REST API edge cases

If you're lucky you can use so-called REST APIs in your daily work. Except, some of the largest (social) APIs make mistakes against the basic rules of REST. If you happen to be in the process of designing a REST API, you better refresh your knowledge on those REST principles. This talk will explain some quick REST API principles with lots of real-life examples, followed by some edge case designs including soft-deletes and "likes" as sub resources.

Presented at Laravel Brussels meetup in Antwerp.

Transcript

1. REST API edge cases
   Soft-deletes, likes/stars/tags


   View Slide

2. Hi, my name is Hannes.


   View Slide

3. laravel


   View Slide

4. mongodb


   View Slide

5. couchdb


   View Slide

6. madewithlove


   View Slide

7. • Developer
   • Laravel since 4.0.0-BETA2
   • madewithlove
   ABOUT ME


   View Slide

8. REST API


   View Slide

9. A Github user stars a repository


   View Slide

10. STAR /repos/username/repo…


    View Slide

11. A user archives an email


    View Slide

12. ARCHIVE /emails/159803922


    View Slide

13. UNARCHIVE /emails/159803922


    View Slide

14. • REST basics
    • Case study
    • How it’s done
    REST API FOR LIKES


    View Slide

15. 1. REST basics


    View Slide

16. View Slide

17. REST BASICS - SOAP
    POST /SomeService.aspx
    Host: example.org


    View Slide

18. REST BASICS - SOAP

    xmlns:soap="http://www.w3.org/2001/…"
    soap:encodingStyle="http://www.w3.org/2001/…">


    IBM





    View Slide

19. REST BASICS - REST EQUIVALENT
    GET /stocks/ibm HTTP/1.1
    Host: example.org
    Accept: application/xml


    View Slide

20. CRUD - HTTP verbs


    View Slide

21. REST BASICS - HTTP METHOD - CREATE
    Create: POST


    View Slide

22. REST BASICS - HTTP METHODS - CREATE
    POST /notes HTTP/1.1
    Host: example.org


    View Slide

23. REST BASICS - HTTP METHODS - CREATE
    Create: POST or PUT


    View Slide

24. REST BASICS - HTTP METHODS - CREATE
    PUT /notes/meeting1-report HTTP/1.1
    Host: example.org


    View Slide

25. REST BASICS - HTTP METHODS - READ
    Read: GET


    View Slide

26. REST BASICS - HTTP METHODS - READ
    GET /users/driesvints HTTP/1.1
    Host: api.github.com
    HTTP/1.1 200 OK


    View Slide

27. REST BASICS - HTTP METHODS - UPDATE
    Update: PUT


    View Slide

28. REST BASICS - HTTP METHODS - UPDATE
    PUT /users/driesvints HTTP/1.1
    Host: api.github.com
    {
    "login": "driesvints",
    "id": 594614,
    "avatar_url": "https://avatars.gith…",
    "email": "dries@beatswitch.com",
    …


    View Slide

29. REST BASICS - HTTP METHODS - UPDATE
    Update: PUT or PATCH


    View Slide

30. REST BASICS - HTTP METHODS - UPDATE
    PATCH /users/driesvints HTTP/1.1
    Host: api.github.com
    email=dries@beatswitch.com


    View Slide

31. REST BASICS - HTTP METHODS - DELETE
    Delete: DELETE


    View Slide

32. REST BASICS - HTTP METHODS - DELETE
    DELETE /repos/driesvints/docs HTTP/1.1
    Host: api.github.com
    HTTP/1.1 204 No Content


    View Slide

33. Headers


    View Slide

34. /followers/ids.json
    REST BASICS - HTTP HEADERS - CONTENT TYPE


    View Slide

35. REST BASICS - HTTP HEADERS - CONTENT TYPE
    Accept:
    application/json


    View Slide

36. https://api.twitter.com/1.0/
    https://api.twitter.com/1.1/
    REST BASICS - HTTP HEADERS - VERSION


    View Slide

37. Accept:
    application/vnd.github.v3+json
    REST BASICS - HTTP HEADERS - VERSION


    View Slide

38. REST BASICS - HTTP HEADERS - AUTHENTICATION
    https://api.instagram.com/v1/users/
    self?access_token=r4nd0m0123456789


