The Scheduler Saga

The Go scheduler is, simply put, the orchestrator of the language runtime.
It schedules and unschedules goroutines, and also coordinates network polling and memory management.

This talk will explore the inner workings of the scheduler machinery. We will delve into the M:N multiplexing of goroutines on system threads, and the mechanisms to schedule, unschedule, and rebalance goroutines. We will touch upon how the scheduler supports the netpoller, and the memory management systems for goroutine stack resizing and heap garbage collection. Finally, we will evaluate the effectiveness and performance of the scheduler.

Transcript

1. @kavya719
   The Scheduler Saga


   View Slide

2. kavya


   View Slide

3. the innards of
   the scheduler


   View Slide

4. the behind-the-scenes orchestrator
   of Go programs.
   the scheduler


   View Slide

5. func main() {
   // Create goroutines.

   for _, i := range images {
   go process(i)
   }
   ...
   // Wait.
   <-ch
   }


   View Slide

6. func main() {
   // Create goroutines.

   for _, i := range images {
   go process(i)
   }
   ...
   // Wait.
   <-ch
   }
   func process(image) {
   // Create goroutine.
   go reportMetrics()


   complicatedAlgorithm(image)
   // Write to file.
   f, err := os.OpenFile()
   ...
   }
   runs goroutines created
   pauses and resumes them:

   blocking channel operations,
   mutex operations.
   coordinates:
   blocking system calls, network I/O,
   runtime tasks garbage collection.


   View Slide

7. func main() {
   // Create goroutines.

   for _, i := range images {
   go process(i)
   }
   ...
   // Wait.
   <-ch
   }
   func process(image) {
   // Create goroutine.
   go reportMetrics()


   complicatedAlgorithm(image)
   // Write to file.
   f, err := os.OpenFile()
   ...
   }
   runs goroutines created
   coordinates:
   blocking system calls, network I/O,
   runtime tasks garbage collection.
   pauses and resumes them:

   blocking channel operations,
   mutex operations.
   …for hundreds of thousands of goroutines*
   * dependent on workload and hardware, of course.


   View Slide

8. the design of the scheduler, & its scheduling decisions
   impact the performance of our programs.


   View Slide

9. spec it
   build!
   the big ideas & one sneaky idea.
   assess it.
   the difficult questions.
   the important questions.


   View Slide

10. spec it
    the what, when & why.


    View Slide

11. why have a scheduler?


    View Slide

12. conceptually similar to kernel threads managed by the OS, but

    managed entirely by the Go runtime.
    lighter-weight and cheaper than kernel threads.

    multiplexed onto kernel threads by the scheduler.
    goroutines are user-space threads.
    why have a scheduler?


    View Slide

13. conceptually similar to kernel threads managed by the OS, but

    managed entirely by the Go runtime.
    lighter-weight and cheaper than kernel threads.

    multiplexed onto kernel threads by the scheduler.
    smaller memory footprint:

    initial goroutine stack = 2KB; default thread stack = 8KB.

    state tracking overhead.
    faster creation, destruction, context switches:

    goroutine switches = ~tens of ns; thread switches = ~a µs.
    goroutines are user-space threads.
    why have a scheduler?


    View Slide

14. conceptually similar to kernel threads managed by the OS, but

    managed entirely by the Go runtime.
    lighter-weight and cheaper than kernel threads.

    multiplexed onto kernel threads by the scheduler.
    CPU core
    thread2
    thread1
    }
    OS scheduler
    …but how are they run?
    goroutines are user-space threads.
    why have a scheduler?


    View Slide

15. goroutines are user-space threads.
    conceptually similar to kernel threads managed by the OS, but

    managed entirely by the Go runtime.
    lighter-weight and cheaper than kernel threads.
    multiplexed onto kernel threads.
    CPU core
    g1 g6
    g2
    thread2
    }
    OS scheduler
    CPU core
    }
    OS scheduler
    } Go scheduler
    why have a scheduler?


    View Slide

16. when does it schedule?


    View Slide

17. when does it schedule?
    func main() {
    // Create goroutines.

    for _, i := range images {
    go process(i)
    }
    ...
    // Wait.
    <-ch
    }
    goroutine creation
    run new goroutines soon,
    continue this for now.
    goroutine blocking
    pause this one immediately.
    func process(image) {
    // Create goroutine.
    go reportMetrics()


    complicatedAlgorithm(image)
    // Write to file.
    f, err := os.OpenFile()
    ...
    }
    the thread itself blocks too!
    blocking system call
    At operations that should or would affect goroutine execution.


