1. MODELING
   COMPLEXITY
   USING MODULARIZATION AND
   BOUNDED CONTEXTS IN DDD
   LEMİ ORHAN ERGİN
   co-founder, craftgate


   View Slide

2. Reference: https://www.reddit.com/r/notinteresting/comments/8l4pct/man_decides_to_keep_box_of_cables


   View Slide

3. everything starts with keeping one


   unused cable from an unknown gadget
   THE START


   View Slide

4. at the beginning, the order and


   entropy is under control
   THE HONEYMOON


   View Slide

5. then with every new adapter and


   cable, entropy increases and chaos starts
   THE INEVITABLE CLUTTER


   View Slide

6. Might work for a while but lead to frustration later


   Hard to find the right cable you need


   Sometimes we connect wrong cables to wrong adapters


   Requires time and patience to simplify the clutter


   At some point, we pour the box and reorganize all the cables


   Throwing the box away completely would also be a solution


   View Slide

7. THE START
   Java
   Spring Boot
   Hibernate
   Postgres


   View Slide

8. THE HONEYMOON
   Java
   Spring Boot
   Hibernate
   Postgres
   Gradle
   Kafka
   Lombok


   View Slide

9. Java
   Hibernate
   Postgres
   Gradle
   Kafka
   Unit Tests
   Lombok
   Kubernetes Integration Tests
   Feign Client
   Docker
   Jenkins
   Sonar
   MongoDB
   JWT
   React Prometheus
   Grafana
   Elastic Search
   Object Mapper
   Actuator
   Open API
   Swagger
   Config Server
   Euroka
   Kotlin
   Groovy
   Spring Cloud
   JPA
   Go
   Node Kibana
   Mockito
   THE REALITY
   Spring Boot


   View Slide

10. Java
    Hibernate
    Postgres
    Gradle
    Kafka
    Unit Tests
    Lombok
    Kubernetes Integration Tests
    Feign Client
    Docker
    Jenkins
    Sonar
    MongoDB
    JWT
    React Prometheus
    Grafana
    Elastic Search
    Object Mapper
    Actuator
    Open API
    Swagger
    Config Server
    Euroka
    Kotlin
    Groovy
    Spring Cloud
    JPA
    Go
    Node Kibana
    Mockito
    Spring Boot
    the implementation of


    customers’ needs
    THE REALITY
    Where is the
    business logic?


    View Slide

11. Java
    Hibernate
    Postgres
    Gradle
    Kafka
    Unit Tests
    Lombok
    Kubernetes Integration Tests
    Feign Client
    Docker
    Jenkins
    Sonar
    MongoDB
    JWT
    React Prometheus
    Grafana
    Elastic Search
    Object Mapper
    Actuator
    Open API
    Swagger
    Config Server
    Euroka
    Kotlin
    Groovy
    Spring Cloud
    JPA
    Go
    Node Kibana
    Mockito
    Spring Boot
    scattered somewhere in the code
    THE REALITY
    Where is the
    business logic?


    View Slide

12. Where is the
    business logic?
    where are the layers ?


    what are the features ?


    where is the business logic ?


    Where should we test ?
    THE REALITY


    View Slide

13. Might work for a while but lead to frustration later


    Hard to find the right cable you need


    Sometimes we connect wrong cables to wrong adapters


    Requires time and patience to simplify the clutter


    At some point, we pour the box and reorganize all the cables


    Throwing the box away completely would also be a solution
    place to update the code
    grow
    the codebase
    the codebase
    stop adding new features and refactor
    Deleting legacy code and rewriting
    dependencies


    View Slide

14. BLOATED
    SERVICES
    IS LIKE


    OVERLOADED PLUGS
    every new feature


    is added like a patch


    View Slide

15. Repository
    One use case, one feature


    all well defined implementation
    Payment


    Service


    View Slide

16. Repository
    new use cases need new functionality


    added to the same service
    same repository is enlarged to


    fulfill the requirements of all use cases


    and reused the existing ones
    Payment


    Service


    View Slide

17. Payment


    Service
    Repository Repository it’s time to split the functionality
    payment service is growing gradually


    View Slide

18. Repository Repository
    Service
    Repository
    Time to split payment service, but


    still dependent to it
    New use cases are comming
    Payment


    Service


    View Slide

19. Rest Client
    Event
    Publisher
    Soap Client
    Repository Repository
    Manager
    Service
    Service
    Repository
    the dead end


    of complexity
    Payment


    Service
    Service
    Service
    Service
    Service
    Repository
    Repository Repository
    Repository


