Introduction to Functional-Reactive Programming v2

v2.0

Transcript

1. Grzegorz Dyrda
   Geeky Devs Studio
   Introduction to
   Functional-Reactive
   Programming


   View Slide

2. Functional-Reactive
   Programming


   View Slide

3. Functional-Reactive
   Programming
   Why?


   View Slide

4. Why?
   • Java 9 + Reactive Streams (JEP 266)
   • Spring WebFlux, Eclipse Vert.x
   • Angular, Cycle.js, React (Native)
   • Android Architecture Components,
   Room, Retrofit… Airbnb MvRx


   View Slide

5. Functional-Reactive


   View Slide

6. Functional + Reactive


   View Slide

7. Functional
   Part 1:


   View Slide

8. You cannot understand
   Functional-Reactive programming,
   if you don’t understand
   Functional programming.


   View Slide

9. What is Functional Programming?


   View Slide

10. Functional Programming
    Programming style in which we avoid
    sharing state and data mutation,
    in favor of composing functions and
    passing data from one to another.


    View Slide

11. Functional Programming
    …is about moving from

    the imperative

    to declarative style.


    View Slide

12. The world’s most popular
    functional language is…
    Excel


    View Slide

13. =IF(A6="", IF(C5<>"", C5, IFERROR(MATCH("?*", A6:$A$20, 0)-1,
    ROWS(A6:$A$20))&" in "&VLOOKUP(A5,$H$6:$I$8, 2, 0)), "")
    Excel
    =IF(MONTH($C$3)<>MONTH($C$3-(WEEKDAY($C$3;1)-($A$1-1))-
    IF((WEEKDAY($C$3;1)-($A$1-1))<=0;7;0)+(ROW(F7)-J3-
    ROW($D$6))*7+(COLUMN(F7)-COLUMN($D$6)+1));"";$C$3-
    (WEEKDAY($C$3;1)-($A$1-1))-IF((WEEKDAY($C$3;1)-
    ($A$1-1))<=0;7;0)+(ROW(F7)-J3-ROW($D$6))*7+(COLUMN(F7)-
    COLUMN($D$6)+1))


    View Slide

14. Language Support


    View Slide

15. • Functions as first-class citizens
    • Higher-order functions
    • Lambda expressions
    • Immutable data types
    • Functions are closures
    Language Support
    JAVA 8+
    APPROVED


    View Slide

16. Example


    View Slide

17. Client says:
    “Make a sum of all our prices

    that are higher than $20,

    discounted by 10%”
    Example


    View Slide

18. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example


    View Slide

19. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    var sum = 0.0
    for (var i = 0; i <= prices.size; i++) {

    if (price[i] > 20) {

    sum += price[i] * 0.9

    }}

    }}
    val prices = listOf(20, 12, 15, 21, 25, 28, 30)


    View Slide

20. var sum = 0.0
    for (var i = 0; i < prices.size; i++) {

    if (price[i] > 20) {

    sum += price[i] * 0.9

    }}

    }}
    Example
    val prices = listOf(20, 12, 15, 21, 25, 28, 30)


    View Slide

21. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    var sum = 0.0
    for (price in prices) {

    if (price > 20) {

    sum += price * 0.9

    }}

    }}


    View Slide

22. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    var sum = 0.0
    for (price in prices) {

    if (price > 20) {

    sum += price * 0.9

    }}

    }}


    View Slide

23. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

24. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

25. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

26. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

27. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

28. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    Important:
    1. No import = stdlib
    2. Cross-platform


    View Slide

29. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

30. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    // Returns list containing only elements matching [predicate]
    fun filter(predicate: (T) -> Boolean): List


    View Slide

31. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    // Returns list containing only elements matching [predicate]
    fun filter(predicate: (T) -> Boolean): List


    View Slide

32. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    // Returns list containing elements transformed by [transform]
    fun map(transform: (T) -> R): List
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

33. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    // Returns list containing elements transformed by [transform]
    fun map(transform: (T) -> R): List
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()


    View Slide

34. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    Single, consistent, higher-level API.
    More readable & closer to the Business Intent


    View Slide

35. val prices = listOf(20, 12, 15, 21, 25, 28, 30)
    Example
    val sum = prices

    .filter { price -> price > 20 }

    .map { price -> price * 0.9 }

    .sum()
    var sum = 0.0
    for (price in prices) {

    if (price > 20) {

    sum += price * 0.9

    }}

    }}


    View Slide

36. Another
    Example


    View Slide

37. You’re a Blog admin:
    “Calculate average blogpost length
    of all your blog’s Users
    that speak Polish”
    Example


