talk:title="@{dataBinding}

A tour through the data binding framework's obvious and not-so-obvious perks. Reduce boilerplate, avoid NullPointerExceptions, decrease code complexity, and maybe even fix some Android pet peeves.

Transcript

1. “@{dataBinding}”
   talk:title=
   @{dataBinding}
   @lisawrayz


   View Slide

2. textView.setCompoundDrawablesWithIntrinsicBounds(
   ContextCompat.getDrawable(this, R.drawable.cat), null, null, null);
   Problem:
   Repetitive Java boilerplate
   @{dataBinding}
   findViewById, casts
   setters are verbose/confusing
   toolbar = (Toolbar) findViewById(R.id.toolbar);


   View Slide

3. Problem:
   Repetitive Java boilerplate
   @{dataBinding}
   findViewById, casts
   setters are verbose/confusing
   XML layout is limited
   Manually keep track of UI updates


   View Slide

4. What is it?
   @{dataBinding}
   A framework to connect your
   model and your UI
   Once or persistently


   View Slide

5. An XML attribute for every Java setter
   @{dataBinding}
   What else is it?


   View Slide

6. Custom XML attributes
   @{dataBinding}
   What else is it?


   View Slide

7. Overwrite Android XML attributes
   @{dataBinding}
   What else is it?


   View Slide

8. An alternative to custom views
   @{dataBinding}
   What else is it?


   View Slide

9. O.K., show me!


   View Slide

10. Find the views
    Set custom
    font
    Set button
    colors
    Load and set
    the image
    Set title


    View Slide

11. Before: inflate and find views
    CollapsingToolbarLayout appBarLayout = (CollapsingToolbarLayout)
    findViewById(R.id.toolbar_layout);
    ImageView backdropImageView = (ImageView)
    findViewById(R.id.backdrop);
    Button upvoteButton = (Button) findViewById(R.id.upvote);
    Button downvoteButton = (Button) findViewById(R.id.downvote);
    setContentView(R.layout.activity_pet_detail);
    After
    PetDetailBinding binding = DataBindingUtil.setContentView
    (this, R.layout.pet_detail);


    View Slide

12. Before:Java
    if (pet != null) {
    appBarLayout.setTitle(pet.getName());
    }
    After:XML
    app:title="@{pet.name}"
    >


    View Slide

13. Before: Java
    Typeface lobster = FontCache.getInstance().get("LobsterTwo-Bold");
    appBarLayout.setCollapsedTitleTypeface(lobster);
    appBarLayout.setExpandedTitleTypeface(lobster);
    After:XML
    app:collapsedTitleTypeface="@{`LobsterTwo-Bold`}"
    app:expandedTitleTypeface=“@{`LobsterTwo-Bold`}"
    >


    View Slide

14. app:selected=“@{vote == VOTE.UPVOTE}"
    android:tint=“@drawable/upvote_selector”
    />
    Before:Java
    After:XML
    switch(pet.vote) {
    case UPVOTE:
    upvoteButton.setSelected(true);
    downvoteButton.setSelected(false);
    break;
    case DOWNVOTE:
    …


    View Slide

15. Before: Java
    Glide.with(this).load(pet.getImageUrl()).into(backdropImageView);
    After:XML



    View Slide

16. Making the connection


    View Slide

17. PetDetailBinding binding = DataBindingUtil.setContentView
    (this, R.layout.pet_detail);
    Before: Java
    …


    name="pet" type="com.xwray.dogmeetscat.Pet"/>

    After:XML

    binding.setPet(pet);
    PetDetailBinding binding = DataBindingUtil.setContentView
    (this, R.layout.pet_detail);
    Your old layout
    goes here
    Your model
    object


    View Slide

18. 100% generated Java code
    Uses bitwise flags to mark ‘dirty’
    One traversal to find all views
    How does it work?
    @{dataBinding}


    View Slide

19. layout/pet.xml
    generated: PetBinding.java
    PetBinding.image
    .title
    .upvote
    @{dataBinding}


    View Slide

20. @{ }


    View Slide

21. Existing attributes
    Pet.getName()
    app:title="@{pet.name}"


    View Slide

22. android:text android:textColor
    Existing attributes
    android:drawableLeft
    android:src
    … and many, many more