    View Slide

20. Complexity is the degree
    of difficulty in sustaining
    quality, maintainability,
    speed, cognitive load,


    and development.
    that is what kills the sustainable growth


    View Slide

21. Adding new features becomes
    harder and harder in time


    Complexity rises till the dead end


    You either redesign or rewrite to
    continue adding new features


    Adding new people to the team
    makes the progress slower


    Microservices transformation
    projects usually aim to fix these
    kinds of legacy projects
    THE IMPACT OF


    COMPLEXITY AS USUAL
    Feature


    Count
    Time
    Growth


    Limit
    Growth


    Limit
    let’s split it into


    microservices
    we need to


    rewrite it again
    Difficulty Level


    While Adding


    New Features
    Time
    refactor


    redesign


    zone
    Growth


    Limit
    Growth


    Limit
    the increase in
    endurance level is
    due to the new senior
    endurance level:


    do not touch


    if it works
    transfor-


    mation


    project


    zone
    go-live


    night


    View Slide

22. Feature


    Count
    Time
    Difficulty Level


    While Adding


    New Features
    Time
    THE IMPACT OF


    MANAGABLE


    COMPLEXITY
    aka. SUSTAINABLE GROWTH
    No need for big redesigns or
    rewrites, refactoring is enough


    Refactoring should be continuous


    The system should be open to
    extension and close to modification


    Adding new people to the team has
    a positive impact


    No direct need for microservices


    View Slide

23. Source code is the real software design.
    Designing software is an exercise in


    What is Software Design? The C++ Journal Vol. 2, No. 2. 1992
    http://user.it.uu.se/~carle/softcraft/notes/Reeve_SourceCodeIsTheDesign.pdf
    Reference:
    Jack W. Reeves
    Author of the "(B)leading Edge"
    column for the publication C++ Report
    “
    managing complexity.


    View Slide

24. The critical complexity of most
    software projects is in understanding
    the business domain itself.
    “Interview With Eric Evans; Why DDD Matters Today” Dec 20, 2006
    http://www.infoq.com/articles/eric-evans-ddd-matters-today
    Reference:
    Eric Evans
    Author of the "Domain-Driven Design:
    Tackling Complexity in Software" “


    View Slide

25. Managing complexity for sustainable growth
    Otel-imiz-in karşı-sın-da-ki dükkan-da gör-dü-ğüm bir elbise-yi dene-mek iste-r-im
    needs a paradigm shift
    like the difference between


    structure in English and Turkish
    Unlearn what you’ve known so far and Relearn with no biases and limits


    View Slide

26. Microservices


    Programming in Go, Rust


    Using Kafka or MongoDB


    Spring Boot, Frameworks


    Cloud Engineering


    Event-based architecture


    Distributed systems


    Scrum, Kanban, etc.


    Story point estimations


    Packaging by infrastructure


    Dependency Injection


    Having modules anywhere
    These may decrease
    complexity but not enough
    for sustainable growth


    View Slide

27. Having modules everywhere makes your
    software modular but it may not achieve


    sustainable growth


    View Slide

28. SEPARATION


    OF CONCERNS
    INFORMATION HIDING
    PRINCIPLE
    INVERSION OF CONTROL
    PRINCIPLE
    DEPENDENCY INVERSION
    PRINCIPLE
    COUPLING
    COHESION
    sustainable growth
    The mentality behind modularization, i.e. the principle of
    “Separation of Concerns” - Edsget W. Dijkstra
    1 Know The Fundamentals
    Details can be found in my talk: Modular Architecture For Pragmatic Developer


    https://speakerdeck.com/lemiorhan/modular-architecture-for-pragmatic-developers
    PRINCIPLES


    View Slide

29. sustainable growth
    Focus on how modules communicate rather
    than what internal properties and behaviors
    should be. - Alan Kay
    2 Focus on Modules & Communication
    Details can be found in my talk: Unlearn OOP


    https://speakerdeck.com/lemiorhan/unlearn-oop-deleted-scenes-misconceptions-unspoken-truths
    OBJECT