    View Slide

38. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example


    View Slide

39. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val users = db.getAllUsers()


    View Slide

40. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = ???
    val users = db.getAllUsers()


    View Slide

41. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users
    val users = db.getAllUsers()


    View Slide

42. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { ??? }}
    val users = db.getAllUsers()


    View Slide

43. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }}
    val users = db.getAllUsers()


    View Slide

44. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .map { ??? }}
    val users = db.getAllUsers()


    View Slide

45. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .map { user -> user.posts }}
    val users = db.getAllUsers()


    View Slide

46. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .map { user -> user.posts }
    // Return type is: List>
    // But we need: List
    val users = db.getAllUsers()


    View Slide

47. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .map { user -> user.posts }
    val users = db.getAllUsers()


    View Slide

48. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }
    val users = db.getAllUsers()


    View Slide

49. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }
    // Returns a single list with all elements yielded from
    // [transform] invoked on on each element of original collection.
    fun flatMap(transform: (T) -> Iterable): List
    val users = db.getAllUsers()


    View Slide

50. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }
    // Returns a single list with all elements yielded from
    // [transform] invoked on on each element of original collection.
    fun flatMap(transform: (T) -> Iterable): List
    val users = db.getAllUsers()


    View Slide

51. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }
    // Returns a single list with all elements yielded from
    // [transform] invoked on on each element of original collection.
    fun flatMap(transform: (T) -> Iterable): List
    val users = db.getAllUsers()


    View Slide

52. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }
    val users = db.getAllUsers()


    View Slide

53. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }

    .map { ??? }}
    val users = db.getAllUsers()


    View Slide

54. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }}
    val users = db.getAllUsers()


    View Slide

55. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .average()
    val users = db.getAllUsers()


    View Slide

56. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .average()
    val users = db.getAllUsers()
    // Easy to maintain and modify


    View Slide

57. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .filter { user -> user.language == "PL" }

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .average()
    val users = db.getAllUsers()


    View Slide

58. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .average()
    val users = db.getAllUsers()


    View Slide

59. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .average()
    val users = db.getAllUsers()


    View Slide

60. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }
    .map { post -> post.body.length }
    .count()
    val users = db.getAllUsers()


    View Slide

61. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .reduce { acc, length -> acc + length }
    val users = db.getAllUsers()


    View Slide

62. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .reduce { acc, length -> acc + length }}
    val users = db.getAllUsers()
    // Returns a single value computed by accumulating values
    // returned from applying [operation] to each element.
    fun reduce(operation: (acc: S, T) -> S): S


    View Slide

63. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .reduce { acc, length -> acc + length }}
    val users = db.getAllUsers()
    // Returns a single value computed by accumulating values
    // returned from applying [operation] to each element.
    fun reduce(operation: (acc: S, T) -> S): S


    View Slide

64. data class Post(val title: String, val body: String)

    data class User(val language: String, val posts: List)
    Example
    val avgPolishPostLength = users

    .take(100)

    .flatMap { user -> user.posts }

    .map { post -> post.body.length }

    .fold(0) { acc, _ -> acc + 1 }}
    val users = db.getAllUsers()
    // Accumulates value starting with [initial] and applying
    // [operation] to current accumulator value and each element.
    fun fold(initial: R, operation: (acc: R, T) -> R): R


    View Slide

65. Benefits


    View Slide

66. • No explicit mutation, reassignment,
    iteration etc. = less error prone
    • Low-level details controlled by the library
    = may be optimized under the hood
    • More expressive, more readable
    • Easy to enhance & modify the logic
    • Closer to the business intent
    Benefits


    View Slide

67. Functional
    -vs-
    Object-Oriented


    View Slide

68. Functional
    -vs-
    Object-Oriented


    View Slide

69. Functional
    +
    Object-Oriented


    View Slide

70. // Returns list containing only elements matching [predicate]
    fun filter(predicate: (T) -> Boolean): List
    // Returns list containing elements transformed by [transform]
    fun map(transform: (T) -> R): List
    // Flattens nested lists into single list
    fun flatMap(transform: (T) -> Iterable): List
    // Accumulates value by applying [operation]
    fun reduce(operation: (acc: S, T) -> S): S
    // Accumulates value, starting with [initial]
    fun fold(initial: R, operation: (acc: R, T) -> R): R
    Common Specialized Functions


    View Slide

71. View Slide

72. View Slide

73. Functional…


    View Slide

74. Functional + Reactive


    View Slide

75. Reactive
    Part 2:


    View Slide

76. What does is mean
    to be “Reactive”?


    View Slide

77. var a = 1
    var b = 2
    var c = a + b
    print("c = $c")
    What does is mean
    to be “Reactive”?
    // ???


