Planning time-resolved experiments: kinetic modelling

Planning time-resolved experiments: kinetic modelling

Presented at the Time-Resolved I19 Workshop at Diamond Light Source.

Jonathan Skelton

January 24, 2023
Tweet

More Decks by Jonathan Skelton

Other Decks in Science

Transcript

  1. Dr Jonathan Skelton
    Department of Chemistry, University of Manchester
    ([email protected])
    Planning time-resolved experiments:
    kinetic modelling

    View Slide

  2. Acknowledgements
    Dr Jonathan Skelton i19 TR Workshop, 24th Jan 2023 | Slide 2
    ... plus many others, too numerous to
    mention

    View Slide

  3. Overview
    i19 TR Workshop, 24th Jan 2023 | Slide 3
    Dr Jonathan Skelton
    o Solid-state linkage isomerism
    o Photocrystallography
    o Kinetics: JMAK theory
    • The decay process
    • The excitation process
    • Steady-state behaviour
    • Numerical simulations
    o Summary: key questions to ask
    o Time-resolved experiment
    https://bit.ly/3ZWTayo

    View Slide

  4. Solid-state linkage isomerism
    i19 TR Workshop, 24th Jan 2023 | Slide 4
    Dr Jonathan Skelton
    https://chem-is-you.blogspot.com/2013/05/chemistry-of-d-and-f-block-origin-of.html

    View Slide

  5. Solid-state linkage isomerism
    i19 TR Workshop, 24th Jan 2023 | Slide 5
    Dr Jonathan Skelton
    SO2
    (sulphoxide)
    NO (nitrosyl)
    NO2
    - (nitrite)
    N2
    (“dinitrogen”)

    View Slide

  6. Solid-state linkage isomerism
    i19 TR Workshop, 24th Jan 2023 | Slide 6
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  7. Photocrystallography
    i19 TR Workshop, 24th Jan 2023 | Slide 7
    Dr Jonathan Skelton
    Images: L. E. Hatcher and M. R. Warren

    View Slide

  8. Photocrystallography
    i19 TR Workshop, 24th Jan 2023 | Slide 8
    Dr Jonathan Skelton

    View Slide

  9. Photocrystallography
    i19 TR Workshop, 24th Jan 2023 | Slide 9
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  10. Kinetics: JMAK theory
    i19 TR Workshop, 24th Jan 2023 | Slide 10
    Dr Jonathan Skelton
    Slow initial rate: waiting
    for nuclei to form
    Fast transformation: existing nuclei
    grow and new nuclei form
    Slow final rate: little untransformed
    phase for nuclei to continue to
    grow
    https://www.tf.uni-kiel.de/matwis/amat/iss/kap_8/illustr/s8_4_3b.html

    View Slide

  11. Kinetics: JMAK theory
    i19 TR Workshop, 24th Jan 2023 | Slide 11
    Dr Jonathan Skelton
    Can be described by the JMAK
    equation:
    𝛼 𝑡 = 𝛼∞
    + (𝛼0
    − 𝛼∞
    )𝑒−𝑘𝑡𝑛
    where:
    𝛼 𝑡
    𝛼0
    /𝛼∞
    𝑘
    𝑛
    =
    =
    =
    =
    fraction transformed
    initial/final fractions
    rate constant
    Avrami exponent
    https://www.tf.uni-kiel.de/matwis/amat/iss/kap_8/illustr/s8_4_3b.html

    View Slide

  12. JMAK: the 𝒌 and 𝒏 parameters
    i19 TR Workshop, 24th Jan 2023 | Slide 12
    Dr Jonathan Skelton
    0.0
    0.2
    0.4
    0.6
    0.8
    1.0
    0 10 20 30 40 50 60
    α(t)
    t [s]
    k = 0.01 k = 0.1 k = 1
    0.0
    0.2
    0.4
    0.6
    0.8
    1.0
    0 10 20 30 40 50 60
    α(t)
    t [s]
    n = 1 n = 2 n = 3 n = 4
    𝛼0
    = 1, 𝛼∞
    = 0, 𝑛 = 1 𝛼0
    = 1, 𝛼∞
    = 0, 𝑘 = 10-2 s−𝑛

    View Slide

  13. JMAK: the Avrami exponent 𝒏
    i19 TR Workshop, 24th Jan 2023 | Slide 13
    Dr Jonathan Skelton
    Initial
    𝑛 = 1 (0D growth) 𝑛 = 2 (1D growth)
    𝑛 = 4 (3D growth)
    𝑛 = 3 (2D growth)

