywhere unchanged
    ● re-use images via composition
    12


    View Slide

13. Docker: why?
    Enables system administrators to:
    ● standardize application deployment
    ● ease scale-up & scale-down
    ● process separation/isolation
    13


    View Slide

14. Docker adoption: platform deployment
    ● Different stacks, different ways to handle deployments
    ○ Docker Image for each component
    ○ Dozens LOC of Chef recipe for deploy / upgrades
    ○ Deployment complexity hidden into Dockerfile
    ○ Rollback is equal to upgrade
    ● Hard to switch between deps versions
    ○ Docker for external dependencies
    ○ Use them without thinking how to deploy / upgrade
    ● Heterogeneous dev environments (vagrant?)
    ○ Docker-compose for each module
    14


    View Slide

15. Docker adoption: application packaging
    How to grab applications from ClouDesire vendors?
    ● Custom ZIP package
    ○ Build a docker image for the application
    ○ Push your image to our registry.
    Advantages:
    ● Easy to follow documentation
    ● Fast Try-Fail-Retry cycle while building
    ● Works-for-me is works everywhere
    ● Re-use community images for dependencies
    15


    View Slide

16. Docker adoption: application packaging
    ● Custom dependencies (e.g.: Alfresco)
    ○ (Re-)Use multiple containers
    ● Custom dependencies versions
    ○ Multiple versions easily available
    ● Configuration for external resources
    ○ Environment variables
    ● Shameful hacks?
    ○ Hidden in the Dockerfile
    16


    View Slide

17. Docker: it looks like something is missing
    Moving to containers introduced a new layer of complexity:
    ● communication between containers:
    ○ Same host (with docker linking feature)
    ■ restart everything after redeploy
    ○ Multiple hosts
    ■ not a docker problem
    ● Scaling/hot-deploy ready
    ○ but load balancers are statically configured
    17


    View Slide

18. “It would be a mess”
    18


    View Slide

19. Service Discovery to the rescue
    19


    View Slide

20. Before Consul (and service discovery)
    ● Hardcoded IP:port configuration
    ○ Hand-made copy-paste
    ○ Not fault-tolerant
    ○ No autoscaling
    ○ No self-healing
    ● Configuration management (e.g. Puppet, Chef)
    ○ Slow to react to events
    ○ Ordered service starting
    Above not really feasible when running dozens of containers
    20


    View Slide

21. Consul on github
    21


    View Slide

22. When service discovery is needed
    ● Monolithic architecture? No problem.
    ● Distributed architecture?
    ○ Is there at least one foo instance running?
    ○ At which address?
    ○ On which port?
    FOO
    BAR
    Service
    Registry
    Client
    22


    View Slide

23. Consul features
    ● Agent based
    ● Query interfaces
    ○ HTTP JSON API
    ○ DNS
    ● Health-Checking
    ○ No one want borked services
    ● Key-Value Store
    ○ Shared dynamic configuration
    ○ Feature toggle
    ○ Leader election
    23


    View Slide

24. docker run --rm --name consul -p 8500:8500 -p 8600:8600
    voxxit/consul agent -server -bootstrap-expect 1 -data-dir
    /tmp/consul --client 0.0.0.0 -node helloworld
    ● consensus protocol
    ○ https://github.com/hashicorp/raft
    ● lightweight gossip protocol
    ○ https://github.com/hashicorp/serf
    Single node bootstrap
    24


    View Slide

25. View Slide

26. Second node bootstrap
    $ docker run --rm --name consul2 voxxit/consul agent -server -
    join 172.17.0.2 -data-dir /tmp/consul --client 0.0.0.0 -node
    helloworld2
    26


    View Slide

27. Two nodes cluster alive
    ● helloworld2 joined cluster
    ● replication take place
    ● helloworld2 marked as healthy
    27


    View Slide

28. Node querying - DNS interface
    $ dig helloworld.node.consul @localhost -p 8600 +tcp
    helloworld.node.consul. 0 IN A 172.17.0.2
    $ dig helloworld2.node.consul @localhost -p 8600 +tcp
    helloworld2.node.consul. 0 IN A 172.17.0.3
    28


    View Slide

29. Node querying - HTTP interface
    $ curl localhost:8500/v1/catalog/nodes
    [{"Node":"helloworld2","Address":"172.17.0.3"},{"Node":"
    helloworld","Address":"172.17.0.2"}]%
    29