    View Slide

18. when does it schedule?
    Tmain
    create g1 <-ch
    S S
    gmain g1
    gmain
    T: threads
    g: goroutines
    S: scheduler
    time
    At operations that should or would affect goroutine execution.
    The runtime causes a switch into the scheduler under-the-hood,
    and the scheduler may schedule a different goroutine on this thread.


    View Slide

19. use a small number of kernel threads.
    kernel threads are expensive to create.
    support high concurrency.
    Go programs should be able to run lots and lots of goroutines.
    leverage parallelism i.e. scale to N cores.
    On an N-core machine, Go programs should be able to run N

    goroutines in parallel.*
    #schedgoals
    for scheduling goroutines onto kernel threads.
    * depending on the program structure, of course.


    View Slide

20. build it!
    the big ideas & neat details.


    View Slide

21. how to multiplex goroutines onto kernel threads?
    when to create threads?
    how to distribute goroutines across threads?


    View Slide

22. Goroutines that ready-to-run and need to be scheduled are tracked

    in heap-allocated FIFO runqueues.
    prelude: runqueues


    View Slide

23. Tmain
    create g1
    gmain
    program heap memory
    add g1
    remove this g to run
    longest waiter
    runq.head runq.tail
    runnable goroutines
    {
    Goroutines that ready-to-run and need to be scheduled are tracked

    in heap-allocated FIFO runqueues.
    prelude: runqueues


    View Slide

24. assume: running on a box with 2 CPU cores.
    creates g1,
    g2
    goroutine blocks
    func main() {
    // Create goroutines.

    for _, i := range images {
    go process(i)
    }
    ...
    // Wait.
    <-ch
    }
    func process(image) {
    // Create goroutine.
    go reportMetrics()


    c ... omplicatedAlgorithm(image)
    // Write to fi, err := os.OpenFile()
    }
    gmain
    g1


    View Slide

25. first, the non-ideas


    View Slide

26. — no concurrency!

    if a goroutine blocks the thread, no other goroutines run either.
    — no parallelism possible:

    can only use a single CPU core, even if more are available.
    first, the non-ideas
    Tmain
    gmain g1
    blocking
    syscall
    <-ch
    I. Multiplex all goroutines on a single thread.
    g3
    runq
    create g1
    g3


    View Slide

27. II. Create & destroy a thread per-goroutine.
    — defeats the purpose of using goroutines

    threads are heavyweight, and expensive to create and destroy.
    okay, here’s an idea…
    first, the non-ideas


    View Slide

28. Create threads when needed; keep them around for reuse.
    idea I: reuse threads
    there’re goroutines to run,
    but all threads are busy.


    View Slide

29. Create threads when needed; keep them around for reuse.
    idea I: reuse threads
    “thread parking” i.e.
    put them to sleep;
    no longer uses a CPU core.
    track idle threads in a list.
    (“mIdle”).
    there’re goroutines to run,
    but all threads are busy.


    View Slide

30. Create threads when needed; keep them around for reuse.
    idea I: reuse threads
    The threads get goroutines to run from a runqueue.


    View Slide

31. Tmain
    gmain
    runq
    program scheduler
    idle threads


    View Slide

32. Tmain
    gmain
    create g1
    runq
    program scheduler
    idle threads


    View Slide

33. add g1
    to runqueue.
    work to do and all threads busy,
    start one to run g1
    !
    Tmain
    gmain
    create g1
    g1
    runq
    program scheduler
    idle threads


    View Slide

34. T1
    Tmain
    gmain
    create g1
    runq
    program scheduler
    idle threads
    g1


    View Slide

35. T1 g1
    Tmain
    gmain
    create g1
    runq
    program scheduler
    idle threads


    View Slide

36. T1
    Tmain
    gmain
    g1 exits
    create g1
    runq
    g1
    program scheduler
    idle threads


    View Slide

37. Say g1
    completes, park T1
    rather than destroying it.
    T1
    Tmain
    gmain
    create g1
    runq
    program scheduler
    idle threads


    View Slide

38. Tmain
    gmain
    create g1
    runq
    program scheduler
    create g2
    idle threads
    T1


    View Slide

39. Tmain
    gmain
    create g1
    runq
    add g2
    to runqueue.
    idle thread present,
    don’t start a thread!
    g2
    program scheduler
    create g2
    idle threads
    T1


    View Slide

40. T1 g2
    runq
    Tmain
    gmain
    create g1
    program scheduler
    a match made in (scheduling) heaven.
    create g2
    idle threads


    View Slide

41. sweet.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.

