Working with binary data in Ruby

Transcript

2. Grzegorz Kołodziejczyk CTO @ Ragnarson
3. Working with
 binary data
 in Ruby
4. How we got into this? Binary data 101 What's available in the STDLIB A gem that makes it all easier
5. How we got into this? Finally not a cookie cutter project Data from meters and sensors Collected by gateways, sent over MQTT MQTT -> Sidekiq OMS protocol, raw payloads
6. How we got into this? In production for over 2 years ~2000 "requests" per minute Industry leaders in amount of supported devices
7. How we got into this? Low-level protocol = C
8. How we got into this? No good open source libraries
9. How we got into this? Niche protocol
10. How we got into this? Do I really want to write C?
11. How we got into this? Can we do it in Ruby instead?
12. Binary data 101
13. Binary data 101 All data is binary
14. Binary data 101 All keyboards are mechanical keyboards
15. Binary data 101 Bit is either 1 or 0
16. Binary data 101 A byte is a group of 8 bits 27 26 25 24 23 22 21 20 128 64 32 16 8 4 2 1 0 1 0 1 1 0 0 1 0 64 0 16 8 0 0 1 89
17. Binary data 101 Endianness is byte order
18. Binary data 101 ASCII is for character encoding "a".ord => 97 122.chr => "z" 10.chr => "\n"
19. Binary data 101 Hexadecimal notation 0b11111111 == 255 == 0xFF 0b01011001 == 89 == 0x59
20. Binary data 101 Bit Byte Endianness ASCII Hex
21. What's available in the STDLIB
22. What's available in the STDLIB String#pack and String#unpack
23. What's available in the STDLIB String#pack and String#unpack "\x8A\xE3".unpack("H*") => ["8ae3"]
24. What's available in the STDLIB String#pack and String#unpack "\x8A\xE3".unpack1("H*") => "8ae3"
25. What's available in the STDLIB String#pack and String#unpack ["8ae3"].pack("H*") => "\x8A\xE3"
26. What's available in the STDLIB String#pack and String#unpack ["420A"].pack("H*") => "B\n"
27. What's available in the STDLIB
28. What's available in the STDLIB Integer | | Directive | Returns | Meaning ----------------------------------------------------------------- C | Integer | 8-bit unsigned (unsigned char) S | Integer | 16-bit unsigned, native endian (uint16_t) L | Integer | 32-bit unsigned, native endian (uint32_t) Q | Integer | 64-bit unsigned, native endian (uint64_t)
29. What's available in the STDLIB String | | Directive | Returns | Meaning ----------------------------------------------------------------- A | String | arbitrary binary string (remove trailing nulls and ASCII spaces) a | String | arbitrary binary string Z | String | null-terminated string B | String | bit string (MSB first) b | String | bit string (LSB first) H | String | hex string (high nibble first) h | String | hex string (low nibble first)
30. Some examples
31. IP Address
32. IP Address "\xC0\xA8\x01\x01" "\xC0\xA8\x01\x01".unpack("CCCC").join(".") => "192.168.1.1 "192.168.1.1".split(".").map(&:to_i).pack("CCCC") => "\xC0\xA8\x01\x01"
33. MAC Address "\x00\x01\x02\x03\x04\x05" "\x00\x01\x02\x03\x04\x05". unpack("H2H2H2H2H2H2").join(":") => "00:01:02:03:04:05" "00:01:02:03:04:05". split(":").pack("H2H2H2H2H2H2") => "\x00\x01\x02\x03\x04\x05"
34. gzip - show original filename +---+---+---+---+---+---+---+---+---+---+ |ID1|ID2|CM |FLG| MTIME |XFL|OS | (more-->) +---+---+---+---+---+---+---+---+---+---+ +---+---+=================================+ | XLEN |...XLEN bytes of "extra field"...| (more-->) +---+---+=================================+ +=========================================+ |...original file name, zero-terminated...| (more-->) +=========================================+