    View Slide

30. Register a new service
    $ curl -X POST -d @service.json localhost:
    8500/v1/agent/service/register
    {
    "ID": "redis1",
    "Name": "redis",
    "Tags": [
    "master",
    "v1"
    ],
    "Address": "172.16.0.2",
    "Port": 8000
    }
    30


    View Slide

31. Retrieve service details
    $ dig redis.service.consul @localhost -p 8600 +tcp
    redis.service.consul. 0 IN A 172.16.0.2
    $ curl localhost:8500/v1/agent/services
    {"consul":{"ID":"consul","Service":"consul","Tags":[],"
    Address":"","Port":8300},"redis1":{"ID":"redis1","Service":"redis","
    Tags":["master","v1"],"Address":"172.16.0.2","Port":8000}}%
    31


    View Slide

32. Populate services from Docker
    https://github.com/gliderlabs/registrator
    ● Discover containers using docker API
    ● Skip containers without published ports
    ● Register service when container goes up
    ○ Service name is the image name
    ○ Tags via environment variables
    ● Unregister service when container goes down
    32


    View Slide

33. Running registrator
    $ docker run -d \
    --name=registrator \
    --net=host \
    --volume=/var/run/docker.sock:/tmp/docker.sock \
    gliderlabs/registrator:latest \
    consul://localhost:8500
    Note: exposing docker.sock in a container is a security
    concern.
    33


    View Slide

34. Enrich service metadata
    ● Registrator auto discovery can be enriched via
    environment variables
    $ docker run --name redis-0
    -p 10000:6379 \
    -e "SERVICE_NAME=db" \
    -e "SERVICE_TAGS=master" \
    -e "SERVICE_REGION=it" redis
    34


    View Slide

35. Retrieve registrator services
    $ dig consul.service.consul @localhost -p 8600 +tcp
    consul.service.consul. 0 IN A 172.17.0.3
    consul.service.consul. 0 IN A 172.17.0.2
    $ curl localhost:8500/v1/agent/services
    {"consul":{"ID":"consul","Service":"consul","Tags":[],"Address":"","Port":8300},"
    viserion:consul:8500":{"ID":"viserion:consul:8500","Service":"consul-8500","Tags":
    null,"Address":"127.0.1.1","Port":8500},"viserion:consul:8600":{"ID":"viserion:consul:
    8600","Service":"consul-8600","Tags":null,"Address":"127.0.1.1","Port":8600}}%
    35


    View Slide

36. Automatic reverse proxy for web services
    $ consul-template \
    -consul 127.0.0.1:8500 \
    -template "/tmp/template.ctmpl:/var/www/nginx.conf:service
    nginx restart" \
    -retry 30s
    upstream upstream-<%= @service_name %> {
    least_conn;
    {{range service "<%= @service_name %>"}}server {{.Address}}:
    {{.Port}} max_fails=3 fail_timeout=60 weight=1;
    {{else}}server 127.0.0.1:65535; # force a 502{{end}}
    } 36


    View Slide

37. Example nginx.conf fragment
    server {
    listen 80 default_server;
    location ~ ^/api/(.\*)$ {
    proxy_pass http://upstream-service-name/$1$is_args$args;
    proxy_set_header X-Forwarded-For
    $proxy_add_x_forwarded_for;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    }
    }
    37


    View Slide

38. Real-world architecture of everything
    Container
    A
    Container
    B
    Registrator
    Consul
    agent
    Consul
    agent
    Registrator
    Backend Node A Backend Node B
    Network
    ● Consul agent running on each node
    ● Registrator on each docker node
    ● Every node has 127.0.0.1 in /etc/resolv.conf
    ● Services discover dependencies via DNS
    ● Nginx endpoint generated by consul-template
    Frontend Node(s)
    Nginx
    Consul
    agent
    Consul-
    template
    38


    View Slide

39. Consul: additional goodies
    ● Key-Value store for configurations
    ● DNS forwarding
    ● DNS caching
    ● WAN replication (Multi-DC)
    ● Atlas bootstrapping (https://atlas.hashicorp.
    com/)
    ● Web UI (http://demo.consul.io/ui/)
    39


    View Slide

40. View Slide

41. Homework for the coming months
    ● Take a look at:
    ○ Docker swarm (1.0 released on nov 2015)
    ○ Kubernetes (1.0 release on july 2015)
    ○ Apache Mesos (0.25 release on oct 2015)
    41


    View Slide

42. Thanks!
    We are hiring!
    https://cloudesire.cloud/jobs/
    42
