Local Persistent Storage
Use cases and motivations for local persistent storage, problems with hostpath volumes, 1.7 feature overview, future roadmap
Michelle Au
June 28, 2017
Transcript
15 slides
-
Google Cloud Platform logo Local Persistent Storage 6/28/2017 Michelle Au
Software Engineer - Google Github: @msau42 -
Google Cloud Platform 1. Motivations and Use Cases 2. Hostpath
Problems 3. Local Persistent Volume Solution 4. Demo 5. Future Roadmap 6. Documentation Agenda Agenda -
Google Cloud Platform Use Cases • Using local storage subject
to node and storage availability • Not suitable for all use cases! • Data gravity (co-locating data and application) • Distributed datastores and filesystems (Cassandra, GlusterFS, etc) • Large caches Cost • Increase disk utilization in baremetal environments • Reduce operator cost for managing distributed storage systems and supporting infrastructure (networking hardware, etc) Performance • Local SSDs in cloud environments Local Persistent Storage Motivations -
Google Cloud Platform Hostpath Volume Issues apiVersion: v1 kind: Pod
metadata: name: sleepypod spec: volumes: - name: data hostPath: path: /mnt/some-disk containers: - name: sleepycontainer image: gcr.io/google_containers/busybox command: - sleep - "6000" volumeMounts: - name: data mountPath: /data readOnly: false -
Google Cloud Platform Hostpath Volume Issues apiVersion: v1 kind: Pod
metadata: name: sleepypod spec: nodeName: node-1 volumes: - name: data hostPath: path: /mnt/some-disk containers: - name: sleepycontainer image: gcr.io/google_containers/busybox command: - sleep - "6000" volumeMounts: - name: data mountPath: /data readOnly: false Portability • Path (and data) is specific to the node • Need to manually schedule pods to specific nodes, bypassing scheduler • Paths can change across clusters and different environments -
Google Cloud Platform Hostpath Volume Issues apiVersion: v1 kind: Pod
metadata: name: sleepypod spec: nodeName: node-1 volumes: - name: data hostPath: path: /mnt/some-disk containers: - name: sleepycontainer image: gcr.io/google_containers/busybox command: - sleep - "6000" volumeMounts: - name: data mountPath: /data readOnly: false Accounting • Path collisions with other pods • Coordinate with other applications and manually schedule pods to specific nodes • Lifecycle is unmanaged. Manual cleanup whenever application is finished -
Google Cloud Platform Hostpath Volume Issues apiVersion: v1 kind: Pod
metadata: name: sleepypod spec: nodeName: node-1 volumes: - name: data hostPath: path: /mnt/some-disk containers: - name: sleepycontainer image: gcr.io/google_containers/busybox command: - sleep - "6000" volumeMounts: - name: data mountPath: /data readOnly: false Security • Pod can specify any path! • Hostpath often disabled through pod security policy -
Google Cloud Platform Portability • Use Persistent Volumes abstraction to
separate storage details from pod consumption Accounting • Only one Persistent Volume Claim can be bound to a Persistent Volume • API objects with managed lifecycles Security • Only administrators can create Persistent Volumes Local Persistent Volumes Solution -
Google Cloud Platform Local Persistent Volumes Example apiVersion: v1 kind:
PersistentVolumeClaim metadata: name: my-pvc spec: resources: requests: storage: 100Gi storageClassName: local-fast apiVersion: v1 kind: PersistentVolume metadata: Name: local-volume-1 spec: capacity: storage: 100Gi storageClassName: local-fast local: path: /tmp/my-test1 nodeAffinity: requiredDuringSchedulingIgnoredDuringExecution: nodeSelectorTerms: - matchExpressions: - key: kubernetes.io/hostname operator: In values: - node-1 -
Google Cloud Platform Local Persistent Volumes Solution apiVersion: v1 kind:
Pod metadata: name: sleepypod spec: nodeName: node-1 volumes: - name: data hostPath: path: /mnt/somedisk containers: - name: sleepycontainer image: gcr.io/google_containers/busybox command: - sleep - "6000" volumeMounts: ... persistentVolumeClaim: claimName: mypvc -
Google Cloud Platform New volume type: “local” volume • Can
only be used as a Persistent Volume • Scheduler is aware of volume’s node constraints External static provisioner for local volumes • Run as a DaemonSet on every node • Discovers local volumes mounted under configurable directories • Automatically create, cleanup and destroy local Persistent Volumes 1.7 Alpha Details -
Google Cloud Platform 1. StatefulSet where each instance writes to
a local volume 2. Reader pod that reads from one of the local volumes 3. The pods will always be scheduled to the same node that the volume is on Demo -
Google Cloud Platform • Persistent Volume binding happens before pod
scheduling • Doesn’t consider pod resource and scheduling requirements (ie, CPU, pod affinity, etc) • Cannot specify multiple local volumes in a single pod spec • External provisioner cannot correctly detect volume capacity for new volumes created after provisioner has started 1.7 Limitations -
Google Cloud Platform • Local block devices as a volume
source, and for pod consumption • Local volume health monitoring, taints and tolerations • Inline PV (use local disk as ephemeral storage) • Dynamic provisioning Roadmap -
Google Cloud Platform User guide • https://github.com/kubernetes-incubator/external-storage/tree/master/lo cal-volume Implementation tracker
• https://github.com/kubernetes/kubernetes/issues/43640 Proposal • https://github.com/kubernetes/community/pull/306 Documentation
