Executing Queries on a Sharded Database

Determining a data storage solution as your web application scales can be the most difficult part of web development, and takes time away from developing application features. MongoDB, Redis, Postgres, Riak, Cassandra, Voldemort, NoSQL, MySQL, NewSQL — the options are overwhelming, and all claim to be elastic, fault-tolerant, durable, and give great performance for both reads and writes. In the first portion of this talk I’ll discuss these different storage solutions and explain what is really important when choosing a datastore — your application data schema and feature requirements.

No matter what datastore you choose, you will eventually have to consider sharding your data store to support growing traffic. Two key challenges arise: (1) web workloads often do not have one clear partitioning and (2) it is challenging to determine how to efficiently execute queries over partitioned tables.

To address these challenges I present Dixie, a SQL query planner, optimizer, and executor for databases horizontally partitioned over multiple servers. Dixie shows that we shouldn’t give up on SQL databases just yet. Dixie automates the exploitation of tables with multiple copies partitioned in different ways, in order to increase throughput by expanding the set of queries that need not be sent to all servers. Central to Dixie’s design are a cost model and plan generator that are mindful of queries small enough that query overhead may dominate the cost. For a large class of joins, which traditional wisdom suggests require tables partitioned on the join keys, Dixie can find higher-performance plans using other partitionings.

Presented at Strange Loop, St. Louis, MO.

Transcript

1. Execu&ng  Queries  on  a  Sharded
   Database
   Neha  Narula
   September  25,  2012


   View Slide

2. Choosing  and  Scaling  Your
   Datastore
   Neha  Narula
   September  25,  2012


   View Slide

3. Who  Am  I?
   Froogle
   Blobstore
   Na&ve  Client


   View Slide

4. In  This  Talk
   •  What  to  think  about  when  choosing  a
   datastore  for  a  web  applica&on
   •  Myths  and  legends
   •  Execu&ng  distributed  queries
   •  My  research:    a  consistent  cache


   View Slide

5. Every  so  oPen…
   Friends  ask  me  for  advice  when  they  are
   building  a  new  applica&on


   View Slide

6. Friend


   View Slide

7. “Hi  Neha!    I  am  making  a  new  applica&on.


   View Slide

8. I  have  heard  MySQL  sucks  and  I  should  use  NoSQL.


   View Slide

9. I  am  going  to  be  itera&ng  on  my  app  a  lot


   View Slide

10. I  don't  have  any  customers  yet


    View Slide

11. and  my  current  data  set  could  fit  on  a  thumb  drive
    from  2004,  but…


    View Slide

12.  Can  you  tell  me  which  NoSQL  database  I
    should  use?


    View Slide

13. And  how  to  shard  it?"



    View Slide

14. Neha


    View Slide

15. h[p://knowyourmeme.com/memes/facepalm


    View Slide

16. View Slide

17. View Slide

18. What  to  Think  about  When  You’re
    Choosing  a  Datastore
    Hint:  Not  Scaling


    View Slide

19. Development  Cycle
    •  Prototyping
    – Ease  of  use
    •  Developing
    – Flexibility,  mul&ple  developers
    •  Running  a  real  produc&on  system
    – Reliability
    •  SUCCESS!    Sharding  and  specialized
    datastorage
    – We  should  only  be  so  lucky


    View Slide

20. Gecng  Started
    First  five  minutes  –  what’s  it  like?
    Idea  credit:  Adam  Marcus,  The  NoSQL  Ecosystem,  HPTS  2011

    via  Jus&n  Sheehy  from  Basho


    View Slide

21. First  Five  Minutes:  Redis
    h[p://simonwillison.net/2009/Oct/22/redis/


    View Slide

22. First  Five  Minutes:  MySQL


    View Slide

23. Developing
    •  Mul&ple  people  working  on  the  same  code
    •  Tes&ng  new  features  =>  new  access  pa[erns
    •  New  person  comes  along…


    View Slide

24. Redis
    Time  to  go  get
    lunch


    View Slide

25. MySQL


    View Slide

26. Ques&ons
    •  What  is  your  mix  of  reads  and  writes?
    •  How  much  data  do  you  have?
    •  Do  you  need  transac&ons?
    •  What  are  your  access  pa[erns?
    •  What  will  grow  and  change?
    •  What  do  you  already  know?


