Working with Webhooks

Working with Webhooks

Lorna Mitchell

May 25, 2017
Tweet

More Decks by Lorna Mitchell

Other Decks in Technology

Transcript

  1. Working with
    Webhooks
    Lorna Mitchell, IBM
    May 2017

    View Slide

  2. Webhooks in the Wild
    Webhooks power:
    • slack notifications
    • continuous integration services
    • other integrations
    @lornajane

    View Slide

  3. How APIs Work
    @lornajane

    View Slide

  4. How APIs Work
    @lornajane

    View Slide

  5. How APIs Work
    @lornajane

    View Slide

  6. How Webhooks Work
    @lornajane

    View Slide

  7. How Webhooks Work
    @lornajane

    View Slide

  8. How Webhooks Work
    @lornajane

    View Slide

  9. What About Time?
    @lornajane

    View Slide

  10. APIs Over Time
    @lornajane

    View Slide

  11. Webhooks Over Time
    @lornajane

    View Slide

  12. Webhooks Require PreArrangement
    @lornajane

    View Slide

  13. Designing Webhooks
    @lornajane

    View Slide

  14. Webhooks in the Wild: GitHub
    "ref": "refs/heads/master",
    "before": "1ae6a404351cead52df24893621d82ba6ec84a1c",
    "after": "e8474d83985330fa36f8862b37ca84ada4313392",
    "created": false,
    "deleted": false,
    "forced": false,
    "compare": "https://github.com/lornajane/demo/compare/1ae6a404351c...e847
    "commits": [ ... ],
    "repository": { ... },
    "pusher": { ... },
    "sender": { ... }
    @lornajane

    View Slide

  15. Designing Webhooks
    Consider the use cases:
    • try to include all information for common outcomes
    • consider impact of payload size vs potentially many followup API calls
    @lornajane

    View Slide

  16. Receiving Webhooks
    @lornajane

    View Slide

  17. Receiving Webhooks
    It's just a POST request! Advice:
    • DO: accept, store and acknowledge quickly
    • DON'T: validate or process before acknowledging
    @lornajane

    View Slide

  18. Ngrok for Testing Webhooks
    https://ngrok.com/ - secure tunnel to your dev platform
    Use this tool to:
    • webhook into code running locally
    • inspect the request and response of the webhook
    • replay requests and see the responses
    @lornajane

    View Slide

  19. Storing Data
    Simplest queue can go in your database!
    • an ID
    • the payload that came in (extract fields to search on)
    • a status field (new/processed/failed)
    A cron job to work through what needs doing and update the status field.
    @lornajane

    View Slide

  20. Storing Data
    @lornajane

    View Slide

  21. Storing Data
    @lornajane

    View Slide

  22. Storing Data
    If you outgrow the database method, use a queue.
    • e.g. RabbitMQ, Beanstalkd, Gearman
    • easy way to link many workers with work to do
    @lornajane

    View Slide

  23. Publishing Webhooks
    @lornajane

    View Slide

  24. Publishing Webhooks
    Offering webhook integrations is ideal if:
    • you have clients polling your API a lot
    • it's common for another system to react to changes in your system
    • you want to offer notifications for specific events
    • any of the above apply either internally or externally
    @lornajane

    View Slide

  25. Example App: Retro Guestbook
    In the olden days, we had guestbooks on our websites.
    • Allow user to leave their name and a comment
    • Show the comments left so far
    • Include webhook management for notifications of new comments
    @lornajane

    View Slide

  26. Example App: Retro Guestbook
    @lornajane

    View Slide

  27. Saving Data: Basic Process
    @lornajane

    View Slide

  28. Saving Data: Handling Webhooks
    @lornajane

    View Slide

  29. Saving Data: Handling Webhooks
    @lornajane

    View Slide

  30. Data Hygiene
    Workers should be independent
    • pass in data up front if you can
    • ideally one component talks to each data store
    • keep metadata and data separate
    @lornajane

    View Slide

  31. Saving Data: Handling Webhooks
    @lornajane

    View Slide

  32. Saving Data: Handling Webhooks
    @lornajane

    View Slide

  33. Saving Data: Handling Webhooks
    @lornajane

    View Slide

  34. About Workers
    Workers are:
    • long running processes
    • may be able to process multiple message types
    • may have many of the same worker (horizontal scaling)
    • can be any tech (for bursty workloads, try serverless workers)
    Many microservices patterns also work well here
    @lornajane

    View Slide

  35. Webhooks in Your Applications
    • Use them WHEN you want to notify other systems
    • Examples of HOW to use webhooks hopefully gave you some ideas
    • Webhooks are HTTP: we already understand this
    @lornajane

    View Slide

  36. Webhooks
    ... are awesome :)
    @lornajane

    View Slide

  37. Thanks!
    • Slides: http://lornajane.net/resources
    • Example app: https://github.com/ibm-cds-labs/guestbook
    • RabbitMQ: https://www.rabbitmq.com/
    • Bluemix: http://www.ibm.com/bluemix
    • Requestbin: http://requestb.in
    • Ngrok: https://ngrok.com/
    • Website: http://lornajane.net
    @lornajane

    View Slide