    View Slide

  14. The decay process
    i19 TR Workshop, 24th Jan 2023 | Slide 14
    Dr Jonathan Skelton
    Decay corresponds to 𝛼𝑡=0
    = 1 and 𝛼𝑡=∞
    = 0:
    𝛼 𝑡 = 𝑒−𝑘dec𝑡𝑛
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  15. Temperature dependence
    i19 TR Workshop, 24th Jan 2023 | Slide 15
    Dr Jonathan Skelton
    The 𝑘dec
    as a function of temperature usually follows the Arrhenius law:
    𝑘dec
    𝑇 = 𝐴exp −
    𝐸A
    𝑅𝑇
    → ln 𝑘dec
    𝑇 = ln 𝐴 −
    𝐸A
    𝑅
    1
    𝑇
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  16. Metastable state lifetime
    i19 TR Workshop, 24th Jan 2023 | Slide 16
    Dr Jonathan Skelton
    Substitute 𝑘dec
    (𝑇) into JMAK equation, set 𝛼 = 0.5 and solve for 𝑡:
    𝑡
    𝛼 = 0.5 = −
    1
    𝐴
    ln 0.5 exp
    𝐸A
    𝑅𝑇
    1
    𝑛
    1 s
    10 s
    1 min
    1 hr
    1 day
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  17. The excitation process
    i19 TR Workshop, 24th Jan 2023 | Slide 17
    Dr Jonathan Skelton
    Excitation corresponds to 𝛼𝑡=0
    = 0 and 𝛼𝑡=∞
    = 1:
    𝛼 𝑡 = 1 − 𝑒−𝑘exc𝑡𝑛
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  18. The excitation process
    i19 TR Workshop, 24th Jan 2023 | Slide 18
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J
    MS occupation after
    120 s illumination w/
    four different xtals

    View Slide

  19. Steady-state behaviour
    i19 TR Workshop, 24th Jan 2023 | Slide 19
    Dr Jonathan Skelton
    For a typical linkage isomer system, we have:
    o A strongly temperature-dependent decay rate 𝑘dec
    o A weakly temperature-dependent (i.e. approximately constant) excitation
    rate 𝑘exc
    Competing processes result in three temperature regimes:
    o Low 𝑇: 𝑘dec
    << 𝑘exc
    → 𝛼 = 1 (complete excitation)
    o High 𝑇: 𝑘dec
    >> 𝑘exc
    → 𝛼 = 0 (no excitation)
    o Intermediate 𝑇: 𝑘dec
    ≈ 𝑘exc
    → 0 < 𝛼 < 1 (steady state)
    Can measure the steady-state occupation as a function of temperature by
    collecting structures under continuous illumination

    View Slide

  20. Steady-state behaviour
    i19 TR Workshop, 24th Jan 2023 | Slide 20
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J
    “metastable limit”

    View Slide

  21. Numerical simulations
    i19 TR Workshop, 24th Jan 2023 | Slide 21
    Dr Jonathan Skelton
    Cannot predict steady-state behaviour analytically -> need numerical simulations
    𝑡 = 0
    𝛼 = 𝛼0
    𝑡dec
    ′ = Τ
    −ln𝛼 𝑘dec
    Τ
    1 𝑛
    ∆𝛼 dec
    = exp −𝑘dec
    𝑡dec
    ′ + ∆𝑡 𝑛 − 𝛼
    Excitation active?
    𝑡 = 𝑡 + ∆𝑡
    𝛼 = 𝛼 + ∆𝛼 dec
    + ∆𝛼 exc
    ∆𝛼 exc
    = 0
    𝑡exc
    ′ = Τ
    −ln 1 − 𝛼 𝑘exc
    Τ
    1 𝑛
    ∆𝛼 exc
    = 1 − exp −𝑘exc
    𝑡exc
    ′ + ∆𝑡 𝑛 − 𝛼
    𝑡 = 𝑡max
    ?
    𝑡 = 𝑡
    𝛼(𝑡) = 𝛼
    Update params?
    Predicted 𝑡, 𝛼(𝑡)
    Y
    N
    N
    Y
    N
    Y

    View Slide

  22. Numerical simulations 1
    i19 TR Workshop, 24th Jan 2023 | Slide 22
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J