    View Slide

27. Reads  and  Writes
    •  Write  op&mized  vs.  Read  op&mized
    •  MongoDB  has  a  global  write  lock  per  process
    •  No  concurrent  writes!


    View Slide

28. Size  of  Data
    •  Does  it  fit  in  memory?
    •  Disk-­‐based  solu&ons  will  be  slower
    •  Worst  case,  Redis  needs  2X  the  memory  of
    your  data!
    – It  forks  with  copy-­‐on-­‐write
    sudo echo 1 > /proc/sys/vm/overcommit_memory!



    View Slide

29. Requirements
    •  Performance
    – Latency  tolerance
    •  Durability
    – Data  loss  tolerance
    •  Freshness
    – Staleness  tolerance
    •  Up&me
    – Down&me  tolerance


    View Slide

30. Performance
    •  Rela&onal  databases  are  considered  slow
    •  But  they  are  doing  a  lot  of  work!
    •  Some&mes  you  need  that  work,  some&mes
    you  don’t.


    View Slide

31. Simplest  Scenario
    •  Responding  to  user  requests  in  real  &me
    •  Frequently  read  data  fits  in  memory
    •  High  read  rate
    •  No  need  to  go  to  disk  or  scan  lots  of  data
    Datastore  CPU  is  the  bo[leneck


    View Slide

32. Cost  of  Execu&ng  a  Primary  Key  Lookup
    Query
    Cost
    •  Receiving  message
    •  Instan&a&ng  thread
    •  Parsing  query
    •  Op&mizing
    •  Take  out  read  locks
    •  (Some&mes)  lookup  in
    an  index  btree
    •  Responding  to  the  client
    Actually  retrieving  data


    View Slide

33. Op&ons  to  Make  This  Fast
    •  Query  cache
    •  Prepared  statements
    •  Handler  Socket
    – 750K  lookups/sec  on  a  single  server
    Lesson:    Primary  key  lookups  can  be  fast  no
    ma[er  what  datastore  you  use


    View Slide

34. Flexibility  vs.  Performance
    •  We  might  want  to  pay  the  overhead  for  query
    flexibility
    •  In  a  primary  key  datastore,  we  can  only  ask
    queries  on  primary  key
    •  SQL  gives  us  flexibility  to  change  our  queries


    View Slide

35. Durability
    •  Persistent  datastores
    –  Client:    write
    –  Server:  flush  to  disk,  then  send  “I  completed  your
    write”
    –  CRASH
    –  Recover:  See  the  write
    •  By  default,  MongoDB  does  not  fsync()  before
    returning  to  client  on  write
    –  Need  j:true
    •  By  default,  MySQL  uses  MyISAM  instead  of
    InnoDB


    View Slide

36. Specializa&on
    •  You  know  your
    – query  access  pa[erns  and  traffic
    – consistency  requirements
    •  Design  specialized  lookups
    – Transac&onal  datastore  for  consistent  data
    – Memcached  for  sta&c,  mostly  unchanging  content
    – Redis  for  a  data  processing  pipeline
    •  Know  what  tradeoffs  to  make


    View Slide

37. Ways  to  Scale
    •  Reads
    – Cache
    – Replicate
    – Par&&on
    •  Writes
    – Par&&on  data  amongst  mul&ple  servers



    View Slide

38. Lots  of  Folklore


    View Slide

39. Myths  of  Sharded  Datastores
    •  NoSQL  scales  be[er  than  a  rela&onal  database
    •  You  can’t  do  a  JOIN  on  a  sharded  datastore


    View Slide

40. MYTH:    NoSQL  scales  be[er  than  a
    rela&onal  database
    •  Scaling  isn’t  about  the  datastore,  it’s  about
    the  applica&on
    – Examples:  FriendFeed,  Quora,  Facebook
    •  Complex  queries  that  go  to  all  shards  don’t
    scale
    •  Simple  queries  that  par&&on  well  and  use  only
    one  shard  do  scale



    View Slide

41. Problem:    Applica&ons  Look  Up
    Data  in  Different  Ways


    View Slide

42. Post  Page
    SELECT * !
    FROM comments!
    WHERE post_id = 100!
    !

    zrange comments:100 0 -1!