    Work is naturally balanced across threads too.


    View Slide

42. sweet.
    …but
    — multiple threads access the same runqueue, so need a lock.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.

    Work is naturally balanced across threads too.
    serializes scheduling.


    View Slide

43. sweet.
    Tmain
    gmain
    create long-running g x10000,
    in quick succession.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.

    Work is naturally balanced across threads too.
    …but
    — multiple threads access the same runqueue, so need a lock.


    View Slide

44. sweet.
    — an unbounded number of threads can still be created.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.
    …but
    — multiple threads access the same runqueue, so need a lock.


    View Slide

45. sweet.
    hella contention possible.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.
    — an unbounded number of threads can still be created.
    …but
    — multiple threads access the same runqueue, so need a lock.


    View Slide

46. sweet.
    hella not scalable.
    We have a scheme that nicely reduces thread creations and
    still provides concurrency, parallelism.
    — an unbounded number of threads can still be created.
    …but
    — multiple threads access the same runqueue, so need a lock.


    View Slide

47. reusing threads is still a good idea.
    If the problem is an unbounded number threads can access the runqueue…
    thread creation is expensive; reusing threads amortizes that cost.


    View Slide

48. idea II: limit threads accessing runqueue


    View Slide

49. idea II: limit threads accessing runqueue
    Limit the number of threads accessing the runqueue.
    As before, keep threads around for reuse;

    get goroutines to run from the runqueue.


    View Slide

50. idea II: limit threads accessing runqueue
    threads that are running goroutines;
    threads in syscalls etc. won’t count
    towards this limit.
    Limit the number of threads accessing the runqueue.
    As before, keep threads around for reuse;

    get goroutines to run from the runqueue.


    View Slide

51. idea II: limit threads accessing runqueue
    Limit the number of threads accessing the runqueue.
    As before, keep threads around for reuse;

    get goroutines to run from the runq.
    …to what?
    too many —> too much contention.
    too few -> won’t use all the CPU cores, i.e.
    will give up on parallelism.


    View Slide

52. idea II: limit threads accessing runqueue
    Limit the number of threads accessing the runqueue.
    As before, keep threads around for reuse;

    get goroutines to run from the runq.
    …to what?
    To the number of CPU cores, to get all the parallelism we can!
    CORES
    too many —> too much contention.
    too few -> won’t use all the CPU cores, i.e.
    will give up on parallelism.


    View Slide

53. T1 g1
    Tmain
    gmain
    create g1
    Say Tmain
    creates g2,
    but gmain
    and g1
    are still running.
    Limit # threads accessing runqueue to number of CPU cores (N) = 2.
    runq
    program scheduler
    create g2


    View Slide

54. T1 g1
    Tmain
    gmain
    create g1 create g2
    Say Tmain
    creates g2,
    but gmain
    and g1
    are still running.
    Limit # threads accessing runqueue to number of CPU cores (N) = 2.
    g2
    runq
    program scheduler
    add g2
    to runqueue.
    work to do, all threads busy,

    but #(runq threads) is not < N,
    don’t start any!


    View Slide

55. T1 g1
    Tmain
    gmain g2
    g2
    will be run at a future point.
    Limit # threads accessing runqueue to number of CPU cores (N) = 2.
    runq
    program scheduler
    create g1 create g2 <-ch


    View Slide

56. CORES
    We get around unbounded thread contention, without

    giving up parallelism.
    seems reasonable.


    View Slide

57. CORES
    We get around unbounded thread contention, without

    giving up parallelism.
    …ship it?
    seems reasonable.


    View Slide

58. CORES
    We get around unbounded thread contention, without

    giving up parallelism.
    …ship it?
    seems reasonable.


    View Slide

59. We get around unbounded thread contention, without

    giving up parallelism.
    — This scheme does not scale with the number of CPU cores!
    As N ↑ ⟶ number of runqueue-accessing threads ↑.
    seems reasonable.
    …ship it?
    ruh-roh, we’re in hella contention land again.


    View Slide

60. the experiment
    the modified Go scheduler:
    uses a global runqueue, and

    #(goroutine-running threads) = #(CPU cores).
    everything else about the runtime is unmodified.
    the benchmark:
    CreateGoroutineParallel, in the go repo.
    creates #(CPU cores) goroutines in parallel,

    until a total of b.N goroutines have been created.
    the machines:
    A 4-core and 16-core x86-64.


