Application deployment with Chef

Agile tour Riga 2012

Transcript

1. Application
   deployment with Chef
   Igor Afonov


   View Slide

2. ‣ Ruby developer
   ‣ I’m participating in Chef development
   Developers Sys Admins
   DevOps
   I’m
   here
   About Me


   View Slide

3. Configuration Management
   Chef Quick Intro
   Application Deployment
   FAQ
   Q & A
   Agenda


   View Slide

4. Configuration
   Management


   View Slide

5. "Keep track of all the stuff you do to take a
   system from 'bare metal' to 'doing its job'."
   - Adam Jacob


   View Slide

6. ๏ Remember everything
   ๏ Keep notes in notepad
   ๏ Maintain wiki
   ๏ Bash scripts
   ๏ Automation frameworks


   View Slide

7. Opscode Chef


   View Slide

8. ๏ Configuration management framework
   ๏ Open source
   ๏ Created by Adam Jacob
   ๏ Maintained by Opscode


   View Slide

9. ๏ Client-server architecture
   ๏ Idempotence
   ๏ Declarative
   ๏ Ruby everywhere


   View Slide

10. Crash course


    View Slide

11. chef-server
    push
    pull
    VCS
    chef-client
    node
    chef-client
    node
    chef-client
    node
    server
    chef repository
    developer
    Workflow


    View Slide

12. cookbook
    recipe
    chef-repository
    resource
    resource
    resource
    Code structure


    View Slide

13. Resource


    View Slide

14. package 'apache2' do
    action :install
    provider Chef::Provider::Package::Apt
    version '2.4'
    end


    View Slide

15. Cookbook File
    Cron
    Deploy
    Directory
    Env
    Execute*
    File
    Git
    Group
    HTTP Request
    Ifconfig
    Link
    Log
    Mount
    Ohai
    Package
    PowerShell Script
    User
    Remote Directory
    Remote File
    Route
    Ruby Block
    SCM
    Script
    Service
    Subversion
    Template
    Bundled resources


    View Slide

16. Provider


    View Slide

17. package
    apt pacman macports
    Resource
    Providers
    Interface
    Implementation


    View Slide

18. service "redis" do
    action :start
    end
    Method call
    Parameter1
    Parameter2
    # lib/chef/platform.rb - Chef::Platform
    :macosx => {
    :default => {
    ...
    :package => Chef::Provider::Package::Macports,
    :service => Chef::Provider::Service::Macosx,
    ...
    }
    }
    # lib/chef/provider/service/macosx.rb
    class Chef::Provider::Service::Macosx < Chef::Provider::Service::Simple
    def start
    if @current_resource.running
    Chef::Log.debug("#{@new_resource} already running, not starting")
    else
    shell_out!("launchctl load -w '#{@plist}'")
    end
    end
    end


    View Slide

19. Recipe


    View Slide

20. package "postfix" do
    action :install
    end
    %w{main master}.each do |config|
    template "/etc/postfix/#{config}.cf" do
    source "#{config}.cf.erb"
    owner "root"
    group "root"
    mode 0644
    end
    end


    View Slide

21. Cookbook


    View Slide

22. cookbook
    |-attributes
    |-files
    |-libraries
    |-recipes
    |-templates
    |---metadata.rb


    View Slide

23. ๏ Cookbooks should be data-driven
    ๏ Do not hardcode anything
    ๏ Control behavior via:
    ๏ Attributes
    ๏ Databags
    ๏ Search


    View Slide

24. Node


    View Slide

25. ๏ Host that runs chef-client
    ๏ Has attributes
    ๏ Has run list


    View Slide

26. Role


    View Slide

27. name "mail-server"
    description "Installs and configures postfix MTA"
    default_attributes :postfix => {
    "mydomain" => "domain.com",
    "myorigin" => "domain.com"
    }
    run_list "recipe[postfix]"


    View Slide

28. Chef repository


    View Slide

29. chef-repo
    |-cookbooks
    |-data_bags
    |-roles
    |-environments
    |---Rakefile
    https://github.com/opscode/chef-repo


