KubeCI - Cloud Native Continuous Delivery

Getting CI/CD pipelines to work on Kubernetes is a tricky endeavor, especially if you are looking for a Cloud Native CI/CD solution. KubeCI is an open source Continuous Delivery system built on Drone for Kubernetes. A simple YAML configuration file is used to the define and execute pipelines inside Kubernetes Pods. We will talk about why CI/CD pipelines are painful today. We will do some live coding, and show you how KubeCI can make a CI/CD deployment on Kubernetes simple. The audience will get insights about why we build KubeCI and how we want to extend it in the future.

Transcript

1. KubeCI
   Cloud Native Continuous Delivery
   Matthias Loibl - @metalmatze
   Loodse


   View Slide

2. Drone


   View Slide

3. Drone
   ● Continuous Delivery
   ● Automates your testing and releases
   ● Open Source
   ● Written in Go
   ● Built on Docker
   ○ Each step is a new container


   View Slide

4. Version Control Support


   View Slide

5. Declarative Configuration
   pipeline:
   frontend:
   image: node
   commands:
   - npm install
   - npm test
   backend:
   image: golang
   commands:
   - go test -v
   - go install
   services:
   database:
   image: mysql


   View Slide

6. Plugins


   View Slide

7. Languages
   Everything that can be executed in a Container


   View Slide

8. Installation
   ● docker-compose.yml
   ● Uses SQLite by default
   ○ MySQL & Postgres are easy to enable
   server:
   image: drone/drone:0.8
   ports:
   - 80:8000
   - 9000
   volumes:
   - /var/lib/drone:/var/lib/drone/
   restart: always
   environment:
   - DRONE_OPEN=true
   - DRONE_HOST=${DRONE_HOST}
   - DRONE_GITHUB=true
   - DRONE_GITHUB_CLIENT=${DRONE_GITHUB_CLIENT}
   - DRONE_GITHUB_SECRET=${DRONE_GITHUB_SECRET}
   - DRONE_SECRET=${DRONE_SECRET}
   agent:
   image: drone/agent:0.8
   command: agent
   restart: always
   depends_on:
   - drone-server
   volumes:
   - /var/run/docker.sock:/var/run/docker.sock
   environment:
   - DRONE_SERVER=drone-server:9000
   - DRONE_SECRET=${DRONE_SECRET}


   View Slide

9. Installation
   ● Can be deployed to Kubernetes
   ● Helm chart available
   $ helm install stable/drone
   Still uses the Docker socket...


   View Slide

10. Demo


    View Slide

11. What’s next?


    View Slide

12. Multi Machine Pipelines
    ● Chain together multiple pipelines
    ● Multi-machine fan-in and fan-out
    ● Multi-operating system and multi-architecture builds
    ● Replaces matrix builds


    View Slide

13. Multi Machine Pipelines
    ---
    pipeline:
    name: backend
    steps:
    - name: build
    image: golang
    commands:
    - go build
    - go test
    ...
    ---
    depends_on: [ backend, frontend ]
    pipeline:
    name: notify
    steps:
    - name: slack
    image: plugins/slack
    ---
    pipeline:
    name: frontend
    steps:
    - name: build
    image: node
    commands:
    - npm install
    - npm test
    ...
    What does it look like?


    View Slide

14. ● Generate config data (YAML)
    ● For really big pipelines
    ● Share config across projects with imports
    Jsonnet
    {
    pipeline: {
    local go = 'golang:1.10.3',
    'test': drone.step.new(go, group='build', commands=[
    'cd api',
    'make test',
    ]),
    'build': drone.step.new(go, group='build', commands=[
    'cd api',
    'make build',
    ]),
    ...
    }
    }
    pipeline:
    test:
    image: golang:1.10.3
    group: go
    commands:
    - cd api
    - make test
    build:
    image: golang:1.10.3
    group: go
    commands:
    - cd api
    - make build
    ...
    $ drone jsonnet
    .drone.jsonnet .drone.yml


    View Slide

15. Kubernetes Runtime
    ● Needs Kubernetes 1.10+
    ● Implements the same interface as the Docker runtime
    ● Takes a kubeconfig to connect to Kubernetes
    ● Talks to the Kubernetes apiserver
    ● Schedules
    ○ Services
    ○ Pods
    ○ Persistent Volumes (local volume)
    DRONE_KUBERNETES=true
    DRONE_KUBERNETES_KUBECONFIG=/home/user/.kube/config
    DRONE_KUBERNETES_NAMESPACE=drone


    View Slide

16. Kubernetes Runtime Improvements
    ● At the moment we pick a random machine
    ○ Use NodeAffinity
    ● Building Docker containers on Kubernetes
    ○ Needs privileges
    ● No way to reference secrets
    ● No way to reference configmaps
    Expect a lot of fixes and improvements!


    View Slide

17. Demo


    View Slide

18. KubeCI
    Cloud Native Continuous Delivery


    View Slide

19. KubeCI
    ● We created a Drone Kubernetes Runtime
    ● We have a lot more ideas


    View Slide

20. ● Wraps kubectl
    ● Decodes base64 secrets
    ● Some basic templating
    ○ {{ .DroneCommit }}
    ○ {{ .DroneBranch }}
    pipeline:
    kubectl:
    image: kubeciio/kubectl
    secrets: [ kubeconfig ]
    kubectl: apply
    files:
    - /path/to/folder/foo.yaml
    - /path/to/folder/bar.yaml
    - /path/to/folder/baz.yaml
    Plugins - kubectl


    View Slide

21. ● Wraps helm
    ● Decodes base64 secrets
    ● Sets tiller namespace
    ● Iterates over charts array
    ● Fetches specific helm version
    pipeline:
    helm:
    image: kubeciio/helm
    secrets: [ kubeconfig ]
    helm: upgrade --install
    tiller_namespace: helm
    charts:
    - name: prometheus
    path: monitoring/prometheues/
    namespace: monitoring
    - name: nginx
    path: ingress/nginx/
    namespace: ingress-nginx
    - name: cert-manager
    path: cert-manager/
    namespace: cert-manager
    Plugins - helm


    View Slide

22. ● Uses genuinetools/img
    ○ daemon-less
    ○ unprivileged Dockerfile
    ○ OCI compatible
    ● Drop-in replacement for Drone’s
    Docker plugin
    ○ Interesting for Kubernetes
    Plugins - img
    pipelines:
    img:
    image: kubeciio/img
    repo: prom/prometheus
    secrets: [ docker_username, docker_password ]
    tag: [ latest, 0.3, 0.3.1 ]
    when:
    event: tag
    WIP


    View Slide

23. What are your needs?
    What CI/CD challenges for Kubernetes do you have?
    Tell us!
    Plugins


    View Slide

24. How we scale DroneCI on demand
    - Patrick Jahns & Thomas Boerger
    Stage 3 - (MS Bleichen)
    Understanding GitLab CI
    - Kamil Trzcinksi
    Stage 3 - (MS Bleichen)
    Upcoming talk


    View Slide

25. Brad Rydzewski - @bradrydzewski
    Creator of Drone
    Chris Bargmann - @chrisbargmann
    Support on KubeCI plugins
    Stefan Schimanski - @the_sttts
    Brainstorming at FOSDEM
    Jason Murray - @chaosaffe
    Initial hacking sessions
    Acknowledgements


    View Slide

26. Thank you
    Matthias Loibl - @metalmatze
    Loodse


    View Slide
