# Extensible Effects: beyond the Monad Transformers

This presentation includes these following three things:
1. Monad
2. Monad Transformers
3. Extensible-Effects
Main topics are how to use atnos-eff and comparison between mtl and eff.

October 31, 2019

## Transcript

1. Extensible-Effects:
beyond the Monad Transformers
Hiroki Fujino
Unipos GmbH
1

2. Introduction
2
• Hiroki Fujino
• Head of Engineer in Unipos
• Came from Japan since this February
• My interests: Scala, Architecture Design, Concurrency
Programming, etc.

3. Agenda
• Monad
• Monad Transformers
• Extensible Effects
3
Prerequisites:
Basic knowledge of Scala(includes Experience with using Monad)
https://github.com/Hiroki6/SampleAtnosEff
Sample Code:

4. Monad
4
Allows composition of dependent effectful functions.
Option
Future
Either
Writer
Reader
State
IO
https://typelevel.org/cats/typeclasses/monad.html

5. Monad
5
trait Monad[M[_]] {
def pure[A](x: A): M[A]
def map[A, B](x: M[A])(f: A => B): M[B]
def flatMap[A, B](x: M[A])(f: A => M[B]): M[B]
}

6. Option Monad
6
sealed trait Option[+A]
case object None extends Option[Nothing]
case class Some[A](value: A) extends Option[A]
new Monad[Option] {
def pure[A](x: A) = Some(x)
def ﬂatMap[A, B](x: Option[A])(f: A => Option[B]): Option[B] =
x match {
case Some(x) => f(x)
case None => None
}
}

7. Option Monad
7
def hogeOption(a: Int): Option[Int] = Some(a)
hogeOption(1).ﬂatMap(a => hogeOption(a).map(b => a+b))
// Some(2)
for {
a b } yield (a + b)
// Some(2)

8. 8
How to use multi monads?

9. Two Monads in program
9
def ﬁndUser(userId: UserId): IO[Option[User]]
def getTeam(userId: UserId): IO[Option[Team]]
def createResponse(user: User, team: Team): Response
def program(userId: UserId): IO[Option[Response]] =
for {
userOpt teamOpt user team } yield createResponse(user, team)

10. 10
[error] found : Option[Response]
[error] required: cats.effect.IO[Option[Response]]
[error] user def ﬁndUser(userId: UserId): IO[Option[User]]
def getTeam(userId: UserId): IO[Option[Team]]
def createResponse(user: User, team: Team): Response
def program(userId: UserId): IO[Option[Response]] =
for {
userOpt teamOpt user team } yield createResponse(user, team)
} Composition of IO
} Composition of Option
Two Monads with
For-statement

11. Two Monads with
For-statement
11
def program(userId: UserId): IO[Option[Response]] =
for {
userOpt teamOpt } yield {
(userOpt, teamOpt) match {
case (Some(user), Some(team)) =>
Some(createResponse(user, team))
case (_, _) =>
None
}
}
def program(userId: UserId): IO[Option[Response]] =
for {
userOpt teamOpt } yield for {
user team } yield createResponse(user, team)

12. Monad Transformers
12

13. Monad Transformers
13
G
F
•Popular solution to create monad stack
•Monads do not compose(G[_], F[_] => F[G[_]])
•But, if G[_] is implemented monad(Option, Either, etc.),
F[G[_]] can be monad
•Option
•Either
•Reader
etc.

14. Monad Transformers
14
case class OptionT[F[_], A](value: F[Option[A]]) {
def map[B](f: A => B)(implicit F: Functor[F]): OptionT[F, B] =
OptionT(F.map(value)(_ map f))
def ﬂatMap[B](f: A => OptionT[F, B])(implicit F: Monad[F]): OptionT[F, B] =
OptionT(F.ﬂatMap(value)(_.fold(F.pure[Option[B]](None))(f(_).value)))
}
Option
F

15. Two Monads with OptionT
15
def program(userId: UserId): OptionT[IO, Response] =
for {
user team } yield createResponse(user, team)
program(userId).value // IO[Option[Response]]
Option
IO
def ﬂatMap[B](f: A => OptionT[F, B])(implicit F: Monad[F]): OptionT[F, B]
} Composition of OptionT

16. Implementation of
Monad Transformers
16
OptionT
EitherT
WriterT
ReaderT
StateT
These are implemented in cats and Scalaz.