    HA!


    View Slide

43. Example  Par&&oned
    Database
    Database
    Database
    Database
    comments table
    post_id!
    100-199!
    0-99!
    200-199!
    Webservers


    View Slide

44. MySQL
    MySQL
    MySQL
    Query  Goes  to  One
    Par&&on
    MySQL
    MySQL
    MySQL
    Comments
    on  post  100
    100-199!
    0-99!
    200-299!


    View Slide

45. MySQL
    MySQL
    MySQL
    Many  Concurrent
    Queries
    MySQL
    MySQL
    MySQL
    Comments
    on  post  100
    100-199!
    0-99!
    200-299!
    Comments
    on  post  52
    Comments
    on  post  289


    View Slide

46. User  Comments  Page
    Fetch  all  of  a  user's  comments:
    SELECT * FROM comments WHERE user = 'sam'!


    View Slide

47. Query  Goes  to  All
    Par&&ons
    MySQL
    MySQL
    MySQL
    Query  goes  to  all  servers
    100-199!
    0-99!
    200-299!
    Sam’s
    comments


    View Slide

48. Costs  for  Query  Go  Up
    When  Adding  a  New
    Server
    MySQL
    0-99!
    Sam’s
    comments
    MySQL
    100-199!
    MySQL
    200-299!
    MySQL
    300-399!


    View Slide

49. CPU  Cost  on  Server  of  Retrieving  One  Row
    Two  costs:    Query  overhead  and  row  retrieval
    MySQL
    Query
    Overhead
    97%


    View Slide

50. Idea:  Mul&ple  Par&&onings
    Par&&on  comments  table  on  post_id  and  user.

    Reads  can  choose  appropriate  copy  so  queries  go  to
    only  one  server.

    Writes  go  to  all  copies.


    View Slide

51. Mul&ple  Par&&onings
    Database
    Database
    Database
    comments table
    post_id!
    100-199!
    0-99!
    200-199!
    user!
    K-R!
    A-J!
    S-Z!


    View Slide

52. All  Read  Queries  Go  To  Only
    One  Par&&on
    MySQL
    MySQL
    MySQL
    100-199!
    0-99!
    S-Z!
    Sam’s
    comments
    Comments  on
    post  100


    View Slide

53. Writes  Go  to  Both  Table
    Copies
    MySQL
    MySQL
    MySQL
    100-199!
    0-99!
    S-Z!
    Write  a  new
    comment  by
    Vicki  on  post
    100


    View Slide

54. Scaling
    •  Reads  scale  by  N  –  the  number  of  servers
    •  Writes  are  slowed  down  by  T  –  the  number  of
    table  copies
    •  Big  win  if  N  >>  T
    •  Table  copies  use  more  memory
    – OPen  don’t  have  to  copy  large  tables  –  usually
    metadata
    •  How  to  execute  these  queries?


    View Slide

55. Dixie
    •  Is  a  query  planner  which  executes  SQL  queries  over  a
    par&&oned  database

    •  Op&mizes  read  queries  to  minimize  query  overhead  and
    data  retrieval  costs
    •  Uses  a  novel  cost  formula  which  takes  advantage  of  data
    par&&oned  in  different  ways


    View Slide

56. 0
    5000
    10000
    15000
    20000
    25000
    1 2 5 10
    QPS
    Number of Partitions
    One copy of page table
    Dixie + page.title copy
    Wikipedia  Workload  with  Dixie
    3.2 X
    Each
    query
    going  to  1
    server
    Many
    queries
    going  to  all
    servers
    Wikipedia
    •  Database  dump  from  2008
    •  Real  HTTP  traces
    •  Sharded  across  1,  2,  5,  and  10  servers
    •  Compare  by  adding  a  copy  of  the  page
    table  (<  100  MB),  sharded  another  way



