1. Total Marine Solution Provider PPT상 노란색 음영은 확인이 필요한 사항입니다.
2. About LSMS Fleet & Subsea Equipment Track Record Upcoming Projects LSMS Capabilities Table of Contents
3. About Founded in 1995 - Acquired by LS C&S for Maximum Efficiency across Units Establishment of Company Contracted as YZ Operator Acquired ISO09001 Certification Company Name Change - Listed on KOSDAQ as KT Submarine Renewal of YZ Contract ~’24 New CLV Contract Signed Renewal of YZ Contract ~’29 Major Shareholder Changed to LS Company Name Change to LSMS 1995 1997 1998 2002 2021 2023 2023 2025 Company Name LS Marine Solution Co., Ltd. CEO Byung-Ok, Kim Subsidiary LS Buildwin Ltd. (100%) Onshore Power Cable Installation & Maintenance
4. About Founded in 1995 - Acquired by LS C&S for Maximum Efficiency across Units Design & Engineering Manufacturing Cable & Materials Joint & Termination Works Testing Marine Survey, BAS Cable Laying & Burial Execution Cable Protection EPCI Turn Key Solution Provider
5. Fleet & Subsea Equipment
6. LSMS Fleet Three Operational Vessels, with a New Cable Laying Vessel under Construction InterLink Specifications InterWave Specifications InterGlobe Specifications InterOcean Specifications LOA 115m Draft 7.8m Payload Max 7,500 ton POB 62 pax. Flag Korea Class KR Telecom Cable Installation LOA 70m Draft 5m Payload N/A POB 52 pax. Flag Korea Class KR LOA 159.25m Draft 7.8m Payload 14,000 ton POB 100 pax. Flag Liberia Class BV/KR LOA 111.5m Draft 4.2m Payload Max 7,000 ton POB 60 pax. Flag Korea Class BV Power Cable Installation Multi Purpose Vessel Power Cable Installation Sizes are illustrative only and not to scale.
7. Uncolored areas indicate tentative arrangements; attachments, machinery, and cable-handling systems may vary. LSMS Fleet New Cable-Laying Vessel Designed for 13,000 Tons of Cable Loading with Dual Carousels Design Sea Trial Deployment: Fixed Wind Farm PJT Ship Building Deployment: Floating Wind Farm PJT Jun. 205 Dec. 2025 May 2028 3Q 2028 4Q 2029 31m 149m Carousel Upper Deck Carousel Lower Deck Specifications Class BV/KR Class 1 Flag Liberia DPS DP2 Propulsion Hybrid Diesel-Electric with ESS Carousel Capacity Total: 14,000t 5,000t + 9,000t (Upper & Lower) Fireline MBR 6m MBR Tensioner 35T x 2ea., 15T x 1ea. Delivery Timeline
8. LSMS Subsea Equipment Multiple Burial Technologies for Project-Specific Seabed and Depth Requirements MD3XT Vertical Injector DJS35 QT1500 Sizes are illustrative only and not to scale. Q800 Cable Plough Burial Equipment Jetting Sled Trencher ROV Trencher ROV Specifications Specifications Specifications Specifications Specifications Burial Tool Dragging/Jetting Maker SMD (UK) Size 5 x 9 x 6m (18 ton) Burial Depth 3.3m Op. WD 2,500m Op. Vessel InterLink Burial Tool Water Jetting Maker Dimension Size 9.5 x 7.3 x 2.7m (14 ton) Burial Depth 10m Op. WD 40m Op. Vessel InterGlobe Burial Tool Water Jetting Maker Dimension Size 9.5 x 7.3 x2.7m (14 ton) Burial Depth 3.3m Op. WD 100m Op. Vessel InterGlobe Burial Tool Water Jetting Maker SMD Size 5.5 x 5.5 x 3.4m (22 ton) Burial Depth 3.0m Op. WD 1,500m Op. Vessel InterWave Burial Tool Water Jetting Maker SMD Size 3 x 4.2 x 5.3m (18 ton) Burial Depth 3.0m Op. WD 1,500m Op. Vessel InterWave
9. Track Record
10. Energy Cable Telecommunications Cable Project Type Capacity Voltage Delivered Length (km) Greater Changhua HVAC 605MW 295MW 66 / 230kV Export: 144km IAC: 204km Wando-Jeju HVDC HVDC 200MW 150kV Off: 178km On: 18km HKN & HKWa HVAC 1,380MW 220kV Export: 200km Norfolk HVDC 3,960MW 320kV Off: 692km On: 390km 2GW HVAC 2GW 525kV Off: 1,060km On: 390km Jeonnam 1 OWF AC 100MW 66kV Off: 30km On: 1km Year Project Name Route Year Project Name Route 2023 ECHO IDN-US 2008 TPE KOR-US 2021 SJC2 KOR-SGP 2002 EAC-C2C KOR-SGP 2019 JUPITER PHL-US 2001 APCN-2 KOR-SGP 2018 NCP KOR-US 2001 FLAG North Asia Loop KOR-TWN 2017 SEA-US PHL-US 1997 FLAG EU-ASIA KOR-UK 2016 APG KOR-SGP Energy Cables Delivered 3,307km Telecommunications Cables Delivered 191,281km Track Record 3 Decades - Making A Difference in 9 Countries, Spanning 194,588 km Worldwide Cable lengths are aggregated by category and includes multiple cable types per category.
