The Security of Classic Game Consoles

It's 1986 and you're sitting a few feet away from your 19" CRT television. Blowing the dust out of your Super Mario cartridge you insert it into your Nintendo and push the power button. The familiar music plays and you're sucked into a world of goombas and castles on your quest to save the princess. While engrossed in your game, you probably didn't realize the engineering that went into the security of your game and console.

Join me as we travel back through history and explore the security of classic game consoles. You don't have to be a gamer to appreciate the various security methods that were employed, including hardware, media, and software security measures. Learn how many of these security measures were exploited, either directly or indirectly, as well as the security measures which have yet to be broken.

You'll leave this fun presentation with not only an understanding of the technical details of what went into protecting the security of your favorite classic game consoles and how they were broken, but also how we can apply these historical lessons learned to the modern software and systems we build today.

Transcript

1. PRESS START
2. KEVIN SHEKLETON 15 YEARS @KPSHEK DISTINGUISHED ENGINEER HP 13/ 37
4. Video game crash of 1983
6. 2 years of exclusivity 5 games per year Content review Nintendo controlled all manufacturing, upfront payments, no returns
8. 1988 © CAPCOM CO. LTD TM AND ©1989 CAPCOM USA, INC. NOT LICENSED BY
 NINTENDO OF AMERICA. INC. KEVIN SHEKLETON @KPSHEK
9. 1988 © CAPCOM CO. LTD TM AND ©1989 CAPCOM USA, INC. NOT LICENSED BY
 NINTENDO OF AMERICA. INC. 2017 NEBRASKA.CODE() KEVIN SHEKLETON 1988 © CAPCOM CO. LTD TM AND ©1989 CAPCOM USA, INC. NOT LICENSED BY
 NINTENDO OF AMERICA. INC. KEVIN SHEKLETON @KPSHEK
11. CRASH GENESIS DREAMCAST NES PSX SATURN INTV II TODAY
12. INTELLIVISION II
15. Intellivision II Executive ROM (EXEC) if bit 6 in $500C == 0 halt if copyright_year < 1978 halt if copyright_year > 1982 halt ;load title on copyright screen ;continue loading game code
16. NES
18. NES Checking Integrated Circuit (CIC) / 10NES Nintendo Console Lock
19. Key Nintendo Console Nintendo Cartridge NES Checking Integrated Circuit (CIC) / 10NES Lock
22. Key Nintendo Console Nintendo Cartridge Attack: Convert the CIC from a lock to key ❌ Key
23. Nintendo Console Nintendo Cartridge Attack: Knock the CIC offline -5V Lock
24. Key Nintendo Console Nintendo Cartridge Attack: Clone your own CIC key Lock
25. GENESIS
28. Trademark Security System (TMSS) ; TMSS first checks for SEGA at $100 Main: ; Put the Genesis model version in d0 move.b $A1OOO1, d0 ; Genesis model version is the last four bits andi.b #$0F, d0 ; The 1st Genesis model didn't implement TMSS beq.b Version_0 move.l $'SEGA', $A14000 Version_0:
29. SATURN
32. Static ‘wobble’ signature readable/writeable using a proprietary CD drive
33. For attackers, work < value(asset) The Sega Saturn CD security represents a very high work factor It has yet to be broken!
34. “The trouble with the work factor principle is that many computer protection mechanisms are not susceptible to direct work factor calculation, since defeating them by systematic attack may be logically impossible. Defeat can be accomplished only by indirect strategies, such as waiting for an accidental hardware failure or searching for an error in implementation. Reliable estimates of the length of such a wait or search are very difficult to make.” Saltzer, J & Schroeder M, (1975) The Protection of Information in Computer Systems
35. Successful Saturn Attacks Disc swap Mods
36. PLAYSTATION
38. Playstation Attacks 1. Read CD-ROM wobble region data Inject proper region header into data stream Tell console to change discs 2. Read license title screen text
39. “Every program and every user of the system should operate using the least set of privileges necessary to complete the job. Primarily, this principle limits the damage that can result from an accident or error. It also reduces the number of potential interactions among privileged programs to the minimum for correct operation, so that unintentional, unwanted, or improper uses of privilege are less likely to occur.” Saltzer, J & Schroeder M, (1975) The Protection of Information in Computer Systems
40. Playstation (1994)
41. “Keep the design as simple and small as possible… design and implementation errors that result in unwanted access paths will not be noticed during normal use (since normal use usually does not include attempts to exercise improper access paths).” Saltzer, J & Schroeder M, (1975) The Protection of Information in Computer Systems Playstation (1999)
42. DREAMCAST
44. }executable code
45. Dreamcast Media Attack
46. Attacks follow the path of least resistance
47. TODAY
48. 1UP Work factor of modern console hardware has surpassed effort
49. Connect to a local malicious server via DNS hijacking. OS is rooted through execution of malicious code that masquerades as an update to the game.
50. Malicious save game file results in buffer overflow when reading in the name of Link’s horse. OS is rooted through execution of malicious code.
53. THANK YOU PRESENTATION AT BIT.LY/CONSOLE-SEC