    View Slide

78. var a = 1
    var b = 2
    var c = a + b
    print("c = $c")
    What does is mean
    to be “Reactive”?
    // c = 3


    View Slide

79. var a = 1
    var b = 2
    var c = a + b
    a = 2
    print("c = $c")
    What does is mean
    to be “Reactive”?
    // ???


    View Slide

80. var a = 1
    var b = 2
    var c = a + b
    a = 2
    print("c = $c")
    What does is mean
    to be “Reactive”?
    // c = 3


    View Slide

81. The world’s most popular
    reactive system is…
    Excel


    View Slide

82. Excel


    View Slide

83. What is Reactive Programming?


    View Slide

84. Reactive Programming
    Programming with

    Asynchronous Event Streams


    View Slide

85. Reactive Programming
    Programming with

    Asynchronous Event Streams


    View Slide

86. Observer Pattern
    on Steroids
    Reactive Programming


    View Slide

87. Observer Pattern
    on Functional Steroids
    Reactive Programming


    View Slide

88. 1 5 12 3 7 4
    This can be anything: Number,
    Object, Blog Post etc.


    View Slide

89. 1
    filter(x > 4)
    5 12 3 7 4


    View Slide

90. 1
    filter(x > 4)
    5 12 7
    5 12 3 7 4


    View Slide

91. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    5 12 3 7 4


    View Slide

92. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

93. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4
    So far everything was…

    Synchronous


    View Slide

94. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4
    Introducing…

    Time


    View Slide

95. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

96. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

97. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

98. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

99. 1
    filter(x > 4)
    5 12 7
    map(x + 2)
    7 14 9
    5 12 3 7 4


    View Slide

100. 1
     filter(x > 4)
     5 12 7
     map(x + 2)
     7 14 9
     5 12 3 7 4


     View Slide

101. 5 12 7
     map(x + 2)
     (Asynchronous Event)
     Stream
     Events
     Operator


     View Slide

102. 5 12 7
     map(x + 2)
     Stream
     Events
     Infinite
     Operator


     View Slide

103. 5 12 7
     map(x + 2)
     Stream
     Events
     Error
     Operator


     View Slide

104. 5 12 7
     map(x + 2)
     Stream
     Events
     Complete
     Operator


     View Slide

105. Implementation


     View Slide

106. Akka
     Reactor
     Reactive Extensions
     Vert.x
     xstream
     Implementation


     View Slide

107. Akka
     Reactor
     Reactive Extensions
     Vert.x
     xstream
     Implementation


     View Slide

108. Rx
     Implementation


     View Slide

109. • RxJava
     • RxJS
     • Rx.NET
     • RxScala
     • RxClojure
     • RxCpp
     Implementation
     • RxPython
     • RxGo
     • RxKotlin
     • RxSwift
     • RxPHP
     • RxDart


     View Slide

110. Stream


     View Slide

111. Stream
     Observable


     View Slide

112. Stream
     Observable
     List
     -vs-


     View Slide

113. Creating a Stream


     View Slide

114. Observable.just(1)
     Observable.just(true)
     Observable.just(user)
     Observable.just("one", "two", "three")
     Creating a Stream
     Observable.fromIterable(users)
     Observable.fromArray(usersArray)
     Observable.fromCallable(this::sendRequest)
     Observable.fromFuture(future)
     Observable.defer(...)
     Observable.create(...)


     View Slide

115. Observing a Stream


     View Slide

116. Observable.just(1))
     Observing a Stream
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = 1


     View Slide

117. Observing a Stream
     // Subscribes the given Observer to this Observable instance.
     fun subscribe(observer: Observer): Unit
     interface Observer {

     fun onNext(t: T)

     fun onError(e: Throwable)

     fun onComplete()
     ...