    View Slide

61. the modified Go scheduler:
    uses a global runqueue, and

    #(goroutine-running threads) = #(CPU cores).
    everything else about the runtime is unmodified.
    the benchmark:
    CreateGoroutineParallel, in the go repo.
    creates #(CPU cores) goroutines in parallel,

    until a total of b.N goroutines have been created.
    the machines:
    A 4-core and 16-core x86-64.
    the experiment


    View Slide

62. scheduler benchmarks
    (CreateGoroutineParallel)
    the experiment
    On the 4-core:
    the modified scheduler takes about
    4x longer than the Go scheduler.
    On the 16-core:
    the modified scheduler takes about
    31x longer than the Go scheduler!


    View Slide

63. We get around unbounded thread contention, without

    giving up parallelism.
    — This scheme does not scale with the number of CPU cores!
    As N ↑ ⟶ number of runqueue-accessing threads ↑.
    ruh-roh, we’re in hella contention land again.
    nope.
    seems reasonable.
    …ship it?


    View Slide

64. really, the problem is the single shared runqueue.
    #(goroutine-running threads) = #(CPU cores) is still clever.
    we maximally leverage parallelism by this.


    View Slide

65. idea III: distributed runqueues
    Use N runqueues on an N-core machine.


    A thread claims a runqueue to run goroutines.


    View Slide

66. it inserts and removes goroutines
    from the runqueue it is associated with.
    idea III: distributed runqueues
    As before, reuse threads.
    Use N runqueues on an N-core machine.


    A thread claims a runqueue to run goroutines.


    View Slide

67. program scheduler
    add g1
    to Tmain
    ’s runq
    work to do, all threads busy,

    #(runq threads) < N,
    start one to run g1
    !
    Tmain
    gmain
    create g1
    runqA
    g1
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

68. T1
    Tmain
    gmain
    create g1
    program scheduler
    g1
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

69. T1
    Tmain
    gmain
    create g1
    program scheduler
    g1
    uh oh.
    !
    The local runq is empty.
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

70. so, steal!
    If the local runqueue is empty, steal work from another runqueue.
    It organically balances work across runqueues.
    “work stealing”
    pick another runqueue at random, steal half its work.


    View Slide

71. so, steal!
    If the local runqueue is empty, steal work from another runqueue.
    It organically balances work across threads.


    View Slide

72. T1
    Tmain
    gmain
    create g1
    program scheduler
    g1
    !
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

73. T1
    Tmain
    gmain
    create g1
    program scheduler
    g1
    the steal
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

74. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    “the end justifies the means”?
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

75. this looks promising!
    let’s continue.
    This scheme scales nicely with the number of CPU cores, and
    threads don’t contend for work.
    The work across threads is balanced with work-stealing.

    handoff prevents starvation from blocked threads.


    View Slide

76. goroutine & thread block
    creates g3
    func process(image) {
    // Create goroutine.
    go reportMetrics()


    complicatedAlgorithm(image)
    // Write to file.
    f, err := os.OpenFile()
    ...
    }
    g1


    View Slide

77. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    g3
    create g3 add g3
    to T1
    ’s runq.
    don’t start a thread;
    #(runq-threads) is not < N
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

78. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    blocking
    syscall
    g3
    create g3
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

79. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create g3 blocking
    syscall
    g3
    The runqueue has work,
    and the thread’s blocked.
    runqA
    runqB
    oh no.
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

80. Use a mechanism to transfer a blocked thread’s runqueue to another
    thread.
    “handoff”
    If it did, it could give up its runqueue unnecessarily!
    Why can’t the thread itself handoff the runqueue, before it enters the
    system call?
    }
    a background monitor thread that detects threads blocked for a while,
    takes and gives the runqueues away.


    View Slide

81. “handoff”
    Use a mechanism to transfer a blocked thread’s runqueue to another
    thread.
    The thread limit (= number of CPU cores) applies to goroutine-running

    threads only.

    The original thread is blocked; so, another thread can take its place
    running goroutines.
    this is okay to do!
    Unpark a parked thread or start a thread if needed.


    View Slide

82. Use a mechanism to transfer a blocked thread’s runqueue to another
    thread.
    “handoff”
    Prevents goroutine starvation.