17. 17
Transformer can wrap another transformer
type EitherIO[A] = EitherT[IO, Error, A]
OptionT[EitherIO, A] // OptionT[EitherT[IO, Error, A]]
IO
Either
Option

18. Three Monad in Program
18
type EitherIO[A] = EitherT[IO, Error, A]
def program(userId: String, teamName: String): OptionT[EitherIO, Response] = {
for {
user EitherT.liftF[IO, Error, Option[User]](ﬁndUser(userId))
}
team EitherT.fromEither[IO](createTeam(userId, teamName))
}
_ EitherT.liftF[IO, Error, Unit](storeTeam(team))
}
} yield createResponse(user, team)
}
program(userId, teamName) // OptionT[EitherIO, Response]
.value // EitherIO[Option[Response]] == EitherT[IO, Error, Option[Response]]
.value // IO[Either[Error, Option[Response]]]
IO[Option[User]]
Either[Error, Team]
IO[Unit]

19. Three Monad in Program
19
type EitherIO[A] = EitherT[IO, Error, A]
def program(userId: String, teamName: String): OptionT[EitherIO, Response] = {
for {
user EitherT.liftF[IO, Error, Option[User]](ﬁndUser(userId))
}
team EitherT.fromEither[IO](createTeam(userId, teamName))
}
_ EitherT.liftF[IO, Error, Unit](storeTeam(team))
}
} yield createResponse(user, team)
}
program(userId, teamName) // OptionT[EitherIO, Response]
.value // EitherIO[Option[Response]] == EitherT[IO, Error, Option[Response]]
.value // IO[Either[Error, Option[Response]]]
IO[Option[User]]
Either[Error, Team]
IO[Unit]

20. Issues of
Monad Transformers
• Cumbersome lift
• Overhead of composition
• Fixed order of Monad Stack
20

21. Cumbersome lift
21
Option
Either
IO
def storeTeam(team: Team): IO[Unit]
OptionT.liftF[EitherIO, Unit] {
EitherT.liftF[IO, Error, Unit](storeTeam(team)).map(_.some)
}
IO
Either
IO
lift lift

22. Overhead of composition
22
OptionT {
Monad[EitherIO].ﬂatMap(value)(_.fold(F.pure[Option[User]](None))(f(_).value))
}
OptionT[EitherIO, User](EitherT.liftF[IO, Error, Option[User]](ﬁndUser(userId))).ﬂatMap(f)
EitherT(Monad[IO].flatMap(value) {
case l @ Left(_) => F.pure(l.rightCast)
case Right(b) => f(b).value
})

23. Fixed order of Monad Stack
23
program.value // Option[Either[String, Int]]
Deﬁnition
Execution
Either
Option
Option
Either

def program: EitherT[Option, String, Int] = for {
t result } yield result

24. 24
Extensible Effects

25. 25
“Extensible Effects:
an alternative to monad transformers”
–Oleg Kiselyov in 2013

26. Extensible Effects(Eff)
Library in Scala
26
•atnos-eff
•emm

27. Today’s Topic about Eff
27
atnos-eff
•How to use atnos-eff
•Advantage and Disadvantage
•How to deﬁne your own Eff monad
•Detail of atons-eff(Union Type, Interpreter)
Not covered:
Explain these below in this presentation:

28. Eff
28
Option State
•Eff is monad.
•Eff has effect stack in a ﬂat state.
•List of effects. order of effects is not important.
Either
Reader
ex. Fx.fx4[Reader[Int, ?], Either[String, ?], Option, State[Int, ?]]