    View Slide

30. chef-server
    push
    pull
    VCS
    chef-client
    node
    chef-client
    node
    chef-client
    node
    server
    chef repository
    developer
    The big picture


    View Slide

31. ๏ Authenticate node
    ๏ Synchronize cookbooks
    ๏ Compile
    ๏ Converge
    chef-client run


    View Slide

32. ๏ Resource is a unit of work
    ๏ Provider take real action
    ๏ Recipe is collection of resources
    ๏ Cookbook is reusable set of recipes
    ๏ Code is pushed to chef-server
    ๏ Node pulls code from chef-server and runs it
    Recap


    View Slide

33. Deployment


    View Slide

34. ๏ Get the code from VCS
    ๏ Put the code to the right place
    ๏ Do some rituals
    Three easy* steps
    * Not true


    View Slide

35. Real-world
    example


    View Slide

36. internet
    nginx
    unicorn
    unicorn
    unicorn
    Simple Rails deployment


    View Slide

37. Get the code &
    put it to the right place
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    end


    View Slide

38. Pick the SCM strategy
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    strategy :deploy_revision # :deploy_timestamped
    end


    View Slide

39. Set the code owner
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    strategy :deploy_revision
    owner 'deploy'
    group 'deploy'
    end


    View Slide

40. Install library dependencies
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    strategy :deploy_revision
    owner 'deploy'
    group 'deploy'
    packages ['libxml2-dev', 'libxslt-dev']
    end


    View Slide

41. Run migrations
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    strategy :deploy_revision
    owner 'deploy'
    group 'deploy'
    packages ['libxml2-dev', 'libxslt-dev']
    migrate true
    end


    View Slide

42. Restart service
    application 'copycopter' do
    repository 'git@github.com:iafonov/copycopter-server.git'
    revision 'master'
    path '/var/www/apps/copycopter'
    strategy :deploy_revision
    owner 'deploy'
    group 'deploy'
    packages ['libxml2-dev', 'libxslt-dev']
    migrate true
    restart_command 'service copycopter restart'
    end


    View Slide

43. ๏ rails
    ๏ java_webapp
    ๏ tomcat
    ๏ django
    ๏ ...
    Sub-resources


    View Slide

44. Rails
    application 'copycopter' do
    ...
    rails do
    gems ['bundler']
    database do
    username node['mysql']['username']
    password node['mysql']['password']
    database 'copycopter_production'
    end
    end
    end


    View Slide

45. Unicorn
    application 'copycopter' do
    ...
    rails do
    ...
    end
    unicorn do
    worker_processes 4
    port 8080
    end
    end


    View Slide

46. nginx
    application 'copycopter' do
    ...
    rails do
    ...
    end
    unicorn do
    ...
    end
    nginx_load_balancer do
    static_files '/public' => 'public'
    application_server_role 'copycopter_app_server'
    end
    end


    View Slide

47. ๏ before_deploy
    ๏ before_migrate
    ๏ before_symlink
    ๏ before_restart
    ๏ after_restart
    Callbacks


    View Slide

48. Run backups
    application 'copycopter' do
    ...
    before_deploy do
    execute 'run_backups' do
    command 'rsync ....'
    end
    end
    end


    View Slide

49. Notify monitoring system
    application 'copycopter' do
    ...
    before_deploy do
    execute 'run_backups' do
    command 'rsync ....'
    end
    end
    after_restart do
    StatsD.gauge("#{node.name}.deploy")
    end
    end


    View Slide

50. ๏ Chef allows declaratively describe deploy
    process
    ๏ A lot of technology stacks are supported via
    sub-resources
    ๏ You can precisely control each step of process
    Recap


    View Slide

51. FAQ


    View Slide

52. When you should
    automate your
    infrastructure?


    View Slide

53. Which tool should
    you use?


    View Slide

54. What are benefits
    of using
    automation tools?


    View Slide

55. Q & A
    afonov@gmail.com
    http://iafonov.github.com
    @iafonov


    View Slide

56. Thank You!
    afonov@gmail.com
    http://iafonov.github.com
    @iafonov


    View Slide