     }}
     // Subscribes to an ObservableSource and provides callbacks.
     fun subscribe(onNext: (T) -> Unit,
     onError: (Throwable) -> Unit,
     onComplete: () -> Unit): Unit


     View Slide

118. Observable.just(1))
     Observing a Stream
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = 1


     View Slide

119. Observable.just(true))
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = true
     Observing a Stream


     View Slide

120. Observable.just(user))
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = User(language="PL",posts=...)
     Observing a Stream


     View Slide

121. Observable.just("one", "two", "three")
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = one
     // Item = two
     // Item = three
     Observing a Stream


     View Slide

122. Observable.fromIterable(users))
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = User(language="PL",posts=...)
     // Item = User(language="EN",posts=...)
     // Item = User(language="PL",posts=...)
     // Item = User(language="PL",posts=...)
     ...
     Observing a Stream


     View Slide

123. Observable.fromIterable(users))
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = User(language="PL",posts=...)
     // Item = User(language="EN",posts=...)
     // Item = User(language="PL",posts=...)
     // Item = User(language="PL",posts=...)
     ...
     Where are my Steroids?
     Observing a Stream


     View Slide

124. Transforming a Stream


     View Slide

125. Observable.just("5", "8", "3", "7")
     .subscribe { item ->

     print("Item = $item")

     }}
     Transforming a Stream


     View Slide

126. Observable.just("5", "8", "3", "7")
     .map(String::toInt)
     .subscribe { item ->

     print("Item = $item")

     }}
     Transforming a Stream


     View Slide

127. Observable.just("5", "8", "3", "7")
     .map(String::toInt)
     .filter { item -> item > 5 }
     .subscribe { item ->

     print("Item = $item")

     }}
     // Item = 8
     // Item = 7
     Transforming a Stream


     View Slide

128. View Slide

129. “There’s an App for that”
     Apple, 2009


     View Slide

130. “There’s an Operator for that”
     Reactive Extensions, 2018


     View Slide

131. ReactiveX Operators
     Creating:
     • create
     • defer
     • empty
     • error
     • fromArray
     • fromCallable
     • fromFuture
     • interval
     • just
     • …
     Transform/Filter:
     • buffer
     • flatMap
     • groupBy
     • map
     • scan
     • window
     • debounce
     • distinct
     • filter
     • …
     Combining:
     • combineLatest
     • withLatestFrom
     • merge
     • switch
     • zip
     Threading:
     • subscribeOn
     • observeOn
     • …


     View Slide

132. Introducing Time


     View Slide

133. Observable.interval(1, TimeUnit.SECONDS)
     Interval
     .subscribe { item ->

     print("Item = $item")

     }}
     //00:00: Item = 0
     //00:01: Item = 1
     //00:02: Item = 2
     //00:03: Item = 3
     //00:04: Item = 4
     //...


     View Slide

134. Observable.interval(1, TimeUnit.SECONDS)
     Interval
     .map { item -> item * item }
     .subscribe { item ->

     print("Item = $item")

     }}


     View Slide

135. Observable.interval(1, TimeUnit.SECONDS)
     Interval
     .map { item -> item * item }.
     .take(3)
     .subscribe { item ->

     print("Item = $item")

     }}
     //00:00: Item = 0
     //00:01: Item = 1
     //00:02: Item = 4


     View Slide

136. // RxBinding
     RxView.clicks(button) // Observable
     .map { click -> 1 }
     .scan { acc, next -> acc + next }
     UI Events
     // Similar to reduce(), but accumulates values over time,
     // each time passing the result of [operation] downstream.
     fun scan(operation: (acc: T, T) -> T): Observable


     View Slide

137. // RxBinding
     RxView.clicks(button) // Observable
     .map { click -> 1 }
     .scan { acc, next -> acc + next }
     UI Events
     .subscribe { count ->

     print("Count = $count")

     }
     // Count = 1
     // Count = 2
     // Count = 3
     // Count = 4
     // ...


     View Slide

138. // Retrofit
     myService.getUsers() // Observable
     .map { user -> user.posts.size }
     .reduce { acc, next -> acc + next }
     Network Requests
     .subscribe { count ->

     print("Post count = $count")

     }
     // Post count = 120


     View Slide

139. Threading


     View Slide

140. fun fetchUser(): User { /* fetch from network */ }
     Threading
     Observable.fromCallable(this::fetchUser)
     .subscribe { user ->

     print("User = $user")

     }}
     // Error: Network on the Main Thread!