29. Monad Transformers Eff
Comparison of concept
29
Deﬁnition
Execution
Option
Either
Either
Option
Option Either
Either
Option
Either
Option

30. Monad Transformers Eff
Comparison of concept
30
Deﬁnition
Execution
Option
Either
Either
Option
Either
Option
Either
Option
No layer of Monad Stack
No need to lift Option Either

31. MTL vs atnos-eff
31
Monad Transformers Eff
Deﬁnition
Execution
program.value // Option[Either[String, Int]]
def program: EitherT[Option, String, Int] = for {
t result } yield result
def program[R :_stringEither :_option]: Eff[R, Int] = for {
t result } yield result
type Stack = Fx.fx2[Option, StringEither]
// Either[String, Option[Int]]
program[Stack].runOption.runEither.run
// Option[Either[String, Int]]
program[Stack].runEither.runOption.run

32. atnos-eff
32
Deﬁnition
Execution
def program[R :_stringEither :_option]: Eff[R, Int] = for {
t result } yield result
Smart Constructor
Eff Monad
type Stack = Fx.fx2[Option, StringEither]
program[Stack] // Eff[Fx2[Option, StringEither], Int]
.runOption // Eff[Fx1[StringEither], Option[Int]]
.runEither // Eff[NoFx, Either[String, Option[Int]]]
.run // Either[String, Option[Int]]
Interpreter

33. Eff Monad
33
import org.atnos.eff.{Eff, Member}
import org.atnos.eff.either._
import org.atnos.eff.option._
type StringEither[A] = String Either A
type _stringEither[R] = StringEither |= R
def program[R :_stringEither :_option]: Eff[R, Int]
type Stack = Fx.fx2[Option, StringEither]
program[Stack]
Eff
sealed trait Eff[R, A] {
def map[B](f: A => B): Eff[R, B]
def ﬂatMap[B](f: A => Eff[R, B]): Eff[R, B]
}
Effect Stack
Option Either
https://github.com/atnos-org/eff/blob/master/shared/src/main/scala/org/atnos/eff/Eff.scala

34. atnos-eff
34
https://atnos-org.github.io/eff/org.atnos.site.OutOfTheBox.html

35. Smart Constructor
35
trait OptionCreation {
type _option[R] = Option |= R
/** create an Option effect from a single Option value */
def fromOption[R :_option, A](o: Option[A]): Eff[R, A] =
send[Option, R, A](o)
}
Option
fromOption
Eff
Transforms effect into Eff
Option Either
https://github.com/atnos-org/eff/blob/master/shared/src/main/scala/org/atnos/eff/
OptionEffect.scala

36. atnos-eff
36
Deﬁnition
import org.atnos.eff.either._
import org.atnos.eff.option._
def program[R :_stringEither :_option]: Eff[R, Int] = for {
t result } yield result
Smart Constructor

37. Interpreter
37
trait OptionInterpretation {
def runOption[R, U, A](effect: Eff[R, A])(implicit m: Member.Aux[Option, R, U]): Eff[U, Option[A]]
}
implicit class OptionEffectOps[R, A](e: Eff[R, A]) {
def runOption(implicit member: Member[Option, R]): Eff[member.Out, Option[A]] =
OptionInterpretation.runOption(e)(member.aux)
}
runOption
Eff
Can execute the effect
Option Either
https://github.com/atnos-org/eff/blob/master/shared/src/main/scala/org/atnos/eff/
OptionEffect.scala

38. Interpreter
38
import org.atnos.eff.syntax.option._
import org.atnos.eff.Fx
/** Stack declaration **/
type Stack = Fx.fx2[Option, StringEither]
program[Stack] // Eff[Fx2[Option, StringEither], Int]
.runOption // Eff[Fx1[StringEither], Option[Int]]
Option
Can execute the effect
runOption
Eff
Either

