Integrating Multiple CDN Providers: Our Experience at Etsy

Until recently Etsy has relied on a single content delivery network (CDN) to optimize delivery of cacheable content, and to accelerate dynamic content to our community. Being tied to a single vendor for such a critical piece of site delivery infrastructure can limit the amount of flexibility you have available to you.

These limits exist in a number of dimensions with the potential to leave your site vulnerable to a single vendor’s availability. By diversifying your CDN providers you can put the power back in your hands, allowing you to get the best of both worlds in terms of performance, reliability and cost.

In this talk Marcus Barczak and Laurie Denness will present the journey Etsy has undertaken over the past 12 months to introduce two additional CDN providers into Etsy’s site delivery infrastructure. They will present:

* Etsy’s rationale for wanting to integrate multiple CDN providers
* The test methodology used for evaluating each provider against live production traffic
* Tooling and monitoring infrastructure built to support multiple providers
* The issues and challenges faced with a multiple vendor solution

The approach and techniques used in the design, evaluation and implementation of Etsy’s multi-CDN solution are applicable to a wide range of use cases. Attendees should leave this talk with some ideas around establishing meaningful evaluation criteria, strategies for conducting A/B split testing in a live production environment, and techniques that they may explore for implementing multiple CDN’s within their own environment.

Transcript

1. Integrating Multiple CDN Providers Our experiences at Etsy @lozzd • @ickymettle
2. Marcus Barczak Laurie Denness Staff Operations Engineers
4. @lozzd • @ickymettle
5. @lozzd • @ickymettle
6. @lozzd • @ickymettle Beginning of 2010 Today
7. @lozzd • @ickymettle Background ▪ First started using a single CDN in 2008 ▪ Exponential Growth ▪ Start of 2012 began investigation into running multiple CDNs
8. @lozzd • @ickymettle Why use a CDN? ▪ Goal: Consistently fast user experience globally ▪ Improve last mile performance by caching content close to the user ▪ Offload content delivery from origin infrastructure to the CDN provider
9. @lozzd • @ickymettle Why use more than one CDN? ▪ Resilience - Eliminate single point of failure ▪ Flexibility - Balance traffic based on business requirements ▪ Cost - Manage provider costs
10. The Plan http://www.flickr.com/photos/malloy/195204215
11. @lozzd • @ickymettle The Plan 1. Establish evaluation criteria 2. Initial configuration and testing 3. Test with production traffic 4. Operationalising
12. @lozzd • @ickymettle Evaluation Criteria http://www.flickr.com/photos/49212595@N00/5646403386
13. @lozzd • @ickymettle Evaluation Criteria ▪ Performance ▪ Configuration ▪ Reporting, Metrics and Logging ▪ Culture
14. @lozzd • @ickymettle Performance ▪ Baseline Response Times - Should be within ±5% of our existing CDN provider’s response times ▪ Hit Ratios and Origin Offload - Provider should achieve equivalent or better origin offload performance and hit ratios
15. @lozzd • @ickymettle Configuration ▪ Complexity - how complex is the providers configuration system ▪ Self service - can you make changes directly or do they require professional services or other intervention ▪ Latency for changes - how quickly do changes take to propagate
16. @lozzd • @ickymettle Reporting, Metrics and Logging ▪ Resolution ▪ Latency ▪ Delivery ▪ Customisation
17. @lozzd • @ickymettle Culture ▪ Understand our culture ▪ Postmortems ▪ Access to technical staff ▪ Shared success
18. Initial Configuration and Testing http://www.flickr.com/photos/7269902@N07/4592239326