    View Slide

39. GET /users/driesvints HTTP/1.1
    Host: api.github.com
    Authorization: Bearer r4nd0m0123456789
    REST BASICS - HTTP HEADERS - AUTHENTICATION


    View Slide

40. REST BASICS - HTTP HEADERS - RATE LIMIT
    https://api.twitter.com/1.1/
    application/rate_limit_status.json


    View Slide

41. REST BASICS - HTTP HEADERS - RATE LIMIT - GH
    HTTP/1.1 403 Forbidden
    X-RateLimit-Limit: 60
    X-RateLimit-Remaining: 0
    X-RateLimit-Reset: 1377013266


    View Slide

42. REST BASICS - HTTP HEADERS - RATE LIMIT
    HTTP/1.1 429 Too Many Requests
    X-RateLimit-Limit: 60
    X-RateLimit-Remaining: 0
    X-RateLimit-Reset: 1377013266


    View Slide

43. HTTP/1.1 429 Too Many Requests
    X-RateLimit-UserLimit: 60
    X-RateLimit-UserRemaining: 0
    X-RateLimit-UserReset: 1377…
    REST BASICS - HTTP HEADERS - RATE LIMIT


    View Slide

44. HTTP/1.1 429 Too Many Requests
    X-RateLimit-ClientLimit: 60
    X-RateLimit-ClientRemaining: 0
    X-RateLimit-ClientReset: 1377…
    REST BASICS - HTTP HEADERS - RATE LIMIT


    View Slide

45. URL scheme


    View Slide

46. REST BASICS - URL SCHEME
    Required params = URL segments


    View Slide

47. REST BASICS - URL SCHEME
    Optional params = GET params


    View Slide

48. REST BASICS - URL SCHEME
    /orgs/{org_slug}/report/
    {start_date}/{end_date}


    View Slide

49. REST BASICS - URL SCHEME
    /orgs/mwl/report/
    2014-01-01/2014-06-30


    View Slide

50. REST BASICS - URL SCHEME
    /orgs/mwl/report
    ?start_date=2014-01-01
    &end_date=2014-06-30


    View Slide

51. REST BASICS - RECAP
    • HTTP Verbs
    • HTTP Headers
    • Required vs. Optional


    View Slide

52. 2. Case study


    View Slide

53. CASE STUDY - TWITTER
    Twitter favorites


    View Slide

54. CASE STUDY - TWITTER - FAVORITED?
    GET /1.1/statuses/show/51673… HTTP/1.1
    Host: api.twitter.com
    {
    "favorited": true,
    …


    View Slide

55. CASE STUDY - TWITTER - FAVORITE
    POST /1.1/favorites/create.json?id=51673… HTTP/1.1
    Host: api.twitter.com


    View Slide

56. CASE STUDY - TWITTER - UNFAVORITE
    POST /1.1/favorites/destroy.json?id=51673… HTTP/1.1
    Host: api.twitter.com


    View Slide

57. CASE STUDY - GITHUB
    Github stargazers


    View Slide

58. CASE STUDY - GITHUB - STARRED?
    GET /user/starred/:owner/:repo HTTP/1.1
    Host: api.github.com
    HTTP/1.1 204 No Content
    HTTP/1.1 404 Not found


    View Slide

59. CASE STUDY - GITHUB - STAR
    PUT /user/starred/:owner/:repo HTTP/1.1
    Host: api.github.com
    HTTP/1.1 204 No Content


    View Slide

60. CASE STUDY - GITHUB - UNSTAR
    DELETE /user/starred/:owner/:repo HTTP/1.1
    Host: api.github.com
    HTTP/1.1 204 No Content


    View Slide

61. CASE STUDY - FOURSQUARE
    Foursquare likes


    View Slide

62. CASE STUDY - FOURSQUARE - LIKED?
    GET /v2/venues/4b292… HTTP/1.1
    Host: api.foursquare.com
    {
    "like": true,
    …


    View Slide

63. CASE STUDY - FOURSQUARE - LIKED?
    GET /v2/venues/4b292… HTTP/1.1
    Host: api.foursquare.com
    {
    "dislike": true,
    …