    View Slide

83. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create gx blocking
    syscall
    g3
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

84. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create gx blocking
    syscall
    g3
    There’s a runqueue with work,
    its thread is blocked, and
    no parked threads, so
    the monitor starts a thread.
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

85. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create gx blocking
    syscall
    T2
    g3
    runqA
    Number of CPU cores (N) = number of runqueues = 2.
    runqB


    View Slide

86. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create gx blocking
    syscall
    g3
    T2
    handoff
    via the monitor
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

87. program scheduler
    T1 g1
    Tmain
    gmain
    create g1
    create gx blocking
    syscall
    g3
    T2
    runqA
    runqB
    Number of CPU cores (N) = number of runqueues = 2.


    View Slide

88. we have (finally) arrived.
    this looks promising!
    this looks promising!
    This scheme scales nicely with the number of CPU cores, and
    threads don’t contend for work.
    The work across threads is balanced with work-stealing;

    handoff prevents starvation from blocked threads.


    View Slide

89. the Go scheduler
    the big ideas.
    reuse threads.


    View Slide

90. the Go scheduler
    the big ideas.
    reuse threads.
    limit #(goroutine-running) threads to
    number of CPU cores.
    GOMAXPROCS


    View Slide

91. the Go scheduler
    the big ideas.
    distributed runqueues with stealing and handoff.
    limit #(goroutine-running) threads to
    number of CPU cores.
    GOMAXPROCS
    reuse threads.


    View Slide

92. …and one sneaky idea.
    The scheduling points are cooperative i.e. the program calls into
    the scheduler.
    // A CPU-bound computation that runs
    // for a long, long time.
    func complicatedAlgorithm(image) {
    // Do not create goroutines, or do
    // anything the blocks at all.
    ...
    }
    ruh-roh.
    a CPU-hog can starve runqueues


    View Slide

93. To avoid this, the Go scheduler implements preemption*.
    * technically, cooperative preemption.
    It runs a background thread called the “sysmon”,
    to detect long-running goroutines (> 10ms; with caveats),
    and unschedule them when possible.


    View Slide

94. * technically, cooperative preemption.
    …where would preempted goroutines be put?
    They essentially starved other goroutines from running, so
    don’t want to put them back on the per-core runqueues;
    it would not be fair.
    To avoid this, the Go scheduler implements preemption*.
    * technically, cooperative preemption.


    View Slide

95. …on a global runqueue.
    “surprise”!
    The Go scheduler has a global runqueue in addition to the
    distributed runqueues.
    that’s right.


    View Slide

96. …on a global runqueue.
    It uses this as a lower priority runqueue.
    Threads access it less frequently than their local runqueues;

    so, contention is not a real issue.


    View Slide

97. a neat detail (or two)…
    thread spinning
    Threads without work “spin” looking for work before parking;
    they check the global runqueue, poll the network, attempt to run gc tasks,
    and work-steal.
    This burns CPU cycles, but maximally leverages available parallelism.
    Ps and runqueues
    The per-core runqueues are stored in a heap-allocated “p” struct.
    It stores other resources a thread needs to run goroutines too, like a
    memory cache.
    A thread claims a p to run goroutines, and the entire p is handed-off
    when it’s blocked.
    Fun fact: this handoff is taken care of by the sysmon too.


    View Slide

98. assess it.
    the difficult questions.


    View Slide

99. #schedgoals
    for scheduling goroutines onto kernel threads.
    use a small number of kernel threads.
    ideas: reuse threads & limit the number of goroutine-running threads.
    support high concurrency.
    ideas: threads use independent runqueues & keep them balanced.
    leverage parallelism i.e. scale to N cores.
    ideas: use a runqueue per core & employ thread spinning.


    View Slide

100. limitations
     FIFO runqueues → no notion of goroutine priorities.
     Implement runqueues as priority queues, like the Linux scheduler.
     No strong preemption → no strong fairness or latency guarantees.
     recent proposal to fix this: Non-cooperative goroutine preemption.
     Is not aware of the system topology → no real locality.
     dated proposal to fix this: NUMA-aware scheduler
     Use LIFO, rather than FIFO, runqueues; better for cache utilization.


     View Slide

101. CORES
     The Go scheduler motto, in a picture.


     View Slide

102. @kavya719
     speakerdeck.com/kavya719/the-scheduler-saga
     Special thanks to Eben Freeman and Austin Duffield for reading drafts of this,
     & also Chris Frost, Bernardo Farah, Anubhav Jain and Jeffrey Chen.


     References

     Scalable scheduler design doc
     https://github.com/golang/go/blob/master/src/runtime/runtime2.go
     https://github.com/golang/go/blob/master/src/runtime/proc.go
     Go scheduler blog post
     Scheduling Multithreaded Computations by Work Stealing


     View Slide

103. View Slide