19. Clean the house http://www.flickr.com/photos/mastergeorge/8562623590
20. @lozzd • @ickymettle Clean the house ▪ Managing caching TTLs from origin - CDNs honour the origin cache-control headers! <LocationMatch "\.(gif|jpg|jpeg|png|css|js)$"> Header set Cache-Control "max-age=94670800" </LocationMatch>
21. @lozzd • @ickymettle Clean the house ▪ Manage gzip compression from origin - Honoured by CDNs - Compression from origin to CDN ## mod_deflate compression - see OPS-1537 ## AddOutputFilterByType DEFLATE text/html text/plain text/css application/x-javascript [..]
22. @lozzd • @ickymettle Clean the house If you can do it at origin, do it at origin
23. Mean Time To Curl http://www.flickr.com/photos/wwarby/3297205226
24. HTTP/1.1 200 OK Server: Apache Last-Modified: Sat, 09 Nov 2013 23:43:38 GMT Cache-Control: max-age=94670800 [...] X-Served-By: cache-lo82-LHR X-Cache: MISS X-Cache-Hits: 0 curl -i -H 'Host: img0.etsystatic.com' \ global-ssl.fastly.net/someimage.jpg
25. HTTP/1.1 200 OK Server: Apache Last-Modified: Sat, 09 Nov 2013 23:43:38 GMT Cache-Control: max-age=94670800 [...] X-Served-By: cache-lo82-LHR X-Cache: HIT X-Cache-Hits: 1 curl -i -H 'Host: img0.etsystatic.com' \ global-ssl.fastly.net/someimage.jpg
26. https://www.etsy.com/listing/99871278 Mean Time To Curl = Done
27. @lozzd • @ickymettle Mean Time To Curl ▪ No need to touch existing infrastructure ▪ Smoke test of functionality ▪ 10 minutes from configuration to curl ▪ New providers should be plug and play
28. Testing In Production http://www.flickr.com/photos/solarnu/10646426865
29. @lozzd • @ickymettle Testing with Production Traffic ▪ Images only at first ▪ Good test of caching performance ▪ Easy to test by swapping hostnames ▪ Made even easier with our A/B testing framework
30. @lozzd • @ickymettle A/B Test Framework ▪ Fine grained control ▪ Enable test for specific users or groups ▪ Percentage of users ▪ All controlled via configuration in code ▪ Rapid and complete rollback
31. @lozzd • @ickymettle Configure Mappings to CDNs $server_config["image"] = array( 'akamai' => array( 'img0-ak.etsystatic.com', 'img1-ak.etsystatic.com', ), 'edgecast' => array( 'img0-ec.etsystatic.com', 'img1-ec.etsystatic.com', ), 'fastly' => array( 'img0-f.etsystatic.com', 'img1-f.etsystatic.com', ), );
32. @lozzd • @ickymettle Test Controls $server_config['ab']['cdn'] = array( 'enabled' => 'on', 'weights' => array( 'akamai' => 0.0, 'edgecast' => 0.0, 'fastly' => 0.0, 'origin' => 100.0, ), 'override' => 'cdn_diversity', );
33. @lozzd • @ickymettle Metrics and Monitoring http://www.flickr.com/photos/nicolasfleury/6073151084
34. @lozzd • @ickymettle Metrics and Monitoring Even if it doesn’t move, graph it anyway
35. @lozzd • @ickymettle Simplest approach: Provider’s dashboards Metrics and Monitoring
36. @lozzd • @ickymettle ▪ Get more detail by pulling metrics in house ▪ Write script to pull data from API ▪ Create dashboards with data Metrics and Monitoring
37. @lozzd • @ickymettle ▪ Get more detail by pulling metrics in house ▪ Write script to pull data from API ▪ Create dashboards with data Metrics and Monitoring
38. @lozzd • @ickymettle Metrics and Monitoring
39. @lozzd • @ickymettle Metrics and Monitoring
40. @lozzd • @ickymettle Testing Plan 1. for c in $cdns; do rampup $c; done; 2. Deliberately slow and steady 3. Watch traffic increase 4. Watch origin offload increase 5. Watch performance
41. @lozzd • @ickymettle Downsides of this approach ▪ AB testing can’t be used for main site ▪ Exposing your test CNAMEs ▪ Especially if hotlinking is a concern
42. @lozzd • @ickymettle Downsides of this approach ▪ Exposing your test CNAMEs ▪ Especially if hotlinking is a concern