    View Slide

23. app:selected=“@{vote == VOTE.UPVOTE}"
    android:tint=“@drawable/upvote_selector”
    />
    Attributes for every Java setter
    View.setSelected()


    View Slide

24. app:imageUrl="@{pet.imageUrl}"
    Custom attributes


    View Slide

25. @BindingAdapter({"bind:imageUrl"})
    public static void loadImage(ImageView view, String url) {
    Glide.with(view.getContext())
    .load(url)
    .into(view);
    }
    Bindings You pick
    The view
    you’re binding
    Attribute


    View Slide

26. app:font
    Custom attributes
    @BindingAdapter({"bind:font"})
    public static void setFont(TextView textView, String fontName) {
    Typeface type = FontCache.getInstance().get(fontName);
    textView.setTypeface(type);
    }
    Bindings
    Tinkerbell


    View Slide

27. app:collapsedTitleTypeface="@{`LobsterTwo-Bold`}"
    app:expandedTitleTypeface="@{`LobsterTwo-Bold`}"
    Custom attributes
    @BindingAdapter("bind:expandedTitleTypeface")
    public static void setExpandedTitleTypeface(
    CollapsingToolbarLayout layout, String fontName) {
    Typeface type = FontCache.getInstance().get(fontName);
    layout.setExpandedTitleTypeface(type);
    }
    @BindingAdapter("bind:collapsedTitleTypeface")
    public static void setCollapsedTitleTypeface …


    View Slide

28. android:drawableRight=“@{isCat ? @drawable/cat : @drawable/dog}”
    />
    android:paddingRight=“@{2 * @dimen/margin}”
    />
    android:paddingRight=“@{@dimen/margin + @dimen/image_width}”
    />
    Evaluate simple expressions
    app:selected=“@{vote == VOTE.UPVOTE}"


    View Slide

29. before:
    if (pet != null) {
    appBarLayout.setTitle(pet.getName());
    }
    after:
    android:text=“@{pet.name}”
    Avoid NPEs
    android:text=“@{pet.name.last}”


    View Slide

30. @BindingAdapter("android:indeterminateTint")
    public static void setIndeterminateTint(
    ProgressBar progressBar, int color) {
    Drawable toTint = progressBar.getIndeterminateDrawable().mutate();
    toTint.setColorFilter(color, PorterDuff.Mode.SRC_IN);
    }
    Overwrite Android attributes
    style="?android:attr/progressBarStyle"
    android:indeterminateTint="@{@color/pink}"
    />


    View Slide

31. layout/family.xml

    …
    layout="@layout/pet"
    app:pet=“@{family.pet}" />


    layout/pet.xml




    …



    View Slide

32. One way binding
    Model changes, view is updated
    Persistent binding


    View Slide

33. enum VOTE {
    UPVOTE, DOWNVOTE, NONE
    }
    public class VoteState {
    public final ObservableField vote =
    new ObservableField();
    }
    voteState.vote.set(VOTE.DOWNVOTE)
    Persistent binding


    View Slide

34. enum VOTE {
    UPVOTE, DOWNVOTE, NONE
    }
    public class VoteState extends BaseObservable {
    private VOTE vote;
    @Bindable getVote();
    setVote(VOTE vote) {
    this.vote = vote;
    notifyChanged(BR.vote)
    }
    }
    Persistent binding


    View Slide

35. “In beta”, you said
    “It’ll be fun”, you said


    View Slide

36. Gradle integration
    Syntax highlighting
    Code completion (2.0.0-alpha5)
    View and debug generated code
    Android Studio and You


    View Slide

37. Refactoring
    “Convert to data binding” shortcut
    “Clean project” required sometimes
    Still to come …


    View Slide

38. Android Studio tips
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools">
    tools:text=“Jane Doe”
    tools:ignore="UnusedAttribute"
    Declare namespaces in layout tag
    Use tools: prefix for layout preview
    Ignore lint warnings


    View Slide

39. app/build.gradle
    android {
    dataBinding {
    enabled = true
    }
    }
    How do I get started?


    View Slide

40. fonts: goo.gl/n6lQY7
    docs: goo.gl/47cVzB
    @lisawrayz