    ORIENTED


    PROGRAMMING
    PRINCIPLES


    View Slide

30. sustainable growth
    SOLID principles are about managing
    dependencies and limiting the impact
    of change. - Robert C. Martin
    3 Learn How to Manage Dependencies
    Details can be found in my talk: It’s Not SOLID Anymore


    https://speakerdeck.com/lemiorhan/it-is-not-solid-anymore
    DESIGN


    PRINCIPLES
    PRINCIPLES


    View Slide

31. sustainable growth
    The timeless goal of software engineering has been to
    separate code rather than change frequently from stable
    code. - James Coplien
    4 Protect Business Logic from Poisoning
    Details can be found in my talk: Growing Hexagonal Microservices with TDD


    https://speakerdeck.com/lemiorhan/growing-hexagonal-microservices-by-tdd
    HEXAGONAL


    ARCHITECTURE
    APPROACH


    View Slide

32. sustainable growth
    Adding a new test to the system should
    be adding a new behavior rather than
    adding a method or class. - Ian Cooper
    5 Test Really What Matters: Behaviors
    Details can be found in my talk: Unlearn Unit Testing


    https://speakerdeck.com/lemiorhan/unlearn-unit-testing
    UNIT TESTING
    APPROACH


    View Slide

33. sustainable growth
    No rules are universal, rules
    need context - Dave Thomas
    6 Focus on Contexts, Build Rules Around
    Details can be found in my talk: Pure Agile


    https://speakerdeck.com/lemiorhan/pure-agile-building-a-culture-without-scrum-kanban-and-xp-extended-version-v22-dot-11
    AGILE IS DEAD


    LONG LIVE AGILITY
    APPROACH
    there are no rules in software,


    there are patterns. The critical part


    is deciding which patterns to use


    View Slide

34. sustainable growth
    Use cases are sequences of tasks toward
    a goal, context represents use cases, one
    per use case - James Coplien
    7 Put Bricks on the Wall One-by-One
    Details can be found in my talk: Domain Driven Modular Architecture


    https://speakerdeck.com/lemiorhan/domain-driven-modular-architecture
    USE CASE
    DRIVEN
    APPROACH
    DESIGN


    View Slide

35. sustainable growth
    If your model is telling a story, the modules are chapters. It
    isn’t just code being divided into modules, but concepts.


    - Eric Evans
    8 Shape Software based on Contexts
    BOUNDED CONTEXT
    DOMAIN DRIVEN DESIGN
    Details can be found in my talk: Domain Driven Modular Architecture


    https://speakerdeck.com/lemiorhan/domain-driven-modular-architecture
    DESIGN


    View Slide

36. 8 Shape Software based on Contexts
    DESIGN
    7 Put Bricks on the Wall One-by-One
    6 Focus on Contexts, Build Rules Around
    5 Test Really What Matters: Behaviors
    4 Protect Business Logic from Poisoning
    APPROACH
    Modularity & Sustainable Growth
    3 Learn How to Manage Dependencies
    2 Focus on Modules & Communication
    1 Know The Fundamentals
    PRINCIPLES


    View Slide

37. DESIGN
    BOUNDED CONTEXT
    DOMAIN DRIVEN DESIGN
    USE CASE
    DRIVEN
    APPROACH
    UNIT TESTING
    HEXAGONAL


    ARCHITECTURE AGILE IS DEAD


    LONG LIVE AGILITY
    APPROACH
    SEPARATION


    OF CONCERNS
    INFORMATION HIDING
    PRINCIPLE
    INVERSION OF CONTROL
    PRINCIPLE
    DEPENDENCY INVERSION
    PRINCIPLE
    COUPLING
    COHESION
    OBJECT


    ORIENTED


    PROGRAMMING
    DESIGN


    PRINCIPLES
    PRINCIPLES


    View Slide

38. Let’s build a payment API


    start from the beginning…


    View Slide

39. Represent the model as how the business sees them
    that is where concepts


    find their meanings, people


    speak the same language and


    share the same concerns
    CARD PAYMENT CONTEXT


    View Slide

40. Any info in the model can change at any time, that’s chaos.


    We need to control the change!
    CARD PAYMENT CONTEXT


    View Slide

41. An aggregate defines
    consistency boundaries,
    everything inside (i.e. the
    data) needs to be always
    consistent
    An aggregate is just a
    construct to organize
    business rules
    Aggregate is a unit for the purpose of data changes
    CARD PAYMENT CONTEXT


    View Slide

42. Each aggregate has a root and a boundary
    Aggregate Root is the
    facade representing the
    whole structure, and it is
    the gateway.