    View Slide

  23. Numerical simulations 2
    i19 TR Workshop, 24th Jan 2023 | Slide 23
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J
    Each simulation started with 𝛼 = 0 and run
    in three segments:
    1. 𝑡 = 0-2 mins: no excitation → nothing
    happens
    2. 𝑡 = 2-4 mins: excitation switched on →
    excites towards steady state
    3. 𝑡 = 4-24 mins: excitation switched off
    → steady-state population decays

    View Slide

  24. Numerical simulations 3
    i19 TR Workshop, 24th Jan 2023 | Slide 24
    Dr Jonathan Skelton
    L. E. Hatcher et al., Phys. Chem. Chem. Phys. 20, 5874 (2018), DOI: 10.1039/C7CP05422J
    180 s pulse

    View Slide

  25. Summary: key questions to ask
    Dr Jonathan Skelton
    o Can we measure the kinetics of the process we want to study?
    • Performed low-𝑇 (“slow”) photocrystallography experiments on a lab
    machine and extrapolated to higher 𝑇
    o Can we estimate a “ballpark” lifetime for the excited state?
    • Can derive from JMAK kinetic fits; ranges from ~days at 𝑇 = 200 K to ~1s at
    300 K
    o Can we use our data to plan any other aspects of the experiments?
    • Can use fairly simple numerical simulations parameterised by kinetic
    measurements to:
    1) predict behaviour during a simulated pump/probe experiment; and
    2) suggest experimental parameters e.g. excitation time and
    measurement temperature
    i19 TR Workshop, 24th Jan 2023 | Slide 25

    View Slide

  26. Time-resolved experiment
    i19 TR Workshop, 24th Jan 2023 | Slide 26
    Dr Jonathan Skelton

    View Slide

  27. Time-resolved experiment
    i19 TR Workshop, 24th Jan 2023 | Slide 27
    Dr Jonathan Skelton
    Our workflow:
    1. Preliminary experiments:
    o Decay curves at 𝑇 = 240-270 K
    o Excitation curve at 𝑇 = 150 K
    o Steady-state occupation between 𝑇 = 250-300 K
    2. Kinetic fitting to derive 𝐴 and 𝐸A
    for decay and estimate 𝑘exc
    3. Numerical simulations to select 𝑡exc
    /𝑡dec
    and estimate 𝑇 for given 𝑡cyc
    4. Time-resolved measurement at estimated 𝑇 + automatic processing to
    determine rough 𝛼 𝑡 - inspect result and raise/lower 𝑇 as required
    5. Data fitting using numerical simulations to extract 𝑘exc
    and 𝑘dec
    from each
    TR dataset

    View Slide

  28. Preliminary measurements
    i19 TR Workshop, 24th Jan 2023 | Slide 28
    Dr Jonathan Skelton

    View Slide

  29. Numerical simulations
    i19 TR Workshop, 24th Jan 2023 | Slide 29
    Dr Jonathan Skelton
    𝑡cyc
    = 170 s 𝑡cyc
    = 34 s
    𝑡cyc
    = 14 s
    𝑡cyc
    = 22 s
    𝑡cyc
    = 108 s
    L. E. Hatcher et al., Nature Comms. Chem. 5, 102 (2022), DOI: 10.1038/s42004-022-00716-1

    View Slide

  30. TR results 1
    i19 TR Workshop, 24th Jan 2023 | Slide 30
    Dr Jonathan Skelton

    View Slide

  31. TR results 2
    i19 TR Workshop, 24th Jan 2023 | Slide 31
    Dr Jonathan Skelton
    Data from lab (Ph-SCXRD), DLS (Ph-SCXRD) and DLS (TR)
    L. E. Hatcher et al., Nature Comms. Chem. 5, 102 (2022), DOI: 10.1038/s42004-022-00716-1

    View Slide

  32. TR results 3
    i19 TR Workshop, 24th Jan 2023 | Slide 32
    Dr Jonathan Skelton
    L. E. Hatcher et al., Nature Comms. Chem. 5, 102 (2022), DOI: 10.1038/s42004-022-00716-1

    View Slide

  33. Follow up: Timepix tests
    i19 TR Workshop, 24th Jan 2023 | Slide 33
    Dr Jonathan Skelton
    L. E. Hatcher et al., Nature Comms. Chem. 5, 102 (2022), DOI: 10.1038/s42004-022-00716-1
    Single module,
    (-2 1 0) reflection

    View Slide

  34. Thankyou for listening!
    Any questions?
