Helium On Air Episode 4 - The Helium Hardware Suite

These slides were used in Episode 4 of Helium On Air. Mark Phillips and Pat Hickey walk users through the suite of hardware tools that Helium offers to developers to make prototyping easy and fast.

Watch here: https://www.youtube.com/watch?v=tX33wj71qlk

Avatar for Helium

Helium

February 10, 2017
Tweet

More Decks by Helium

Other Decks in Technology

Transcript

  1. Helium Atom Development
 Board Helium Element Helium Cloud Helium Technology

    Overview Business Intelligence Alerting / Visualizations Data Warehouse Factory Environment
  2. Helium Atom Development Board Helium Element
 Access Point Analog
 Extension

    Board Digital
 Extension Board 4-20mA Smart Sensor Adapter Helium Hardware Overview
  3. Prototyping Helium’s hardware suite makes it dead simple to prototype

    sensing applications. 1. Select a sensor 2. Plug it into a Helium Dev Board 3. Write Helium Script 4. Deploy
  4. Helium Element Access Point • Helium Element Access Point routes

    data for any number of sensors in range • Connects to Helium Cloud via Ethernet and Cellular • Small form factor with huge coverage range • Zero configuration; deploys in seconds • Routes encrypted, bi-directional data • Enables any type of wireless sensing on Helium.
  5. Helium Atom Development Board • Primary prototyping platform for Helium

    • Built around the Helium Atom; dual band 802.15.4 wireless, compute / scripting, security, flash storage, and much more. • Speaks I2C natively; can support multiple I2C sensors in parallel
  6. Helium Analog Extension Board • Extends Helium Dev Board to

    make analog sensing possible. • Supports 0-24V • Can also measure Current: 0-500mA • Scriptable with Helium Script • Popular analog sensing types: Accelerometers, Light, Pressure, Sound, Temp / Thermistors.
  7. Helium Digital Extension Board • Adds Digital sensing capabilities to

    Helium Dev Board. • 10 Pin Sensor Bus for easy connection to Helium Dev Board with ribbon cable. • 16 Digital GPIOs; all software-configurable via Helium Script • In Script, set interrupts on any digital pin and have them fire interrupts to Dev Board.
  8. Helium 4-20mA Smart Sensor Adapter • Opens Helium platform to

    millions of existing industrial sensors already on the market and/or in the field. • Turns any sensor that outputs 4-20mA into a wireless device. (Uses analog extension board under the hood.) • Scriptable with Helium Script • Popular 4-20mA sensing types: vibration, acceleration, pressure, C02/VOCs, fill level, etc.