43. @lozzd • @ickymettle How do you know it’s broke? ▪ Check the graphs! ▪ Check with your community ▪ Keep support in the loop
44. Operationalising http://www.flickr.com/photos/98047351@N05/9706165200
45. @lozzd • @ickymettle Content Partitioning
46. @lozzd • @ickymettle Etsy’s site partitioning Dynamic HTML Content www.etsy.com
47. @lozzd • @ickymettle Etsy’s site partitioning Static Assets (js, css, fonts) site.etsystatic.com
48. @lozzd • @ickymettle Etsy’s site partitioning Listing Images, Avatars imgX.etsystatic.com
49. @lozzd • @ickymettle Etsy’s site partitioning Listing Images, Avatars imgX.etsystatic.com Static Assets (js, css, fonts) site.etsystatic.com Dynamic HTML Content www.etsy.com
50. Balancing Traffic in Production http://www.flickr.com/photos/wok_design/2499217405
51. @lozzd • @ickymettle Balancing Traffic Using DNS ▪ Traffic Manager ▪ Extends DNS to dynamically return records based on rules ▪ Weighted round robin
52. @lozzd • @ickymettle Balancing Traffic Using DNS [2589:~] $ dig +short www.etsy.com www.etsy.com.edgekey.net. e2463.b.akamaiedge.net. 23.74.122.37 [2589:~] $ dig +short www.etsy.com cs34.adn.edgecastcdn.net. 93.184.219.54 [2589:~] $ dig +short www.etsy.com global-ssl.fastly.net. 185.31.19.184 [2589:~] $ dig +short www.etsy.com etsy.com. 38.123.123.123
53. @lozzd • @ickymettle Balancing Traffic Using DNS [2589:~] $ dig +short www.etsy.com www.etsy.com.edgekey.net. e2463.b.akamaiedge.net. 23.74.122.37 [2589:~] $ dig +short www.etsy.com cs34.adn.edgecastcdn.net. 93.184.219.54 [2589:~] $ dig +short www.etsy.com global-ssl.fastly.net. 185.31.19.184 [2589:~] $ dig +short www.etsy.com etsy.com. 38.123.123.123
54. @lozzd • @ickymettle Balancing Traffic Using DNS ▪ Rule updates typically made via web UI ▪ Can be slow and error prone ▪ Changes need to be applied to all three domains ▪ API available to make changes programmatically
55. @lozzd • @ickymettle cdncontrol http://www.flickr.com/photos/foshydog/4441105829
56. @lozzd • @ickymettle cdncontrol
57. @lozzd • @ickymettle cdncontrol
58. @lozzd • @ickymettle cdncontrol
59. @lozzd • @ickymettle cdncontrol
60. @lozzd • @ickymettle cdncontrol
61. @lozzd • @ickymettle cdncontrol
62. @lozzd • @ickymettle cdncontrol
63. @lozzd • @ickymettle cdncontrol
64. @lozzd • @ickymettle cdncontrol
65. @lozzd • @ickymettle cdncontrol
66. @lozzd • @ickymettle DNS balancing downsides ▪ Low TTLs for fast convergence ▪ More DNS lookups for users ▪ Not 100% instant or deterministic ▪ Mo QPS == Mo Money
67. @lozzd • @ickymettle 50% within 1 minute Long Tail is Loooong
68. @lozzd • @ickymettle Monitoring in Production http://www.flickr.com/photos/9229426@N05/5160787240
69. @lozzd • @ickymettle Whoopsie Page ▪ Static HTML delivered for 5xx errors - Branding - Translated error messages - Links to status page
70. @lozzd • @ickymettle Whoopsie Page ▪ Static HTML delivered for 5xx errors - Branding - Translated error messages - Links to status page
71. @lozzd • @ickymettle Failure Beacons 1. 1x1 tracking pixel embedded in page [...] <img src="//failure.etsy.com/status/images/beacon.gif? beacon_source=fastly_origin_failure-etsy.com"> </body> </html>
72. @lozzd • @ickymettle Failure Beacons 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line
73. @lozzd • @ickymettle Failure Beacons 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line 3. Scrape them out minutely using logster self.reg = re.compile('^\S+(\s:)? (?P<remote_addr>[0-9\.]+),? [0-9\.,\- ]+ \[[^\]]+\] \"GET /status/images/beacon\.gif\? (beacon_)?source=(?P<source>\S+) HTTP/1\.\d\" \d+ [\d\-]+ \"(? P<referrer>[^\"]+)\" \"(?P<user_agent>[^\"]+)\" .*$')