    It enforces the aggregate's
    business/consistency rules
    References to aggregate
    internals from the outer
    world are strictly forbidden
    CARD PAYMENT CONTEXT


    View Slide

43. AGGREGATE
    BUSINESS
    RULES
    DOMAIN MODEL
    CONTEXT
    TRANSACTIONAL AND
    LINGUISTIC BOUNDARY
    INPUT OUTPUT
    Each BC is loosely coupled &
    independent and has its own
    ubiquitous language, own data, and
    an explicit owner.


    We split software into BCs, like
    microservices.


    Unlike modules, which are organized
    primarily around technical concerns,
    BCs are organized around business
    concerns.
    is it a realization of Moduliths ?


    View Slide

44. CONTEXT A CONTEXT B
    CONTEXT C
    CONTEXT D
    Context Map includes a high-level
    view of the domains involved, along
    with the relationships and interactions
    between them
    communication patters used in


    microservices are applicable here
    Relationship Models
    Customer-Supplier


    Conformist


    Partneship


    Anti-Corruption Layer


    Separate Ways


    Open-Host Service


    Shared Kernel


    View Slide

45. The communication strategy between
    bounded contexts defines how extensible
    your software is
    Different than relationship models
    Strategies
    Chained - Unchained


    Transactional - Non-Transactional
    CONTEXT A CONTEXT B
    CONTEXT C
    CONTEXT D


    View Slide

46. CREATE USER
    NOTIFY CUSTOMER
    SAVE OUTBOX
    CREATE USER


    USE CASE
    USER CREATED


    MESSAGE
    USER CREATED


    MESSAGE
    OUTBOX SAVED


    MESSAGE
    CUSTOMER NOTIFIED


    MESSAGE
    CHAINED
    SYNC
    SYNC


    View Slide

47. CREATE USER
    NOTIFY CUSTOMER
    SAVE OUTBOX
    CREATE USER


    USE CASE
    USER CREATED


    MESSAGE
    USER CREATED


    MESSAGE
    OUTBOX SAVED


    MESSAGE
    CUSTOMER NOTIFIED


    MESSAGE
    UN-CHAINED
    ASYNC
    ASYNC


    View Slide

48. CREATE USER NOTIFY CUSTOMER SAVE OUTBOX
    CREATE USER


    USE CASE
    USER CREATED


    MESSAGE
    OUTBOX SAVED


    MESSAGE
    CUSTOMER


    NOTIFIED


    MESSAGE
    TRANSACTIONAL
    SINGLE TRANSACTION
    One exception triggers rollbacking of all previous operations in multiple contexts


    View Slide

49. CREATE USER NOTIFY CUSTOMER SAVE OUTBOX
    CREATE USER


    USE CASE
    USER CREATED


    MESSAGE
    OUTBOX SAVED


    MESSAGE
    CUSTOMER


    NOTIFIED


    MESSAGE
    NON-TRANSACTIONAL
    TRANSACTIONAL TRANSACTIONAL TRANSACTIONAL


    View Slide

50. MANAGING THE LEVEL OF


    HOW DEPENDENT BOUNDED
    CONTEXTS TO EACH OTHER
    thinking in communicating objects?


    View Slide

51. We want to avoid having to
    change the source code and
    then rebuild the system every
    time you make these shifts
    Two patterns closely related with each
    other to achieve this
    A. Configurable Connection Pattern


    B. Configurable Dependency Pattern
    https://alistaircockburn.com/Configurable%20Connection%20Configurable%20Dependency.pdf


    View Slide

52. Configurable Connection Pattern
    Configurable Dependency Pattern
    Sender does not depend on any receiver.


    It’s like polymorphism from OOP.


    Sender has a source-code dependency


    on the receiver.
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    sender’s provided
    interface
    sender’s required
    interface
    RECEIVER


    CONTRACT
    Sender asks the configurator which receiver


    to use, like in dependency lookup.


    Sender contains a hard-coded reference to


    the configurator.


    We avoid hard-coding the names of classes


    on which we depend in our code.


    Sender has a source-code dependency on


    the configurator.
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    RECEIVER


    CONTRACT
    CONFIGURATOR
    CONFIGURATOR CONFIGURATOR
    B
    application


    context
    spring
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    sender’s provided
    interface
    sender’s required
    interface
    RECEIVER


    CONTRACT
    CONFIGURATOR
    Configurator tells the sender what receiver


    to use, like in dependency injection.


