Camunda Meetup Vienna 2017: Microservices & Workflow

Camunda Meetup Vienna 2017: Microservices & Workflow

Microservices and Workflow? They can become a power couple. But don't force them together. And know their culture!-)

2999fab21d182294fad0b2cc590fd54d?s=128

Martin Schimak

April 04, 2017
Tweet

Transcript

  1. Microservices and Workflow Martin Schimak • • Camunda Vienna Meetup

    • April 4th, 2017 With thoughts from http://flowing.io @berndruecker | @martinschimak
  2. Microservices and Workflow? Well, first at all: do not force

    them... ! But then: expect surprises if you treat both of them well!
  3. Microservices

  4. Monolithic vs. Microservices Architecture https://martinfowler.com/articles/microservices.html

  5. Characteristics of Microservices • Application as a Suite of Small

    Services • Each Service in its own Application Process • Communicating via e.g. HTTP/REST or Messaging • Independently Deployable and Scalable • Built around a specific Business Capability • Owned by a Cross-Functional Team • Aiming at a Maximum of Autonomy
  6. Cross-functional teams around capabilities https://martinfowler.com/articles/microservices.html

  7. Conway‘s Law & Team Autonomy • “Organizations which design systems

    […] are constrained to produce designs which are copies of the communication structures of these organizations.“ • Agile organisations with highly autonomous teams … do the same!
  8. Microservices & Decentral Governance • No standardisation on single technology

    platforms • Instead „using the right tool for the job“ • In particular: decentral Data Management
  9. Microservices & Decentral Data Management https://martinfowler.com/articles/microservices.html

  10. Decentral Data Management via Events Inventory Service Shipment Service Customer1

    Account Service Payment Service Microservices Events Address changed µS µS µS µS
  11. Microservices are actually not SOA • SOA aimed for reusability

    - on the level of services • Microservices instead aim for replaceability and autonomy • Microservices store “duplicated“ data locally - in a controlled manner • Microservices may store data in the form needed for their service • Event collaboration enables nicely decoupled Microservices
  12. Everybody Microservices? Buyer‘s beware. • Microservices fit to organisations with

    highly autonomous teams and high levels of dev/ops automation. • As desirable as this seems, organisational „success“ may depend on industry and still come in different shapes
  13. Microservices and Workflow

  14. Workflow ... a simple example. Fetch items Ship parcel Collect

    money Order:placed Order:delivered • Simple order in the happy scenario ! • Money is collected, e.g. via Credit Card • Items are fetched from inventory • Parcel is shipped
  15. Business Capabilities? Inventory Shipment Shop Payment Business1 Capabilities Order:placed Money:collected

    Item(s):fetched Parcel shipped Business Outputs
  16. Microservices! Inventory Service Shipment Service Checkout Service Payment Service Order:placed

    Money:collected Item(s):fetched Parcel shipped Microservices „Events“ µS µS µS µS
  17. Good Practice for Microservices Autonomy Inventory Service Shipment Service Checkout

    Service Payment Service µS µS µS µS „Reach out to maximise the situations for which you need to change only one service to implement a business requirement!“
  18. But where to put the overall „flow“? Inventory Service Shipment

    Service Checkout Service Payment Service µS µS µS µS ? ? ? ?
  19. Into the pipe? Don‘t even dare. ! Inventory Service Shipment

    Service Checkout Service Payment Service µS µS µS µS ? „Smart:endpoints: and:dumb1pipes!” Martin:Fowler:
  20. We could create an order service... Inventory Service Shipment Service

    Checkout Service Payment Service µS µS µS µS Order1Service µS An Order Service transforms events to commands. May still be asynchronous. May make use of workflow or not. Other services are listening to commands. Money:collected Item(s):fetched Parcel shipped Collect money! Fetch items! Order:placed
  21. Known as Orchestration Principle -Build a centralised service managing the

    overall flow -You may use workflow in that service, or just hardcode the flow -Upside: You have very good management regarding the flow logic -Downside: Some features require change of central „flow service“ „A:few smart:god1services1tell: anemic CRUD:services:what:to:do!” Sam:Newman:(Author of „Building:Microservices“)
  22. But then... do we need any central flow? Inventory Service

    Shipment Service Checkout Service Payment Service Order:placed Money:collected Item(s):fetched Parcel shipped µS µS µS µS
  23. Known as Choreography Principle -Services decentrally subscribe on events published

    by other services. -„Upside“: „no central director“, each endpoint works out its own duty -„Downside: extra work to monitor and track the processes „Systems:tending toward choreoN graphy are more loosely coupled!” Sam:Newman:(Author of „Building:Microservices“)
  24. 95% Agreed! -„Sender“ (publisher) does not need to know of

    „receiver“ (subscriber) -Event driven architectures encourage decentral data management! -Microservices Architectures should heavily tend to choreography.
  25. But, event purism has coupling issues, too. Inventory Service Shipment

    Service Checkout Service Payment Service Order:placed Money:collected Item(s):fetched Parcel shipped µS µS µS µS
  26. Let‘s look at a simple business requirement. „Our customer is

    king.:From now on,:we fetch the items before we collect the money!“ Fetch items Ship parcel Collect money Order:placed Order:delivered
  27. Event subscriptions of three (!) services change Fetch Items Service