74. @lozzd • @ickymettle 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line 3. Scrape them out minutely using logster 4. Logster posts event counts to Graphite Failure Beacons
75. @lozzd • @ickymettle 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line 3. Scrape them out minutely using logster 4. Logster posts event counts to Graphite Failure Beacons
76. @lozzd • @ickymettle Failure Beacons 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line 3. Scrape them out minutely using logster 4. Logster posts event counts to Graphite 5. Alert on Graphite graph in Nagios
77. @lozzd • @ickymettle Failure Beacons 1. 1x1 tracking pixel embedded in page 2. Request creates an access log line 3. Scrape them out minutely using logster 4. Logster posts event counts to Graphite 5. Alert on Graphite graph in Nagios
78. @lozzd • @ickymettle Failure Beacons ▪ Client IP address can be geolocated
79. @lozzd • @ickymettle Failure Beacons ▪ Optional extra debugging information [31/Oct/2013:07:06:42 +0000] "GET /status/images/ beacon.gif?beacon_source=fastly_origin_failure-etsy.com &provider_error=Connection%20timed%20out &server_identity=cache-ny57-NYC HTTP/1.1"
80. @lozzd • @ickymettle Failure Beacons ▪ Optional extra debugging information
81. @lozzd • @ickymettle Tracking Requests to Origin GET / HTTP/1.1 User-Agent: curl/7.24.0 Accept: */* X-Forwarded-Host: www.etsy.com [...] X-CDN-Provider: edgecast [...] Host: www.etsy.com
82. @lozzd • @ickymettle GET / HTTP/1.1 User-Agent: curl/7.24.0 Accept: */* X-Forwarded-Host: www.etsy.com [...] X-CDN-Provider: edgecast [...] Host: www.etsy.com Tracking Requests to Origin
83. @lozzd • @ickymettle Backend Monitoring ▪ Vendor APIs to bring data in house
84. @lozzd • @ickymettle Backend Monitoring ▪ Logster on CDN provider header ▪ Vendor APIs to bring data in house
85. @lozzd • @ickymettle Backend Monitoring ▪ Vendor APIs to bring data in house ▪ Data in-house benefits include - Integration with our anomaly detection systems - Consistent and unified view of all CDN metrics - We control data retention period
86. @lozzd • @ickymettle Awareness ▪ Over 100 engineers ▪ Deploying 60 times a day ▪ Correlating external and internal services
87. @lozzd • @ickymettle Awareness
88. @lozzd • @ickymettle Awareness Deploy lines
89. @lozzd • @ickymettle Frontend Monitoring ▪ Performance is important to us ▪ Monitoring overall site performance ▪ Monitoring performance by CDN provider ▪ Real User Monitoring on key pages to track page performance
90. @lozzd • @ickymettle Frontend Monitoring ▪ Performance is important to us ▪ Monitoring overall site performance ▪ Monitoring performance by CDN provider ▪ SOASTA mPulse on key pages to track real user page performance
91. Downsides http://www.flickr.com/photos/39272170@N00/3841286802
92. @lozzd • @ickymettle Debugging: What broke? ▪ MTTD/MTTR can be extremely low with this system ▪ But not always
93. @lozzd • @ickymettle Debugging: What broke? ▪ MTTD/MTTR can be extremely low with this system ▪ But not always
94. @lozzd • @ickymettle Debugging: What broke? ▪ Non technical member base ▪ Confusing and time consuming ▪ Amazing support team ▪ Log as much information as possible
95. Conclusions/Takeaways http://www.flickr.com/photos/sk8geek/4649776194
96. @lozzd • @ickymettle Great success ▪ 12 months in the benefits have far outweighed the few downsides ▪ We’re continuing to evolve the system ▪ We’ll be sure to share our experience with the community along the way
97. @lozzd • @ickymettle Links/Open Source ▪ cdncontrol http://github.com/etsy/cdncontrol http://github.com/etsy/cdncontrol_ui ▪ logster http://github.com/etsy/logster ▪ CDN API to Graphite scripts http://github.com/lozzd/cdn_scripts
98. Thanks! Questions? @lozzd • @ickymettle