35. 1 def original_filename(file_path) 2 File.open(file_path, "rb") do |f| 3 header = f.read(10) 4 magic, cm, flg, mtime, xfl, os = header.unpack("H4H2B8LH2C") 5 6 (magic == "1f8b") || raise("Invalid gzip header") 7 (cm == "08") || raise("Unknown compression method") 8 9 _, _, _, fcomment, fname, fextra, fhcrc, ftext = flg.split("") 10 11 if fextra == "1" 12 xlen = f.read(2).unpack1("S") 13 f.seek(xlen, IO::SEEK_CUR) 14 end 15 16 f.gets("\x00").unpack1("Z*") if fname == "1" 17 end 18 end
36. gzip - show original filename original_filename("test2.txt.gz") => "test.txt"
37. 1 def original_filename(file_path) 2 File.open(file_path, "rb") do |f| 3 header = f.read(10) 4 magic, cm, flg, mtime, xfl, os = header.unpack("H4H2B8LH2C") 5 6 (magic == "1f8b") || raise("Invalid gzip header") 7 (cm == "08") || raise("Unknown compression method") 8 9 _, _, _, fcomment, fname, fextra, fhcrc, ftext = flg.split("") 10 11 if fextra == "1" 12 xlen = f.read(2).unpack1("S") 13 f.seek(xlen, IO::SEEK_CUR) 14 end 15 16 f.gets("\x00").unpack1("Z*") if fname == "1" 17 end 18 end
38. 1 ['audio/x-ms-asx', [[0, 'ASF '], [0..64, '<ASX'], [0..64, '<asx'], [0..64, '<Asx']]], 2 ['application/annodex', [[0, 'OggS', [[28, "fishead\000", [[56..512, "CMML\000\000\000\000"]]]]]]], 3 ['application/dicom', [[128, 'DICM']]], 4 ['application/gnunet-directory', [[0, "\211GND\r\n\032\n"]]], 5 ['application/gzip', [[0, "\037\213"]]], 6 ['application/javascript', [[0, '#!/bin/gjs'], [0, '#! /bin/gjs'], [0, "eval \"exec /bin/ gjs"], [0, '#!/usr/bin/gjs'], [0, '#! /usr/bin/gjs'], [0, "eval \"exec /usr/bin/gjs"], [0, '#!/usr/ local/bin/gjs'], [0, '#! /usr/local/bin/gjs'], [0, "eval \"exec /usr/local/bin/gjs"], [2..16, '/bin/ env gjs']]], 7 ['application/mac-binhex40', [[11, 'must be converted with BinHex']]], 8 ['application/mathematica', [[0, '(************** Content-type: application/mathematica'], [100..256, 'This notebook can be used on any computer system with Mathematica'], [10..256, 'This is a Mathematica Notebook file. It contains ASCII text']]], 9 ['application/metalink+xml', [[0..256, "<metalink version=\"3.0\""]]], "\037\213" => "\u001F\x8B"
39. BinData - a better way
40. BinData - a better way https://github.com/dmendel/bindata "BinData provides a declarative way to read and write structured binary data." used by ~1300 repos
41. 1 class IPAddr < BinData::Primitive 2 array :octets, type: :uint8, initial_length: 4 3 4 def set(val) 5 self.octets = val.split(/\./).map(&:to_i) 6 end 7 8 def get 9 self.octets.map(&:to_s).join(".") 10 end 11 end IPAddr.new("192.168.1.1").to_binary_s => "\xC0\xA8\x01\x01"
42. 1 class IPAddr < BinData::Primitive 2 array :octets, type: :uint8, initial_length: 4 3 4 def set(val) 5 self.octets = val.split(/\./).map(&:to_i) 6 end 7 8 def get 9 self.octets.map(&:to_s).join(".") 10 end 11 end IPAddr.read("\xC0\xA8\x01\x01") => "192.168.1.1"
43. 1 class MacAddr < BinData::Primitive 2 array :octets, type: :uint8, initial_length: 6 3 4 def set(val) 5 self.octets = val.split(/:/).collect(&:to_i) 6 end 7 8 def get 9 octets.collect { |octet| "%02x" % octet }.join(":") 10 end 11 end MacAddr.new("00:01:02:03:04:05"). to_binary_s => "\x00\x01\x02\x03\x04\x05"