    Ship Parcel Service Checkout Service Collect Money Service Order:placed Money:collected Item(s):fetched Parcel shipped µS µS µS µS A:Red Flag !
  28. An order service would be really nice here... Inventory Service

    Shipment Service Checkout Service Payment Service µS µS µS µS Order1Service µS
  29. Let‘s look at another business requirement. „For VIP:customers,:we will: collect

    the money by invoice!“ Fetch items Ship parcel Collect money Order:placed Order:delivered
  30. Let‘s look where to implement... Inventory Service Shipment Service Checkout

    Service Payment Service µS µS µS µS • The payment service would need a concept of a VIP customer to decide whether to collect directly or issue an invoice later. • But the inventory service would be affected, too. And it would need to know the VIP concept, too. That‘s not good. A:Red Flag !
  31. Such requirements suggest an order service. Inventory Service Shipment Service

    Checkout Service Payment Service µS µS µS µS Order1Service µS Don‘t use events in a way which are semantical commands. Transforming some events to commands increases Microservices Autonomy.
  32. Business Capabilities - revisited. Inventory Shipment Shop Payment Order:placed Money:collected

    Item(s):fetched Parcel shipped Order1 Fulfillment Order:delivered Support1Capabilities Core1Capability
  33. What now? God plus anemic CRUD? Inventory Service Shipment Service

    Checkout Service Payment Service Order1Service
  34. It‘s a question of autonomy and ownership. Inventory Service Shipment

    Service Checkout Service Payment Service µS µS µS µS Order1Service µS „Could potentially take long,:if an:item:is out:of stock. „Will:for all:practical cases always take longer than wanted.: !
  35. Flow logic must be provided inside services Inventory Service Shipment

    Service Checkout Service Payment Service µS µS µS µS Order1Service µS „If a:credit card is rejected the customer has a:week to provide new details...
  36. God services harm autonomy. Inventory Service Shipment Service Checkout Service

    Payment Service µS µS µS µS Order1Service µS A:red flag for god.:!
  37. Move responsibility to where it belongs. Inventory Service Shipment Service

    Checkout Service Payment Service µS µS µS µS Order1Service µS Core1Process Support1Process The:payment service is a:black box1to the order service team
  38. For BPMN folks it‘s well known: „Collaboration“ Payment Service Order1Service

    µS µS
  39. Microservices and Workflow? • Many (Micro-)Services can potentially need long

    to deliver their service • It‘s a service team‘s decentral decision how this is implemented • Workflow is an option, if the requirements are tricky or change often • A separate service managing end-to-end flow logic may be necessary • But to avoid god services, each service takes care of its own flow logic • Microservice architectures use events to decentralise data management • For the 95% of cases event collaboration increases service decoupling • But instead of „event chains“ I prefer event-command transformation
  40. Architectural Consequences

  41. Several services (potentially) need „long“ Inventory Service Shipment Service Checkout

    Service Payment Service µS µS µS µS Order1Service µS Order:placed Money:collected Item(s):fetched Parcel shipped Order:delivered May:finish:fast,:but: may take long,:e.g.: due:to outdated payment details
  42. Some services may choose a workflow engine Inventory Service Shipment

    Service Checkout Service Payment Service µS µS µS µS Order1Service µS Order:placed Money:collected Item(s):fetched Parcel shipped Order:delivered Workflow: engine HardN coded flows 3rdparty solution
  43. Workflow must be lightweight and embeddable Payment Service µS Order1Service

    µS Money:collected Order:delivered Embedded: workflow Embedded: workflow
  44. Workflow tooling must be composable Payment Service µS Order1Service µS

    Money:collected Task:completed Order:delivered Human1Task Service Monitoring Service µS µS Flow:canceled Independently deployable Solutions
  45. Workflow monitoring must provide e2e views Payment Service Order1Service µS

    µS
  46. Integrated tooling must show „foreign“ systems Payment Service µS Order1Service

    µS Money:collected Task:completed Order:delivered Human1Task Service Monitoring Service µS µS Inventory Service Item(s):fetched Inventory Service: with hardcoded flow logic Monitoring: Service: integrates with inventory events
  47. Workflow monitoring must provide integration Inventory Service Order1Service µS µS

    Generated flow visualisation could track 3rd:party system events
  48. Conclusions • Real Life Business Processes may be more or

    less centrally managed • Microservices Architectures ask for heavily decentral governance • Choreography and Event Collaboration are fundamental to achieve that • Sophisticated End-To-End flow logic may ask for a separate service • Such services transform events to commands offered by other services • Commands may increase autonomy when compared to event chains • Events should trigger additional logic the publisher does not care about • Workflow Tools must be embeddable, composable and integrate „e2e“
  49. https://github.com/flowing Slides online at plexiti.com, feedback there or at twitter.com/martinschimak

    With thoughts from http://flowing.io @berndruecker | @martinschimak
  50. Microservices and Workflow? Any questions open? !
