  1. Linux Container Basics
    Michael Kehoe
    Staff Site Reliability Engineer

    View Slide

  2. Michael Kehoe
    $ WHOAMI
    • Staff Site Reliability Engineer @ LinkedIn
    • Production-SRE Team;
    • Disaster Recovery
    • Incident Response
    • Visibility Engineering
    • Reliability Principles
    • Find me online at:
    • @matrixtek
    • https://michael-kehoe.io
    • linkedin.com/in/michaelkkehoe

    View Slide

  3. Outline
    1 What are Containers
    2 Containers, Zones, Jails, VMs
    3 Containers in detail
    4 Containers: cgroups
    5 Containers: Namespaces
    6 Containers: CoW
    7 Containers: LSM
    8 Runtimes

    View Slide

  4. What are containers?

    View Slide

  5. “CONTAINERS ARE NOT A REAL THING!!!”
    J E S S I E F R A Z E L L E
    https://twitter.com/thejsj/status/840295431779172352

    View Slide

  6. Wait, What???

    View Slide

  7. “The word ‘container’ doesn’t mean anything super precise.
    Basically there are a few new Linux kernel features (‘namespaces’
    and ’cgroups’) that let you isolate processes from each other. When
    you use those features, you call it ‘containers’”
    J U L I A E V A N S
    https://jvns.ca/blog/2016/10/10/what-even-is-a-container/

    View Slide

  8. “Containers are processes, born from tarballs, anchored to
    namespaces, controlled by cgroups”
    A L I C E G O L D F U S S
    https://twitter.com/lucacanducci/status/1011909897640927232

    View Slide

  9. Containers
    • Security Wise: Acts like a chroot jail
    • Resource Wise: Similar to VM
    • Deployment Wise: Fast and
    lightweight
    What are containers?

    View Slide

  10. Containers, Zones, Jails, VMs

    View Slide

  11. Built off chroot
    BSD Jails
    • Processes created in the chrooted
    environment cannot access files or
    resources outside of it*
    • Processes are only limited by the part
    of the filesystem they can access
    • Four key elements:
    • Directory subtree
    • Hostname
    • IP Address
    • Command to run
    BSD Jails

    View Slide

  12. Virtualizing operating system services
    Solaris Zones
    • A zone is a virtualized operating
    system environment created within a
    single instance of the Solaris
    Operating System
    • Root zone – Default zone for the
    system & system-wide administrative
    tasks
    • Non-global zone - Zones for running
    specific workloads
    Solaris Zones

    View Slide

  13. Solaris Zones
    https://docs.oracle.com/cd/E19044-01/sol.containers/817-1592/zones.intro-1/index.html

    View Slide

  14. Solaris Zones
    FEATURES
    Processes cannot
    change zones
    Security
    Zone can provide
    isolation at almost
    any level of
    granularity
    Granularity
    Applications are
    prevented from
    monitoring or
    intercepting each other's
    network traffic, file
    system data, or process
    activity.
    Isolation
    Flexible network
    segmentation
    options
    Network Isolation
    The same
    application
    environment can be
    maintained on
    different physical
    machines
    Virtualization
    https://docs.oracle.com/cd/E19044-01/sol.containers/817-1592/zones.intro-1/index.html

    View Slide

  15. Emulation of a Computer System
    Virtual Machine
    • Hypervisor uses native execution to
    share & manage hardware
    • Multiple environments isolated from
    each other
    • Separate kernel & operating system
    instances
    Virtual Machine

    View Slide

  16. Containers
    Limiting the resources
    that can be used by a
    process/ set of
    processes
    cgroups
    Isolating filesystem
    resources
    Namespaces
    Implicit sharing or
    shadowing
    Copy on Write
    Locking down
    container privileges
    Linux Security Modules

    View Slide

  17. Containers in detail: cgroups

    View Slide

  18. cgroups
    • CPU – Limit CPU bandwidth
    • Cpuacct
    • Cpuset
    • Memory – Control the userland
    memory, kernel data structures, TCP
    socket buffers
    • IO – Control bandwidth or IOPS
    • PID-Limit number of PIDs
    • Network – Control Bandwidth *
    • And more…
    * With use of tc/ iptables
    Containers in Detail

    View Slide

  19. Containers in detail:
    Namespaces

    View Slide

  20. Namespaces
    • CGroup – Cgroup root directory
    • IPC – Control the userland memory,
    kernel data structures, TCP socket
    buffers
    • Network (net) – Network devices/
    stacks/ ports
    • Mount – Mount points can be private
    or shared
    • Process ID (pid) – Only see PID’s in
    same PID namespace
    • User ID (user) – Mapping of UID’s
    • UTS – Set the hostname in cgroup
    Containers in Detail

    View Slide

  21. Containers in detail: CoW

    View Slide

  22. Copy on Write
    • Reduces memory footprint
    • Helps to reduce container boot times
    • Details:
    • Memory “resource” can be shared if
    only read
    • Copy of data is deferred until first
    write
    Containers in Detail

    View Slide

  23. Containers in detail: LSM

    View Slide

  24. Linux Security Modules
    • AppArmor
    • SELinux
    • Seccomp
    • Capabilities
    • NoNewPrivs
    Containers in Detail

    View Slide

  25. Container Runtimes

    View Slide

  26. Container Runtimes
    • LXC
    • runc
    • lmctfy
    • cri-o
    • containerd
    • rkt
    Container Runtimes

    View Slide

  27. Other Resources
    ZONES
    Oracle: System Administration Guide: Oracle Solaris Containers-Resource Management and Oracle Solaris Zones
    https://docs.oracle.com/cd/E19044-01/sol.containers/817-1592/zones.intro-1/index.html
    https://docs.oracle.com/cd/E19253-01/817-1592/zone/index.html
    Brendan Gregg: Documentation: Zones
    http://www.brendangregg.com/zones.html#resource0

    View Slide

  28. Other Resources
    CONTAINERS
    Jerome Petazzoni: Anatomy of a Container: Namespaces, cgroups & Some Filesystem Magic - LinuxCon
    https://www.slideshare.net/jpetazzo/anatomy-of-a-container-namespaces-cgroups-some-filesystem-magic-
    linuxcon
    Jessie Frazelle: Containers from User Space (LinuxConfAU 2018)
    https://docs.google.com/presentation/d/1UuHvR_kvZ3BF1pSXyv4mMKX9vmGr7GXm97USx7mzTXY/
    Julia Evans: What is even a container
    https://jvns.ca/blog/2016/10/10/what-even-is-a-container/
    Redhat: Managing system resources on Red Hat Enterprise Linux 6 & 7
    https://access.redhat.com/documentation/en-us/red_hat_enterprise_linux/6/html-
    single/resource_management_guide/index
    https://access.redhat.com/documentation/en-us/red_hat_enterprise_linux/7/html-
    single/resource_management_guide/index
    Akihiro Suzuki: Real-Time Task Partitioning using Cgroups
    https://elinux.org/images/8/84/Real-Time_Tasks_Partitioning_using_Cgroups.pdf