44. 1 class Gzip < BinData::Record 2 # Known compression methods 3 DEFLATE = 8 4 5 endian :little 6 7 uint16 :ident, asserted_value: 0x8b1f 8 uint8 :compression_method, asserted_value: DEFLATE 9 10 bit3 :freserved, asserted_value: 0 11 bit1 :fcomment 12 bit1 :ffile_name 13 bit1 :fextra 14 bit1 :fcrc16 15 bit1 :ftext 16 17 uint32 :mtime 18 uint8 :extra_flags 19 uint8 :os 20 21 struct :extra, onlyif: -> { fextra.nonzero? } do 22 uint16 :len 23 string :data, read_length: :len 24 end 25 stringz :file_name, onlyif: -> { ffile_name.nonzero? } 26 stringz :comment, onlyif: -> { fcomment.nonzero? } 27 uint16 :crc16, onlyif: -> { fcrc16.nonzero? } 28 29 # ignore rest so that we don't load everything into memory 30 end 1 def original_filename(file_path) 2 File.open(file_path, "rb") do |f| 3 header = f.read(10) 4 magic, cm, flg, mtime, xfl, os = header.unpack("H4H2B8LH2C") 5 6 (magic == "1f8b") || raise("Invalid gzip header") 7 (cm == "08") || raise("Unknown compression method") 8 9 _, _, _, fcomment, fname, fextra, fhcrc, ftext = flg.split("") 10 11 if fextra == "1" 12 xlen = f.read(2).unpack1("S") 13 f.seek(xlen, IO::SEEK_CUR) 14 end 15 16 f.gets("\x00").unpack1("Z*") if fname == "1" 17 end 18 end
45. Real life examples
46. 1 class Mbus::BCD4 < BinData::Primitive 2 bit4 :d3 3 bit4 :d4 4 bit4 :d1 5 bit4 :d2 6 7 def set(value) 8 self.d1 = (value / 10**3) % 10 9 self.d2 = (value / 10**2) % 10 10 self.d3 = (value / 10**1) % 10 11 self.d4 = (value / 10**0) % 10 12 end 13 14 def get 15 d1 * 10**3 + 16 d2 * 10**2 + 17 d3 * 10**1 + 18 d4 * 10**0 19 end 20 end
47. 1 class Mbus::DataInformationField < BinData::Record 2 bit1 :extension_bit 3 bit1 :storage_number_lsb 4 bit2 :function_field_code 5 bit4 :data_field_code 6 data_information_field_extension :data_information_field_extension, onlyif: -> { extension? } 7 8 # ... 9 end 1 class Mbus::DataInformationFieldExtension < BinData::Record 2 bit1 :extension_bit 3 bit1 :device_unit 4 bit2 :tariff 5 bit4 :storage_number 6 data_information_field_extension :data_information_field_extension, onlyif: -> { extension? } 7 8 # ... 9 end data_information_field.data_information_field_extension.data_information_field_extension....
49. 1 class Mbus::DataTypeI < BinData::Primitive 2 bit1 :leap_year 3 bit1 :dst 4 bit6 :second 5 6 bit1 :invalid 7 bit1 :dst_direction 8 bit6 :minute 9 10 bit3 :day_of_week 11 bit5 :hour 12 13 bit3 :year_lower 14 bit5 :day 15 16 bit4 :year_upper 17 bit4 :month 18 19 bit2 :dst_offset 20 bit6 :week_number 21 22 def get 23 Time.new(year, month, day, hour, minute, second) 24 end 25 26 def year 27 2000 + year_upper * 2**3 + year_lower 28 end 29 end
50. 1 class Mbus::AuthenticationAndFragmentationLayer < BinData::Record 2 include Mbus::CI 3 4 # AFL-Length [OMSvol2:4.1.2 6.2.1] 5 uint8 :afll 6 # Fragmentation Control Field [OMSvol2:4.1.2 6.2.1] 7 fragmentation_control_field :fcl 8 # Message Control Field [OMSvol2:4.1.2 6.2.1] 9 uint8 :mcl, onlyif: -> { fcl.mclp == 1 } 10 # Key Information Field [OMSvol2:4.1.2 6.2.1] 11 int16le :ki, onlyif: -> { fcl.kip == 1 } 12 # Message Counter Field [OMSvol2:4.1.2 6.2.1] 13 int32le :message_counter_c, onlyif: -> { fcl.mcrp == 1 } 14 # Message Authentication Code [OMSvol2:4.1.2 6.2.1] 15 string :cmac, length: 8, onlyif: -> { fcl.macp == 1 } 16 # Message Length Field [OMSvol2:4.1.2 6.2.1] 17 int16le :ml, onlyif: -> { fcl.mlp == 1 } 18 19 uint8 :next_control_info 20 count_bytes_remaining :bytes_remaining 21 transport_layer :transport_layer, read_length: :bytes_remaining, onlyif: :ci_transport_layer? 22 23 # ... 24 end
51. Recap Definitely doable in Ruby Even quite fun! Simple operations -> pack/unpack BinData saved our lives
