Nutanix Meetup Hybrid 23.03 ① Prism Central pc.2022.9 の機能追加 ②
Prism Operations について ③マイクロサービスインフラストラクチャー(MSP)のデフォルト有効化 Nutanix Meetup Hybrid 23.03 2023.03.08 友松 桂吾 @ TomoMartin
Prism Central pc.2022.9 の機能追加 一部抜粋して紹介
イメージ配置ポリシーのサスペンド イメージ配置ポリシーを新規に適用したり更新したりすると、ポリシーが適用されているクラスター間 でイメージの転送が発生します。イメージ転送によってネットワーク帯域幅の消費が想定されるため、 ネットワークに負荷をかけたくないタイミングや時間帯がある場合は、ポリシーによるデータの転送を 一時停止することができます。 Suspending or Resuming Enforcement of
an Image Placement Policy https://portal.nutanix.com/page/documents/details?targetId=Prism-Central-Guide:mul-image-upload-task-cancel-pc-t.html
セキュリティダッシュボード 全体のサマリ セキュリティ強化の設定状況 脆弱性情報 STIG の準拠状況 Security Dashboard https://portal.nutanix.com/page/documents/details?targetId=Nutanix-Security-Guide:mul-security-dashboard-overview-pc.html
ストレージポリシーの機能強化 レプリケーションファクターの設定 コンプライアンス状態の表示 Storage Policy Details View https://portal.nutanix.com/page/documents/details?targetId=Prism-Central-Guide:mul-cluster-storage-policy-detailed-pc-c.html
Prism Central を使用した AHV ホスト名の変更 ホスト名の変更 Renaming an AHV Host
https://portal.nutanix.com/page/documents/details?targetId=AHV-Admin-Guide:ahv-renaming-ahv-host-t.html
Prism Operations について
◼NCM ソフトウェアエディションでの「Intelligent Operations」に相当する機能を Prism Operationsと呼ぶようになった模様。 ◼Intelligent Operations の機能を使用したい場合は、Prism Operations という項目を
有効化することでクラスターへ適用している NCM ライセンスごとの機能が利用可能となる。 ◼Prism Operations を有効化する際に、4 vCPU 追加が要件として表示されるが 最小構成の Prism Central(6vCPU 26GBメモリ)にプラスで追加する必要があるのかは ドキュメントからは正確に判断が難しい。(おしえて Nutanix さん) ◼Prism Central における機能ごとのリソース要件は KB にて公開されている情報もあるが Prism Operations は複数の機能をまとめたものであるため現状は解釈が難しい部分がある。 https://portal.nutanix.com/kbs/08932 Prism Operations とは Prism Operations https://portal.nutanix.com/page/documents/details?targetId=Prism-Central-Guide-vpc_2022_9:mul-prism-operations-pc-c.html
Prism Operations の適用範囲 カテゴリ NCM ライセンスの機能 Starter Pro Ultimate Intelligent
Operations レポート機能 〇 〇 〇 キャパシティプランニング 〇 〇 〇 リソースの非効率性の検出・適正サイジング 〇 〇 〇 非 NCI 環境における ESXi のサポート 〇 〇 〇 ローコード/ノーコード運用のオートメーション 〇 〇 〇 IT 運用のための SQL Server モニタリング 〇 〇 アプリケーション検出 〇 〇 機械学習による自己調整 〇 〇 Cost Governance プライベートクラウドコストメータリング 〇 〇 マルチクラウド可視化と最適化 〇 〇 予算編成とチャージバック 〇 〇 Self-Service セルフサービス 〇 〇 IaaS VMブループリント 〇 〇 高度なオーケストレーションランブック 〇 〇 アプリのブループリント 〇 ガバナンス(承認とスケジュール) 〇 Security Compliance セキュリティ監視および修復 〇 ネットワークセキュリティプランニング 〇 法令順守 〇 NCM ソフトウェア エディション Prism Operations Prism Central [Cost Management] から Xi Beam に飛ぶ際も有効化が必要であるが Xi Beam はクラウドサービスなのであまり関係なさそう
レポート機能 Prism Operations 無効化のメッセージが上部に表示される 無効化されている
キャパシティプランニング 無効化されている
リソースの非効率性の検出・適正サイジング 無効化されている
・非 NCI 環境における ESXi のサポート ・IT 運用のための SQL Server モニタリング
無効化されている
・ローコード/ノーコード運用のオートメーション ・機械学習による自己調整 無効化されている
アプリケーション検出 無効化されている
Prism Operations の有効化 4vCPU 追加するかの選択肢
Prism Operations 有効化後 レポート機能などがこれまで通り使用可能となる
マイクロサービスインフラストラクチャー(MSP) のデフォルト有効化
◼Flow Virtual Networking や Objects などの Prism Central を必要とする機能に関連付けられた様々 なサービス(Identity
and Access Management: IAM、負荷分散: LB、Virtual Private Networking: VPNなど)がマイクロサービスとしてコンテナにパッケージ化され、Prism Central によって提供 されているもの。 ◼Prism Central バージョン、pc.2022.6 までは使いたい場合に有効化していたが pc.2022.9 以降は標準で有効化一択となる。 ◼クラスターへ新しく Prism Central(pc.2022.9以降)をデプロイする場合は、Prism Centralサービ スドメイン名やMSP 用のネットワークを追加で設定する必要がある。 ◼また、既存の MSP が有効になっていない Prism Central を pc.2022.9以降へアップグレードした場 合は、自動で MSP が有効化され、デフォルトのネットワーク設定が割り振られる。 ◼Prism Central 2022.9 へのアップグレードやインストールをまとめた KB https://portal.nutanix.com/kbs/14004 マイクロサービスインフラストラクチャー(MSP)とは Microservices Infrastructure https://portal.nutanix.com/page/documents/details?targetId=Prism-Central-Guide-vpc_2022_9:mul-cmsp-overview-pc-c.html
Prism Central(pc.2022.9以降)の新規デプロイ 追加で必要な設定
pc.2022.9以降へのアップグレード
有効化されている MSP の確認
Nutanix Meetup Hybrid 23.03 ご清聴ありがとうございました
