Lightweight Architectures: With Angular's Signals and Standalone
Manfred Steyer
PRO
September 19, 2023
Transcript
52 slides
@ManfredSteyer Lightweight Architectures With Angular's Signals and Standalone ManfredSteyer
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer Manfred Steyer
@ManfredSteyer
@ManfredSteyer NgModules + EcmaScript Modules import { NgModule } from
'@angular/core'; import { BrowserModule } from '@angular/platform-browser'; import { AppComponent } from './app.component'; […] @NgModule({ imports: [BrowserModule, OtherModule], declarations: [AppComponent, OtherComponent, OtherDirective], providers: [], bootstrap: [AppComponent], }) export class AppModule {} TypeScript Modules Angular Modules
@ManfredSteyer @Component({ standalone: true, imports: [ […], FlightCardComponent, CityPipe, CityValidator,
], selector: 'flight-search', templateUrl: '…' }) export class FlightSearchComponent { […] }
@ManfredSteyer
@ManfredSteyer Small and Medium Apps: Folder per Feature
@ManfredSteyer Your Public APIs: Barrels // index.ts == Public API
export * from './flight-booking.routes';
@ManfredSteyer Medium and Large Apps: Folder per Domain
@ManfredSteyer Restricting Access b/w Domains, etc. on a library basis
@ManfredSteyer Restricting Access on a folder basis Tech Lead Rainer
Hahnekamp, AngularArchitects @softarc/eslint-plugin-sheriff
@ManfredSteyer
@ManfredSteyer Free eBook ANGULARarchitects.io/standalone Standalone Components Download here:
@ManfredSteyer
@ManfredSteyer Zone.js: Monkey Patching After Event Handler: Inform Angular CD
Checks Components all components (default) or selected ones (OnPush)
@ManfredSteyer Zone.js: Magic Zone.js: ~100K Cannot patch async/await coarse grained
CD e.g. Components are always checked as a whole, even if only a tiny fraction changed
@ManfredSteyer Signals!
@ManfredSteyer Signals!
@ManfredSteyer Signal as Producer 4711 Consumer read set notify 4712
@ManfredSteyer flights: Flight[] = []; const flights = await this.flightService.findAsPromise(from,
to); this.flights = flights; <div *ngFor="let f of flights"> <flight-card [item]="f" /> </div>
@ManfredSteyer flights = signal<Flight[]>([]); const flights = await this.flightService.findAsPromise(from, to);
this.flights.set(flights); <div *ngFor="let f of flights()"> <flight-card [item]="f" /> </div>
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private _flights = signal<Flight[]>([]); readonly flights = this._flights.asReadonly(); async load(from: string, to: string) { const flights = await […]; this._flights.set(flights); } }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private _flights = signal<Flight[]>([]); readonly flights = this._flights.asReadonly(); async load(from: string, to: string) { const flights = await […]; this._flights.set(flights); } }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private _flights = signal<Flight[]>([]); readonly flights = this._flights.asReadonly(); private _from = signal('Hamburg'); readonly from = this._from.asReadonly(); private _to = signal('Graz'); readonly to = this._to.asReadonly(); […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private state = signal({ from: 'Hamburg', to: 'Graz', flights: [] as Flight[], […] }, { equal }); […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private state = signal({ from: 'Hamburg', to: 'Graz', flights: [] as Flight[], […] }, { equal }); flights = computed(() => this.state().flights, { equal }); from = computed(() => this.state().from, { equal }); […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
private state = signal({ from: 'Hamburg', to: 'Graz', flights: [] as Flight[], […] }, { equal }); flights = computed(() => this.state().flights, { equal }); from = computed(() => this.state().from, { equal }); […] } const equal = (a,b) => a === b
@ManfredSteyer
@ManfredSteyer select(selector) selectSignal(selector)
@ManfredSteyer
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { private
state = signalState({ from: 'Paris', to: 'London', flights: [] as Flight[], basket: {} as Record<number, boolean>, }); flights = this.state.flights; from = this.state.from; […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
selected = selectSignal( () => this.flights().filter((f) => this.basket()[f.id]); […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
selected2 = selectSignal( this.flights, this.basket, (flights, basket) => flights.filter((f) => basket[f.id]) ); […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
updateCriteria(from: string, to: string): void { this.state.$update({ from, to }); } […] }
@ManfredSteyer @Injectable({ providedIn: 'root' }) export class FlightBookingFacade { […]
updateCriteria(from: string, to: string): void { this.state.$update(state => ({ ...state, from, to })); } […] }
@ManfredSteyer
@ManfredSteyer export const FlightBookingStore = signalStore( { providedIn: 'root' },
[…] );
@ManfredSteyer export const FlightBookingStore = signalStore( { providedIn: 'root' },
withState({ from: 'Paris', to: 'London', […] }), […] );
@ManfredSteyer export const FlightBookingStore = signalStore( { providedIn: 'root' },
withState({ from: 'Paris', to: 'London', […] }), withSignals(([…]) => ({ […] })), withMethods(([…]) => ({ })), withHooks({ […] }), withCallState() );
@ManfredSteyer
@ManfredSteyer const BooksStore = signalStore( withEntities<Book>({ collection: 'book' }), withEntities<Author>({
collection: 'author' }) );
@ManfredSteyer const BooksStore = signalStore( withLoadEntities<Book>(BookService), withLoadEntities<Author>(AuthorService), );
@ManfredSteyer
@ManfredSteyer
@ManfredSteyer d Slides & Examples Remote Company Workshops and Consulting
http://angulararchitects.io