     View Slide

141. fun fetchUser(): User { /* fetch from network */ }
     Threading
     Observable.fromCallable(this::fetchUser)
     .subscribe { user ->

     print("User = $user")

     }}
     .subscribeOn(Schedulers.io())


     View Slide

142. fun fetchUser(): User { /* fetch from network */ }
     Threading
     Observable.fromCallable(this::fetchUser)
     .subscribe { user ->

     print("User = $user")

     }}
     .subscribeOn(Schedulers.io())


     View Slide

143. fun fetchUser(): User { /* fetch from network */ }
     Threading
     Observable.fromCallable(this::fetchUser)
     .subscribe { user ->

     print("User = $user")

     }}
     .subscribeOn(Schedulers.io())


     View Slide

144. fun fetchUser(): User { /* fetch from network */ }
     Threading
     Observable.fromCallable(this::fetchUser)
     .subscribeOn(Schedulers.io())
     .subscribe { user ->
     statusLabel.text = user.firstName

     }}
     // Error: Accessing UI from the background thread!


     View Slide

145. fun fetchUser(): User { /* fetch from network */ }
     Threading
     .subscribe { user ->
     statusLabel.text = user.firstName

     }}
     Observable.fromCallable(this::fetchUser)
     .subscribeOn(Schedulers.io())
     .observeOn(AndroidSchedulers.mainThread())


     View Slide

146. fun fetchUser(): User { /* fetch from network */ }
     Threading
     .subscribe { user ->
     statusLabel.text = user.firstName

     }}
     Observable.fromCallable(this::fetchUser)
     .subscribeOn(Schedulers.io())
     .observeOn(AndroidSchedulers.mainThread())


     View Slide

147. fun fetchUser(): User { /* fetch from network */ }
     Threading
     .subscribe { user ->
     statusLabel.text = user.firstName

     }}
     Observable.fromCallable(this::fetchUser)
     .subscribeOn(Schedulers.io())
     .observeOn(AndroidSchedulers.mainThread())
     // OK


     View Slide

148. Combining Streams


     View Slide

149. // Task: perform network request after each click
     Combining Streams
     // Return type: Observable>
     // But we want: Observable
     val buttonClicks = RxView.clicks(button)
     val userInfoRequest = myService.getUserInfo()
     buttonClicks
     .map { click -> myService.getUserInfo() }


     View Slide

150. // Returns Observable that emits all items emitted by
     // Observables returned by [mapper].
     fun flatMap(mapper: (T) -> Observable): Observable
     buttonClicks
     .flatMap { click -> myService.getUserInfo() }
     val buttonClicks = RxView.clicks(button)
     val userInfoRequest = myService.getUserInfo()
     // Task: perform network request after each click
     Combining Streams


     View Slide

151. .map { user -> user.firstName }
     .subscribe { firstName ->

     print("firstName = $firstName")

     }
     // firstName = John
     val buttonClicks = RxView.clicks(button)
     val userInfoRequest = myService.getUserInfo()
     buttonClicks
     .flatMap { click -> myService.getUserInfo() }
     // Task: perform network request after each click
     Combining Streams


     View Slide

152. // Task: do the same thing on btn1 & btn2 click
     val btn1Clicks = RxView.clicks(button1)
     val btn2Clicks = RxView.clicks(button2)
     btn1Clicks
     .map { click -> "Click!" }
     .subscribe { msg ->

     print("msg = $msg")

     }}
     Combining Streams


     View Slide

153. // Task: do the same thing on btn1 & btn2 click
     val btn1Clicks = RxView.clicks(button1)
     val btn2Clicks = RxView.clicks(button2)
     Observable.merge(btn1Clicks, btn2Clicks)
     .map { click -> "Click!" }
     .subscribe { msg ->

     print("msg = $msg")

     }}
     // Merges two (or more) Observables into a single one.
     fun merge(s1: Observable, s2: Observable): Observable
     Combining Streams


     View Slide

154. Combining Streams


     View Slide

155. Combining Streams


     View Slide

156. Netflix


     View Slide

157. Netflix


     View Slide

158. Netflix


     View Slide

159. Netflix


     View Slide

160. Netflix


     View Slide

161. Netflix


     View Slide

162. Netflix


     View Slide

163. Netflix


     View Slide

164. Conclusions


     View Slide

165. • FRP is great for composing/
     orchestrating multiple Event streams
     • “There’s an Operator for that”
     • Declarative Threading, Error handling,
     Cancellation of async tasks etc.
     • Do not overuse for simple tasks
     Conclusions


     View Slide

166. How to Start?


     View Slide

167. How to Start?
     • ReactiveX.io
     • github.com/ReactiveX
     • rxmarbles.com
     • geekydevs.com/rx


     View Slide

168. Thank You


     View Slide

169. Thank You
     Any questions?


     View Slide