39. atnos-eff
39
Deﬁnition
Execution
def program[R :_stringEither :_option]: Eff[R, Int] = for {
t result } yield result
import org.atnos.eff.syntax.either._
import org.atnos.eff.syntax.option._
import org.atnos.eff.syntax.eff._
type Stack = Fx.fx2[Option, StringEither]
program[Stack] // Eff[Fx2[Option, StringEither], Int]
.runOption // Eff[Fx1[StringEither], Option[Int]]
.runEither // Eff[NoFx, Either[String, Option[Int]]]
.run // Either[String, Option[Int]]
Interpreter

40. Three effects in eff
40
type ErrorOr[A] = Either[Error, A]
type _option[R] = Option |= R
type _io[R] = |=[IO, R]
type _errorOr[R] = ErrorOr |= R
def program[R :_io :_option :_errorOr]
(userId: UserId, teamName: TeamName): Eff[R, Response] =
for {
userOpt user team _ } yield createResponse(user, team)
type Stack = Fx.fx3[Option, ErrorOr, IO]
program[Stack](userId, teamName)
.runOption // Eff[Fx2[Either, IO], Option[Response]]
.runEither[Error] // Eff[Fx1[IO], Either[Error, Option[Response]]
.to[IO] // IO[Either[Error, Option[Response]]]

41. type ErrorOr[A] = Either[Error, A]
type _option[R] = Option |= R
type _io[R] = |=[IO, R]
type _errorOr[R] = ErrorOr |= R
def program[R :_io :_option :_errorOr]
(userId: String, teamName: String): Eff[R, Response] =
for {
userOpt user team _ } yield createResponse(user, team)
MTL Eff
type Stack = Fx.fx3[Option, ErrorOr, IO]
program[Stack](userId, teamName)
.runOption // Eff[Fx2[Either, IO], Option[Response]]
.runEither[Error] // Eff[Fx1[IO], Either[Error, Option[Response]]
.to[IO] // IO[Either[Error, Option[Response]]]
program(userId, teamName) // OptionT[EitherIO, Response]
.value // EitherT[IO, Error, Option[Response]]
.value // IO[Either[Error, Option[Response]]]
type EitherIO[A] = EitherT[IO, Error, A]
def program(userId: String, teamName: String):
OptionT[EitherIO, Response] = {
for {
user (EitherT.liftF[IO, Error, Option[User]](ﬁndUser(userId)))
team (EitherT.fromEither[IO](createTeam(userId, teamName)))
_ (EitherT.liftF[IO, Error, Unit](storeTeam(team)))
} yield createResponse(user, team)
}
MTL vs atnos-eff
41

42. Apply Eff to entire program
42
class CreatePostService[R: _io: _connectionIO: _errorOr] (…) {
override def execute(in: CreatePostParam): Eff[R, CreatePostDTO] = {
for {
_ post _ } yield CreatePostDTO(post.id.value)
}
}
def resolve[R: _connectionIO](id: Id[E]): Eff[R, Option[E]]
def store[R: _connectionIO](entity: E): Eff[R, Unit]
Service
Repository
Domain Model
def create[R: _errorOr](…): Eff[R, Post]

43. Apply Eff to entire program
43
trait CreatePostController {
type R = Fx.fx3[IO, ConnectionIO, Validated]
def run(createPostParam: CreatePostParam):
IO[ThrowableEither[ErrorOr[CreatePostDTO]]] =
CreatePostService[R]
.execute(createPostParam)
.runValidatedNel[String]
.runConnectionIO(Database.xa)
.ioAttempt
.to[IO]
}
Controller

44. Advantage of Eff
44
• Readability
• Easy to compose
• No match type game
for {
userOpt user team _ } yield createResponse(user, team)