11. Wando-Jeju HVDC #3 Capacity DC ± 150kV, 200MW (200MW x 1 Pole) Cable Length Offshore 178km / Onshore 18km Project Period 2023 ~ 2025 Owner KEPCO (Korea Electronic Power Corp.) Contractor LSC (EPCI)+LSMS (Cable Laying & Burial) Track Record One-team Delivery Model with LSC & LSMS, Proven across Jeju HVDC #3 and Jeonnam 1 OWF Routes, bearing, map elements, icons, and sizes are illustrative only and not to scale. Export Cable HVDC #3 HVDC #2 HVDC #1
12. Jeonnam 1 OWF Capacity 100MW (10MW x 10WTG) Cable Length Export (2 lines): Approx. 10km x 2 InterArray (8 lines): Approx. 10km Project Period Jun. 2022 ~ Feb. 2025 Owner Jeonnam Offshore Wind Farm Power (SPC - SK E&S 51%: CIP 49%) Contractor LSMS (EPCi), Cable supplied by LSC Routes, bearing, map elements, icons, and sizes are illustrative only and not to scale. Track Record One-team Delivery Model with LSC & LSMS, Proven across Jeju HVDC #3 and Jeonnam 1 OWF Export Cable Onshore Transmission Cable
13. Taiwan TPC2 OWF Description Offshore Wind Farm ROV Trenching Capacity 295MW (9.5MW x 31WTG) Cable Length Export (3 lines): Approx. 21km x 3 Trenching InterArray (32 lines): Approx. 65km Trenching Project Period Campaign 1 (2025) – Burial Operation for EPC Campaign 2 (2026) – Burial Operation for IAC Owner Developer: TAIPOWER (台電) EPCI: Foxwell Energy Corporation Contractor LSMS *Status: LSMS awarded as the ROV Trenching Service Provider to conduct entire EC & IAC totaling 128km Routes, bearing, map elements, icons, and sizes are illustrative only and not to scale. Track Record InterWave Executing ROV Trenching for TPC2 OWF (2025–2026) Project Area TBD
14. Upcoming Projects
15. Capacity 504MW (14MW x 36WTG) Cable Length Export : Approx. 40km x 2 InterArray: 81.5km Project Period 2028 ~ 2029 Owner Taean Wind Power Developer: Vena Energy & CIP Contractor LSC & LSMS as a Consortium Capacity 390MW (15MW x 26WTG) Cable Length Export : Approx. 32.5km x 2 InterArray: 44.2km Project Period 2026 ~ 2027 Owner Hanwha Ocean Developer: KOMIPO, SK Eternix, HD E&C Contractor LSMS Capacity 2 x 504MW (14MW x 36WTG) Cable Length HS1: Export Approx. 98km x 2 InterArray (36 lines) Approx. 70km HS3: Export Approx. 85km x 2 InterArray (36 lines) Approx. 83km Project Period 2029 ~ 2030 Owner CIP & COP Contractor LSC & LSMS as a Consortium Routes, bearing, map elements, icons, and sizes are illustrative only and not to scale. Taean OWF EPCI Shinan-Ui OWF EPCI Haesong OWF EPCI Bidding Process Underway for Bandibuli (750MW) & East Blue Power (375MW) Planned for 2029 ~ 2031 Taean Shinan-Ui Haesong Bandibuli East Blue Power 40km 33km 80~100km Busan Ulsan Upcoming Projects LSMS Awarded Multiple Contracts and Selected as the Preferred T&I Supplier Export Cable
16. TurnKey Solution Provider
17. LSMS Capabilities Strengthening TurnKey Delivery Capability with a New 10,000 MT Carousel Cable Barge Designed for HVAC Projects in Singapore
18. For Inquiries, Please Do Not Hesitate to Contact: Hans Kim Ray Yoon Email sr.yoon@lsms.co.kr Mobile +82 10-6550-8973 What’s App Line Team Leader Energy Business Team General Manager Energy Business Team Email hans.kim@lsms.co.kr Mobile +82 10-2529-7928 What’s App Line Total Marine Solution Provider Company Headquarters 16F, 184, Jungang-daero, Dong-gu, Busan, Republic of Korea (48821)