    Receiver is held in sender in a local variable.


    It is set the receiver during execution, or


    at initialization.


    Sender still has a source-code dependency


    on the receiver.
    A
    spring


    View Slide

53. Configurable Connection Pattern
    C
    spring
    Only one configurator exists & sender calls


    it via static methods.


    Receivers register themselves at initialization


    to the configurator.


    Configurator knows which receiver to select.


    Sender has no source-code dependency.
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    RECEIVER


    CONTRACT
    CONFIGURATOR
    CONFIGURATOR CONFIGURATOR
    the new approach
    publisher
    Sender asks the configurator which receiver


    to use, like in dependency lookup.


    Sender contains a hard-coded reference to


    the configurator.


    We avoid hard-coding the names of classes


    on which we depend in our code.


    Sender has a source-code dependency on


    the configurator.
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    RECEIVER


    CONTRACT
    CONFIGURATOR
    CONFIGURATOR CONFIGURATOR
    B
    application


    context
    spring
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    sender’s provided
    interface
    sender’s required
    interface
    RECEIVER


    CONTRACT
    CONFIGURATOR
    Configurator tells the sender what receiver


    to use, like in dependency injection.


    Receiver is held in sender in a local variable.


    It is set the receiver during execution, or


    at initialization.


    Sender still has a source-code dependency


    on the receiver.
    A
    spring


    View Slide

54. C
    spring
    Only one configurator exists & sender calls


    it via static methods.


    Receivers register themselves at initialization


    to the configurator.


    Configurator knows which receiver to select.


    Sender has no source-code dependency.
    SENDER
    RECEIVER 1 RECEIVER 2 RECEIVER3
    RECEIVER


    CONTRACT
    CONFIGURATOR
    CONFIGURATOR CONFIGURATOR
    the new approach
    publisher
    CONFIGURATOR: MESSAGE PUBLISHER
    SENDER
    RECEIVER: USE CASE HANDLER


    View Slide

55. RECEIVER: USE CASE HANDLER
    Use case handlers are injected by Spring
    into the registry, which is accessed by
    Message Publisher to submit messages
    HANDLER REGISTRATION
    Receivers are extended by MessageHandlers
    not only for being detected by Spring, and
    also for providing base “handle method”
    infrastructure
    STEP 1


    View Slide

56. RECEIVER: USE CASE HANDLER
    Use case handlers return Aggregate Roots
    (if required) since it is the gateway for data
    change
    USE CASE HANDLING
    Use case handlers trigger “publishMessages”
    after handling is completed
    STEP 2


    View Slide

57. Bounded contexts do not know which
    bounded contexts are connected with
    which strategy. That makes every
    bounded context independent.
    DEFINING COMMUNICATION STRATEGIES
    STEP 3
    SYNC
    SINGLE


    TRANSACTION


    View Slide

58. Java library for building loosely-coupled bounded contexts
    https://github.com/craftgate/craftgate-modulith-messaging
    Supports loosely coupled, real-time
    dependency strategy to bounded
    contexts


    Supports aggregate roots and
    domain events


    Supports use-case driven approach
    and hexagonal architecture


    Supports transactional flows among
    aggregates


    Supports sync and async call chains
    between bounded contexts


    Contains unit tests for the API and
    acceptance tests for checking
    possible flows


    Detailed documentation describing
    why we need that & how it works


    Actively being used in production
    craftgate-modulith-messaging


    View Slide

59. HOW
    MODULARITY
    LOOKS LIKE?


    View Slide

60. THE SHAPE OF MODULARITY
    Each module is self-contained, with well-
    defined input/output interfaces


    Each module hides implementation details and
    exposes a high-level contract


    Each module handles multiple use cases directly
    related to user needs


    Each module extends by one use case at a time,
    no bloating experienced


    Each module is loosely coupled and highly
    coherent


    View Slide

61. WE ARE


    HIRING
    speakerdeck.com/lemiorhan


    twitter.com/lemiorhan
    lemi orhan ergin co-founder
    mail: talent@craftgate.io
    CRAFTGATE
    one-stop shop payment gateway


    payment hub for your virtual poses


    with dynamic pos routing, you always
    pay the lowest commission to banks
    craftgate.io @craftgateio


    View Slide