45. Disadvantage of Eff
45
• Dependency of syntax
• Confused to multiple run

46. Dependency of syntax
46
type R = Fx.fx3[IO, ConnectionIO, Validated]
CreatePostService[R].execute(createPostParam)
def resolve[R: _connectionIO](id: Id[E]): Eff[R, Option[E]]
def create[R: _errorOr](userId: String,
text: String,
parentPostId: Option[String]): Eff[R, Post]
class CreatePostService[R: _io: _connectionIO: _errorOr]
Controller
Service
Repository
Domain Model

47. Confused to multiple run
47
type Stack = Fx.fx3[Option, ErrorOr, IO]
program[Stack](userId, teamName)
.runOption // Eff[Fx2[Either, IO], Option[Response]]
.runEither[Error] // Eff[Fx1[IO], Either[Error, Option[Response]]
.to[IO] // IO[Either[Error, Option[Response]]
program[Stack](userId, teamName)
.runEither[Error] // Eff[Fx2[Option, IO], Either[Error, Response]]
.runOption // Eff[Fx1[IO], Option[Either[Error, Response]]
.to[IO] // IO[Option[Either[Error, Response]]])

48. Summary
48
•Compose two monads
•Compose more than three monads
•Entire Architecture
Monad Transformer is suit.
Eff is better.
Eff is good, but there are some challenges.

49. References
49
•Emm A Sane Alternative to Monad Transformers in Scala
•Monad transformers down to earth
•A Journey into Extensible Effects in Scala
•Extensible Effects vs Monad Transformers

50. Appendix
50
type Stack = Fx.fx2[Option, StringEither]
def program: Eff[Stack, Int] = for {
t result } yield result
program.runOption.runEither.run
=
def program[R :_stringEither :_option]: Eff[R, Int] = for {
t result } yield result
type Stack = Fx.fx2[Option, StringEither]
program[Stack].runOption.runEither.run

51. Appendix
51
def program[R: _stateInt :_option]: Eff[R, Int]
def program[R](implicit stateInt: _stateInt[R], option: _option[R]): Eff[R, Int]
=

52. Appendix
52
/** create an Either effect from a single Either value */
def fromEither[R, E, A](Either: E Either A)(implicit member: (E Either ?) |= R): Eff[R, A] =
Either.fold[Eff[R, A]](left[R, E, A], right[R, E, A])
/** create an Either effect from a value possibly throwing an exception */
def fromCatchNonFatal[R, E, A](a: =>A)(onThrowable: Throwable => E)(implicit member: (E Either ?) |= R): Eff[R, A] =
fromEither(Either.catchNonFatal(a).leftMap(onThrowable))
/** create an Either effect from a value possibly throwing a Throwable */
def catchNonFatalThrowable[R, A](a: =>A)(implicit member: (Throwable Either ?) |= R): Eff[R, A] =
fromCatchNonFatal(a)(identity)
SmartConstructor is not only one each Effect.
https://github.com/atnos-org/eff/blob/master/shared/src/main/scala/org/atnos/eff/
EitherEffect.scala

53. Appendix
53
Interpreter is not only one each Effect.
https://github.com/atnos-org/eff/blob/master/shared/src/main/scala/org/atnos/eff/
EitherEffect.scala
/** catch possible left values */
def attemptEither[R, E, A](effect: Eff[R, A])(implicit member: (E Either ?) /= R): Eff[R, E Either A] =
catchLeft[R, E, E Either A](effect.map(a => Either.right(a)))(e => pure(Either.left(e)))
/** catch and handle a possible left value */
def catchLeft[R, E, A](effect: Eff[R, A])(handle: E => Eff[R, A])(implicit member: (E Either ?) /= R): Eff[R, A] =
catchLeftEither[R, E, A](effect)(handle)(cats.instances.either.catsStdInstancesForEither[E])
/** run the Either effect, handling E (with effects) and yielding A */
def runEitherCatchLeft[R, U, E, A](r: Eff[R, A])(handle: E => Eff[U, A])(implicit m: Member.Aux[(E Either ?), R, U]): Eff[U, A] =
runEither(r).ﬂatMap(_.fold(handle, pure))