    View Slide

64. CASE STUDY - FOURSQUARE - LIKE
    POST /v2/venues/4b292…/like HTTP/1.1
    Host: api.foursquare.com
    set=1


    View Slide

65. CASE STUDY - FOURSQUARE - UNLIKE
    POST /v2/venues/4b292…/like HTTP/1.1
    Host: api.foursquare.com
    set=0


    View Slide

66. CASE STUDY - FOURSQUARE - LIKE
    POST /v2/checkins/4b292…/like HTTP/1.1
    Host: api.foursquare.com
    set=1


    View Slide

67. CASE STUDY - FOURSQUARE - UNLIKE
    POST /v2/checkins/4b292…/like HTTP/1.1
    Host: api.foursquare.com
    set=0


    View Slide

68. CASE STUDY - INSTAGRAM
    Instagram likes


    View Slide

69. CASE STUDY - INSTAGRAM - LIKED?
    GET /v1/media/4b292…/likes HTTP/1.1
    Host: api.instagram.com
    {
    "data": [
    {
    "username": "gilbert_west",
    "id": "586708382",
    …


    View Slide

70. CASE STUDY - INSTAGRAM - LIKE
    POST /v1/media/4b292…/likes HTTP/1.1
    Host: api.instagram.com


    View Slide

71. CASE STUDY - INSTAGRAM - UNLIKE
    DELETE /v1/media/4b292…/likes HTTP/1.1
    Host: api.instagram.com


    View Slide

72. 3. How it’s done


    View Slide

73. In my opinion


    View Slide

74. Github + Instagram
    HOW IT’S DONE - LIKES


    View Slide

75. HOW IT’S DONE - LIKES - LIKED?
    GET /notes/{id} HTTP/1.1
    Host: example.org
    {
    "liked": true,
    …


    View Slide

76. HOW IT’S DONE - LIKES - PEOPLE WHO LIKED
    GET /notes/{id}/likes HTTP/1.1
    Host: example.org


    View Slide

77. HOW IT’S DONE - LIKES - LIKE
    PATCH /notes/{id} HTTP/1.1
    Host: example.org
    liked=true


    View Slide

78. HOW IT’S DONE - LIKES - UNLIKE
    PATCH /notes/{id} HTTP/1.1
    Host: example.org
    liked=false


    View Slide

79. Soft delete?
    DELETE /endpoint


    View Slide

80. HOW IT’S DONE - SOFT DELETE
    DELETE /notes/1234 HTTP/1.1
    Host: example.org


    View Slide

81. HOW IT’S DONE - SOFT DELETE
    GET /deleted_notes HTTP/1.1
    Host: example.org


    View Slide

82. HOW IT’S DONE - SOFT DELETE
    PATCH /deleted_notes/1234 HTTP/1.1
    Host: example.org
    deleted=false


    View Slide

83. Archiving?


    View Slide

84. HOW IT’S DONE - ARCHIVING
    PATCH /notes/1234 HTTP/1.1
    Host: example.org
    archived=true


    View Slide

85. HOW IT’S DONE - ARCHIVING
    GET /archived_notes HTTP/1.1
    Host: example.org


    View Slide

86. HOW IT’S DONE - ARCHIVING
    PATCH /archived_notes/1234 HTTP/1.1
    Host: example.org
    archived=false


    View Slide

87. • Likes
    • Soft deletes
    • Archiving
    RECAP - EDGE CASES


    View Slide

88. • REST basics
    • Case study
    • How it’s done
    RECAP


    View Slide

89. View Slide

90. View Slide

91. Questions/discussions


    View Slide

92. Thank you!
    @hannesvdvreken


    View Slide

93. • http:/
    /wikipedia.org/wiki/SOAP
    • http:/
    /meetup.com/mongodb-belgium
    • http:/
    /mwl.be
    • http:/
    /shop.oreilly.com/product/0636920028468.do
    • https:/
    /leanpub.com/build-apis-you-wont-hate
    • https:/
    /dev.twitter.com
    • http:/
    /instagram.com/developer
    • https:/
    /developer.github.com
    • https:/
    /developer.foursquare.com
    REFERENCES


    View Slide
