AnDevCon: Android Reverse Engineering

Slides of the presentation at the AnDevCon

Transcript

2. Agenda: -Intro -Purpose -Tools -APK Structure -Obtaining APKs -Decompiling -Manipulation -Repackage/signing -Examples -Prevention !
3. Ego slide Mobile Developer @ Sixt M. Sc. UCM/RWTH CS Teacher at Alcalá University ! ! ! +EnriqueLópezMañas @eenriquelopez
4. Reverse Engineering Obtaining source code from a compiled source !
5. Why Java? -Java code is partially compiled and then interpreted -JVM and opcodes are fixed -Few instructions -No real protection
6. Why Android? -APKs are easily downloadable -Obfuscation does not happen by default - APK to JAR translation is easy
7. Legal issues Small set: ! - Don’t decompile, recompile and pass it off as your own - Don’t try to sell it as your own - If License Agreement forbids decompiling, do not decompile -Don’t decompile to remove protection mechanisms
8. Legal issues US ! - Precedents allowing decompilation ! (Sega vs. Acolade, http://digital- law-online.info/cases/ 24PQ2D1561.htm)
9. Legal issues EU (Directive on the Legal Protection of Computer Programs ) - Allows decompilation ! (if you need access to internal calls and authors refuse to divulge API) ! BUT: ! -Only to interface your program -Only if they are not protected
10. Generally YES: ! - Understand interoperatibility - Create a program interface ! NO: ! - Create a copy and sell it.
11. Malware Privacy leaks Cheating Code injection Passwords Score manipulation Download from obscure sources Personal data Asset manipulation Unrequested data collection/steal Ads
12. Educational Interfacing Protection Learning code Creating interfaces Checking our own mistakes! Researching bugs Improving existing resources
13. Dex2Jar
14. JD-GUI
15. JAD
16. apktool
17. Eclipse
18. Java programming (SDK/NDK) Compiling to DEX, running in DVM Package signed as APK Distribution (freely, Google Play or other)
19. Obtaining APK Converting DEX to Jar Decompiling Java
20. How to obtain APKs 1.- Pulling from device 2.- Using GooglePlay Python API 3.- Alternative sources 4.- Sniffer transfer
21. Pulling from device: Connect with USB cable ADB Root
22. Alternative Sources:
23. Sniffer:
24. Google Play Python API:
25. First unzip
26. Using dex2jar to create a Jar
27. Using a Java Decompiler
28. Some tips: •Look for known strings •Not only code: also XML and resources •Be aware of obfuscation
29. •Edit and modify resources •Change essential code •SMALI
30. •Create certificate with JDK Keytool •Sign Jar with JDK jarsigner
31. •HelloWorld •Crackme •Code injection
32. Protecting your source [We want] to protect [the] code by making reverse engineering so technically difficult that it becomes impossible or at the very least economically inviable. ! -Christian Collberg,
33. Idea #1 Writing two versions of the app
34. Idea #2 Obfuscation When obfu scation is outlawed, only outlaw s will sifj difdm wofiefiemf eifm.
35. Idea #3 WebServices
36. Idea #4 FingerPrinting our code
37. Idea #5 Native methods
39. Thank you ! + Enrique López Mañas @eenriquelopez