    View Slide

57. Myths  of  Sharded  Datastores
    •  NoSQL  scales  be[er  than  a  rela&onal  database
    •  You  can’t  do  a  JOIN  on  a  sharded  datastore


    View Slide

58. MYTH:    You  can’t  execute  a  JOIN  on  a
    sharded  database
    •  What  are  the  JOIN  keys?    What  are  your
    par&&on  keys?
    •  Bad  to  move  lots  of  data
    •  Not  bad  to  lookup  a  few  pieces  of  data
    •  Index  lookup  JOINs  expressed  as  primary  key
    lookups  are  fast


    View Slide

59. Join  Query
    Fetch  all  of  Alice's  comments  on  Max's  posts.
    3 Alice First post!
    comments table
    post_id user text
    6
    7
    22
    Alice
    Alice
    Alice
    Like.
    You think?
    Nice work!
    1 Max http://…
    posts table
    id author link
    3
    22
    37
    Max
    Max
    Max
    www.
    Ask Hacker
    http://…


    View Slide

60. Join  Query
    Fetch  all  of  Alice's  comments  on  Max's  posts.
    3 Alice First post!
    comments table
    post_id user text
    6
    7
    22
    Alice
    Alice
    Alice
    Like.
    You think?
    Nice work!
    1 Max http://…
    posts table
    id author link
    3
    22
    37
    Max
    Max
    Max
    www.
    Ask Hacker
    http://…


    View Slide

61. Distributed  Query  Planning
    •  R*
    •  Shore
    •  The  State  of  the  Art  in  Distributed  Query
    Processing,  by  Donald  Kossman
    •  Gizzard


    View Slide

62. Conven&onal  Wisdom
    Par&&on  on  JOIN  keys,  Send  query
    as  is  to  each  server.
    0-99! 0-99!
    100-
    199!
    100-
    199!
    200-
    299!
    200-
    299!
    SELECT comments.text !
    FROM posts, comments!
    WHERE comments.post_id = posts.id!
    AND posts.author = 'Max'!
    AND comments.user = 'Alice'!


    View Slide

63. …
    Conven&onal  Plan  Scaling
    MySQL
    Alice’s
    comments  on
    Max’s  posts
    MySQL MySQL


    View Slide

64. Index  Lookup  Join
    Par&&on  on  filter  keys,  retrieve  Max's
    posts,  then  retrieve  Alice's  comments  on
    Max's  posts.
    0-99!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    A-I!
    0-99!
    A-I!
    SELECT posts.id !
    FROM posts!
    WHERE posts.author = 'Max’!


    View Slide

65. 0-99!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    A-I!
    0-99!
    A-I!
    ids of Max’s
    posts
    Index  Lookup  Join

    Par&&on  on  filter  keys,  retrieve  Max's
    posts,  then  retrieve  Alice's  comments  on
    Max's  posts.


    View Slide

66. 0-99!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    100-
    199!
    200-
    299!
    A-I!
    J-R!
    S-Z!
    0-99!
    A-I!
    SELECT comments.text !
    FROM comments!
    WHERE comments.post_id IN […]!
    AND comments.user = 'Alice'!
    Index  Lookup  Join
    Par&&on  on  filter  keys,  retrieve  Max's
    posts,  then  retrieve  Alice's  comments  on
    Max's  posts.


    View Slide

67. 0-99!
    100-
    199!
    200-
    299!
    J-R!
    S-Z!
    100-
    199!
    200-
    299!
    A-I!
    J-R!
    S-Z!
    0-99!
    A-I!
    Alice’s  comments  on
    Max’s  posts
    Index  Lookup  Join
    Par&&on  on  filter  keys,  retrieve  Max's
    posts,  then  retrieve  Alice's  comments  on
    Max's  posts.


