2024-05-31 Spring IO - Micrometer Mastery: Unleash Advanced Observability in your JVM Apps

Transcript

1. Micrometer Mastery: Unleash Advanced Observability in your JVM Apps Spring I/O 2024-05-31 Jonatan Ivanov & Tommy Ludwig
2. Spring Team/Micrometer Jonatan Ivanov Tommy Ludwig
3. Agenda • Brief recap of observability • Micrometer Observation API • Micrometer Docs Generator • Demos
4. Observability basics recap
5. Recap of observability basics • Purpose • Metrics • Tracing • Out-of-the-box instrumentation for common components • Spring Boot auto-configuration
6. What is Observability? How well we can understand the internals of a system based on its outputs (Providing meaningful information about what happens inside) (Data about your app)
7. Why do we need Observability? Today's systems are increasingly complex (cloud) (Death Star Architecture, Big Ball of Mud)
8. Environments can be chaotic You turn a knob here a little and apps are going down there We need to deal with unknown unknowns We can’t know everything Things can be perceived differently by observers Everything is broken for the users but seems ok to you Why do we need Observability?
9. Why do we need Observability? (business perspective) Reduce lost revenue from production incidents Lower mean time to recovery (MTTR) Require less specialized knowledge Shared method of investigating across system Quantify user experience Don't guess, measure!
10. Logging Metrics Distributed Tracing
11. Examples Latency Logging (What?) Processing took 140ms Metrics (Context?) P99.999: 140ms Max: 150ms Distributed Tracing (Why?) DB was slow (lot of data was requested) Error Logging (What?) Processing failed (stacktrace?) Metrics (Context?) The error rate is 0.001/sec 2 errors in the last 30 minutes Distributed Tracing (Why?) DB call failed (invalid input)
12. SLF4J with Logback comes pre-configured SLF4J (Simple Logging Façade for Java) Simple API for logging libraries Logback Natively implements the SLF4J API If you want Log4j2 instead of Logback: - spring-boot-starter-logging + spring-boot-starter-log4j2 Logging with JVM/Spring: SLF4J + Logback
13. Metrics with JVM/Spring: Micrometer Dimensional Metrics library on the JVM Like SLF4J, but for metrics API is independent of the configured metrics backend Supports many backends Comes with spring-boot-actuator Spring projects are instrumented using Micrometer Many third-party libraries use Micrometer
14. Supported metrics backends/formats/protocols Ganglia Graphite Humio InfluxDB JMX KairosDB New Relic (/actuator/metrics) OpenTSDB OTLP Prometheus SignalFx Stackdriver (GCP) StatsD Wavefront (VMware) AppOptics Atlas Azure Monitor CloudWatch (AWS) Datadog Dynatrace Elastic
15. Distributed Tracing with JVM/Spring Boot 2.x: Spring Cloud Sleuth Boot 3.x: Micrometer Tracing (Sleuth w/o Spring dependencies) Provide an abstraction layer on top of tracing libraries - Brave (OpenZipkin), “default” - OpenTelemetry (CNCF), “experimental” Instrumentation for Spring Projects, 3rd party libraries, your app Support for various backends
16. DEMO 🍵 github.com/jonatan-ivanov/teahouse
17. Tea Service 💻 Tealeaf Service Water Service Architecture Tealeaf DB Water DB
18. through traces TraceID ❮ Exemplars Tags ❯ metrics logs traces
19. Cover w/ Image So we’re done…? • Out-of-the-box instrumentation is useful! • But what about: ◦ Custom components ◦ Customization of existing instrumentation ◦ Understanding how instrumentation works
20. Observation API
21. • Add logs (application logs) • Add metrics • Add Distributed Tracing You want to instrument your application…
22. Introducing Observation API • New module in Micrometer 1.10 (micrometer-observation) - micrometer-core has a dependency on it • Higher level abstraction than metrics or tracing for timing an operation • Instrument once, configure handlers for multiple purposes (e.g.: metrics, tracing, logging) • Already used for most instrumentation shown
23. Observation API basic usage example Observation observation = Observation.start("talk",registry); try { // TODO: scope doSomething(); // ← This is what we’re observing } catch (Exception exception) { observation.error(exception); throw exception; } finally { // TODO: attach tags (key-value) observation.stop(); }
24. ObservationHandler with Spring Boot Spring Boot auto-configures handlers for meters and tracing. Boot will also register ObservationHandler beans to the ObservationRegistry that it auto-configures. @Bean ObservationHandler<MyContext> myHandler() { return new MyObservationHandler(); }
25. Configuring an ObservationHandler (without Boot) ObservationRegistry registry = ObservationRegistry.create(); registry.observationConfig() .observationHandler(new MetricsHandler(...)) .observationHandler(new TracingHandler(...)) .observationHandler(new LoggingHandler(...)) .observationHandler(new AuditEventHandler(...));
26. Let’s look at some code
27. Observation Predicate and Filter ObservationPredicate • BiPredicate: (name, context) → Boolean • Whether an Observation is ignored (noop) ObservationFilter • Modify the Observation.Context • Right before ObservationHandler#onStop • e.g. common tags (KeyValues)
28. Conventions for instrumentation • Instrumentation by default provides a convention ◦ Naming, tags (KeyValues) • You may want to customize the convention for an instrumentation without rewriting the instrumentation • Control the timing of changing conventions ◦ Convention changes are breaking changes
29. Introducing ObservationConvention • Instrumentation can use a default ObservationConvention while allowing users to provide a custom implementation • Extend a default implementation or implement your own • See, for example, Spring Framework’s docs
30. Observation.Context • Holds the state/data of an Observation ◦ e.g. request/response object • ObservationHandler / ObservationConvention will receive it • Mutable, you can add data to it ◦ Instrumentation time ◦ Pass data between handler methods
31. Let’s look at some code (again)
32. Micrometer Docs Generator
33. Documenting instrumentation • Keeping documentation in sync with the implementation is difficult and error-prone. • Introducing Micrometer Docs Generator • Define an ObservationDocumentation enum for your Observation-based instrumentation and generate documentation based on it as part of the build • Integrate it with ObservationConvention
34. Let’s look at some code (again) (again)
35. Observation API real-world usage examples ServerHttpObservationFilter (Spring MVC) DefaultServerRequestObservationConvention ServerHttpObservationDocumentation RestTemplate
36. DEMO👂🎶 github.com/jonatan-ivanov/teahouse
38. Thank you! github.com/jonatan-ivanov/teahouse (branch: 2024-springio) slack.micrometer.io
