Android Things - Things matter

Android Things is an Android-based embedded operating system platform by Google. Android Things lets you build professional, mass-market products on a trusted platform, without previous knowledge of embedded system design. This talk covers how to start with Android Things, Flash OS on development board and Connect devices with NXP Pico i.MX7D platform and control that using Android mobile & Google Assistant application.

You will be learning below things,
- Getting started with Android Things
- How to build and flash OS on development board
- Control devices through Google Assistant (NXP Pico i.MX7D, Breadboard, LED, Google Home, Dialogflow application, Firebase Real time database & Cloud Functions)

Transcript

1. Jaldeep Asodariya, GDG Ahmedabad @jaldeepasodariy Gandhinagar Android Things - Things matter
2. Jaldeep Asodariya Android Developer Core Organising Team Member
3. Let’s turn on the light Gandhinagar
5. Triggering Ok Google, talk to brainy things. Gandhinagar Hey Google, let me talk to brainy things. Ask brainy things about power on my living room main light.
6. Gandhinagar
7. Gandhinagar How does it work? Actions on Google Dialogflow Firebase Realtime Database Firebase Cloud Functions Android Things Android
8. Android Things is an extension of the Android platform for IoT and embedded devices Gandhinagar
9. Easy and Secure Deployment
10. The Architecture Gandhinagar
15. Pinout Diagram Gandhinagar
16. Pico NXP i.MX7D Gandhinagar
17. Let’s build Things together Gandhinagar
18. /jalotsav/brainy-things Gandhinagar
19. Gandhinagar
20. Gandhinagar
22. things: build.gradle dependencies { compileOnly 'com.google.android.things:androidthings:1.0' }
23. things: build.gradle dependencies { compileOnly 'com.google.android.things:androidthings:1.0' } AndroidManifest.xml <application ...> <uses-library android:name="com.google.android.things" /> <activity ...> ... </activity> </application>
24. things: build.gradle dependencies { compileOnly 'com.google.android.things:androidthings:1.0' } AndroidManifest.xml <application ...> <uses-library android:name="com.google.android.things" /> <activity ...> ... <!--Launch activity automatically on boot--> <intent-filter> <action android:name="android.intent.action.MAIN" /> <category android:name="android.intent.category.IOT_LAUNCHER" /> <category android:name="android.intent.category.DEFAULT" /> </intent-filter> </activity> </application>
25. MainActivity.java //Init PeripheralManager PeripheralManager mPeripheralManager = PeripheralManager.getInstance(); Gpio mGpio1IO10 = mPeripheralManager.openGpio("GPIO1_IO10");
26. MainActivity.java //Init PeripheralManager PeripheralManager mPeripheralManager = PeripheralManager.getInstance(); Gpio mGpio1IO10 = mPeripheralManager.openGpio("GPIO1_IO10"); // Configure the peripheral mGpio1IO10.setDirection(Gpio.DIRECTION_OUT_INITIALLY_LOW); // Set it at some point later mGpio1IO10.setValue(false);
27. MainActivity.java //Init PeripheralManager PeripheralManager mPeripheralManager = PeripheralManager.getInstance(); Gpio mGpio1IO10 = mPeripheralManager.openGpio("GPIO1_IO10"); // Configure the peripheral mGpio1IO10.setDirection(Gpio.DIRECTION_OUT_INITIALLY_LOW); // Set it at some point later mGpio1IO10.setValue(false); // Do not forget to close gpio mGpio1IO10.close();
28. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { @Override public void onDataChange(@NonNull DataSnapshot dataSnapshot) { @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
29. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { @Override public void onDataChange(@NonNull DataSnapshot dataSnapshot) { for(DataSnapshot roomSnapshot : dataSnapshot.getChildren()) { MdlRooms objMdlRoom = roomSnapshot.getValue(MdlRooms.class); @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
30. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { @Override public void onDataChange(@NonNull DataSnapshot dataSnapshot) { for(DataSnapshot roomSnapshot : dataSnapshot.getChildren()) { MdlRooms objMdlRoom = roomSnapshot.getValue(MdlRooms.class); if(objMdlRoom.getDevices() != null) { Map<String, MdlDevices> objMap = objMdlRoom.getDevices(); ... @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
31. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { ... Map<String, MdlDevices> objMap = objMdlRoom.getDevices(); @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
32. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { ... Map<String, MdlDevices> objMap = objMdlRoom.getDevices(); for (MdlDevices objMdlDevices : objMap.values()) { } @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
33. MainActivity.java mRoomRef.addValueEventListener(new ValueEventListener() { ... Map<String, MdlDevices> objMap = objMdlRoom.getDevices(); for (MdlDevices objMdlDevices : objMap.values()) { switch (objMdlDevices.getGpio()) { case PIN_NXPMX7D_GPIO1_IO10: ... mGpio1IO10.setValue(objMdlDevices.getTraits().isOn()); break; } } @Override public void onCancelled(@NonNull DatabaseError databaseError) { … } });
34. Intent Matching - Match and categorize user utterances to an intent. Gandhinagar Entity Extraction - Identify key words and phrases spoken by the user. “ @
40. /brainythings.page.link/devfest18 Gandhinagar
41. Useful Links Gandhinagar https://dialogflow.com/ https://console.dialogflow.com/api-client/ Dialogflow https://firebase.google.com/docs/database/ https://firebase.google.com/docs/functions/ Firebase https://developer.android.com/things/ https://developer.android.com/things/hardware/imx7d-pico-io.html AThings
42. Q&A “Hey Jaldeep”...