    View Slide

68. …
    MySQL
    Alice’s
    comments
    on Max’s
    posts
    MySQL MySQL
    Index  Lookup  Join  Plan  Scaling



    View Slide

69. Comparison
    Conven&onal  Plan   Index  Lookup  Plan
    Intermediate
    data,  Max’s
    posts  Alice
    DIDN’T
    comment  on


    View Slide

70. Comparison
    Conven&onal  Plan   Index  Lookup  Plan
    Intermediate
    data,  Max’s
    posts  Alice
    DIDN’T
    comment  on


    View Slide

71. Dixie
    •  Cost  model  and  query  op&mizer  which
    predicts  the  costs  of  the  two  plans
    •  Query  executor  which  executes  the  original
    query,  designed  for  a  single  database,  on  a
    par&&oned  database  with  table  copies


    View Slide

72. Dixie's  Predic&ons  for  the  Two  Plans
    0
    2000
    4000
    6000
    8000
    10000
    0 50 100 150
    Queries/Sec
    Posts/Author
    2-Step Join
    Estimate
    Pushdown
    Join Estimate
    •  Varying  the  size  of  the  intermediate  data
    •  Max’s  posts,  Alice  didn’t  comment  on
    •  Fixing  the  number  of  results  returned
    •  Par&&oned  over  10  servers

    Conven&onal
    Plan,  each
    query  going
    to  all  servers
    Index  Lookup
    Plan,  each
    query  going  to
    two  servers


    View Slide

73. Performance  of  the  Two  Plans
    0
    2000
    4000
    6000
    8000
    10000
    0 50 100 150
    Queries/Sec
    Posts/Author
    2-Step Join
    Pushdown Join
    2-Step Join
    Estimate
    Pushdown Join
    Estimate
    Blue  beats  yellow  aPer  this.
    Dixie  predicts  it!


    View Slide

74. JOINs  Are  Not  Evil
    •  When  only  transferring  small  amounts  data
    •  And  with  carefully  par&&oned  data


    View Slide

75. Lessons  Learned
    •  Don’t  worry  at  the  beginning:  Use  what  you
    know
    •  Not  about  SQL  vs.  NoSQL  systems  –  you  can
    scale  any  system
    •  More  about  complex  vs.  simple  queries
    •  When  you  do  scale,  try  to  make  every  query
    use  one  (or  a  few)  shards


    View Slide

76. Research:    Caching
    •  Applica&ons  use  a  cache  to  store  results
    computed  from  a  webserver  or  database  rows
    •  Expira&on  or  invalida&on?
    •  Annoying  and  difficult  for  app  developers  to
    invalidate  cache  items  correctly
    Work  in  progress  with  Bryan  Kate,  Eddie  Kohler,  Yandong  Mao,  and  Robert  Morris
    Harvard  and  MIT


    View Slide

77. Solu&on:  Dependency  Tracking  Cache
    •  Applica&on  indicates  what  data  went  into  a
    cached  result
    •  The  system  will  take  care  of  invalida&ons
    •  Don’t  need  to  recalculate  expired  data  if  it  has
    not  changed
    •  Always  get  the  freshest  data  when  data  has
    changed
    •  Track  ranges,  even  if  empty!


    View Slide

78. Example  Applica&on:  Twi[er
    •  Cache  a  user’s  view  of  their  twi[er  homepage
    (&meline)
    •  Only  invalidate  when  a  followed  user  tweets
    •  Even  if  many  followed  users  tweet,  only
    recalculate  the  &meline  once  when  read
    •  No  need  to  recalculate  on  read  if  no  one  has
    tweeted


    View Slide

79. Challenges
    •  Invalida&on  +  expira&on  &mes
    – Reading  stale  data
    •  Distributed  caching
    •  Cache  coherence  on  the  original  database
    rows


    View Slide

80. Benefits
    •  Applica&on  gets  all  the  benefits  of  caching
    – Saves  on  computa&on
    – Less  traffic  to  the  backend  database
    •  Doesn’t  have  to  worry  about  freshness


    View Slide

81. Summary
    •  Choosing  a  datastore
    •  Dixie
    •  Dependency  tracking  cache


    View Slide

82. Thanks!

    narula@mit.edu
    h[p://nehanaru.la
    @neha


    View Slide
